CSCI 1302

1
CSCI 1302

• Algorithmic Cost Complexity
• Analysis of Data Structures and Algorithms

2
Correctness is Not Enough

• It isnt sufficient that our algorithms perform
  the required tasks.
• We want them to do so efficiently, making the
  best use of
• Space
• Time

3
Time and Space

• Time
• Instructions take time.
• How fast does the algorithm perform?
• What affects its runtime?
• Space
• Data structures take space.
• What kind of data structures can be used?
• How does the choice of data structure affect the
  runtime?

4
Time vs. Space

• Very often, we can trade space for time
• For example maintain a collection of students
  with SSN information.
• Use an array of a billion elements and have
  immediate access (better time)
• Use an array of 35 elements and have to search
  (better space)

5
The Right Balance

• The best solution uses a reasonable mix of space
  and time.
• Select effective data structures to represent
  your data model.
• Utilize efficient methods on these data
  structures.

6
Scenarios

• Ive got two algorithms that accomplish the same
  task
• Which is better?
• Given an algorithm, can I determine how long it
  will take to run?
• Input is unknown
• Dont want to trace all possible paths of
  execution
• For different input, can I determine how an
  algorithms runtime changes?

7
Measuring the Growth of Work

• While it is possible to measure the work done by
  an algorithm for a given set of input, we need a
  way to
• Measure the rate of growth of an algorithm based
  upon the size of the input
• Compare algorithms to determine which is better
  for the situation

8
Why Use Big-O Notation

• Used when we only know the asymptotic upper
  bound.
• If you are not guaranteed certain input, then it
  is a valid upper bound that even the worst-case
  input will be below.
• May often be determined by inspection of an
  algorithm.
• Thus we dont have to do a proof!

9
Size of Input

• In analyzing rate of growth based upon size of
  input, well use a variable
• For each factor in the size, use a new variable
• N is most common
• Examples
• A linked list of N elements
• A 2D array of N x M elements
• A Binary Search Tree of P elements

10
Formal Definition

• For a given function g(n), O(g(n)) is defined to
  be the set of functions
• O(g(n)) f(n) there exist positive
  constants c and n0 such that 0 ? f(n) ?
  cg(n) for all n ? n0

11
Visual O() Meaning
cg(n)
Upper Bound
f(n)
f(n) O(g(n))
Work done
Our Algorithm
n0
Size of input
12
Simplifying O() Answers(Throw-Away Math!)

• We say 3n2 2 O(n2) drop constants!
• because we can show that there is a n0 and a c
  such that
• 0 ? 3n2 2 ? cn2 for n ? n0
• i.e. c 4 and n0 2 yields
• 0 ? 3n2 2 ? 4n2 for n ? 2

13
Correct but Meaningless

• You could say
• 3n2 2 O(n6) or 3n2 2 O(n7)
• But this is like answering
• Whats the world record for the mile?
• Less than 3 days.
• How long does it take to drive to Chicago?
• Less than 11 years.

14
Comparing Algorithms

• Now that we know the formal definition of O()
  notation (and what it means)
• If we can determine the O() of algorithms
• This establishes the worst they perform.
• Thus now we can compare them and see which has
  the better performance.

15
Comparing Factors
N2
N
Work done
log N
1
Size of input
16
Correctly Interpreting O()

• O(1) or Order One
• Does not mean that it takes only one operation

• Does mean that the work doesnt change as N
  changes
• Is notation for constant work
• O(N) or Order N
• Does not mean that it takes N operations
• Does mean that the work changes in a way that is
  proportional to N
• Is a notation for work grows at a linear rate

17
Complex/Combined Factors

• Algorithms typically consist of a sequence of
  logical steps/sections
• We need a way to analyze these more complex
  algorithms
• Its easy analyze the sections and then combine
  them!

