IDN: Technology, Status, Overview, and Directions

1
IDN Technology, Status, Overview, and Directions

• John C KLENSIN, Ph.D.
• APT Workshop on ENUM and IDN
• August 2003

2
Internationalized Domain Names (IDN)

• Term used in many ways
• Strictly, domain name labels that represent names
  containing non-host name characters.
• Only host name (or LDH) strings are actually
  entered into the DNS.
• Sometimes, IDN is used to refer to a
  fully-qualified domain name that contains at
  least one non-LDN label/
• Sometimes used to refer to other ways of
  internationalization or localization
• Keywords,
• Special searching or directory mechanisms, etc.

3
Internationalization and Users

• Users typically do not want internationalization
  (or multilingual capability) but
• Systems that are localized adapted to their
  particular
• Language
• Writing system and character codes
• Location
• Interests
• Internationalization is
• A means to localization
• Necessary given the global nature of the Internet

4
Internationalization and the Internet

• Consideration given to international characters
  in the 1970s
• Character set standards werent ready
• Project that led to MIME
• multimedia email capability
• initiated largely to standardize and permit
  non-ASCII characters
• Web
• Recognized requirement early
• Details only for Western European languages until
  mid-90s
• All were done by tagging
• Tagging is consistent with localization approaches

5
DNS Internationalization

• Tension between
• Network-facing identifier
• User-facing name (of a company, product,
  organization,)
• Constraints on solutions
• Short label strings no reasonable way to tag
• Uniqueness of names
• Potential for confusion or fraud
• Requirement for non-ASCII names is clear but
• Caution is in order many possible traps and
  risks
• Hard to go back if too permissive

6
Why Look at this Now

• Many opportunities for confusion
• Some national regulation may be in order.
• Some real technical constraints
• Assuming the DNS is like something else and
  proceeding on that basis can be problematic
• Good tutorial in forthcoming US National Academy
  of Engineering/ National Research Council report
• Much better to think through things now than to
  try to undo or redo later.
• Easier and safer to adopt narrow rules and then
  expand as understanding grows than to try to
  restrict what was previously permitted.
• Advice Permit only what you fully understand and
  need.

7
IETF Encoding Standards or Local Variations

• Utility and spread of the Internet has depended
  critically on
• End to end connectivity
• Internet hosts can reach each other or understand
  why not
• DNS integrity
• Any DNS reference means the same thing,
  worldwide
• There is huge flexibility within the existing
  standards for per-zone (local/national) policies
  and decisions.
• A country that adopts its own protocols or DNS
  string interpretations is likely to isolate its
  businesses and users from global connectivity and
  global markets.

8
The History of the LDH Name

• Concerns in the 1970s about user confusion and
  transcription from non-computer forms
• Eliminating, where possible, characters that
  could be confused when written
• Hence
• Case-insensitive
• Prohibition of _ could be confused with -
• Prohibition of national use character positions
• Resulted in host name rules letters, digits,
  and hyphen
• Host name rules are about
• What can be registered in a zone
• Applications restrictions
• Ultimately not the DNS technology, which can
  store binary strings with few restrictions.

9
Why Internationalize Domain Names

• Important concern about people using their own
  languages and characters
• Use of domain names in interfaces by end users,
  not just as system/network identifiers.

10
Representing Unicode/ ISO10646

• No tagging equals no national character sets
• Unlike applications (such as the web), no room in
  DNS for character set tagging, so a
  comprehensive, universal character set UCS--
  is a requirement
• More characters, mixing scripts
• Many opportunities for problems from look-alikes
  that were not present in ASCII alone
• Ambiguities about
• Scripts
• Case-matching
• Unification

11
Applications International Characters

• Most Internet application protocols defined for
  ASCII, or at least seven-bit characters
• Often not an accident or ignorance consider use
  of IA4 and IA5 in many ITU Recommendations
• Waiting for applications to be upgraded could
• Be a long wait
• Involve some unpredictability with sender not
  knowing receiver capabilities
• Plug-ins and patches do not yield a consistent
  user experience

12
The IETF IDNA Standard

• Internationalizing Domain Names in Applications
• Some mappings within Unicode
• Normalization of different ways to represent some
  characters
• Mapping of some similar or identical characters
• Some case-mappings
• Some forbidden characters/ code points
• But many issues not addressed
• Encoding Unicode characters into LDH form for the
  DNS
• The xn string
• Applications and character representations.

