Multithreading patterns

1
Multithreading patterns
Cristian Nicola Development Manager Net
Evidence (SLM) Ltd http//www.tonicola.com
cn_at_net-evidence.com
2
1. Introduction to multithreading 2.
Multithreading patterns
3
1. Introduction to multithreading
4
In this section

• Why do multi-threading?
• When and when not to use threads?
• Multithreading basic structures (Critical
  sections, Mutexes, Events, Semaphores and Timers)
• Multithreading problems (atomic operations, race
  conditions, priority inversion, deadlocks,
  livelocks, boxcar / lock convoys / thundering
  herd)

5
Why multi-threading?

• Multi-core / multi-CPU machines are now standard
• Makes programming more fun

6
When to use threads?

• Clearly defined work-tasks, and the work-tasks
  are long enough
• Data needed to complete the work tasks does not
  overlap (or maybe just a little)
• Generally UI interaction is not needed
  background tasks

7
When NOT to use threads?

• Work-tasks are not clearly defined
• There is a lot of shared data between the tasks
• UI interaction is a requirement
• Work-tasks are small
• You do not have a good reason to use it

8
Multithreading structures
9
Jobs, processes, threads, fibers
Job 1
Process 1
Process N
Thread 1
Thread 2


Thread M

Fiber 1
Fiber 2
Fiber X
10
What we needa way to

• avoid simultaneous access to a common resource
  (mutexes, critical sections)
• signal an occurrence or an action (events)
• restrict/throttle the access to some shared
  resources (semaphores)
• signal a due time sometimes periodically
  (timers)

11
Critical sections

• User object - lightweight
• Their number is limited by memory
• Re-entrant
• Very fast when no collisions (10s of
  instructions)
• Downgrades to a kernel object when locked
• No time-out

12
Mutexes

• Kernel object
• Can be named for inter-process communication
• Can have security flags
• Can be inherited by child processes
• Can be acquired/released

13
Events

• Kernel object
• Can be named for inter-process communication
• Can have security flags
• Can be inherited by child processes
• Holds a state signalled, non-signalled
• Can be auto-reset - PulseEvent (should not be
  used)
• Auto-reset events are NOT re-entrant

14
Semaphores

• Kernel object
• Can be named for inter-process communication
• Can have security flags
• Can be inherited by child processes
• Have a count property, but it cannot be
  interrogated
• Signalled when count gt 0

15
Timers

• Kernel object
• Can be named for inter-process communication
• Can have security flags
• Can be inherited by child processes
• Can be auto-reset

16
Kernel-land / User-land

• Kernel transition expensive
• User transition fast
• Should avoid kernel transitions when possible
  (system calls, usage of kernel objects, un-needed
  thread creation or destruction)

17
Multithreading problems
18
Atomic operations

• A set of operations that must be executed as a
  whole, so they appear to the rest of the system
  to be a single operation
• There can be 2 outcomes
• - success
• - failure

19
Atomic operations

• For example the code
• I J 1
• Can be compiled as
• MOV EAX, EBP-10
• INC EAX
• MOV EBP-0C, EAX

Solution Lock I J 1 Unlock
Possible task switch
Possible task switch
20
Race conditions

• A task switch can occur any time

21
Race conditions

• When 2 threads race to change the data
• Problem
• Unpredictable result

22
Race conditions
Example 2 threads incrementing a variable by
1 If we start from 1 then the expected result
would be 3
Input A 1
Thread 1 Read A1 into register Increment
register Write register 2 into A in
memory
Thread 2 Read A1 into register Increment
register Write register 2 into A in memory
Output A 2
23
Priority inversion

• A thread with a higher priority waits for a
  resource used by a thread with a lower priority
• Problem
• A high priority thread is executed less often
  than a lower priority thread

24
Priority inversion
Example 2 threads accessing the same file
Thread 1 (low priority) Lock a file for usage
writing some data into it Do some more work
with the file Release the file
Thread 2 (high priority) Wait for the file to
be available Use the file
Out of 3 switches Low priority 2 High priority 1
25
Deadlock

• 2 or more actions depend on each other for
  completion, and as a result none finishes
• Problem
• One or more threads stop working for indefinite
  amounts of time

26
Deadlock conditions

• 1. Mutual exclusion locking of resources
• 2. Resources are locked while others are waited
  for
• 3. Pre-emption while holding resources is
  permitted
• 4. A circular wait condition exists

27
Deadlock
Example 2 threads accessing the same resources

• Thread 1
• Lock resource A
• Wait for resource B to
• be available

Thread 2 Lock resource B Wait for
resource A to be available
Both threads are now stopped, no way to wake up
28
Livelock

