Tool ID WEEK 1

1
Tool ID WEEK 1
Study Guide
Compliments of T. Gravatt 2007
2
KEY OBJECTIVE

• Identify Common Hand Tools which includes but is
  not limited to axes, bars, and tools used for
  boring from both description and visually!
• Explain safe use of each tool!
• Selection of correct tool for the use!

Compliments of T. Gravatt 2007
3
SelectionTool ID Week 1
1
6
2
3
4
5
11
12
7
8
9
10
13
14
15
16
17
18
Compliments of T. Gravatt 2007
4
1.Single Bit Axe
TOOL IDENTIFICATION
Building fence, cutting small trees and
construction work. Very versatile tool not to
be used as a sledge hammer on wedges or iron
stakes. Hickory Handle 36 inches long, oval in
cross section and shaped for good balance.
Home
Compliments of T. Gravatt 2007
5
2 Double Bit Axe
TOOL IDENTIFICATION
Used to cut small trees, trim logs, and tree
tops. Two cutting edges pose a safety hazard
and should never be left in a vertical position.
Handles are 36 inches, oval, and straight.
Home
Compliments of T. Gravatt 2007
6
3. Hand Axe
TOOL IDENTIFICATION
Used for sharpening stakes, cutting small limbs
and brush. Also used to drive small stakes,
grade stakes, and corner stakes.Handle similar to
single bit axe but smaller. Handle are 16 18
inches long.
Home
Compliments of T. Gravatt 2007
7
4. Broad Hatchet
TOOL IDENTIFICATION
Designed to hew wood and reduce stock. The
cutting edge has a bevel of 25 30 degrees on
the right side. The other side has a straight
flat surface. This tools symmetrical shape makes
it easy for a left handed person to use. This
hatchet is frequently mistaken for a hand axe.
Home
Compliments of T. Gravatt 2007
8
5. Shinglers Hatchet
TOOL IDENTIFICATION
Used for shingling and lathing. It has a bevel
on both sides and a serrated head. It has a
gauge that can be adjusted for desired shingle
exposure
Home
Compliments of T. Gravatt 2007
9
6. Crow Bar
TOOL IDENTIFICATION
Used for heavy prying of stones, timbers and
machinery. It is normally, 4 to 5 feet long
with one end tapered round and the other end with
a chisel point.
Home
Compliments of T. Gravatt 2007
10
7. Pry or Fitting Bar
TOOL IDENTIFICATION
Used for aligning bolt holes in fitting machinery
parts. It has a long round taper at one end and
a curved pry hook at the other end.
Home
Compliments of T. Gravatt 2007
11
8. Ripping Bar
TOOL IDENTIFICATION
Used for pulling nail, wrecking buildings,
opening boxes and many other jobs. It has a
curved claw at one end and a flat tapered pry at
the other end. Usually made out of octagon
tempered steel. Also called a Wrecking Bar
Home
Compliments of T. Gravatt 2007
12
9. Nail Puller
TOOL IDENTIFICATION
Used to pull nails. A pair of jaws are driven
into the wood below the nail head by impact
action of the handle.
Home
Compliments of T. Gravatt 2007
13
10. Flat Pry Bar
TOOL IDENTIFICATION
Used for pulling nails, prying and lifting. Made
of forged steel for extra toughness with polished
and beveled cutting edges. Contoured flat bar,
with beveled nail slots at each end. Also called
a Wonder Bar
Home
Compliments of T. Gravatt 2007
14
11. Auger Bit
TOOL IDENTIFICATION
Used to bore holes in wood. The point, lead,
screw, guides and draws the cutting parts, called
lips and spurs into the wood. The spurs score
the wood and the lips cut out the wood. Bits are
numbered by whole numbers. These numbers are in
fractions of sixteenths.
Home
Compliments of T. Gravatt 2007
15
12. Bit Brace
TOOL IDENTIFICATION
Used for turning Auger bits, twist drills,
screwdriver bits, countersinks, and reamers. It
is made with and without a ratchet. The ratchet
makes it possible to bore in close quarters and
to drive large wood screws.
Home
Compliments of T. Gravatt 2007
16
13. Carbide-tipped Masonry drill
TOOL IDENTIFICATION
Used for drilling holes in masonry and concrete.
The tip is treated with tungsten-carbide to
resist heat and wear
Home
Compliments of T. Gravatt 2007
17
14. Hole Saw
TOOL IDENTIFICATION
Used to make clean round cuts in wood,
composition board, plastics, and soft metals.
Can be used in portable electric drills and drill
presses. Shaped like a circular steel cup with
teeth on the edge. A mandrel is used to attach
to the hole to enable it to be powered by a
drill. Sizes range from ¾ to 2 ½ inches
larger. One mandrel fits all.
Home
Compliments of T. Gravatt 2007
18
15. Expansive Bit
TOOL IDENTIFICATION
Used to bore holes in wood 5/8 to 3 inches in
diameter. The cutters are adapted to the size
desired by a set screw. The shank is a square
taper, adapted for the bit brace.
Home
Compliments of T. Gravatt 2007
19
16. Straight Shank Twist Drill
TOOL IDENTIFICATION
Used in a standard drill chuck. Used to cut wood
or metal. If used to cut hard steel at high
speeds, it should be made of high speed steel.
Home
Compliments of T. Gravatt 2007
20
17. Star Drill
TOOL IDENTIFICATION
Used to Drive holes in concrete or masonry. The
drill point is temper hardened and looks like a
four point star. The shank is made of a high
grade octagon steel drill rod. It is operated by
striking with a hammer while rotating by hand.
Home
Compliments of T. Gravatt 2007
21
18. Tapered Shank Twist Drill
TOOL IDENTIFICATION
Used in a drill press with a hallow morse taper
spindle and with out a chuck. The shank is
tapered and should never be used in a chuck.
Used to cut metal.
Home
Compliments of T. Gravatt 2007
22
TOOL TIME POP QUIZ
Identify the following tools!!!!
Compliments of T. Gravatt 2007
23
TOOL TIME QUIZ 1
Compliments of T. Gravatt 2007
24
TOOL TIME QUIZ 2
Compliments of T. Gravatt 2007
25
TOOL TIME QUIZ 3
Compliments of T. Gravatt 2007
26
TOOL TIME QUIZ 4
Compliments of T. Gravatt 2007
27
TOOL TIME QUIZ 5
Compliments of T. Gravatt 2007
28
TOOL TIME QUIZ 6
Compliments of T. Gravatt 2007
29
Prepare for the answers!!They will appear in 12
seconds or click.
Compliments of T. Gravatt 2007
30
ANSWERS

• Bit Brace
• Expansive Bit
• Crow Bar
• Single Bit Axe
• Star Drill
• Wonder Bar

Compliments of T. Gravatt 2007
31
End Of Tool ID Week 1
