ECE 1747 Parallel Programming

1
ECE 1747 Parallel Programming

• Shared Memory OpenMP
• Environment and Synchronization

2
What is OpenMP?

• Standard for shared memory programming for
  scientific applications.
• Has specific support for scientific application
  needs (unlike Pthreads).
• Rapidly gaining acceptance among vendors and
  application writers.
• See http//www.openmp.org for more info.

3
OpenMP API Overview

• API is a set of compiler directives inserted in
  the source program (in addition to some library
  functions).
• Ideally, compiler directives do not affect
  sequential code.
• pragmas in C / C .
• (special) comments in Fortran code.

4
OpenMP API Example

• Sequential code
• statement1
• statement2
• statement3
• Assume we want to execute statement 2 in
  parallel, and statement 1 and 3 sequentially.

5
OpenMP API Example (2 of 2)

• OpenMP parallel code
• statement 1
• pragma ltspecific OpenMP directivegt
• statement2
• statement3
• Statement 2 (may be) executed in parallel.
• Statement 1 and 3 are executed sequentially.

6
Important Note

• By giving a parallel directive, the user asserts
  that the program will remain correct if the
  statement is executed in parallel.
• OpenMP compiler does not check correctness.
• Some tools exist for helping with that.
• Totalview - good parallel debugger
  (www.etnus.com)

7
API Semantics

• Master thread executes sequential code.
• Master and slaves execute parallel code.
• Note very similar to fork-join semantics of
  Pthreads create/join primitives.

8
OpenMP Implementation Overview

• OpenMP implementation
• compiler,
• library.
• Unlike Pthreads (purely a library).

9
OpenMP Example Usage (1 of 2)
Sequential Program
OpenMP Compiler
Annotated Source
compiler switch
Parallel Program
10
OpenMP Example Usage (2 of 2)

• If you give sequential switch,
• comments and pragmas are ignored.
• If you give parallel switch,
• comments and/or pragmas are read, and
• cause translation into parallel program.
• Ideally, one source for both sequential and
  parallel program (big maintenance plus).

11
OpenMP Directives

• Parallelization directives
• parallel region
• parallel for
• Data environment directives
• shared, private, threadprivate, reduction, etc.
• Synchronization directives
• barrier, critical

12
General Rules about Directives

• They always apply to the next statement, which
  must be a structured block.
• Examples
• pragma omp
• statement
• pragma omp
• statement1 statement2 statement3

13
OpenMP Parallel Region

• pragma omp parallel
• A number of threads are spawned at entry.
• Each thread executes the same code.
• Each thread waits at the end.
• Very similar to a number of create/joins with
  the same function in Pthreads.

14
Getting Threads to do Different Things

• Through explicit thread identification (as in
  Pthreads).
• Through work-sharing directives.

15
Thread Identification

• int omp_get_thread_num()
• int omp_get_num_threads()
• Gets the thread id.
• Gets the total number of threads.

16
Example

• pragma omp parallel
• if( !omp_get_thread_num() )
• master()
• else
• slave()

17
Work Sharing Directives

• Always occur within a parallel region directive.
• Two principal ones are
• parallel for
• parallel section

18
OpenMP Parallel For

• pragma omp parallel
• pragma omp for
• for( )
• Each thread executes a subset of the iterations.
• All threads wait at the end of the parallel for.

19
Multiple Work Sharing Directives

• May occur within a single parallel region
• pragma omp parallel
• pragma omp for
• for( )
• pragma omp for
• for( )
• All threads wait at the end of the first for.

20
The NoWait Qualifier

• pragma omp parallel
• pragma omp for nowait
• for( )
• pragma omp for
• for( )
• Threads proceed to second for w/o waiting.

21
Parallel Sections Directive

• pragma omp parallel
• pragma omp sections
• pragma omp section ? this is a delimiter
• pragma omp section

22
A Useful Shorthand

• pragma omp parallel
• pragma omp for
• for ( )
• is equivalent to
• pragma omp parallel for
• for ( )
• (Same for parallel sections)

23
Note the Difference between ...

• pragma omp parallel
• pragma omp for
• for( )
• f()
• pragma omp for
• for( )

24
and ...

