Neural Control and the Senses

1
Neural Control and the Senses

• Chapter 30

2
Neurons

• Basic units of communication in nearly all
  nervous systems
• Monitor information in and around the body and
  issue commands for responsive actions

3
In Pursuit of Ecstasy

• MDMA is amphetamine-like drug
• Interferes with removal of chemical messenger
  (serotonin) used by nervous system
• Memory loss and depression are common side
  effects
• In rare cases it causes seizures, hypothermia,
  and even death

4
Neurons

• Communication units of the nervous system
• Sensory neurons
• Interneurons
• Motor neurons

5
Neuroglia

• Make up more than half the volume of the
  vertebrate nervous system
• A variety of cells that metabolically assist,
  structurally support, and protect the neurons

6
Structure of a Neuron
dendrites
INPUT ZONE
cell body
axon
OUPUT ZONE
TRIGGER ZONE
CONDUCTING ZONE
axon endings
7
How Ions Move across Membrane
interstitial fluid
cytoplasm
Na/K pump
passive transporters with open channels
passive transporters with voltage-sensitive gated
channels
active transporters
lipid bilayer of neuron membrane
8
Ion Concentrations in a Resting Neuron

• Potassium (K)
• Higher inside than outside
• Sodium (Na)
• Higher outside than inside

9
Action Potential

• A brief reversal in membrane potential
• Voltage change causes voltage-gated channels in
  the membrane to open
• Inside of neuron briefly becomes more positive
  than outside

10
Action Potential
Na
1
2
Na
Na
K
K
K
K
K
K
K
Na
Na
Na
Na
3
4
Na
Na
11
Positive Feedback
more Na ions flow into the neuron
neuron becomes more positive inside
more gated channels for Na open
12
All or Nothing

• All action potentials are the same size
• If stimulation is below threshold level, no
  action potential occurs
• If it is above threshold level, cell is always
  depolarized to the same level

13
Repolarization

• Once action potential peak is reached, Na gates
  close and K gates open
• Movement of K out of cell
• The inside of the cell once again becomes more
  negative than the outside

14
Recording of Action Potential
action potential
20
0
-20
Membrane potential (millivolts)
threshold
-40
resting membrane potential
-70
0
2
3
5
1
4
Time (milliseconds)
15
Propagation of Action Potentials

• An action potential in one part of an axon brings
  a neighboring region to threshold
• Action potential occurs in one patch of membrane
  after another

16
Chemical Synapse
plasma membrane of axon ending of presynaptic cell

• Gap between the terminal ending of an axon and
  the input zone of another cell

plasma membrane of postsynaptic cell
synaptic vesicle
synaptic cleft
membrane receptor
17
Synaptic Transmission

• Action potential in axon ending of presynaptic
  cell causes voltage-gated calcium channels to
  open
• Flow of calcium into presynaptic cell causes
  release of neurotransmitter into synaptic cleft

18
Synaptic Transmission

• Neurotransmitter diffuses across cleft and binds
  to receptors on membrane of postsynaptic cell
• Binding of neurotransmitter to receptors opens
  ion channels in the membrane of postsynaptic cell

19
Ion Gates Open
neurotransmitter
ions
receptor for neurotransmitter
gated channel protein
20
Synaptic Integration

• Many signals reach a neuron at the same time
• Signals may suppress or reinforce one another
• Whether or not an action potential occurs depends
  on the sum of the signals the neuron is receiving

21
Cleaning Up

• Presence of neurotransmitter in synaptic cleft is
  normally brief
• Molecules diffuse away, are reabsorbed, or broken
  down
• Drugs, such as ecstasy and cocaine, interfere
  with the reuptake of neurotransmitters

22
Information Flow
23
Nerve
axon
myelin sheath

• A bundle of axons enclosed within a connective
  tissue sheath

many neurons inside a connective tissue sheath
24
Myelin Sheath

• Sheath blocks ion movements
• Action potential must jump from node to node
• Greatly enhances speed of transmission

25
Multiple Sclerosis

• A condition in which nerve fibers lose their
  myelin
• Slows conduction
• Symptoms include visual problems, numbness,
  muscle weakness, and fatigue

26
Reflexes

• Automatic movements made in response to stimuli
• In the simplest reflex arcs, sensory neurons
  synapse directly on motor neurons
• Most reflexes involve an interneuron

27
Stretch Reflex
STIMULUS Biceps stretches.
sensory neuron
motor neuron
RESPONSE Biceps contracts.
28
Drugs and Addiction

• A drug is a substance introduced into the body to
  provoke a specific physiological response
• In addiction, a drug assumes an essential
  biochemical role in the body

29
Types of Drugs

• Stimulants
• Depressants, hypnotics
• Analgesics
• Psychedelics, hallucinogens

30
Sensory Receptors

• Convert the energy of a stimulus into action
  potentials

Mechanoreceptors Thermoreceptors Pain
receptors
Chemoreceptors Osmoreceptors Photoreceptors
31
Assessing a Stimulus

• Action potentials dont vary in amplitude
• Brain tells nature of stimulus by
• Particular pathway that carries the signal
• Frequency of action potentials along an axon
• Number of axons recruited

32
Somatic Sensations

• Touch
• Pressure
• Temperature
• Pain
• Motion
• Position

33
Receptors in Skin

• Free nerve ending
• Ruffini ending
• Pacinian corpuscle
• Bulb of Krause
• Meissners corpuscle

34
Smell

• A special sense
• Olfactory receptors
• Receptor axons lead to olfactory lobe

olfactory bulb
receptor cell
35
Taste

• A special sense
• Chemoreceptors
• Five primary sensations
• sweet, sour, salty, bitter, and umami

36
Balance and Equilibrium

• Organs of equilibrium are located in the inner ear

semicircular canals
utricle
saccule
vestibular apparatus
37
Properties of Sound

• Ear detects pressure waves
• Amplitude of waves corresponds to perceived
  loudness
• Frequency of waves (number per second)
  corresponds to perceived pitch

38
Anatomy of Human Ear
stirrup
auditory nerve
anvil
hammer
auditory canal
eardrum
cochlea
39
Sound Reception

• Sound waves make the eardrum vibrate
• Vibrations are transmitted to the bones of the
  middle ear
• The stirrup transmits force to the oval window of
  the fluid-filled cochlea

40
Sound Reception

• Movement of oval window causes waves in the fluid
  inside cochlear ducts

oval window (behind stirrup)
scala vestibuli
eardrum
round window
scala tympani
41
Sound Reception
hair cells in organ of Corti
lumen of cochlear duct
tectorial membrane
basilar membrane
to auditory nerve
lumen of scala tympani
42
Vision

• Sensitivity to light does not equal vision
• Vision requires two components
• Eyes
• Capacity for image formation in the brain

43
Human Eye
sclera
retina
choroid
iris
fovea
optic disk
lens
pupil
cornea
part of optic nerve
aqueous humor
ciliary muscle
vitreous body
44
Pattern of Stimulation

• Light rays pass through lens and converge on
  retina at back of eye
• The image that forms on the retina is upside down
  and reversed right to left compared with the
  stimulus
• Brain accounts for this during processing