• Same as deadlock, except the detection/prevention
  of deadlocks would wake up the threads, without
  progressing
• Problem
• One or more threads do not progress, they do
  spin
• 2 people travelling in opposite directions, each
  other is polite and moves aside to make space
  none of them can pass as the move from side to
  side

29
Boxcar / Lock Convoys / Thundering herd

• Can have a serious performance penalty
• The application would work fine
• A certain flag wakes up many threads, however
  only the first one has work to do
• Problem
• Threads wake up, wait on a resource and then
  there is no work to do

30
Boxcar / Lock Convoys / Thundering herd
Example 2 threads wake up to use the same
resource
Thread 1 Sleep waiting for event Lock
data Use data Unlock data Go back to
sleep
Thread 2 Sleep waiting for event Wait for
the data lock to be available Lock data
Nothing to do Unlock data Go back to sleep
Flag is signalled
31
2. Multithreading patterns
32
In this section

• What is a design pattern?
• Groups of patterns (control-flow patterns, data
  patterns, resource patterns, exception/error
  patterns)
• Multithreading patterns sources

33
What is a design pattern?

• A design pattern is a reusable solution to a
  recurring problem in the context of object
  oriented development
• Patterns can be about other topics

34
Groups of patterns

• Control-flow aspects related to control and flow
  dependencies between various threads (e.g.
  parallelism, choice, synchronization)
• Data perspective passing of information ,
  scoping of variables, etc
• Resource perspective resource to thread
  allocation, delegation, etc.
• Exception handling various causes of exceptions
  and the various actions that need to be taken as
  a result of exceptions occurring

35
Control-flow patterns
36
Worker threads

• Sometimes referred as Active Object, Cyclic
  Executive or Concurrency Pattern
• Generic threads doing some work without being
  aware of what kind of work they do
• They share a common work queue
• Very useful in highly parallel systems

37
Worker threads

• Windows Vista/Server has API support for creating
  thread pools (CreateThreadpool)
• Use a semaphore to limit the number of active
  threads to a number compared to the CPUs count
  (usually 2 x CPU)

38
Worker threads - variants

• Background Worker Patternnotifications when the
  thread completes, but provides an update on the
  status of the operation
• May need a cancel of the operation
• Asynchronous Results Patternyou are more
  interested in the result than the actual status
  of the operations

39
Worker threads - Termination

• Implicit Termination
• the worker has finished its work and can end
• Explicit Termination
• the worker is asked to terminate

40
Scheduler

• Explicitly control when threads may execute
  single-threaded code (sequences waiting threads)
• Independent mechanism to implement a scheduling
  policy
• Read/Write lock is usually implemented using the
  scheduler pattern to ensure fairness in
  scheduling
• Adds significant overhead

41
Thread pool

• A number of threads are created to perform a
  number of tasks, usually organized in a queue
• There are many more tasks than threads
• When thread completes its task
• If more tasks -gt request the next task from the
  queue
• If no more tasks -gt it terminates, or sleeps
• Number of threads used is a parameter that can be
  tuned - can be dynamic based on the number of
  waiting tasks

42
Thread pool

• The creating or destroying algorithm impacts
  overall performance
• Create too many threads resources and time are
  wasted
• Destroy too many threads time spent re-creating
• Creating threads too slowly poor client
  performance
• Destroying threads too slowly starvation of
  resources
• Negates thread creation and destruction overhead
• Better performance and better system stability

43
Thread pool - triggers

• Transient Trigger
• Offers the capability to signal currently running
  threads
• They are lost if not acted upon right away
• Persistent Trigger
• Generally it would result in the pool actions
• They would be persisted and would eventually be
  handled

44
Message Queuing

• Asynchronous communications, implemented via
  queued messages
• Simple, without mutual exclusion problems
• No resource is shared by reference
• The shared information is passed by value

45
Interrupt

• Occurs when the event of interest occurs
• Executes very quickly and with little overhead
• Provide a means for timely response to urgent
  needs
• There are circumstances when their use can lead
  to system failure
• Asynchronous procedure calls (APC)

46
Guarded Call

• Used when it may not be possible to wait for an
  asynchronous rendezvous
• The call of the method of the appropriate object
  in the other thread can lead to mutual exclusion
  problems if the called object is currently active
  doing something else
• The Guarded Call Pattern handles this case
  through the use of a mutual exclusion semaphore

47
Rendezvous

• Concerned with modelling the preconditions for
  synchronization or rendezvous of threads
• ready threads registers with the Rendezvous class

• then blocks until the Rendezvous class releases
  it to run
• Build a collaboration structure that allows any
  arbitrary set of preconditions to be met for
  thread synchronization,
• Independent of task phrasings, scheduling
  policies, and priorities