13
Current Status IETF

• IDNA complete and awaiting more implementation
  and user experience
• General recognition that additional registration
  restrictions are needed but
• IETF is not going to specify it
• Unlike LDH, seen as a per-zone problem
• EPP Registrar-Registry protocol
• Can accommodate internationalized names
• Some registry decisions about extensions
  registrars may not be able to use same techniques
  with different registries
• Preliminary efforts underway (no working groups
  yet) on
• Fully-internationalized URIs (IRIs)
• Email addresses

14
Technology Developments

• Several browser plug-ins
• No known implementations in widely-available
  general-purpose browsers or other applications
  yet.
• DNS diagnostic tools (nslookup, dig, etc) not yet
  upgraded to permit entry/display of Unicode
  strings.

15
Current Status ICANN

• Prohibition/ recommendation against labels
  starting with two characters and two hyphens if
  they are not IDNA strings.
• Recommendation established just before Montreal
  meeting
• Specifies language-based registry restrictions
  but no details
• Agreed to by CJK registries
• Some resistance from some gTLD registries
• Growing feeling that it will need some revision,
  but no plan about how and when to do one.
• Continuing uncertainty about gTLDs

16
The Meaning of Language

• JET, ICANN, etc., use the term language to
  describe tables and rules.
• Not the normal usage
• Really Zone-Language-Script
• No one really knows what the limits of a
  language are, although governments can make
  decisions within their territories.
• Scripts actually overlap in strange ways.
  Neither Unicode Consortium nor ISO have been able
  to define scripts associated with particular
  languages
• E.g., for some zones in Western Europe the
  appropriate language-script is generic
  European, i.e., Latin-1. For others, more
  specific lists of characters may be needed.

17
Look-alike Character Confusion

• Much focus so far on CJK
• Characters based on Chinese Han writing
• Making differently-encoded or different-appearing
  characters match
• Alphabetic language problem may turn out to be
  harder
• Common origins ?
• Avoiding having similar-looking, but distinct,
  characters confused.
• Not new 1 and l, 0 and O
• USA
• pectopan

18
JET Guidelines and Their Extensions

• Per-zone, per-language restrictions on
  registration
• The idea of a variant character and IDN Package
• Mixed-script labels are
• Particularly good opportunities for deception
• Sometimes useful
• Well-defined (now) for CJK, but
• Alphabets may be harder
• Particularly difficult issues with
  Roman-Greek-Cyrillic (pecopan, EAH,)
• Labels as words in a language
• Not a traditional approach excludes fanciful
  labels
• Dictionary lookup is an approach, but may cause
  other problems.

19
Major Issues

• Multilingual strings
• Labels and names
• Variant charging in JET-like models
• Cost of a reserved label
• Cost of activation given that the label has no
  value to anyone else
• DNS as an administrative hierarchy
• New types of conflict/ dispute problems

20
Technical Interoperability

• IDNA is entirely a client algorithm and
  procedure, hence depends on correct client
  implementations.
• Plug-ins may help, but only with specific
  applications.
• Open source development effort being put
  together.
• JET Guidelines and similar approaches are
  registry-dependent
• Do not raise interoperability issues.
• May raise user experience ones

21
Administrative Hierarchy Issues

• Policy and trust relationships
• No cross-tree cross-references to branches of
  hierarchy
• Organizational branding
• http//www.product.tld/ or
• http//www.organization.tld/product

22
New Dispute and Resolution Issues

• ICANN-WIPO UDRP assumes
• Homogeneous scripts and language characters
• Conflicts about rights to identical names
• but not
• Labels constructed from line or box-drawing
  characters
• Look-alike characters and strings from different
  scripts
• Translations, transcriptions, transcodings
• Is the relevant name the IDNA encoding or its
  display/presentation form?

