Homology Modelling

1
Homology Modelling

• Thomas Blicher
• Center for Biological Sequence Analysis

2
Why Do We Need Homology Modelling?

• Ab Initio protein folding (random sampling)
• 100 aa, 3 conf./residue gives approximately 1048
  different overall conformations!
• Random sampling is NOT feasible, even if
  conformations can be sampled at picosecond (10-12
  sec) rates.
• Levinthals paradox
• Do homology modelling instead.

3
How Is It Possible?

• The structure of a protein is uniquely determined
  by its amino acid sequence(but sequence is
  sometimes not enough)
• prions
• pH, ions, cofactors, chaperones
• Structure is conserved much longer than sequence
  in evolution.
• Structure gt Function gt Sequence

4
How Often Can We Do It?

• There are currently 40000 structures in the PDB
  (but only 4000 if you include only ones that are
  not more than 30 identical and have a resolution
  better than 3.0 Å).
• An estimated 25 of all sequences can be modeled
  and structural information can be obtained for
  50.

5
Worldwide Structural Genomics

• Fold space coverage
• Complete genomes
• Signaling proteins
• Improving technology
• Disease-causing organisms
• Model organisms
• Membrane proteins
• Protein-ligand interactions

6
Structural Genomics in North America

• 10 year 600 million project initiated in 2000,
  funded largely by NIH.
• AIM structural information on 10000 unique
  proteins (now 4-6000), so far 1000 have been
  determined.
• Improve current techniques to reduce time (from
  months to days) and cost (from 100.000 to
  20.000/structure).
• 9 research centers currently funded (2005),
  targets are from model and disease-causing
  organisms (a separate project on TB proteins).

7
Homology Modeling for Structural Genomics
Roberto Sánchez et al. Nature Structural Biology
7, 986 - 990 (2000)
8
How Well Can We Do It?
Sali, A. Kuriyan, J. Trends Biochem. Sci. 22,
M20M24 (1999)
9
How Is It Done?

• Identify template(s) initial alignment
• Improve alignment
• Backbone generation
• Loop modelling
• Side chains
• Refinement
• Validation ?

10
Template Identification

• Search with sequence
• Blast
• Psi-Blast
• Fold recognition methods
• Use biological information
• Functional annotation in databases
• Active site/motifs

11
Alignment
12
1 2 3 4 5 6 7 8 9 10 11 12
13 14 PHE ASP ILE CYS ARG LEU PRO GLY SER ALA
GLU ALA VAL CYS PHE ASN VAL CYS ARG THR PRO ---
--- --- GLU ALA ILE CYS PHE ASN VAL CYS ARG ---
--- --- THR PRO GLU ALA ILE CYS
13
1 2 3 4 5 6 7 8 9 10 11 12
13 14 PHE ASP ILE CYS ARG LEU PRO GLY SER ALA
GLU ALA VAL CYS PHE ASN VAL CYS ARG THR PRO ---
--- --- GLU ALA ILE CYS PHE ASN VAL CYS ARG ---
--- --- THR PRO GLU ALA ILE CYS
14
Improving the Alignment
1 2 3 4 5 6 7 8 9 10 11 12
13 14 PHE ASP ILE CYS ARG LEU PRO GLY SER ALA
GLU ALA VAL CYS PHE ASN VAL CYS ARG THR PRO ---
--- --- GLU ALA ILE CYS PHE ASN VAL CYS ARG ---
--- --- THR PRO GLU ALA ILE CYS
From Professional Gambling by Gert Vriend
http//www.cmbi.kun.nl/gv/articles/text/gambling.
html
15
Template Quality

• Selecting the best template is crucial!
• The best template may not be the one with the
  highest id (best p-value)
• Template 1 93 id, 3.5 Å resolution ?
• Template 2 90 id, 1.5 Å resolution ?

16
The Importance of Resolution
4 Å
3 Å
2 Å
1 Å
17
Ramachandran Plot

• Allowed backbone torsion angles in proteins

Amino acid residue
18
Template Quality Ramachandran Plot
X-ray structure good data.
19
Backbone Generation

• Generate the backbone coordinates from the
  template for the aligned regions.
• Several programs can do this, most of the groups
  at CASP6 use Modeller
• http//salilab.org/modeller/modeller.html

20
Loop Modelling

• Knowledge based
• Searches PDB for fragments that match the
  sequence to be modelled (Levitt, Holm, Baker
  etc.).
• Energy based
• Uses an energy function to evaluate the quality
  of the loop and minimizes this function by Monte
  Carlo (sampling) or molecular dynamics (MD)
  techniques.
• Combination

21
Loops the Rosetta Method

• Find fragments (10 per amino acid) with the same
  sequence and secondary structure profile as the
  query sequence.
• Combine them using a Monte Carlo scheme to build
  the loop.
• David Baker et al.

22
Side Chains

• Side chain rotamers are dependent on backbone
  conformation.
• Most successful method in CASP6 was SCWRL by
  Dunbrack et al.
• Graph-theory knowledge based method to solve the
  combinatorial problem of side chain modelling.
• http//dunbrack.fccc.edu/SCWRL3.php

23
Side Chains

• Prediction accuracy is high for buried residues,
  but much lower for surface residues
• Experimental reasonsside chains at the surface
  are more flexible.
• Theoretical reasonsmuch easier to handle
  hydrophobic packing in the core than the
  electrostatic interactions, including H-bonds to
  waters.

24
Side Chains

• If the seq. id is high, the networks of side
  chain contacts may be conserved, and keeping the
  side chain rotamers from the template may be
  better than predicting new ones.

25
Refinement

• Energy minimization
• Molecular dynamics
• Big errors like atom clashes can be removed, but
  force fields are not perfect and small errors
  will also be introduced keep minimization to a
  minimum or matters will only get worse.

26
Error Recovery

• If errors are introduced in the model, they
  normally can NOT be recovered at a later step
• The alignment can not make up for a bad choice of
  template.
• Loop modeling can not make up for a poor
  alignment.
• If errors are discovered, the step where they
  were introduced should be redone.

27
Validation

• Most programs will get the bond lengths and
  angles right.
• The Ramachandran plot of the model usually looks
  pretty much like the Ramachandran plot of the
  template (so select a high quality template).
• Inside/outside distributions of polar and apolar
  residues can be useful.

28
Validation ProQ Server

• ProQ is a neural network based predictor that
  based on a number of structural features predicts
  the quality of a protein model.
• ProQ is optimized to find correct models in
  contrast to other methods which are optimized to
  find native structures.

Arne Elofssons group http//www.sbc.su.se/bjorn
/ProQ/
29
Structure Validation

• ProCheck
• http//www.biochem.ucl.ac.uk/roman/procheck/proch
  eck.html
• WhatIf server
• http//swift.cmbi.kun.nl/WIWWWI/

30
Homology Modelling Servers

• Eva-CM performs continous and automated analysis
  of comparative protein structure modeling servers
• A current list of the best performing servers can
  be found at
• http//cubic.bioc.columbia.edu/eva/doc/intro_cm.ht
  ml

31
The Hardest Target in CASP6

• Only 8 sequence id between target and template.

Dunbrack, Wang Jin (2004) CASP6 Fold
Recognition Assessment
32
Summary

• Successful homology modelling depends on the
  following
• Template quality
• Alignment (add biological information)
• Modelling program/procedure (use more than one)
• Always validate your final model!