18
Example Insert in a Sorted Linked List

• Insert an element into an ordered list
• Find the right location
• Do the steps to create the node and add it to the
  list

//
head
17
38
142
Step 1 find the location O(N)
Inserting 75
19
Example Insert in a Sorted Linked List

• Insert an element into an ordered list
• Find the right location
• Do the steps to create the node and add it to the
  list

//
head
17
38
142
75
Step 2 Do the node insertion O(1)
20
Combine the Analysis

• Find the right location O(N)
• Insert Node O(1)
• Sequential, so add
• O(N) O(1) O(N 1) O(N)

Only keep dominant factor
21
Example Search a 2D Array

• Search an unsorted 2D array (row, then column)
• Traverse all rows
• For each row, examine all the cells (changing
  columns)

Row
1 2 3 4 5
O(N)










1 2 3 4 5 6 7 8 9 10
Column
22
Example Search a 2D Array

• Search an unsorted 2D array (row, then column)
• Traverse all rows
• For each row, examine all the cells (changing
  columns)

Row
1 2 3 4 5



















1 2 3 4 5 6 7 8 9 10
Column
O(M)
23
Combine the Analysis

• Traverse rows O(N)
• Examine all cells in row O(M)
• Embedded, so multiply
• O(N) x O(M) O(NM)

24
Sequential Steps

• If steps appear sequentially (one after another),
  then add their respective O().
• loop
• . . .
• endloop
• loop
• . . .
• endloop

N
O(N M)
M
25
Embedded Steps

• If steps appear embedded (one inside another),
  then multiply their respective O().
• loop
• loop
• . . .
• endloop
• endloop

O(NM)
M
N
26
Correctly Determining O()

• Can have multiple factors
• O(NM)
• O(logP N2)
• But keep only the dominant factors
• O(N NlogN) O(NlogN)
• O(NM P) remains the same
• O(V2 VlogV) O(V2)
• Drop constants
• O(2N 3N2) O(N N2) O(N2)

27
What You Should Know So Far

• We use O() notation to discuss the rate at which
  the work of an algorithm grows with respect to
  the size of the input.
• O() is an upper bound, so only keep dominant
  terms and drop constants

28
Analyzing Data Structures

• Weve talked about data structures and methods to
  act on these structures
• Linked lists, arrays, trees
• Inserting, Deleting, Searching, Traversal,
  Sorting, etc.
• Now that we know about O() notation, lets
  discuss how each of these methods perform on
  these data structures!

29
Recipe for Determining O()

• Break algorithm down into known pieces
• Well learn the Big-Os in this section
• Identify relationships between pieces
• Sequential is additive
• Nested (loop / recursion) is multiplicative
• Drop constants
• Keep only dominant factor for each variable

30
Array Size and Complexity

• How can an array change in size?
• const int N 30
• int DataN
• We need to know what N is in advance to declare
  an array, but for analysis of complexity, we can
  still use N as a variable for input size.

31
Traversals

• Traversals involve visiting every element in a
  collection.
• Because we must visit every node, a traversal
  must be O(N) for any data structure.
• If we visit less than N elements, then it is not
  a traversal.

32
Searching for an Element

• Searching involves determining if an element is a
  member of the collection.
• Simple/Linear Search
• If there is no ordering in the data structure
• If the ordering is not applicable
• Binary Search
• If the data is ordered or sorted
• Requires non-linear access to the elements

33
Simple Search

• Worst case the element to be found is the Nth
  element examined.
• Simple search must be used for
• Sorted or unsorted linked lists
• Unsorted array
• Binary tree
• Binary Search Tree if it is not full and balanced

34
Balanced Binary Search Trees

• If a binary search tree is not full, then in the
  worst case it takes on the structure and
  characteristics of a sorted linked list with N/2
  elements.

35
Binary Search Trees

• If a binary search tree is not full or balanced,
  then in the worst case it takes on the structure
  and characteristics of a sorted linked list.