• pragma omp parallel for
• for( )
• f()
• pragma omp parallel for
• for( )

25
Sequential Matrix Multiply

• for( i0 iltn i )
• for( j0 jltn j )
• cij 0.0
• for( k0 kltn k )
• cij aikbkj

26
OpenMP Matrix Multiply

• pragma omp parallel for
• for( i0 iltn i )
• for( j0 jltn j )
• cij 0.0
• for( k0 kltn k )
• cij aikbkj

27
Sequential SOR

• for some number of timesteps/iterations
• for (i0 iltn i )
• for( j1, jltn, j )
• tempij 0.25
• ( gridi-1j gridi1j
• gridij-1 gridij1 )
• for( i0 iltn i )
• for( j1 jltn j )
• gridij tempij

28
OpenMP SOR

• for some number of timesteps/iterations
• pragma omp parallel for
• for (i0 iltn i )
• for( j0, jltn, j )
• tempij 0.25
• ( gridi-1j gridi1j
• gridij-1 gridij1 )
• pragma omp parallel for
• for( i0 iltn i )
• for( j0 jltn j )
• gridij tempij

29
Equivalent OpenMP SOR

• for some number of timesteps/iterations
• pragma omp parallel
• pragma omp for
• for (i0 iltn i )
• for( j0, jltn, j )
• tempij 0.25
• ( gridi-1j gridi1j
• gridij-1 gridij1 )
• pragma omp for
• for( i0 iltn i )
• for( j0 jltn j )
• gridij tempij

30
Some Advanced Features

• Conditional parallelism.
• Scheduling options.
• (More can be found in the specification)

31
Conditional Parallelism Issue

• Oftentimes, parallelism is only useful if the
  problem size is sufficiently big.
• For smaller sizes, overhead of parallelization
  exceeds benefit.

32
Conditional Parallelism Specification

• pragma omp parallel if( expression )
• pragma omp for if( expression )
• pragma omp parallel for if( expression )
• Execute in parallel if expression is true,
  otherwise execute sequentially.

33
Conditional Parallelism Example

• for( i0 iltn i )
• pragma omp parallel for if( n-i gt 100 )
• for( ji1 jltn j )
• for( ki1 kltn k )
• ajk ajk - aikaij / ajj

34
Scheduling of Iterations Issue

• Scheduling assigning iterations to a thread.
• So far, we have assumed the default which is
  block scheduling.
• OpenMP allows other scheduling strategies as
  well, for instance cyclic, gss (guided
  self-scheduling), etc.

35
Scheduling of Iterations Specification

• pragma omp parallel for schedule(ltschedgt)
• ltschedgt can be one of
• block (default)
• cyclic
• gss

36
Example

• Multiplication of two matrices C A x B, where
  the A matrix is upper-triangular (all elements
  below diagonal are 0).

0
A
37
Sequential Matrix Multiply Becomes

• for( i0 iltn i )
• for( j0 jltn j )
• cij 0.0
• for( ki kltn k )
• cij aikbkj
• Load imbalance with block distribution.

38
OpenMP Matrix Multiply

• pragma omp parallel for schedule( cyclic )
• for( i0 iltn i )
• for( j0 jltn j )
• cij 0.0
• for( ki kltn k )
• cij aikbkj

39
Data Environment Directives (1 of 2)

• All variables are by default shared.
• One exception the loop variable of a parallel
  for is private.
• By using data directives, some variables can be
  made private or given other special
  characteristics.

40
Reminder Matrix Multiply

• pragma omp parallel for
• for( i0 iltn i )
• for( j0 jltn j )
• cij 0.0
• for( k0 kltn k )
• cij aikbkj
• a, b, c are shared
• i, j, k are private

41
Data Environment Directives (2 of 2)

• Private
• Threadprivate
• Reduction

42
Private Variables

• pragma omp parallel for private( list )
• Makes a private copy for each thread for each
  variable in the list.
• This and all further examples are with parallel
  for, but same applies to other region and
  work-sharing directives.

43
Private Variables Example (1 of 2)

• for( i0 iltn i )
• tmp ai
• ai bi
• bi tmp
• Swaps the values in a and b.
• Loop-carried dependence on tmp.
• Easily fixed by privatizing tmp.

44
Private Variables Example (2 of 2)

• pragma omp parallel for private( tmp )
• for( i0 iltn i )
• tmp ai
• ai bi
• bi tmp
• Removes dependence on tmp.
• Would be more difficult to do in Pthreads.

45
Private Variables Alternative 1

• for( i0 iltn i )
• tmpi ai
• ai bi
• bi tmpi
• Requires sequential program change.
• Wasteful in space, O(n) vs. O(p).

