Emerging Technologies: Grid Computing

1
Emerging Technologies Grid Computing

• Jon B. Weissman (jon_at_cs.umn.edu) Department of
  Computer Science
• University of Minnesota
• http//dcsg.cs.umn.edu

2
Outline

• What is a Grid?
• What is it good for?
• Grid Evolution and Models
• Grid Initiatives at the DTC and U Minnesota

3
What is a Grid?

• Computational Grids
• ensemble of geographically-dispersed resources
• seamless, transparent
• Analogy to Power Grids
• cheap, ubiquitous, consistent
• computational grids deliver computing data -
  not power
• Core Grid Features and Challenges
• single-sign on
• dynamic and shared
• highly heterogeneous
• multiple administrative domains
• sheer scale

4
What is it good for?

• Grid is an Opportunity
• High performance computing
• Distributed Supercomputing
• aggregate resources for large problems to reduce
  runtime
• e.g. physical process simulation climate
  modeling
• High Throughput Computing
• throughput gt many jobs or tasks / unit time
• exploit idle resources to increase throughput
• e.g simulate 10 parameters each taking on 10
  values 1010 tasks!
• Resource sharing
• Exploit idle resources
• On-demand computing near real-time remote access
• short-term access of remote capability (CPUs,
  software, etc)
• driven by cost-performance and increased
  functionality
• e.g. one-time access to a computer-enhanced MRI
  machine

5
Grids are Evolving

• Grid Evolution
• 1st Generation enabling technology make it
  run
• Globus and Legion toolkits - focus on HPC,
  resources were computers, and data stores
• Grid is visible
• 2nd Generation problem-solving
  commercialization make it familiar
• Moving out of academic labs into govt labs
  resources include scientific instruments
• Grid is becoming invisible
• 3rd Generation problem-solving make it
  useable and general-purpose
• Moving into the Enterprise focus on
  integration/standards, resources include
  software, services, and people.
• Grid will be invisible

6
1st Gen Grid Infrastructure

• Legion/Avaki - Everything is an object
• CPU host object, Data store vault objects,
• Globus Bag of functions
• Job submission, Remote I/O,

Applications
Middleware
Core Globus services
Local OS
7
2nd Gen (today) Grid Paradigms

• Grid Models
• Top-down Nasa IPG, DOE PPDG
• expensive resources, few resource owners
• Bottom-up seti, genome, _at_home
• cheaper donated resources P2P, many resource
  owners
• users donate for participation in new technology
  or other incentives
• Grid Function Diversity
• Data Grids, Compute Grids, Physics Grids, etc.
• NeesGrid, PPDG,
• Grid Standards
• Global Grid Forum 500-1000 attendees 4 X a year
• 25 Corporate Sponsors IBM, HP, Sun, Msoft,

8
3rd Gen Virtual Organizations and Grid Services

• A Virtual Organization is a logically
  centralized, physically distributed community
  that pursues common goals and objectives
• multi-institutional
• no central authority
• sharing conditional issues of trust, policy,
  negotiation, payment,
• dynamic requires new capabilities synthesized
  from existing services
• multiple qualities of service

9
VO Examples (Foster 2002)

• Civil engineers collaborate to design, execute,
  analyze shake table experiments
• A biochemist exploits 10,000 computers to screen
  100,000 compounds in an hour
• 1,000 physicists worldwide pool resources for
  analyses of petabytes of data
• Climate scientists visualize, annotate, analyze
  terabyte simulation datasets
• An emergency response team couples real time
  data, weather model, population data
• A multidisciplinary analysis in aerospace couples
  code and data in four companies

10
Grid Services

• Construct VOs Using Grid Services
• Services Encapsulate
• Computations, resources, information sources,
• Everything is a service
• Web Service Standard
• Protocols for service and interface discovery
• Web services are static
• Grid Service is a Dynamic Web Service
• Grid service has a negotiated lifetime
• Open Grid Services Architecture (OGSA)

11
Grid Services OGSA

• OGSA provides lifetime management and
  introspection for Grid Services
• OGSA provides several standard services
  including
• factory service that creates other service
  instances
• registry service that registers services for
  lookup
• myVO will be a collection of interacting Grid and
  non-Grid Services

12
Example Genome Comparison

• A GenCompare Grid service has two interfaces
• GenCompare comparison algorithm (SW, BLAST, )
• Compare (source, target) -gt score
• GridService lifetime, introspection,
• Query_Comparison() -gt BLAST