7
11
14
42
58
36
Example Linked List

• Lets determine if the value 83 is in the
  collection

Head
\\
42
5
19
35
83 Not Found!
37
Simple/Linear Search Algorithm

• cur head
• while ((cur ! null) (cur.Data ! target))
• cur cur.Next
• if(cur ! null)
• DISPLAY Yes, target is there
• else
• DISPLAY No, target isnt there

38
Pre-Order Search Traversal Algorithm

• As soon as we get to a node, check to see if we
  have a match
• Otherwise, look for the element in the left
  sub-tree
• Otherwise, look for the element in the right
  sub-tree

14
Left ???
Right ???
39
Find 9
40
Find 9
cur
41
Find 9
42
Find 9
22
43
Find 9
22
44
Find 9
22
45
Find 9
22
14
46
Find 9
22
14
47
Find 9
22
14
48
Find 9
22
14
49
Find 9
22
14
67
50
Find 9
22
14
67
51
9 Found!
22
14
67
52
Big-O of Simple Search

• The algorithm has to examine every element in the
  collection
• To return a false
• If the element to be found is the Nth element
• Thus, simple search is O(N).

53
Binary Search

• We may perform binary search on
• Sorted arrays
• Full and balanced binary search trees
• Tosses out ½ the elements at each comparison.

54
Full and Balanced Binary Search Trees

• Contains approximately the same number of
  elements in all left and right sub-trees
  (recursively) and is fully populated.

55
Binary Search Example
Looking for 89
56
Binary Search Example
Looking for 89
57
Binary Search Example
Looking for 89
58
Binary Search Example
89 not found 3 comparisons 3 Log(8)
59
Binary Search Big-O

• An element can be found by comparing and cutting
  the work in half.
• We cut work in ½ each time
• How many times can we cut in half?
• Log2N
• Thus binary search is O(Log N).

60
Insertion

• Inserting an element requires two steps
• Find the right location
• Perform the instructions to insert
• If the data structure in question is unsorted,
  then it is O(1)
• Simply insert to the front
• Simply insert to end in the case of an array
• There is no work to find the right spot and only
  constant work to actually insert.

61
Insert into a Sorted Linked List

• Finding the right spot is O(N)
• Recurse/iterate until found
• Performing the insertion is O(1)
• 4-5 instructions
• Total work is O(N 1) O(N)

62
Inserting into a Sorted Array

• Finding the right spot is O(Log N)
• Binary search on the element to insert
• Performing the insertion
• Shuffle the existing elements to make room for
  the new item

63
Shuffling Elements
Note we must have at least one empty cell
Insert 29
64
Shuffling Elements
Note we must have at least one empty cell
Insert 29
65
Shuffling Elements
Note we must have at least one empty cell
Insert 29
66
Shuffling Elements
Note we must have at least one empty cell
Insert 29
67
Shuffling Elements
Note we must have at least one empty cell
77
Insert 29
68
Shuffling Elements
Note we must have at least one empty cell
77
35
Insert 29
69
Shuffling Elements
Note we must have at least one empty cell
77
29
35
70
Big-O of Shuffle
Worst case inserting the smallest number
101
35
77
Would require moving N elements Thus shuffle is
O(N)
71
Big-O of Inserting into Sorted Array

• Finding the right spot is O(Log N)
• Performing the insertion (shuffle) is O(N)
• Sequential steps, so add
• Total work is O(Log N N) O(N)

72
Inserting into a Full and Balanced BST

• Always insert when current null.
• Find the right spot
• Binary search on the element to insert
• Perform the insertion
• 4-5 instructions to create add node

73
Full and Balanced BST Insert
Add 4
12
41
3
98
7
35
2
74
Full and Balanced BST Insert
Add 4
12
41
3
98
7
35
2
75
Full and Balanced BST Insert
Add 4
12
41
3
98
7
35
2
76
Full and Balanced BST Insert
Add 4
12
41
3
98
7
35
2
77
Full and Balanced BST Insert
Add 4
12
41
3
98
7
35
2
78
Full and Balanced BST Insert
12
41
3
98
7
35
2
4
79
Big-O of Full Balanced BST Insert

• Find the right spot is O(Log N)
• Performing the insertion is O(1)
• Sequential, so add
• Total work is O(Log N 1) O(Log N)

