Runtime Safety Analysis of Concurrent and Distributed Systems

1
Runtime Safety Analysis of Concurrent and
Distributed Systems

• Koushik Sen
• University of Illinois at
• Urbana-Champaign, USA

Joint work with Gul Agha, Grigore Rosu and Abhay
Vardhan.
2
Increasing Software Reliability

• Current solutions
• Human review of code and testing
• Most used in practice
• Usually ad-hoc, intensive human support
• (Advanced) Static analysis
• Often scales up
• False positives and negatives, annotations
• (Traditional) Formal methods
• Model checking and theorem proving
• General, good confidence, do not always scale up

3
Runtime Verification

• Merge testing and temporal logic specification
• Specify safety properties in proper temporal
  logic.
• Monitor safety properties against a run of the
  program.
• Examples JPaX (NASA Ames), Upenn's Java MaC
  analyzes the observed run.
• Disadvantage
• Lack of coverage.
• Not suitable for Distributed Systems.

Run
Naïve Observer
4
Our Approach

• For Distributed Programs
• Use Distributed Temporal Logic.
• Use KnowledgeVector
• Decentralize Monitoring by distributing monitors
  to all processes.
• For MultiThreaded Programs
• Use smart observers to predict safety violations
• Vector Clock Algorithm for MultiThreaded Programs
• Construct Computation Lattice
• Analyze Lattice level by level
• Use Causality Cone Heuristics to increase
  efficiency

5
Decentralized Distributed Program Monitoring
(DIANA)
http//osl.cs.uiuc.edu/
6
Centralized Monitoring Approach

• Distributed Systems
• Global state is distributed
• To Monitor
• For every state update send state to a central
  monitor
• Central monitor assembles them to form consistent
  execution traces
• Verify global safety property on these execution
  traces

7
An Example

• Mobile node a requests certain value from node b
• b computes the value and sends it to a
• Property no node receives a value from another
  node to which it had not sent a request

8
Centralized Monitoring Example
If a receives a value from b then b calculated
the value after receiving request from a
For large number of nodes size of property in LTL
may be large
Message is sent to monitor for every state update
valRcv ? ?(valComputed ? ?valReq)
valRcv ? ?(valComputed ? ?valReq)
valReq
?valReq
valComputed ? ?valReq
?(valComputed ? ?valReq)
b
valComputed
a
valReq
valRcv
9
Decentralized Approach

• Distribute property
• Properties expressed with respect to a process
• Local properties at every process
• Decentralize Monitoring
• Maintain knowledge of global state at each
  process
• Update knowledge with incoming messages
• Attach knowledge with outgoing messages
• At each process check safety property against
  local knowledge

10
Decentralized Monitoring Example
If a receives a value from b then b calculated
the value after receiving request from a
valRcv ? _at_a(?(valComputed ? _at_b(?valReq)))
valComputed ? _at_b(?valReq)
?(valComputed ? _at_b(?valReq))
_at_b(?valReq)
Formulas w.r.t processes
No extra message
b
No Need for Global Snapshot
valComputed
a
valReq
valRcv
?valReq
valRcv ? _at_a(?(valComputed ? _at_b(?valReq)))
11
Past time Distributed Temporal Logic (pt-DTL)

• Based on epistemic logic
• Properties with respect to a process, say p
• Interpreted over a sequence of global states that
  the process p is aware of
• Each process monitors the properties local to it
• No need for extra messages to create a relevant
  portion of global state
• KnowledgeVector keeps track of relevant global
  state that can effect a property.

12
Remote Expressions in pt-DTL

• Remote expressions arbitrary expressions
  related to the state of a remote process
• Propositions constructed from remote and local
  expressions
• If my alarm is set then eventually in past
  difference between my temperature and temperature
  at process b exceeded the allowed value
• alarm ? ?((myTemp - _at_btemp) gt allowed)

13
Safety in Airplane Landing

• If my airplane is landing then the runway that
  the airport has allocated matches the one that I
  am planning to use
• landing ? (runway _at_airportallocRunway)

14
Leader Election Example

• If a leader is elected then if the current
  process is a leader then, at its knowledge, none
  of the other processes is a leader
• elected ? (stateleader ? /\i?j(_at_j(state ?
  leader)))

15
pt-DTL syntax and semantics

• Fi true false P(Ei) Fi Fi Æ Fi
  propositional
• Fi Fi ?Fi Fi S Fi temporal
• _at_jFj epistemic
• Ei c vi 2 Vi f(Ei) functional
• _at_jEj epistemic

