A calculation model for the collinear holographic systems

1
A calculation model for the collinear holographic
systems

• Tsutomu SHIMURA, Shotaro ICHIMURA,
• Ryushi FUJIMURA, and Kazuo KURODA
• IIS, the University of Tokyo
• Xiaodi TAN and Hideyoshi HORIMAI
• OPTWARE Corp

2
Collinear Holographic System

• Common objective lens for signal and reference
  beams.
• simple system
• stable
• servo system for conventional optical discs
• Good performance in experiments
• low bit error rate
• high shift selectivity
• large tolerance

3
But...

• Theoretical background
• has not been made fully clear yet.
• Especially, why radial, wheel like illumination
  pattern gives good experimental results?
• We present a simple model which gives,
• physical picture of the image formation,
• calculation of pixel spread function,
• a tool to consider the recording density.

4
Our Model
Spatial Light Modulator
pixel square aperture
reference pixels
data pixels
f
objective lens
Frounhofer regime
signal
f
reference
recording medium
grating ? coupled mode theory
5
Key of our model

• We consider the collinear holographic system can
  as summation of interference of two plane waves.

6
Phase mismatch

• Deviation from the Eward sphere
• Existing gratings Kijkl
• all combinations of (i,j), (k,l)
• Diffraction efficiency h, read by (m,n)
• In most cases
• h 0 for (m,n)?(k,l)
• Exception
• Bragg degeneracy

7
Diffracted light from one grating Kijkl
illuminated by all reference pixels
calculation 201?201 pixels
just for ONE data pixel
8
Integrate all diffracted waves over all gratings

• coherent summation of all diffracted waves to the
  data pixel (i,j) (example)

9
Pixel spread function (PxSF)

• has same function as Point Spread Function (PSF)
  in linear imaging system.
• As long as the response of the recording media is
  linear,
• The reconstructed image of the system can be
  calculated by convolution of the PxSF and the
  object.
• Note that PxSF for holographic memory is complex
  function.

10
E2 for ring and radial reference pattern
thickness 500 mm
11
Ring illumination pattern
Bragg degeneracy
Bragg selectivity
Integration of the diffracted line pattern over
all gratings
12
Radial 3 degrees
Integration of the diffracted line pattern over
all gratings
13
radial 6 degrees
Integration of the diffracted line pattern over
all gratings
14
Thickness
thickness 0.1 mm ? 0.2 mm ? 1.0 mm
15
Summary

• Simple model for understanding the image
  formation in Collinear holographic system
• Spread of single point image is determined by
• illumination pattern
• to avoid the effect of Bragg degeneracy
• media thickness
• due to Bragg selectivity
• Recording density
• Media thickness -gt pixel size
• Shift selectivity -gt NA of objective lens