80
Comparing Data Structures and Methods

• Data Structure Traverse Search Insert
• Unsorted L List N N 1
• Sorted L List N N N
• Unsorted Array N N 1
• Sorted Array N Log N N
• Binary Tree N N 1
• BST N N N
• FB BST N Log N Log N

81
Two Sorting Algorithms

• Bubblesort
• Brute-force method of sorting
• Loop inside of a loop
• Mergesort
• Divide and conquer approach
• Recursively call, splitting in half
• Merge sorted halves together

82
Bubblesort

• Bubblesort works by comparing and swapping values
  in a list

1 2 3 4 5
6
12
101
5
35
42
77
83
Bubblesort

• Bubblesort works by comparing and swapping values
  in a list

1 2 3 4 5
6
Swap
12
101
5
35
42
77
84
Bubblesort

• Bubblesort works by comparing and swapping values
  in a list

1 2 3 4 5
6
Swap
12
101
5
35
77
42
85
Bubblesort

• Bubblesort works by comparing and swapping values
  in a list

1 2 3 4 5
6
Swap
12
101
5
77
35
42
86
Bubblesort

• Bubblesort works by comparing and swapping values
  in a list

1 2 3 4 5
6
77
101
5
12
35
42
No need to swap
87
Bubblesort

• Bubblesort works by comparing and swapping values
  in a list

1 2 3 4 5
6
Swap
77
101
5
12
35
42
88
Bubblesort

• Bubblesort works by comparing and swapping values
  in a list

1 2 3 4 5
6
101
77
5
12
35
42
Largest value correctly placed
89

• void Bubblesort(ref int A)
• int to_do, index
• to_do N 1 // N size of A
• while (to_do ! 0)
• index 1
• while (index lt to_do)
• if(Aindex gt Aindex 1)
• Swap(Aindex, Aindex 1)
• index
• to_do--
• // Bubblesort

to_do
N-1
90
Analysis of Bubblesort

• How many comparisons in the inner loop?
• to_do goes from N-1 down to 1, thus
• (N-1) (N-2) (N-3) ... 2 1
• Average N/2 for each pass of the outer loop.
• How many passes of the outer loop?
• N 1

91
Bubblesort Complexity

• Look at the relationship between the two loops
• Inner is nested inside outer
• Inner will be executed for each iteration of
  outer
• Therefore the complexity is
• O((N-1)(N/2)) O(N2 N/2) O(N2)

92
Mergesort
67
45
23
14
6
33
98
42
67
45
23
14
6
33
98
42
Log N
45
23
14
98
67
6
33
42
23
98
45
14
67
6
33
42
23
98
45
14
67
6
42
33
Log N
6
33
42
67
14
23
45
98
6
14
23
33
42
45
67
98
93
Analysis of Mergesort

• Phase I
• Divide the list of N numbers into two lists of
  N/2 numbers
• Divide those lists in half until each list is
  size 1
• Log N steps for this stage.
• Phase II
• Build sorted lists from the decomposed lists
• Merge pairs of lists, doubling the size of the
  sorted lists each time
• Log N steps for this stage.

94
Analysis of the Merging
23
98
45
14
67
6
33
42
Merge
Merge
Merge
Merge
23
98
45
14
67
6
42
33
Merge
Merge
6
33
42
67
14
23
45
98
Merge
6
14
23
33
42
45
67
98
95
Mergesort Complexity

• Each of the N numerical values is compared or
  copied during each pass
• The total work for each pass is O(N).
• There are a total of Log N passes
• Therefore the complexity is
• O(Log N N Log N) O (N Log N)

Break apart
Merging
96
Summary

• You now have the O() for basic methods on varied
  data structures.
• You can combine these in more complex situations.
• Break algorithm down into known pieces
• Identify relationships between pieces
• Sequential is additive
• Nested (loop/recursion) is multiplicative
• Drop constants
• Keep only dominant factor for each variable

97
FIN