• c constant
• vi variable at process I
• P(Ei) predicate on Ei
• f(Ei) function f applied to Ei
• _at_jEj expression Ej at process j

• Fi previously Fi
• Fi always in past Fi
• ?Fi eventually in past Fi
• Fi S Fi Fi since Fi
• _at_jFj Fj at process j

16
Interpretation of _at_jEj at process i
s31
s32
s33
p3
m4
m1
m2
s22
p2
s23
s21
m3
p1
s12
s11
Since, at s23 p2 is aware of s12 of p1 value of
_at_1E in s23 at p2 value of E in s12 at p1
17
Monitoring Algorithm

• Requirements
• Should be fast so that online monitoring is
  possible
• Little memory overhead
• Additional messages sent should be minimal
  ideally zero
• KnowledgeVector
• Motivated by Vector Clocks
• Unlike Vector Clocks size independent of number
  of processes

18
KnowledgeVector

• KV is vector
• one entry for each process appearing in formula
• KVj denotes entry for process j
• KVj.seq is the sequence number of last event
  seen at process j
• KVj.values stores values of j-expressions and
  j-formulae

19
KnowledgeVector Algorithm

• internal event (at process i)
• store eval(Ei,si) and eval(Fi,si) for each _at_iEi
  and _at_iFi in KVii.values
• send m
• KVii.seq à KVii.seq 1. Send KVi with m as
  KVm
• receive m
• for all j, if KVmj.seq gt KVij.seq then
• KVij.seq à KVmj.seq
• KVij.values à KVmj.value

20
Example
p3
p2
Y7
Y3
violation
p1
X5
X9
X6
KV1.seq
(Y _at_1X) at p2
KV1.values
21
DIANA Architecture
pt-DTL Monitor
22
MultiThreaded Program Analysis (JMPaX)
23
MultiThreaded Smart Observer

• Ideas
• A single execution trace contains more
  information than appears at first sight
• Extract other possible runs from a single
  execution
• Analyze all these runs intelligently.
• A technique between model checking and testing.

Run
Smart Observer
24
MultiPathExplorer JMPaX (Java)

• Based on smart observers
• Smartness obtained by proper instrumentation
  vector clocks
• Possible global states generated dynamically ?
  form a lattice
• Analysis is performed on a level-by-level basis
  in the lattice of global states

25
Motivating Example Safe Landing
Safe Landing Land the air/space craft only after
approval from ground and only if, since then, the
radio signal has not been lost

• Three variables
• Landing indicating air/space craft is landing
• Approved indicating landing has been approved
• Radio indicating radio signal is live

?Landing ? ?Approved, ?Radio?
26
Code of a Landing Controller

• Two threaded program to control landing

• int landing 0, approved 0, radio 1
• void thread1()
• askLandingApproval()
• if (approved 1)
• print("Landing approved") landing1
  print("Landing started")
• else print("Landing not approved")
• void askLandingApproval()
• if (radio 1) approved 1 else
  approved 0
• void thread2()
• while (true) checkRadio()

27
Landing Safety Violation

• Suppose the plane has received approval for
  landing and just before it started landing the
  radio signal went off
• the plane must abort landing!
• A simple observer will most likely not detect the
  bug.
• JMPaX can construct a possible run in which radio
  goes off between approval and landing

approved 1
landing 1
28
Events in Multithreaded Programs

• Given n threads p1, p2, ..., pn,
• A multithreaded execution is a sequence of events
  e1 e2 er of type
• internal or,
• read of a shared variable or,
• write of a shared variable.
• eij represents the jth event generated by thread
  pi since the start of its execution.

29
Causality in Multithreaded Programs

• Define the partial order Á on the set of events
  as follows
• eik Á eil if k lt l
• e Á e' if there is some x 2 S such that e ltx e'
  and at least one of e, e is a write.
• e Á e'' if e Á e' and e' Á e''.

30
Vector Clocks and Relevant Events

• Consider a subset R of relevant events.
• (typically those writing specifications
  variables)
• R-relevant causality is a relation C µ Á
• C is a projection of Á on R R.
• We provide a technique based on vector clocks
  that correctly implements the relevant causality
  relation.

31
Vector Clock Algorithm

• Let Vi be an n-dimensional vector of natural
  numbers for each thread pi.
• Let Vxa and Vxw be vectors for each shared
  variable x.
• if eik is relevant, i.e., if eik 2 R, then
• Vii à Vii 1
• if eik is a read of a variable x then
• Vi à maxVi,Vxw
• Vxa à maxVxa,Vi
• if eik is a write of a variable x then
• Vxw à Vxa à Vi à maxVxa,Vi
• if eik is relevant then
• send message h eik, i, Vi i to observer.

