Welcome to Getting Started With PIKA Fax for Asterisk

1
Welcome toGetting Started WithPIKA Fax for
Asterisk trixboxWe will begin at 1pm EDT
2
Getting Started WithPIKA Fax for Asterisk
trixbox Eric PretlacTechnical Support
EngineerJune 18, 2008
3
Before we get started

• Audio dial into the conference call
• Send questions at any time during webinar
• Question and Answer window
• Type in question, hit send
• Answered at the end
• Disable pop-up blockers

4
Agenda

• What is a channel driver?
• What is supported?
• Versions of Asterisk, trixbox
• What hardware is supported?
• Fax features
• Installing PIKA fax with trixbox
• How to download files
• Step-by-step installation
• Dialplan syntax
• Installing PIKA fax with stock Asterisk
• How to download files
• Step-by-step installation
• Dialplan syntax
• Question Answer

5
Terminology

• What is a channel driver?
• According to www.asterisk.org
• Each call into Asterisk must come in through a
  channel driver that supports a technology
  like SIP, ZAP, IAX2 etc.
• Program that allows PIKA cards to work with
  Asterisk

6
PIKA Terminology

• chan_pika_dsp
• low density analog (4 port fxo) card
• On-board DSP
• chan_pika
• high density analog fxo / fxs cards
• digital T1/E1 cards
• fax with any Asterisk compatible board!!

7
What you can do with PIKA Fax for Asterisk

• Send and receive faxes (to a file)
• Fax with any Asterisk compatible board
• e.g. PIKA, Digium, Sangoma, Rhino
• Works with Asterisk and trixbox

8
PIKA Fax Reliable Fax

• Same stack as our business class fax
• Based on Commetrex fax technology
• Broad range of fax machine compatibility
• Case Study Protus IP Solutions

9
PIKAs Fax Features

• Supports ITU-T T.30
• Supports ITU-T V.21, V.27ter, V.29 and V.17
  modems for send and receive data rates up to 14.4
  Kbps.
• ECM (error correction mode)
• Header and footers can be added by senders and
  receivers

10
PIKAs Fax Features (contd)

• Subscriber ID
• T.4 and T.6 formats including
• Metric- and inch-based page sizes
• All resolutions including 100x100, 200x200,
  300x300 and 400x400
• MH, MR and MMR encoding
• TIFF-F format

11
Installing PIKA Fax with trixbox
12
PIKA support for trixbox

• PIKA supports trixbox CE 2.2, 2.4, 2.6
• PIKA hardware
• Low Density Analog (4 fxo)
• High density Analog Trunk/ fxo
• High density Analog Station/ fxs
• Digital T1/E1 PCI/PCIe

13
PIKA Hardware for Asterisk
14
Installing PIKA Fax with trixbox
15
Download the files

• Download and install trixbox
• www.trixbox.org
• Download and install PIKA files
• using yum install
• Installation instructions
• www.pikatechnologies.com/asterisk

16
Installing chan_pika with trixbox

• Install the PIKA card optional
• yum install pika-repo
• yum install pika_aoh_
• yum install chan_pika-3
• pikalm to install fax licenses
• Use FreePBX to configure a fax extension
• add custom-pikafax to extensions_custom.conf
• Add Extension Other (Custom) Device
• dial Local/s_at_custom-pikafax
• General Settings PIKA fax lt9998gt
• Restart asterisk

17
Using PIKA fax in your Dialplan - Receiving

• custom-pikafax
• exten gt s,1,Wait(1)
• exten gt s,n,NoOp(Answer from a PSTN port)
• exten gt s,n,Answer
• exten gt s,n,Wait(1)
• exten gt s,n,Set(LOCALSTATIONID1078)
• exten gt s,n,Set(LOCALHEADERINFO
• "PIKARxFax Test Page P Time
  HM To l From r")
• exten gt s,n,Set(FAXFILE/tmp/pikafax-UNIQUEID.
  tif)
• exten gt s,n,Wait(1)
• exten gt s,n,PIKARxFax(FAXFILE)
• exten gt s,n,NoOp(REMOTESTATIONID)
• exten gt s,n,NoOp(FAXPAGES)
• exten gt s,n,NoOp(FAXBITRATE)
• exten gt s,n,NoOp(FAXRESOLUTION)
• exten gt s,n,Hangup

18
Installing PIKA fax with stock Asterisk
19
PIKA support for Asterisk

• PIKA supports Asterisk 1.2 and 1.4
• PIKA hardware
• Low Density Analog (4 fxo)
• High density Analog Trunk/ fxo
• High density Analog Station/ fxs
• Digital T1/E1 PCI/PCIe

20
Before you begin

• gcc and glibc must be installed
• Kernel source must be installed
• Must disable SElinux
• Any 32-bit distro using kernel 2.6
• Must use the smp kernel (chan_pika)
• PIKA scripts check all of this! ?

