Title: Approximation Algorithms


1
Approximation Algorithms
  • Analysis of Algorithms CS 515
  • Ashish Kapoor

2
Motivation Getting around NP-completeness
  • Exponential time may be acceptable for small
    inputs Brute Force
  • Isolate special cases that can run in polynomial
    time Divide-and-Conquer
  • Near-optimal solutions may be acceptable
    Approximation Algorithms

3
Performance Ratios
  • C is the cost of the optimal solution
  • C is the cost of the solution produced by an
    approximation algorithm
  • An algorithm has an approximation ratio of ?(n)
    if for an input of size n, C is within a factor
    of C

4
Performance Ratios cont.
  • Maximization problem
  • 0 lt C lt C
  • C / C factor by which the cost of the optimal
    solution is larger than the cost of the
    approximate solution
  • Minimization problem
  • 0 lt C lt C
  • C / C factor by which the cost of the
    approximate solution is larger than the cost of
    the optimal solution

5
How do approximations algorithms work?
  • Exploit the nature of the problem
  • Use greedy techniques
  • Use linear programming
  • Use dynamic programming
  • Use random assignments

6
Speaking of random stuff
  • random_sort (int array )
  • boolean done false
  • while (!done)
  • work_array copy_array(array)
  • randomize_array(work_array)
  • done is_sorted(work_array)
  • return work_array
  • I really tried to resist but hey, you had to know
    this was coming.

7
The vertex-cover problem
  • A vertex cover of an undirected graph G(V,E) is
    a subset V of V such that if (u,v) is an edge of
    G, then either u belongs in V or v belongs in V
    (or both)
  • The size of a vertex cover is the number of
    vertices in it

8
The vertex-cover problem cont.
  • The vertex-cover problem is to find a vertex
    cover of minimum size
  • Such a vertex-cover is called an optimal vertex
    cover
  • This problem is NP-complete

9
Consider the graph
b
c
d
a
e
f
g
By inspection, optimal vertex cover is
b,d,e C size of optimal solution 3
10
Approx-Vertex-Cover (G)
  • C ? NULL
  • E ? EG
  • while E ! NULL
  • do let (u,v) be an edge of E
  • C ? C U u,v
  • remove from E all edges incident on u
    or v
  • return C

11
Back to our graph
b
c
d
a
e
f
g
C
a b
c d
e f
Approximate vertex cover. C6
E
(a,b)
(b,c)
(c,d)
(c,e)
(d,e)
(d,f)
(d,g)
(e,f)
12
Improved version
b
c
d
a
e
f
g
C
d e b c
Approximate vertex cover. C4
E
(a,b)
(b,c)
(c,d)
(c,e)
(d,e)
(d,f)
(d,g)
(e,f)
13
Is it possible to approximate the optimal
solution?
b
c
d
a
e
f
g
In this case, and with our algorithm, NO!
14
Analysis of Algorithm
  • Running time O(VE)
  • 2-Approximation Algorithm
  • Minimization problem C 3 C 6
  • Factor C/C 2

15
2-Approximation Algorithm
  • A set of edges picked by approximation
    algorithm
  • No 2 edges in A share an endpoint. Thus no 2
    edges in A are covered by the same vertex in C
  • Lower bound C gt A
  • We pick an edge for which neither of its
    endpoints are already in C
  • Upper bound C 2A
  • Therefore C 2A lt C

16
  • Any questions Connie?

17
The traveling-salesperson problem.
  • Given a complete undirected graph G(V,E)
  • Each edge has a nonnegative integer cost c(u,v)
  • Find a Hamiltonian cycle of G with minimum cost.
  • This is a NP complete problem

18
TSP side note
  • Performance of exact methods to solve the problem
  • Graph Year versus the size of problem solved to
    optimality

19
TSP side note cont.
  • Largest problem solved to optimality till circa
    2002 has 16,862 cities
  • Using heuristics, a problem with 1,904,711 cities
    was solved to 1 of optimality

20
TSP side note cont. Optimal solution to…
21
TSP side note cont. Heuristic solution to…
22
Metric TSP approximation
  • The cost function satisfies the triangle
    inequality for all vertices u, v, w in V
  • c(u,w) lt c(u,v) c(v,w)
  • Eulerian graphs and Eulerian circuits
  • Eulerian circuit cycle that uses each edge
    exactly once
  • Eulerian graph graph with a Eulerian circuit
  • An undirected graph is Eulerian iff each vertex
    has even degree.