46
Private Variables Alternative 2

• f()
• int tmp / local allocation on stack /
• for( ifrom iltto i )
• tmp ai
• ai bi
• bi tmp

47
Threadprivate

• Private variables are private on a parallel
  region basis.
• Threadprivate variables are global variables that
  are private throughout the execution of the
  program.

48
Threadprivate

• pragma omp threadprivate( list )
• Example pragma omp threadprivate( x)
• Requires program change in Pthreads.
• Requires an array of size p.
• Access as xpthread_self().
• Costly if accessed frequently.
• Not cheap in OpenMP either.

49
Reduction Variables

• pragma omp parallel for reduction( oplist )
• op is one of , , -, , , , , or
• The variables in list must be used with this
  operator in the loop.
• The variables are automatically initialized to
  sensible values.

50
Reduction Variables Example

• pragma omp parallel for reduction( sum )
• for( i0 iltn i )
• sum ai
• Sum is automatically initialized to zero.

51
SOR Sequential Code with Convergence

• for( diff gt delta )
• for (i0 iltn i )
• for( j0 jltn, j )
• diff 0
• for( i0 iltn i )
• for( j0 jltn j )
• diff max(diff, fabs(gridij -
  tempij))
• gridij tempij

52
SOR Sequential Code with Convergence

• for( diff gt delta )
• pragma omp parallel for
• for (i0 iltn i )
• for( j0 jltn, j )
• diff 0
• pragma omp parallel for reduction( max diff )
• for( i0 iltn i )
• for( j0 jltn j )
• diff max(diff, fabs(gridij -
  tempij))
• gridij tempij

53
SOR Sequential Code with Convergence

• for( diff gt delta )
• pragma omp parallel for
• for (i0 iltn i )
• for( j0 jltn, j )
• diff 0
• pragma omp parallel for reduction( max diff )
• for( i0 iltn i )
• for( j0 jltn j )
• diff max(diff, fabs(gridij -
  tempij))
• gridij tempij
• Bummer no reduction operator for max or min.

54
Synchronization Primitives

• Critical
• pragma omp critical name
• Implements critical sections by name.
• Similar to Pthreads mutex locks (name lock).
• Barrier
• pragma omp critical barrier
• Implements global barrier.

55
OpenMP SOR with Convergence (1 of 2)

• pragma omp parallel private( mydiff )
• for( diff gt delta )
• pragma omp for nowait
• for( ifrom iltto i )
• for( j0 jltn, j )
• diff 0.0
• mydiff 0.0
• pragma omp barrier
• ...

56
OpenMP SOR with Convergence (2 of 2)

• ...
• pragma omp for nowait
• for( ifrom iltto i )
• for( j0 jltn j )
• mydiffmax(mydiff,fabs(gridij-tempij)
• gridij tempij
• pragma critical
• diff max( diff, mydiff )
• pragma barrier

57
Synchronization Primitives

• Big bummer no condition variables.
• Result must busy wait for condition
  synchronization.
• Clumsy.
• Very inefficient on some architectures.

58
PIPE Sequential Program

• for( i0 iltnum_pic, read(in_pic) i )
• int_pic_1 trans1( in_pic )
• int_pic_2 trans2( int_pic_1)
• int_pic_3 trans3( int_pic_2)
• out_pic trans4( int_pic_3)

59
Sequential vs. Parallel Execution

• Sequential
• Parallel
• (Color -- picture horizontal line -- processor).

60
PIPE Parallel Program

• P0 for( i0 iltnum_pics, read(in_pic) i )
• int_pic_1i trans1( in_pic )
• signal(event_1_2i)
• P1 for( i0 iltnum_pics i )
• wait( event_1_2i )
• int_pic_2i trans2( int_pic_1i )
• signal(event_2_3i)

61
PIPE Main Program

• pragma omp parallel sections
• pragma omp section
• stage1()
• pragma omp section
• stage2()
• pragma omp section
• stage3()
• pragma omp section
• stage4()

62
PIPE Stage 1

• void stage1()
• num1 0
• for( i0 iltnum_pics, read(in_pic) i )
• int_pic_1i trans1( in_pic )
• pragma omp critical 1
• num1

63
PIPE Stage 2

• void stage2 ()
• for( i0 iltnum_pic i )
• do
• pragma omp critical 1
• cond (num1 lt i)
• while (cond)
• int_pic_2i trans2(int_pic_1i)
• pragma omp critical 2
• num2

64
OpenMP PIPE

• Note the need to exit critical during wait.
• Otherwise no access by other thread.
• Never busy-wait inside critical!