21
Download the files

• Full instructions are in the INSTALL doc
• on our website (and in the download)
• Download Zaptel and Asterisk source
• www.asterisk.org
• Download PIKA files
• www.pikatechnologies.com/asterisk

22
Installing PIKA fax with stock Asterisk
23
Installing chan_pika

• Extract Asterisk source
• tar -zxf asterisk-1.4.17.tar.gz -C
  /usr/src/
• Extract Zaptel source
• tar -zxf zaptel-1.4.7.tar.gz -C /usr/src/
• PIKA uses ztdummy module
• Extract PIKA channel driver source
• tar -zxf chan_pika-3.3.0.tgz -C /usr/src/

24
chan_pika (contd)

• Physically install the PIKA board
• Install the PIKA board driver and SDK
• cd /usr/src/chan_pika-3.3.0
• ./pikaaoh-2.2.8-linux-installer
• Activate PIKA fax licenses
• pikalm
• Enter the license string emailed to you

25
Installing chan_pika (contd)

• Build and install Zaptel
• ./configure make make install
• Build and install Asterisk
• ./configure make make install
• Build and install chan_pika
• cd /usr/src/chan_pika-3.3.0
• ./configure make make install
• Configure chan_pika
• make config

26
Using PIKA fax in your Dialplan - Receiving

• custom-pikafax
• exten gt s,1,Wait(1)
• exten gt s,n,NoOp(Answer from a PSTN port)
• exten gt s,n,Answer
• exten gt s,n,Wait(1)
• exten gt s,n,Set(LOCALSTATIONID1078)
• exten gt s,n,Set(LOCALHEADERINFO
• "PIKARxFax Test Page P Time
  HM To l From r")
• exten gt s,n,Set(FAXFILE/tmp/pikafax-UNIQUEID.
  tif)
• exten gt s,n,Wait(1)
• exten gt s,n,PIKARxFax(FAXFILE)
• exten gt s,n,NoOp(REMOTESTATIONID)
• exten gt s,n,NoOp(FAXPAGES)
• exten gt s,n,NoOp(FAXBITRATE)
• exten gt s,n,NoOp(FAXRESOLUTION)
• exten gt s,n,Hangup

27
Using PIKA fax in your Dialplan - Sending

• outgoing
• exten gt s,1,Dial(Zap/g0/6135551234)
• exten gt s,n,Set(LOCALSTATIONID1078)
• exten gt s,n,Set(LOCALHEADERINFO
• "PIKARxFax Test Page P Time
  HM To l From r")
• exten gt s,n,Set(FAXFILE/tmp/pikafax.tif)
• exten gt s,n,Wait(1)
• exten gt s,n,PikaTxFax(FAXFILE)
• exten gt s,n,Hangup

28
Installing PIKA fax Last Step!

• Start Asterisk
• To verify that Pika fax applications have been
  successfully installed
• CLIgt  show applications
• PikaRxFax and PikaTxFax
• CLIgt  pika show version
• PIKA Channel Driver for Asterisk 3.3.0.194
• GrandPrix version 2.4.0.100
• AoH version 2.4.0.130

29
Why choose PIKA Fax for Asterisk?

• Easy to install
• Accessible Support
• Reliable, market proven performance
• High Density
• Low cost

30
Agenda

• What is a channel driver?
• What is supported?
• trixbox 2.2, 2.4, 2.6
• Asterisk 1.2 1.4
• PIKA hardware 3rd party
• Fax features
• Installing PIKA fax with trixbox
• How to download files
• Step-by-step installation
• Dialplan syntax
• Installing PIKA fax with stock Asterisk
• How and where to download files
• Step-by-step installation
• Dialplan syntax
• Question Answer

31
Question Answer

• We invite you to ask questions.
• Enter your question
• in the Question and Answer window.
• Send to LEADER.
• Well answer as many questions
• as we have time.

32
Contact Us

• Support
• Mon-Fri 600 a.m. to 500 p.m. EST/EDT
• Phone [phone]
• Dial 2 for Support
• Skype pikatechnologies
• Email support_at_pikatech.com

33
Upcoming PIKA Technical Webinars
www.pikatech.com NEWS EVENTS / Technical
Webinars
34
Before you go . .

• Please fill out the on-line survey
• Tell us how we did
• Give us suggestions for future topics

35
Thank you for your time.
