Database Management Systems Security

1
Database Management Systems Security
Raval Fichadia John Wiley Sons, Inc. 2007

• Chapter Nine
• Prepared by Raval, Fichadia

2
Chapter Nine Objectives

• Learn the basic concepts of database management
  systems (DBMS) and associated terminology.
• Understand the risks that impact DBMS and the
  controls to mitigate them.
• Gain the skills to assess the security posture of
  a database infrastructure and make management
  recommendations.
• Apply security principles and best practices to a
  database infrastructure.

3
The Big Picture

• Elements of a database management system.
• Some risks that impact the DBMS.

4
Database primer

• Databases collection of related-data in an
  organized fashion that allows for easier access,
  management, and updates.
• Applications need a place to store data. They
  could do so in application-specific files.
• Doing so makes it extremely difficult to manage
  especially in keeping data synched across
  applications.
• Databases solve this problem by handling all data
  management issues.
• Examples of popular database management systems
  software includes Oracles Oracle DBMS,
  Microsofts SQL Server, and IBMs DB2 system.

5
Database primer

• Databases collection of related-data in an
  organized fashion that allows for easier access,
  management, and updates.
• Synchronizing files and updating all
  application-specific files is inefficient.

6
Database primer

• Databases collection of related-data in an
  organized fashion that allows for easier access,
  management, and updates.
• Synchronizing files and updating a common source
  is efficient.

7
Database primer

• Databases Types of databases include
• Hierarchical DBs that store data in an inverted
  tree form and each parent node has one or more
  child nodes.
• Network DBs is similar to hierarchical, with no
  parent-child constraints.
• Relational DBs store data in tabular format in
  rows and columns. Most popular database type.
• Object-oriented DBs allow storage of binary
  and/or complex data types (BLOBs).
• Examples of popular database management systems
  software includes Oracles Oracle DBMS,
  Microsofts SQL Server, and IBMs DB2 system.

8
Management concerns

• Concerns about database system security typically
  include the following
• Maximizing the database performance and
  availability for business transactions and
  queries.
• Minimizing data redundancy and standardizing data
  management and access methods.
• Keeping up with existing and upcoming security
  threats and implementing mitigating controls.
• Having an effective backup, recovery, business
  resumption and a disaster recovery plan.

9
Risks and Controls

• Authentication Process of validating a users
  identity to a database.
• Users (or applications) have to prove their
  identity to the database before being able to
  access data from it.
• This is typically done via user IDs and passwords
  or via a third-party authentication wherein a
  operating system authenticates a user and the
  database takes the OSs word for the users
  identity.
• There are several ways that can expose
  authentication credentials.

10
Risks and Controls

• Authentication risks
• Default accounts with default passwords are often
  left unprotected by administrators. For example
  Oracle has well-known administrative user account
  sys with a password change_on_install. SQL
  server 6.5 has no password for the administrative
  sa account.
• Database often have weak password management
  features (when compared to operating systems) in
  that they may not have intruder lockouts,
  periodic password change requirements, etc..
• Database administrators often use batch scripts
  to perform administrative tasks. Often these
  scripts contain user IDs and password and are
  left unprotected.

11
Risks and Controls

• Authentication risks
• Administrators use utilities like
• Database often have weak password management
  features (when compared to operating systems) in
  that they may not have intruder lockouts,
  periodic password change requirements, etc..
• Database administrators often use batch scripts
  to perform administrative tasks. Often these
  scripts contain user IDs and password and are
  left unprotected.

12
Risks and controls

• Authentication risks
• Administrators use utilities like sqlplus to
  connect to database. UserIDs/passwords used as
  parameters to these utilities may show up in
  process listings which can be viewed by other
  users.

13
Risks and controls

• Authentication risks
• Password hashes arent often well secured. For
  e.g. Oracles dba_users view, if unprotected,
  can disclose hashes. SQL server at times stores
  the password hashes in the Windows registry. At
  times, setup and log files have password hashes.
• Controls
• Default accounts should have their password
  changed and/or be disabled.
• Companies should upgrade to newer versions of
  DBMS that have more robust password management
  features.

