Long-Distance Disaster Tolerance Technology,
Challenges, State of the Art, and Directions

• Keith Parris Systems/Software Engineer, HP
• Session 1520

2
Topics

• Terminology
• Disaster Recovery vs. Disaster Tolerance
• Metrics
• Basic technologies and state of the art
• Historical Context
• Trends
• Challenges
• Promising areas for future directions

3
High Availability (HA)

• Ability for application processing to continue
  with high probability in the face of common
  (mostly hardware) failures
• Typical technique redundancy

4
Fault Tolerance (FT)

• Ability for a computer system to continue
  operating despite hardware and/or software
  failures
• Typically requires
• Special hardware with full redundancy,
  error-checking, and hot-swap support
• Special software
• Provides the highest availability possible within
  a single datacenter

5
Disaster Recovery (DR)

• Disaster Recovery is the ability to resume
  operations after a disaster
• Foundation Off-site data storage of some sort
• Typically,
• There is some delay before operations can
  continue (many hours, possibly days), and
• Some transaction data may have been lost from IT
  systems and must be re-entered

6
DR Methods

• Tape Backup
• Expedited hardware replacement
• Vendor Recovery Site
• Data Vaulting
• Hot Site

7
Disaster Tolerance vs.Disaster Recovery

• Disaster Recovery is the ability to resume
  operations after a disaster.
• Disaster Tolerance is the ability to continue
  operations uninterrupted despite a disaster.

8
Disaster Tolerance Ideals

• Ideally, Disaster Tolerance allows one to
  continue operations uninterrupted despite a
  disaster
• Without any appreciable delays
• Without any lost transaction data

9
Quantifying Disaster Tolerance and Disaster
Recovery Requirements

• Commonly-used metrics
• Recovery Point Objective (RPO)
• Amount of data loss that is acceptable, if any
• Recovery Time Objective (RTO)
• Amount of downtime that is acceptable, if any

10
Recovery Point Objective (RPO)

• Recovery Point Objective is measured in terms of
  time
• RPO indicates the point in time to which one is
  able to recover the data after a failure,
  relative to the time of the failure itself
• RPO effectively quantifies the amount of data
  loss permissible before the business is adversely
  affected

Recovery Point Objective
Time
Disaster
Backup
11
Recovery Time Objective (RTO)

• Recovery Time Objective is also measured in terms
  of time
• Measures downtime
• from time of disaster until business can continue
• Downtime costs vary with the nature of the
  business, and with outage length

Recovery Time Objective
Time
Business Resumes
Disaster
12
Disaster Tolerance vs. Disaster Recoverybased on
RPO and RTO Metrics
Increasing Data Loss
Recovery Point Objective
Disaster Recovery
Disaster Tolerance
Zero
Zero
Recovery Time Objective
Increasing Downtime
13
Historical Context

• 1993 World Trade Center bombing raised awareness
  of DR and prompted some improvements
• Sept. 11, 2001 has had dramatic and far-reaching
  effects
• Scramble to find replacement office space
• Many datacenters moved off Manhattan Island, some
  out of NYC entirely
• Increased distances to DR sites
• Induced regulatory responses (in USA and abroad)

14
Trends and Driving Forces

• BC, DR and DT in a post-9/11 world
• Recognition of greater risk to datacenters
• Particularly in major metropolitan areas
• Push toward greater distances between redundant
  datacenters
• It is no longer inconceivable that, for example,
  terrorists might obtain a nuclear device and
  destroy the entire NYC metropolitan area

15
Trends and Driving Forces

• "Draft Interagency White Paper on Sound Practices
  to Strengthen the Resilience of the U.S.
  Financial System
• http//www.sec.gov/news/studies/34-47638.htm
• Agencies involved
• Federal Reserve System
• Department of the Treasury
• Securities Exchange Commission (SEC)
• Applies to
• Financial institutions critical to the US economy

16
Draft Interagency White Paper

• The early concept release inviting input made
  mention of a 200-300 mile limit (only as part of
  an example when asking for feedback as to whether
  any minimum distance value should be specified or
  not)
• Sound practices. Have the agencies sufficiently
  described expectations regarding out-of-region
  back-up resources? Should some minimum distance
  from primary sites be specified for back-up
  facilities for core clearing and settlement
  organizations and firms that play significant
  roles in critical markets (e.g., 200 - 300 miles
  between primary and back-up sites)? What factors
  should be used to identify such a minimum
  distance?

17
Draft Interagency White Paper

• This induced panic in several quarters
• NYC feared additional economic damage of
  companies moving out
• Some pointed out the technology limitations of
  some synchronous mirroring products and of Fibre
  Channel at the time which typically limited them
  to a distance of 100 miles or 100 km
• Revised draft contained no specific distance
  numbers just cautionary wording
• Ironically, that same non-specific wording now
  often results in DR datacenters 1,000 to 1,500
  miles away

18
Draft Interagency White Paper

• Maintain sufficient geographically dispersed
  resources to meet recovery and resumption
  objectives.
• Long-standing principles of business continuity
  planning suggest that back-up arrangements should
  be as far away from the primary site as necessary
  to avoid being subject to the same set of risks
  as the primary location.