48
Data patterns
49
Thread-Specific Storage

• Also called thread-local storage
• Any function in that thread will get the same
  value, TLS is allocated per thread
• Similar to global storage - unlike global
  storage, functions in another thread will not get
  the same value
• Thread specific storage sometimes refers to the
  private virtual address space of a running task

50
Static Allocation

• Dynamic memory problems
• nondeterministic timing of memory allocation and
  de-allocation
• memory fragmentation
• Simple approach to solving both these problems
  disallow dynamic memory allocation
• Only used simple systems with highly predictable
  and consistent loads
• All objects are allocated during system
  initialization (the system takes longer to
  initialize, but it operates well during execution)

51
Pool Allocation

• Involves creating of pools of objects at start-up
• Doesn't address needs for dynamic memory
• The pools are not necessarily initialized at
  start-up
• The pools are available upon request

52
Fixed Sized Buffer

• Memory fragmentation occurs when
• The order of allocation is independent of the
  release order
• Memory is allocated in various sizes from the
  heap
• Used when we cannot tolerate dynamic allocation
  problems like fragmentation
• Fragmentation-free dynamic memory allocation at
  the cost of loss of memory usage optimality
• Similar to a dynamic allocation but only allows
  fixed pre-defined sizes to be allocated

53
Garbage Collection

• Solves memory leaks and dangling pointers
• It does not address memory fragmentation
• Takes the programmer out of the loop
• Adds run-time overhead
• Adds a loss of execution predictability

54
Garbage Compactor

• Removes memory fragmentation
• Maintains two memory segments in the heap
• Moves live objects from one segment to the next
• The free memory in on of the segments is a
  contiguous block

55
Resource patterns
56
Locked structures

• Structures that use a locking mechanism
• Easy to implement, easy to debug
• Can deadlock
• Do not scale well

57
Lock-free structures

• They do not need to lock
• They need hardware support (e.g. compare-and-swap
  instructions)
• They can burn CPU
• Hard to implement and debug

58
Wait-free structures

• Same as lock free structures, but there is a
  guarantee they would finish in a certain number
  of steps
• All wait-free structures are lock-free
• Very difficult to implement
• Very few real life applications

59
Single writer / multi reader

• Special kind of lock that would allow multiple
  read access to the data but only a single write
  (exclusive write access)
• Problems on promoting from read to write (reader
  starvation, writers starvation) Scheduler
  pattern

60
Double-checked locking

• Also known as "Double-Checked Locking
  Optimization"
• Reduces the overhead of acquiring a lock
• Used for implementing "lazy initialization" in a
  multi-threaded environment
• If check failed then
• Lock
• If check failed then
• Initialize
• Unlock

61
Shared Memory

• Common memory area addressable by multiple
  processors
• Almost always involves a combined
  hardware/software solution
• If the data to be shared is read-only then
  concurrency protection mechanisms may not be
  required
• Used when responses to messages and events are
  not desired or too slow

62
Simultaneous Locking

• Deadlocks avoidance
• Works in an all-or-none fashion
• Prevents the condition of holding some resources
  while requesting others
• Allows higher-priority tasks to run if they don't
  need any of the locked resources

63
Ordered Locking

• Eliminates deadlocks
• Orders resources and enforcing an ordered policy
  in which resources must be allocated
• If enforced then no circular waiting condition
  can ever occur
• Explicitly lock and release the resources
• Has the potential for neglecting to unlock the
  resource exists

64
Exception/error patterns
65
Exceptions/errors

• Work failure
• Deadline expiry
• Resource unavailability
• External trigger
• Constraint violation

• Handling
• Continue
• Remove work item
• Remove all items
• Recovery
• no action
• rollback
• compensate

66
Balking

• Executes an action on an object when the object
  is in a particular state
• An attempt to use the object out of its legal
  state would result in an "Illegal State Exception"

67
Triple Modular Redundancy

• Used when there is no fail-safe state
• Based on an odd number of channels operating in
  parallel
• The computational results or resulting actuation
  signals are compared, and if there is a
  disagreement, then a two-out-of-three majority
  wins
• Any deviating computation of the third channel is
  discarded

68
Watchdog

• Lightweight and inexpensive
• Minimal coverage
• Watches out over processing of another component
• Usually checks a computation time base
• or ensures that computation steps are
  proceeding in a predefined order

69
Multithreading patterns sources

• http//www.workflowpatterns.com
• Real-Time Design Patterns Robust Scalable
  Architecture for Real-Time Systems by Bruce
  Powel Douglass

70
Questions ?
71
Big thank you!