14
Risks and controls

• Controls
• Batch files, setup files or log files should
  either be deleted or protected via stronger ACLs.
• Administrators should be educated to not pass
  credentials via command line to prevent them
  showing up in process listings.
• ACLs on tables, views, registries that contain
  password hashes should be tightened and
  periodically reviewed.

15
Risks and Controls

• Trust relationships DBs can be configured to
  trust operating systems for authenticating users.
• Companies prefer reducing the number of user IDs
  and passwords a user has to remember.
• Hence most DBs allow a pass-through
  authentication feature wherein the DB asks the OS
  for the users identity. For example, Oracle
  allows for two types of accounts
• External account User accounts that have been
  authenticated by the OS. The DB relies on the OS
  for the users identity.
• Internal account Users that belong to a
  particular group (dba) can access the DB with
  administrative rights. The DB relies on the OS
  to ensure user belongs to administrative group.

16
Risks and controls

• Trust relationships risks
• Trusting a client OS is a really bad idea since
  the end user can create any account say
  oracle on the client OS and the DB will trust
  the user to be oracle.
• Use of Internal account causes a loss of
  accountability since all users access the DB as
  the same account.
• Controls
• Company should ensure that DBs rely on a trusted
  OS typically the server OS, not the client OS.
• Disable the use of Internal account.

17
Risks and Controls

• Networking within DBs and to OSs Pathways from a
  database to other databases or to operating
  systems.
• Databases can be linked with other databases so
  that a users can access data from either DBs.
  This is done via links. For example, Oracle
  allows two types of links
• Public links that allow all users of a DB to
  access the linked DB.
• Private links that allows only specific users of
  a DB to access the linked database.
• Databases can also allow users access to the
  operating system hosting the database or
  certain features thereof. For example, SQL server
  has several stored procedures such as
  xp_cmdshell that allows shell access within
  an operating system.

18
Risks and controls

• Networking within DBs and to OSs risks
• Links have embedded credentials (with which the
  remote DB is accessed). Views that display these
  are often not secured.
• Links to OS or DBs allows intruders to explore
  more areas to find weaknesses. The higher the
  privileges of the embedded credentials, the
  greater opportunity for the intruders.
• Remote databases are accessed via the credentials
  stored with the link. Hence, accountability of
  end users actions is lost.
• Use of xp_cmdshell features makes the impact of
  SQL injection type attacks much worse (since the
  malicious SQL can now impact not only the DB, but
  the OS also).

19
Risks and controls

• Controls
• Company should avoid links as far as possible.
• If required, private links should be used rather
  than public links.
• The credentials used to access linked DBs should
  be as minimal as possible.
• Limit pathways into OS as far as possible. If
  required, ensure qualified developers are using
  it in a secure fashion.

20
Risks and Controls

• Insecure DB application designs Applications
  often use database as back-end tiers.
• Databases often store application-related data,
  transaction information, user credentials, etc.
• If the DB applications arent properly designed,
  the database contents can be compromised.
• Poor designs can lead to bypass of application
  controls, identity spoofing (impersonation), and
  privilege escalation.

21
Risks and Controls

• Insecure DB application designs Bypass of
  application controls.
• Developers often design a client application that
  talks to a back-end database.
• This client application often has several
  controls embedded in them (edit checks, content
  check, etc.) to ensure that the data reaching the
  DB is proper.
• However this approach mistakenly assumes a user
  cant talk to the DB directly.
• Skilled users can submit SQL commands directly to
  the database, leading to a bypass of the controls
  embedded in the client application.

22
Risks and controls

• Insecure DB application designs Bypass of
  application controls.
• Relying on front-end GUI for controls is not
  enough.

23
Risks and Controls

• Insecure DB application designs Identity
  spoofing and privilege escalation.
• Developers may design a database application
  relies on a the clients operating system to
  establish clients identity (third-party-based
  authentication).
• This leads to single-sign on users logged onto
  their PCs dont have to re-authenticate to the DB
  application.
• In addition, the DB application doesnt have to
  program for managing clients user ID and
  passwords.
• This approach often fails because the clients
  operating system is not trust-worthy end users
  can easily create accounts of their choice on
  their machines.