19
Draft Interagency White Paper

• Organizations should establish back-up
  facilities a significant distance away from their
  primary sites.
• The agencies expect that, as technology and
  business processes continue to improve and
  become increasingly cost effective, firms will
  take advantage of these developments to increase
  the geographic diversification of their back-up
  sites.

20
Ripple effect of Regulatory Activity within the
USA

• National Association of Securities Dealers
  (NASD)
• Rule 3510 3520
• New York Stock Exchange (NYSE)
• Rule 446

21
Regulatory Activity Outside the USA

• United Kingdon Financial Services Authority
• Consultation Paper 142 Operational Risk and
  Systems Control
• Europe
• Basel II Accord
• Australian Prudential Regulation Authority
• Prudential Standard for business continuity
  management APS 232 and guidance note AGN 232.1
• Monetary Authority of Singapore (MAS)
• Guidelines on Risk Management Practices
  Business Continuity Management affecting
  Significantly Important Institutions (SIIs)

22
Resiliency Maturity Model project

• The Financial Services Technology Consortium
  (FTSC) has begun work on a Resiliency Maturity
  Model
• Taking inspiration from the Carnegie Mellon
  Software Engineering Institutes Capability
  Maturity Model (CMM) and Networked Systems
  Survivability Program
• Intent is to develop industry standard metrics to
  evaluate an institutions business continuity,
  disaster recovery, and crisis management
  capabilities

23
Technologies

• Inter-site data replication
• Clustering for availability

24
Data Replication Technologies

• Hardware
• Mirroring between disk subsystems
• Software
• Host-based mirroring software
• Database replication or log-shipping
• Middleware or transaction processing monitor with
  replication functionality (e.g. HP Reliable
  Transaction Router)

25
Data Replication in Hardware

• HP StorageWorks Continuous Access (CA)
• EMC Symmetrix Remote Data Facility (SRDF)

26
Data Replication in Software

• Host software disk mirroring or shadowing
• Volume Shadowing Software for OpenVMS
• MirrorDisk/UX for HP-UX
• Veritas VxVM with Volume Replicator extensions
  for UNIX and Windows

27
Data Replication in Software

• Database replication or log-shipping
• Replication within the database software
• Remote Database Facility (RDF) on NonStop
• Oracle DataGuard (Oracle Standby Database)
• Database backups plus Log Shipping

28
Data Replication in Software

• TP Monitor/Transaction Router
• e.g. HP Reliable Transaction Router (RTR)
  Software on OpenVMS, UNIX, Linux, and Windows

29
Data Replication in Hardware

• Data mirroring schemes
• Synchronous
• Slower, but no chance of data loss in conjunction
  with a site loss
• Asynchronous
• Faster, and works for longer distances
• but can lose seconds or minutes worth of data
  (more under high loads) in a site disaster

30
Basic underlying challenges, and technologies to
address them

• Data protection through data replication
• Geographic separation for the sake of relative
  safety
• Careful site selection
• Application coordination
• Long-distance multi-site clustering
• Inter-site link technologies choices
• Inter-site link bandwidth and media types
  available vary widely with location
• Cost can be very high in some cases
• Inter-site latency due to the speed of light
• And its adverse impact on performance

31
Inter-site Link Options

• Sites linked by
• DS-3/T3 (E3 in Europe) or ATM circuits from a
  telecommunications vendor
• Microwave link DS-3/T3 or Ethernet
• Free-Space Optics link (short distance, low cost)
• Dark fiber where available. ATM over SONET,
  or
• Ethernet over fiber (10 mb, Fast, Gigabit)
• FDDI
• Fibre Channel
• Fiber links between Memory Channel switches (up
  to 3 km)

32
Inter-site Link Options

• Sites linked by
• Wave Division Multiplexing (WDM), in either
  Coarse (CWDM) or Dense (DWDM) Wave Division
  Multiplexing flavors
• Can carry any of the types of traffic that can
  run over a single fiber
• Individual WDM channel(s) from a vendor, rather
  than entire dark fibers

33
Bandwidth of Inter-Site Link(s)
34
Long-distance Cluster Issues

• Latency due to speed of light becomes significant
  at higher distances. Rules of thumb
• About 1 ms per 125 miles, one-way or
• About 1 ms per 62 miles, round-trip latency
• Actual circuit path length can be longer than
  highway mileage between sites
• Latency adversely affects performance

35
Round-trip Packet Latencies
36
Inter-site LatencyActual Customer Measurements
37
Differentiate between latency and bandwidth

• Cant get around the speed of light and its
  latency effects over long distances
• Higher-bandwidth link doesnt mean lower latency