23
Problems IDNs Dont Solve

• Registration policy issues
• This language is more important
• The gTLD problem
• Applications and local character sets
• Even JET Guidelines wont eliminate confusion
• DNS is a poor search mechanism and getting
  worse.

24
The Whois Policy Issues

• Registration in non-ASCII and data in ???
• Searching of a multilingual/ multiscript database
• Reading the records
• Information about variants and IDN Package
  contents

25
Economics

• Domain Name Market has collapsed.
• Original success projections and the ICANN
  Seven
• Notions of a profitable monopoly over
  multilingual TLDs do not seem to be going
  anywhere.

26
Competition and Policy

• Policy tradeoff between
• More flexibility of registrations
• Less risk of conflicts, deception, or fraud
• Each domain or zone will need to develop its own
  policy, and there will probably be wide
  variations.
• So-called ML.ML introduces complex questions of
  allocations
• essentially independent TLDs.
• ICANN policy so far apply separately, no
  rights to added domains
• Implications of a country deciding to go its own
  way with, e.g., local character codings.

27
The Path Forward with IDNs

• Implementation on a per-zone and per-application
  basis
• Development of new dispute resolution policies
• Discovery of new interface, confusion, and
  user-level interoperability problems
• What do you do with a domain name in a script you
  cant read or write?
• The two hundred-sided business card
• Local character codings and Unicode mapping
• Running out of those names too
• DNS name guessing is not a good search/location
  procedure in a growing network.

28
Where Will We End Up

• Increasing use of search engines??
• Clear trend, but
• As the Internet gets larger, general-purpose free
  text ones may have already peaked
• Increasing use of interest-specific portals??
• DNS labels, IDNA strings, or label translation
• The idea of unique keywords
• More separation of searching or locating and
  retrieval??
• Stable-reference URIs ?
• Information retrieval experience and bookmarks
• Deliberately-populated directories??

29
Conclusions

• IDN deployment is starting and will succeed, but
• Registries, application developers, and users
  have a lot to learn
• Except in special cases, early user experiences
  may not be wonderful.
• An Internet that is
• Optimized to local language and culture
• Globally accessible and useful
• may not be easily attained
• IDNs are, at best, a useful tool in effective
  localization and use in user languages and
  scripts.

30
Balancing Localization, Internationalization, and
User Experience

• Probably requires going beyond the DNS
• May require an Internet presentation layer
• Rethinking, not just patching
• Ways to find information
• Ways to remember what was found and accessing it
  again
• Thinking about things librarians have known for
  centuries
• New ideas about user interfaces
• Translation of a good French-language-oriented
  interface into Chinese or Arabic may not produce
  a good Chinese or Arabic interface.

31
Selected Further Readings

• Role of the DNS RFC 3467
• IDNA RFCs 3490, 3491, 3492, 3454
• Unicode evolution and stability
• draft-faltstrom-unicode-synchronization-00.txt
  (forthcoming)
• JET Guidelines for CJK, applications to other
  scripts
• draft-jseng-idn-admin-04.pdf
• draft-xdlee-idn-cdnadmin-00.txt
• draft-klensin-reg-guidelines-00.txt
• draft-hoffman-idn-reg-00.txt
• Tradeoffs between labels and translations
• draft-klensin-idn-tld-00.txt
• Issues with domain names in unexpected forms
• draft-klensin-name-filters-02.txt
• Alternate searching and retrieval models
• draft-klensin-dns-search-05.txt
• draft-mealing-sls-02.txt
• ICANN Policy Statements and Recommendations
• IDN deployment statement http//www.icann.org/ann
  ouncements/announcement-20jun03.htm
• More generally http//www.icann.org/document-name

32
Finding these documents

• RFCs
• ftp//ftp.rfc-editor.org/in-notes/rfcNNNN.txt
  (NNNN is the RFC number)
• Internet-Drafts (draft-xxxx)
• http//www.ietf.org/internet-drafts/document-name.

• Note that these documents are transient and that
  the two-digit number is a version number. If the
  version cited is not found, try a higher number
  or the search engine at http//www.ietf.org/ID