23
Approximate-TSP-tour (G)
  • Find MST T of G
  • Double every edge of the MST to get a Eulerian
    graph G
  • Find an Eulerian circuit E on G
  • Output the vertices of G in order of appearance
    in E

24
Analysis
  • This is a 2 approximation algorithm
  • Proof
  • cost(T) lt C (if we remove an edge from the
    optimal solution, we get a spanning tree)
  • cost(E) 2 cost(T)
  • C lt cost(E) (due to triangular inequality)
  • C lt cost(E) 2cost(T) lt 2 C

25
Can we improve this approximation
  • The previous algorithm was a factor 2 algorithm.
  • Recall line 2
  • Double every edge of the MST to get a Eulerian
    graph G
  • If we can work avoid this, we could possibly have
    a better solution !

26
Perfect Matching
  • Matching a matching is a subset M of E such that
    for all vertices v in V, at most one edge is
    incident on v.
  • Perfect Matching is a matching M such that for
    all vertices v in V exactly one edge of M is
    incident on v.

27
1.5 approximation algorithm
  • Find a MST T of G
  • Find a minimum cost perfect matching M on the set
    of odd degree vertices in T.
  • Add M to T to get the Eulerian graph G
  • Find an Eulerian circuit E on G
  • Output the vertices of G in order of appearance
    in E

28
Example
29
Analysis
  • cost(E) cost(T) cost(M) lt C C/2
  • C lt cost(E) lt 1.5 C

30
Randomized approximation algorithm for
MAX-3-CNF-SAT
  • Each clause has 3 distinct literals. Also assume
    that no clause contains a variable and its
    negation.
  • Problem Return an assignment of variables which
    maximizes the number of clauses which evaluate to
    true.

31
The random approximation algorithm
  • Now pay close attention because this algorithm is
    really complex! No really it is.
  • Are you ready to be amazed? Here it comes
  • Randomly assign a 0 or a 1 value to all variables.

32
Analysis
  • We have set each variable to 1 with a ½
    probability.
  • We have set each variable to 0 with a ½
    probability.
  • We define an indicator random variable
  • Yi I clause i is satisfied
  • Yi 1 as long as at least one of the literals in
    the ith clause has been set to 1.
  • A clause is not satisfied iff all its literals
    are 0.
  • Pr clause i is not satisfied (½)3 1/8

33
Analysis cont.
  • So Pr clause i is satisfied 1 1/8 7/8
  • Lemma 5.1 (CLRS)
  • Given a sample space S and an event A in the
    sample space, let XA IA. Then EXA PrA
  • EYi 7/8

34
Analysis cont.
  • Let Y number of satisfied clauses.
  • Y Y1Y2…..….. Ym
  • So EY
  • Esum i to m of Yi
  • sum i to m of EYi by linearity of expectation
  • 7m/8
  • Since m is the upper bound on the number of
    satisfied clauses, the approximation ratio is
    m/(7m/8) 8/7
  • Therefore this is a 8/7 approximation algorithm
  • gotta love these proofs by randomificationality

35
Approximate weighted vertex cover using linear
programming
  • CLRS says
  • We shall, however, compute a lower bound on the
    weight of the minimum-weight vertex cover, by
    using a linear program. We will then round this
    solution and use it to obtain a vertex cover. (my
    italics and underline)

36
The equations
  • Associate a variable x(v) with each vertex v in
    V. x(v) is in 0,1
  • Linear programming system
  • Minimize sum of w(v).x(v) for all v in V
  • x(u) x(v) gt 1 for each u,v in E
  • x(v) belongs in 0,1 for each v in V

NP-hard
37
So we change the equations…
  • Minimize sum of w(v).x(v) for all v in V
  • x(u) x(v) gt 1 for each u,v in E
  • x(v) lt 1 for each v in V
  • x(v) gt 0 for each v in V

38
Analysis
  • The algorithm used to compute the minimal weight
    vertex cover using this system of linear
    equations is a 2-approximate algorithm.
  • Proof is left as an exercise.

39
References
  • Chaper 35, Introduction to Algorithms, Cormen et.
    al.
  • University of Copenhagen, Stefan Røpke, lecture
    notes
  • http//www.diku.dk/undervisning/2003e/404/
