Title: WorldOS Corp.


1
WorldOS Corp.
  • NYJavaSig Talk 1/30/2001

2
Introduction
  • Me
  • Lucas Gonze
  • Web/eCommerce developer
  • Open source culture
  • Network emphasis

3
Introduction
  • WorldOS
  • One year old
  • Topology centric
  • Java
  • About the software
  • About the business

4
Introduction
  • Web era led to Java and Windows standoff
  • In general Internet era, what next?
  • .Net C?
  • Java on the client?
  • Client-Server or Server-Client?
  • Whither Perl, Python and VB?

5
Overview
  • This talk will
  • Introduce peer to peer ideas
  • Evaluate Java as a tool for peer to peer.
  • Show common approaches
  • Show infrastructure you can use
  • Focus on practical knowledge over theory.

6
Basics of Peer to Peer
  • Working definition of P2P Projects that
    followed directly on Napster.
  • P2P networks often allow computers to act as both
    client and server.
  • Every computer connected to the network will
    probably provide resources to the system as a
    whole. That is not as true for a web browser.

7
Basics of Peer to Peer
  • You only own your side of the connection. The
    other side is a black box.
  • It is not safe to assume that you wrote the
    software on the other side. You have no way of
    knowing what is on the other end of a connection.
  • This precludes approaches like storing unsigned
    state in outgoing messages, and assuming that it
    is canonical when it comes back.
  • Use nodewise encapsulation to leverage this
    heuristic.
  • Connections between nodes are interfaces, not
    buses. Design for rough grained transactions.

8
Client/Server Job Search
9
P2P Job Search
10
Families of P2P applications
  • Put dark (but normal) matter to work
  • CPU
  • Seti_at_home, PopularPower
  • Files
  • Napster, Gnutella
  • Bandwidth
  • Swarmcast

11
Families of P2P applications
  • Use the unique properties of decentralized
    computer networks
  • Privacy
  • Publius
  • Freenet
  • Complex systems
  • MojoNation
  • Random number generator
  • Economic modeling
  • Cellular automata

12
An Example Swarmcast
  • Parallel streams via rebroadcast
  • Immunizes against /. effect. As a piece of
    content becomes more popular, downloads become
    faster to the consumer, and less costly to the
    provider.
  • Flood strategy. You cant be inefficient in
    using stuff that would have been thrown out
    anyway.

13
Heterogeneousness
  • P2P puts network effects to work
  • Putting network effects to work means large
    networks
  • In a very large network there is no boss to
    enforce standards
  • To thrive without standards
  • Use LCD approach
  • Be adaptable

14
Heterogeneousness
  • Dont try to force it the network is bigger
    than you.
  • Jujitsu is the only chance you have.
  • Think of the Fed manipulating the US economy via
    the prime rate, rather than by wage and price
    controls.

15
Heterogeneousness Java
  • Evaluating the suitability of Java to P2P is a
    question of how well Java helps you to exploit
    network effects.
  • A Java program is often poorly adapted to local
    conditions like users are not computer experts.
    A native program can be optimized for a dominant
    platform. This allows it to
  • target and take advantage of local conditions
    (e.g. with a newbie oriented GUI), and
  • leverage the ensuing popularity to drive native
    implementations on other platforms.
  • Such a program thrives by avoiding heterogenous
    situations. Not a bad strategy!
  • So how does Java stack up in taking advantage of
    network effects? That is, if you are are trying
    to use jujitsu to get network effects on your
    side, how does Java measure up the problem?

16
Heterogeneousness Java
  • Strategies
  • Avoid heterogeneousness
  • Example Microsoft applications software works
    extremely well, but only in Windows
  • Stick to least common denominators
  • Example Email works everywhere, for everyone,
    but only if we all stick to the standards at the
    time email became popular - ASCII and SMTP.
  • Be as adaptable as possible
  • Example A P2P project with an IE plugin that
    allowed searching Gnutellanet, Napster and Google
    at the same time.

17
Javas ability to exploit LCDs
  • HTTP
  • Pro Jakarta-Tomcat works great
  • Con Tomcat requires Java 2 or better
  • ASCII
  • Pro Javas support for ASCII is second to none
  • Con
  • Java is itself designed to be an LCD
  • Pro JVMs
  • Con JVMs Java 2 are rare on user machines
  • Windows
  • Pro popularity of Mac and Unix.
  • Con ubiquitousness of Windows.