32
Correspondence with Standard Vector Clocks
33
Implementing Causality by Vector Clocks

• Theorem If he, i, Vi and he', j, V' i are
  messages sent by our algorithm, then
• e C e' iff Vi V'i
• If i and j are not given, then
• e C e' iff V lt V

34
Example with Two Threads

• thread T1
• x
• ...
• y x 1

• thread T2
• z x 1
• ...
• x

(initially x -1)
35
Relevant Global State

• The program state after the events
  ek11,ek22,...,eknn is called a relevant global
  multithreaded state or simply a state.
• A state ?k1 k2 kn is called consistent if and
  only if it can be seen in some possible run of
  the system.

36
MultiThreaded Run

• e1e2 eR is a multithreaded run iff it
  generates a sequence of global states ?K0 ?K1
  ?KR such that
• each ?Kr is consistent and
• ?Kr after event er becomes ?Kr1.
• (consecutive states)

37
Computation Lattice

• We say ? À ?' when there is some run in which ?
  and ?' are consecutive states
• Consistent global states together with the
  transitive closure of À form a lattice
• Multithreaded runs are paths in the lattice

38
Example Revisited

• thread T1
• x
• ...
• y x 1

• thread T2
• z x 1
• ...
• x

39
Monitoring Safety Formula
(x gt 0) ! (y 0), (y gt z))s
40
Safety Violation in a Possible Run
(x gt 0) ! (y 0), (y gt z))s
41
Past Time Linear Temporal Logic Syntax

• F true false a 2 A F F op F
  Propositional ops
• O F ltgt F F F Ss F F Sw F Standard
  ops
• " F F F,F)s F,F)w
  Monitoring ops

42
Semantics

• ? ² ltgt F iff ? ² F or (n gt 1 and ?n-1 ² ltgt F)
• ? ² F iff ? ² F and (n gt 1 implies ?n-1 ²
  F)
• ? ² F1 Ss F2 iff ? ² F2 or (n gt 1 and ? ² F1
  and ?n-1 ² F1 Ss F2)
• ? ² F1 Sw F2 iff ? ² F2 or (? ² F1 and (n gt 1
  and ?n-1 ² F1 Sw F2))
• ? ² F1,F2)s iff ? 2 F2 and (? ² F1 or (n gt 1
  and ?n-1 ² F1,F2)w))
• ? ² F1,F2)w iff ? 2 F2 and (? ² F1 or (n gt 1
  implies ?n-1 ² F1,F2)w))

43
Safety Against All Runs

• Number of possible runs can be exponential
• Traverse the state lattice level by level
• Avoids analyzing an exponential number of runs
• Maintain a queue of events
• Enqueue an event as soon as it arrives
• Construct a new level from the set of states in
  the previous level and the events in the queue
• Monitor safety formula against all states in a
  level using dynamic programming and intelligent
  merging.

44
Algorithm Pseudocode

• for each (e 2 Q)
• if exists s 2 CurrentLevel s.t. isNextState(s,e)
  then
• NextLevel à addToSet(NextLevel,createState(s,e))

• if isUnnecessary(s) then
• remove(s,CurrentLevel)
• if isEmpty(CurrentLevel) then
• monitorAll(NextLevel)
• CurrentLevel à NextLevel NextLevel Ã
• Q Ã removeUnnecessaryEvents(CurrentLevel,Q)

45
Complexity

• Time complexity is O(w.2m.n)
• w width of the lattice
• m size of the formula
• n length of the run
• Memory used is O(w.2m)
• w width of the lattice
• m number of temporal operators in the formula
• Further optimizations
• Consider bounded width w of queue Q

46
Computation Lattice Width

• The number of states in a level can be large
• Observe that all states are not equi-probable
• Ignore states in lattice that are formed by
  events that are largely separated by distance
• Distance can be measured
• In terms of real-time between the events
• Some notion of distance between Vector Clocks
• Euclidean Distance

47
Causality Cone Heuristics
48
JMPaX Architecture
49
Further Applications

• Security
• Security policies as safety requirements
• Predict safety violations efficiently!

?communicate(A,B,K) ? ? (sendKey(S,(A,B),K) ?
? requestKey(S,A,B))
50
Future Work

• Evaluate JMPaX and DiAna on real, large
  applications
• Investigate for programmer friendly and more
  expressive logics
• Extend EAGLE logic (NASA Ames)
• Add more epistemic operators
• Find techniques to increase coverage of analysis
• Use Machine Learning
• Apply Statistical Analysis
• Investigate efficient instrumentation techniques