13
VO Scenario
GenCompare Factory
GeneDB Service
Community Registry
GeneDB 1
Compute Service Provider
User Application
. . .
. . .
GeneDB Service
Target Factory
I want to compare my source sequence library
against all known target sets
GeneDB n
Storage Service Provider
14
VO Scenario
Find me a genome comparison service, and a
target service
GenCompare Factory
GeneDB Service
Community Registry
GeneDB 1
Compute Service Provider
User Application
. . .
. . .
GeneDB Service
Target Factory
GeneDB n
Storage Service Provider
15
VO Scenario
Handle for GenCompare And Target factories
GenCompare Factory
GeneDB Service
Community Registry
GeneDB 1
Compute Service Provider
User Application
. . .
. . .
GeneDB Service
Target Factory
GeneDB n
Storage Service Provider
16
VO Scenario
GenCompare Factory
GeneDB Service
Community Registry
Create a Genome Compare service with initial
lifetime x
GeneDB 1
Compute Service Provider
User Application
. . .
. . .
GeneDB Service
Target Factory
GeneDB n
Create a Target service with initial lifetime x
Storage Service Provider
17
VO Scenario
GenCompare Factory
GeneDB Service
GeneDB 1
Miner
Compute Service Provider
User Application
. . .
GeneDB Service
Target Factory
GeneDB n
Miner
Storage Service Provider
18
VO Scenario
GenCompare Factory
GeneDB Service
Compare MySourceDB
GeneDB 1
Miner
Compute Service Provider
User Application
. . .
GeneDB Service
Target Factory
GeneDB n
Miner
Storage Service Provider
19
VO Scenario
GenCompare Factory
GeneDB Service
Compare MySourceDB
GeneDB 1
Miner
pull source lib
Compute Service Provider
User Application
. . .
GeneDB Service
Target Factory
GeneDB n
Miner
Storage Service Provider
20
VO Scenario
pull target lib
GenCompare Factory
GeneDB Service
Compare MySourceDB
GeneDB 1
Miner
Compute Service Provider
User Application
. . .
get next target
GeneDB Service
Target Factory
GeneDB n
Miner
Storage Service Provider
21
VO Scenario
GenCompare Factory
GeneDB Service
Compare MySourceDB
GeneDB 1
Miner
Compute Service Provider
User Application
pull target lib
get next target
GeneDB Service
Target Factory
GeneDB n
Miner
Storage Service Provider
22
VO Scenario
GenCompare Factory
GeneDB Service
comparison score
GeneDB 1
Miner
Compute Service Provider
User Application
. . .
GeneDB Service
Target Factory
GeneDB n
Miner
Storage Service Provider
23
Grid Initiatives at the DTC

• Research theme make the Grid invisible
• Four points in Grid space
• basic research (NSF)
• scheduling and resource management
• infrastructure (NSF, DOE)
• community services
• programming (AHPCRC)
• component-based toolkit for a Grid API
• live Grids (DTC, NSF)
• ADCS student lab

24
Infrastructure

• Community Services Project
• the Grid should be service-oriented ala OGSA
• code -gt service -gt Grid service
• designing infrastructure for high-end services
• adaptive, scalable, resilient, self-managing,
  consistent, high performance
• reusable libraries and software that can be used
  by service-providers
• service provider maintains, tunes, and upgrades
  service automatically
• user need not have high-end resources

25
Mixture of Experts

• System Architecture

Service Manager
Request
Request Manager
Adaptive code library
Result
26
Grid-Enabled Network Services
Home Site
Network Service Front-End
SM
Request
RM
RM
..
Site N
SM
Result
RM
27
Gene Sequence Service Manager
Request
Request Manager
Result
beowulf.cs.umn.edu
Gene Sequence Libraries
28
Experimental Results

• Dynamic selection of performance predictors and
  scheduling policies

29
Grid Programming Toolkit

• How to Program Grid Applications?
• many Grid applications are not just a single
  component or service but a web of interacting
  components ala OGSA
• Component Model Toolkit
• allow components and services to be composed
  together
• toolkit allows component interactions to be
  specified
• Toolkit runtime will (goal)
• schedule components/services
• select best component/service communication
  mechanism

30
ADCS Grid

• Shared Student Lab of 98 machines downstairs
• Outfitted with GigE and fast large disks
• Turn Lab into a large storage Grid for data
  processing and visualization first
• Astronomy (PPM gas dynamics/visualization) -
  Woodward
• Movie Making
• Biology (Plant Genomics) - Retzel
• Similarity searches on large plant genomic
  datasets
• Students!