18
Javas ability to exploit LCDs
  • Conclusion
  • If Java 2 isnt needed
  • Or if your users will download the JRE()
  • Or if your app needs to support Mac and Unix
    users
  • Then Java is a good bet for exploiting LCDs.
  • broadband makes this reasonably likely for high
    end users dialup makes this unlikely for
    consumer users.

19
Javas ability to be adaptable
  • Multiprotocol
  • Pro Javas roots among network oriented
    programmers (Unix people) make it the killer
    environment for TCP development.
  • There exist excellent implementations of
  • SMTP (via Javamail)
  • NNTP
  • HTTP
  • Gnutella
  • CORBA
  • RMI
  • SOAP/HTTP
  • Con No support for raw IP.
  • No implementation of Ping!
  • Why does multiprotocol matter? Network effects
    of joining multiple subnets.

20
Javas ability to be adaptable
  • Hardware agnostic handles multiple binary
    formats gracefully
  • Pro Network-order byte stream everywhere
  • Con C has better tools for binary operations.
  • Con RMI is Java-to-Java only.
  • WORA
  • Pro not bad, all things considering. No serious
    competition in this area, because no other
    interpreted languages have the same range of
    support.
  • Con not nearly good enough.

21
Javas ability to be adaptable
  • Flexible trust models
  • Pro Huge range of encryption, AI and other
    modern tools.
  • Pro Fine grained sandboxing policies.
  • Pro Runtime loading and evaluation allow great
    flexibility.
  • Pro Javas user base in the complex systems
    academic communities
  • Con CPU intensive work plays to Javas weakness
    (performance).
  • Con MojoNation is the most mature toolkit, and
    that is in Python. WorldOS is in Java, but is
    far from mature.

22
Javas ability to be adaptable
  • XML
  • Pro Allows for decentralized extension of
    message formats.
  • Pro Is unequalled cross-platform glue.
  • Con Has no efficient binary equivalent for
    high-volume messaging (yet).
  • Java XML support
  • Pro Industry standard XML tools are Java
    Xerces, Xalan, JDOM.
  • Con Java 2 required for Xerces, Xalan, JDOM.
  • Con Parsers are slow.

23
Javas ability to be adaptable
  • Conclusion
  • If high adaptability is needed, Java is a good
    tool.

24
Real World Comparisons
  • Gnutella
  • not Java Bearshare
  • Footprint 1.09 MB
  • Appearance pretty great
  • Usability excellent throughout
  • (but partially due to much effort)
  • Java LimeWire
  • Footprint 6.39 MB
  • Appearance somewhat ugly
  • Usability relatively bad
  • (but not due to not trying)
  • Does not match other native software
  • e.g. the file open and save dialogs are not the
    standard
  • E.g. you cant sort a file list by clicking on
    sub-heads
  • Buggy
  • E.g. the details option in the file browse
    dialog doesnt work

25
Real World Comparisons
  • Gnutella/Windows BearShare

26
Real World Comparisons
  • Gnutella/Java LimeWire

27
Real World Comparisons
  • Unique features of Limewire
  • Community -- Enter an open community of similar
    users, as defined by interests and computing
    power / bandwidth, to optimize search performance
  • Anti-Freeloader Features - Choose to protect and
    enhance the gnutella network by "preferring"
    nodes who share files and information.
  • Browse Host -- See all files a given host has
  • Library Function -- Launch and manage downloaded
    and shared files
  • Relevancy Scoring -- See which search results are
    most relevant to the search terms

28
Implementation
  • Q How do you get started?
  • A Look for precedents.

29
Implementation ClientServer
  • Simplest approach to converting a web app to a
    P2P app is to run the web server on localhost.
  • Minimal modifications to the code, if youre
    lucky.
  • Need a database, tag replacer, perl etc. on
    client side.
  • Immature technology.

30
Implementation Desktop Web Server
  • A web server running on the client
  • Webby UI
  • Either
  • SOAP calls between native GUI and your web
    server.
  • Interface can be written in VB
  • Magi uses this approach
  • OR
  • HTTP calls between browser UI and your web server
  • With reasonable latency web UIs are much more
    usable.