24
Risks and controls

• Insecure DB application designs Identity
  spoofing and privilege escalation.
• Relying on client OS for user credentials is a
  bad idea.

25
Risks and controls

• Insecure DB application designs SQL injection
  attacks.
• Applications, typically web-based, with back-end
  databases are susceptible to these attacks.
• These applications convert user supplied input
  into SQL commands that are processed by the
  database.
• Attackers can craft special input that make the
  SQL commands malicious in nature.
• The database processes these malicious SQL
  commands and end up disclosing sensitive data or
  running sensitive database commands.

26
Risks and controls

• Insecure DB application designs SQL injection
  attack example 1.
• Consider, a web application, that allows users to
  change their password and asks for following
  inputs
• UserID pankaj
• Old password reuse99
• New password simplify87
• The resulting SQL executed by the database then
  is
• UPDATE usertable SET pwd'simplify87' WHERE
• userid'pankaj'
• This changes the pwd value in the usertable for
  the user pankaj

27
Risks and controls

• Input manipulation SQL injection attack example
  1 contd.
• Now consider, if the user provides the following
  special input
• UserID pankaj' OR userid 'administrator'--
• Old password reuse99
• New password simplify87
• The resulting SQL executed by the database then
  is
• UPDATE usertable SET pwd'simplify87' WHERE
• userid'pankaj' OR userid 'administrator'--'

• This changes the pwd value in the usertable for
  the user administrator!!
• (the - - ask the database to ignore any
  characters that follow)

28
Risks and controls

• Insecure DB application designs SQL injection
  attack example 2.
• Consider, a web application, that allows users to
  type in a keyword to search a particular product
  type by asking
• Product keyword antique
• Say, the resulting SQL executed by the database
  is
• SELECT product FROM product_table
• WHERE product_description like antique
• This query results in showing all products from
  the product_table that have the keyword antique
  in it.

29
Risks and controls

• Input manipulation SQL injection attack example
  2 contd.
• Now consider, if the user provides the following
  special input
• Product keyword antique UNION SELECT
  username, password FROM dba_users WHERE username
  like
• The resulting SQL executed by the database then
  is
• SELECT product FROM product_table
• WHERE product_description like antique
• UNION SELECT username, password
• FROM dba_users WHERE username like
• This results in display user IDs and password
  hashes for all users in addition to the
  products!!

30
Risks and controls

• Insecure DB application designs risks
• Intruders can exploit poor application designs to
  bypass controls, spoof identities, escalate
  privileges, and compromise database security.
• Controls
• Application developers should be educated in the
  art of design secure applications.
• Applications that have DB controls built into the
  client portion should ensure end users cant
  directly connect to DBs (typically by obfuscating
  user credentials that are needed to connect to
  the database).

31
Risks and controls

• Controls contd
• Application should never rely on third-parties
  that arent controllable and trustworthy.
  Instead, rely on third parties such as server OS
  or domain credentials that arent in users
  control.
• Protect against SQL injection attacks by
• Sanitizing user inputs by rejecting known bad
  data/characters, accepting only valid data, and
  cleaning bad data.
• Not using dynamic SQL. Instead use bind
  variables or parameterized SQL.
• Minimizing privileges of the database application
  user. This will limit the damage if SQL
  injection succeeds.

32
Assurance considerations

• An audit to assess database management system
  security should include the following
• Ensure quality user ID and password management
  techniques are used for databases.
• Review authentication methods, user accounts and
  their privileges.
• Assess the patch deployment process. All
  necessary patches for databases are implemented.
• Ensure that the database applications have
  mechanisms to filter out untrusted user inputs.

33
Assurance considerations

• Determine the business needs of links between
  databases. Public links should not be used.
• Evaluate the need and security of all file
  shares.
• Ensure that functional plans for backup and
  recovery, business resumption, disaster recovery
  are in place.

34
Recap