38
SAN Extension

• Fibre Channel distance over fiber is limited to
  about 100-200 kilometers
• Shortage of buffer-to-buffer credits adversely
  affects Fibre Channel performance above about 50
  kilometers some vendors provide more for a price
• Various vendors provide SAN Extension boxes to
  connect Fibre Channel SANs over an inter-site
  link like SONET, DS-3, ATM, Gigabit Ethernet, IP
  network, etc.
• See SAN Design Reference Guide Vol. 4 SAN
  extension and bridging
• http//h20000.www2.hp.com/bc/docs/support/SupportM
  anual/c00310437/c00310437.pdf

39
Long-distance SynchronousHost-based Mirroring
Software Tests

• OpenVMS Host-Based Volume Shadowing (HBVS)
  software (host-based mirroring software)
• Synchronous mirroring product
• SAN Extension used to extend SAN using FCIP boxes
• AdTech box used to simulate distance via
  introduced packet latency
• No OpenVMS Cluster involved across this distance
  (no OpenVMS node at the remote end just data
  vaulting to a distant disk controller)

40
Long-distance HBVS Test Results
41
Mitigating the Impact of Distance

• Do transactions as much as possible in parallel
  rather than serially
• May have to find and eliminate hidden
  serialization points in applications and system
  software
• Minimize number of round trips between sites to
  complete a transaction

42
Minimizing Round Trips Between Sites

• Some vendors have Fibre Channel SCSI-3 protocol
  tricks to do writes in 1 round trip vs. 2
• e.g. Ciscos Write Acceleration

43
Mitigating Impact of Inter-Site Latency

• How applications are distributed across a
  multi-site cluster can affect performance when a
  distributed lock manager is involved (e.g. Oracle
  RAC, OpenVMS Cluster or TruCluster)
• But this represents a trade-off among
  performance, availability, and resource
  utilization

44
Application Scheme 1Hot Primary/Cold Standby

• All applications normally run at the primary site
• Second site is idle, except for volume shadowing,
  until primary site fails, then it takes over
  processing
• Performance will be good (all-local locking)
• Fail-over time will be poor, and risk high
  (standby systems not active and thus not being
  tested)
• Wastes computing capacity at the remote site

45
Application Scheme 2Hot/Hot but Alternate
Workloads

• All applications normally run at one site or the
  other, but not both data is shadowed between
  sites, and the opposite site takes over upon a
  failure
• Performance will be good (all-local locking)
• Fail-over time will be poor, and risk moderate
  (standby systems in use, but specific
  applications not active and thus not being tested
  from that site)
• Second sites computing capacity is actively used

46
Application Scheme 3Uniform Workload Across
Sites

• All applications normally run at both sites
  simultaneously surviving site takes all load
  upon failure
• Performance may be impacted (some remote locking)
  if inter-site distance is large
• Fail-over time will be excellent, and risk low
  (standby systems are already in use running the
  same applications, thus constantly being tested)
• Both sites computing capacity is actively used

47
Work-arounds being used today

• Multi-hop replication
• Synchronous to nearby site
• Asynchronous to far-away site

48
Promising areas for investigation

• Replicate at higher levels to reduce round-trips
  and replication volumes
• e.g. replicate transaction (a few hundred bytes)
  with Reliable Transaction Router instead of
  having to replicate all the database page updates
  (often 8 kilobytes or 64 kilobytes per page) and
  journal log file writes behind a database
• or replicate database transactions instead of
  database disk writes

49
Promising areas for investigation

• Parallelism as a potential solution
• Rationale
• Adding 30 milliseconds to a typical transaction
  for a human may not be noticeable
• Having to wait for many 30-millisecond
  transactions in front of yours slows things down
• Applications in the future may have to be built
  with greater awareness of inter-site latency
• Promising direction
• Allow many more transactions to be in flight in
  parallel
• Each will take longer, but overall throughput
  (transaction rate) might be the same or even
  higher than now

50
Useful Resources

• Tabb Research report
• "Crisis in Continuity Financial Markets Firms
  Tackle the 100 km Question"
• available from https//h30046.www3.hp.com/campaign
  s/2005/promo/wwfsi/index.php?mcclanding_pagejump
  idex_R2548_promo/fsipaper_mcc7Clanding_page

51
Useful Resources

• Disaster Recovery Journal
• http//www.drj.com/
• Continuity Insights Magazine
• http//www.continuityinsights.com//
• Contingency Planning Management Magazine
• http//www.contingencyplanning.com/
• All are high-quality journals. The first two are
  available free to qualified subscribers
• All hold conferences as well.

52
Keith Parris

• Case studies
• a large Credit Union
• New York clearing firms

53
Questions?
54
Speaker Contact Info

• Keith Parris
• E-mail Keith.Parris_at_hp.com or keithparris_at_yahoo.c
  om
• Web http//www2.openvms.org/kparris/

55
(No Transcript)
56
get connected
People. Training. Technology.
57
(No Transcript)
58
(No Transcript)