31
Implementation Desktop Web Server
  • Desktop web servers
  • Pro
  • HTTP and HTML are mature designs.
  • Can use web skills and tools.
  • With home and UI uncoupled, you have remote
    access to the app.
  • Lower fixed costs to pay for centralized servers.

32
Implementation Desktop Web Server
  • Desktop web servers
  • Con
  • You have to make a web server look and feel like
    a GUI application.
  • Immature technology you have to roll your own.
  • Security how to avoid opening up the users
    machine to crackers?
  • You still have to put up with web problems like
    browser incompatibility and statelessness.
  • OS may not be well adapted
  • Scheduling problems
  • DNS lookup of localhost when offline
  • If everyone uses this approach then server
    sockets will be crowded.

33
Implementation Desktop Web Server
  • Java web servers
  • Sun Brazil
  • small and adaptable
  • Apache Jakarta-Tomcat
  • Reliable, large, Java 2
  • Apache Jserve
  • Reliable, large, Java 1
  • Roll your own
  • Best fit, time consuming, you know the code

34
Implementation Publishing
  • Like Freenet, MojoNation, FreeHaven
  • Allows for remote disk storage.
  • Splits data up across a number of different
    computers.
  • Heavy encryption and security demands.
  • Use Freenet for a Java base
  • See Uprizer for a commercial implementation and
    professional services.

35
Implementation Data Synchronization
  • Allows for synchronizing data across multiple
    devices.
  • For example, sharing your schedule across your
    laptop, PDA, PC and cell phone.
  • To avoid reinventing the wheel WRT version
    control, use CVS or WebDAV
  • Use Magi for an Java base

36
Implementation Infrastructure
  • Open source Java projects that you can work from

37
Summary
  • Use
  • Nodewise encapsulation
  • Rough grained transactions
  • Either LCDs or Adaptability
  • Java 2 for broadband users, Java users are dialup.
  • Take advantage of network effects
  • Use jujitsu

38
(No Transcript)
39
WorldOS Application Engine
  • The barebones skeleton of a peer node.
  • A data interchange
  • Plugin points for
  • Protocol handlers
  • Peer CGI (P-CGI) scripts

40
System Architecture

41
Protocol Morphing
  • A protocol agnostic stance for transport and
    message protocols. This allows developers to use
    any collection of protocol that best fits their
    needs, enabling Goa users access to take
    advantage of resources on other networks.
  • Hence, a Goa user searching for a file could
    simultaneously query Napster, MojoNation, and
    Lightshare via a single user interface.

42
Protocol Morphing
  • Protocol morphing leverages the externalities of
    multiple networks, creating a supernetwork for
    Goa users.

43
P-CGI Application Interface

44
Traditional Client/Server
  • Information and processing are distributed on
    the Internet, but much of the control
    applications is still greatly centralized.

45
P2P Peer Network
  • Peer technology blurs the distinguishing line
    between clients and servers, creating a network
    of peers, such that each node can behave as both
    client and server.

46
Peer to Peer (P2P)
  • P2P networks allow computers to act as both
    client and server.
  • Each computer connected to the network provides
    resources to the system as a whole.
  • P2P is particularly useful for scalability and
    redundancy. Use of P2P to reduce single points
    of failure and controller bottlenecks is likely
    to be effective.
  • Data centers and Akamai-type mirrors are natural
    candidates for P2P.

47
The Status Quo Job Search
  • Client-Server Technology
  • A job seeker has to log onto multiple job sites,
    post resumes and search for jobs.
  • An employer must go through the same steps,
    seeking out relevant resumes and posting jobs.

48
The Status Quo Job Search
49
The Ideal Job Search
  • The Ideal Peer-Peer Technology
  • A single request can be sent from a peer to its
    neighbors, being forwarded via viral
    distribution along to others. Hence, the
    success rate for a prospective employer or
    employee has a very high probability of success
    with minimal effort.

50
The Ideal Job Search
51
The Real Job Search
  • Leveraging The Strengths Of Each System
  • This network is interoperable with currently
    installed systems and utilizes the resources of
    the central job sites, treating each one as a
    peer.
  • The increased traffic to the job sites provides
    new revenue opportunities for these companies.

52
The Real Job Search
Write a Comment
User Comments (0)
About PowerShow.com
