PERMUTATION CIRCUITS

1
PERMUTATION CIRCUITS

• Presented by Wooyoung Kim, 1/28/2009
• CSc 8530 Parallel Algorithms, Spring 2009
• Dr. Sushil K. Prasad

2
Outline

• Introduction Problem Definition, Terminology.
• Lower bound.
• Permutation Circuit Design
• Example
• Constructive Proof
• Analysis
• Application

3
Definition
A permutation circuit is a combinational circuit
that applies a given permutation ?n to its input
x1,x2, xn to get an output y1, y2, , yn such
that y1, y2, yn ?n (x1, x2, , xn) An
example ?8 1 2 3 4 5 6 7 8 4 8 3 2
1 7 6 5

• This means
• Input Output
• ? 4
• ? 8 ..

Hence, y1 5, y2 4, y3 3, y41,
4
Circuit component Switch

• A switch as the name suggests is a simple
  component that can do the following
• OFF state Inputs are sent to output in the
  same order.
• ON state Inputs are switched or
  interchanged at the output.

OFF
ON
5
Some basic terminology
Size of a circuit Number of components in the
circuit. Depth of a circuit Max number of
stages in the path. Width of a circuit Max
number of components in a stage. Hence,
6
Lower Bounds
Let us say that for an input size n we need s
switches. Each switch ? 2 stages (ON/OFF) s
switches ? 2s stages To satisfy any
permutation, 2s gt n! s gt n log n . LB on size
is O (n log n)
7
Lower Bounds
Therefore,
, since there are n inputs and n outputs

• , since
• each input line must have a path to each output
  line.
• each switch has only two inputs and two outputs.

8
Permutation Vs. Sorting
The order in which the inputs to a Sorting
Circuit appear at the output, depends on the
values of the input. Hence, by having inputs in
the form of a pair (i, j) (which implies input i
is sent to output j ) we can perform permutations
by using a sorting circuit and sorting by the j
values.
9
Permutation Vs. Sorting
Sorting circuits are self-routing. That is, each
comparator makes its decision as to which way the
data it receives are to be directed this
decision is made when they reach the comparator
and is based on their values. In permutation
circuits, switches are to be set ahead of time.
10
Circuit Design
Once again we use a recursive design based on
smaller permutation circuits. The basic idea is
to design the circuit in 3 layers Stage 1 The
first layer decides which of the 2 Stage 2
circuits the Input goes to. Stage 2 Permutes
the input at one scale less. Stage 3 Decides
where Output of Stage 2 goes in the final
output sequence.
11
(No Transcript)
12
Description

• We need to show that any permutation can be
  performed for the given input.
• If for some output yl we trace back to input x2k
  then select its neighbor in switch Ik (x2k-1) and
  set the switches from there to its correct
  output. If neighbor is already selected, select
  any other i/p.
• If for some input xl output y2k is reached,
  select its neighbor in switch Ok (y2k-1) and set
  switches from there to correct input.
• Ping Pong Technique

13
An Example
Let us construct the circuit for the example
shown earlier. It is given below. ?8 1 2 3
4 5 6 7 8 4 8 3 2 1 7 6 5 We shall
consider it step by step. Our basic building
blocks are a based on the following n1 No
switches needed. n2 One Switch sufficient. n gt
2 Input fed into switches I that direct them
towards two n/2 permutation circuits.
14
(No Transcript)
15
Constructive Proof Waksman67
Consider a network like the one above with no
links. We are given any arbitrary permutation.
The upper n/2 circuit is called Pa and the lower
Pb. Start with y1 and establish a link through Pa
to some x through its corresponding I. Switch I
is set if u is even. Proceed next with the
second u associated with this I and establish a
link through Pb to its y through the O associated
with it. Set this O if y is even.
16
Repeat the process until all input-output pairs
have been matched. Now, since by construction Pa
and Pb, are each associated with exactly N/2
inputs and N/2 outputs, and since by assumption
Pa and Pb are permutation networks the assignment
is complete and the link pattern is as in the
figure.
17
Analysis

• Depth
• d(n) d (n/2) 2
• d(n/4) 2 2
• d( n/ 2k) 2k ( d(2)1)
• n/ 2k 2
• log n k1 klog n -1
• d(n) 2 log n 1

18
Analysis (contd.)
2. Width n/2 3. Size -gt p(n) p(1) 0 ,
p(2) 1 p(n) 2 p (n/2) n 1 Hence, p(n)
n log n n 1
19
Applications
Fast Parallel Permutation Algorithms Hagerup 95

• Investigate the problem of permuting n data
  items on an EREW PRAM with p processors using
  little additional storage.
• Present a simple algorithm with run time O(n/p
  logn) and an improved algorithm with run time
  O(n/p lognlog log(n/p)).
• Both algorithms require n additional global bits
  and O local storage per processor.
• If prex summation is supported at the
  instruction level the run time of the improved
  algorithm is O(n/p)
• The algorithms can be used to rehash the address
  space of a PRAM emulation

20
Applications
Sequential Algorithm

• Permute along the cycle until you reach it
  again.
• Mark all positions that visited.
• Continue until all positions have been visited.
• O(n) to move all items and O(n) t search for
  unvisited positions.

21
Applications
Basic Algorithm

• EREW PRAM with p processors.
• Each processor P takes care of one block of
  Bn/p positions.
• P starts with x in its block and follows the
  cycle until it meets a position y that is already
  marked as visited.
• P is one of three states searching, working on
  a cycle, terminated.
• Time O((n/p)logn)

22
Applications
Improved Algorithm

• Basic algorithm is not optimal because many
  processors could terminate early- unbalanced.
• The array of items is dynamically partitioned
  into active and passive blocks.
• passive all positions have been visited.
• active split into smaller ones as the algorithm
  proceeds.
• Time O(n/p logn log log (n/p))

23
References
Akl97 Selim G Akl, Parallel Computation,
Prentice Hall, New Jersey, 1997. Waksman68 A
permutation network. Journal of the ACM, Vol. 15,
1968, pp. 159-163. Hagerup 95 Fast Parallel
Permutation Algorithms, Journal of Parallel
Processing Letters, Vol. 5, No. 2, 995, pp.
139-148.
