ECE6130: Computer Architecture: Instruction Set Architecture

1
ECE6130 Computer ArchitectureInstruction Set
Architecture

• Dr. Xubin He
• http//iweb.tntech.edu/hexb
• Email hexb_at_tntech.edu
• Tel [phone], Brown Hall 319

2

• Previous Class
• Fundamentals of computer design
• Today
• Instruction Set Architecture

3
Summary of Chapter 1

• Quantitative principles
• Technology trends
• Cost trends
• Measure, report and summarize performance

4
Summary of Chapter 1

• Time to run the task
• Execution time, response time, latency, CPU time
• Tasks per day, hour, week, sec, ns,
• Throughput, bandwidth
• X is n times faster than Y means
• ExTime(Y) Performance(X)
• --------------- -------------------- n
• ExTime(X) Performance(Y)

5
Summary of Chapter 1

• Amdahls Law
• Iron CPI Law
• Execution time is the REAL measure of computer
  performance!

6
ISA Outline

• ISA principles and classifications
• CISC and RISC
• Addressing modes
• Operations in ISA (control flow instructions)
• Compiler for ISA and ISA on Compiler

7
Instruction Set Architecture (ISA)
software
instruction set
hardware
8
Evolution of Instruction Sets

• Major advances in computer architecture are
  typically associated with landmark instruction
  set designs
• Ex Stack vs GPR (System 360)
• Design decisions must take into account
• technology
• machine organization
• programming languages
• compiler technology
• operating systems
• And they in turn influence these

9
Instruction Set Principles

• ISA should reflect application characteristics
• Desktop computing is compute-intensive, thus
  focusing on features favoring Integer and FP ops
• Server computing is data-intensive, focusing on
  integers and char-strings (yet FP ops are still
  standard in them)
• Embedded computing is time-sensitive, memory and
  power concern, thus focusing on code-density,
  real-time and media data streams.

10
Classifying ISA

• Taxonomy of ISA
• Stack both operands are implicit on the top of
  the stack, a data structure in which items are
  accessed in a last in, first out fashion.
• Accumulator one operand is implicit in the
  accumulator, a special-purpose register.
• General Purpose Register all operands are
  explicit in specified registers or memory
  locations. Depending on where operands are
  specified and stored, there are three different
  ISA groups
• Register-Memory one operand in register and one
  in memory.Examples IBM 360/370, Intel 80x86
  family, Mototola 68000
• Memory-Memory both operands are in memory.
  Example VAX.
• Register-Register (load store) all operands,
  except for those in load and store instructions,
  are in registers. Examples SPARC (Sun
  Microsystems), MIPS, Precision Architecture (HP),
  PowerPC (IBM), Alpha (DEC).

11
Instruction Set Principles

• Taxonomy of ISA Examples

C?AB
(a) Stack
(d) Reg-Reg/Load-Store
(e) Memory-Memory
(b) Accumulator
(c) Register-Memory
TOS
Reg. Set
Reg. Set
Stack
Accumulator
ALU
ALU
ALU
ALU
ALU
Memory
Memory
Memory
Memory
Memory
Push A Push B Add Pop C
Load A Add B Store C
Load R1,A Add R3,R1,B Store R3,C
Load R1,A Load R2,B Add R3,R1,R2 Store R3,C
Add C,A,B
12
Instruction Set Principles
13
ISA Principles about Pipelining

• Register-Register RISC
• Load-store machine with no memory references
• Easy to pipeline, higher IC (why?)
• Register-Memory IBM 360, Intel 80x86
• Harder to pipeline but reduce IC
• Memory-Memory VAX
• Hardest to pipeline, most compact IC

14
Evolution of Instruction Sets
Single Accumulator (EDSAC 1950)
Accumulator Index Registers
(Manchester Mark I, IBM 700 series 1953)
Separation of Programming Model from
Implementation
High-level Language Based
Concept of a Family
(B5000 1963)
(IBM 360 1964)
General Purpose Register Machines
Complex Instruction Sets
Load/Store Architecture
(CDC 6600, Cray 1 1963-76)
(VAX, Intel 432 1977-80)
RISC
(Mips,Sparc,HP-PA,IBM RS6000, . . .1987)
Post-RISC(Intel Petium3,41998,2001)
15
RISC/CISC

• Complex Instruction Set Computer
• Intel x86
• DEC VAX, PDP11
• Motorola 68k
• IBM 360, 370
• Complex instructions bring the hardware closer to
  high-level languages
• Memory was expensive
• Fewer, more powerful instructions
• Smaller programs
• More space for data

16
CISC - ISA

• Instruction type count
• Usually almost 256
• Maximum number of 8-bit opcodes!
• Powerful instructions
• Many microcode steps
• Multiple cycle latency
• Faster in microcode than users program!
• Added some complexity to interrupt handling,
  page faulting, etc
• Instructions too long to be uninterruptible!
• Variable instruction length, multiple formats
• 1 to 10 bytes

17
CISC - ISA critique

• Studies of compilers showed
• Many instructions unused
• DEC even dropped an indexed memory access,
  post-decrement y xi-- from the ISA going
  from PDP -gt VAX!
• Compiler writers were sometimes simply not using
  complex instructions when they were appropriate
• because they could write faster sequences of
  simple instructions for the most common cases!

18
CISC - the death knell

• Irrespective of its performance ...
• Complex hardware is expensive!
• Speed improvements
• Change microcode to hard-wired control
• Irregularity of instruction OP format, length
  (long design times)
• Long lead times to market

19
CISC - the death knell

• A prediction (qualified!)
• x86 probably the last major CISC architecture
• and it probably would have died a well-deserved
  death a few years ago if it hadnt been for Bill
  Gates
• Its too expensive to design another one!
• Even Intel are abandoning it in favor of a RISC
  architecture
• Joint Intel/HP project
• If they cant afford a 786 design,nobody can!

20
Reduced Instruction Set Computer

• also Load-store architecture
• Only a few instruction types
• No memory-memory instructions
• Data loaded to registers
• lw 3, 0(2)
• Data stored from registers
• st 4,40(5)
• Arithmetic, logical, etc operations are all
• Register -gt Register
• Mostly 3-operand type
• op dest_reg, src_regA, src_regB
• Mostly 1-cycle in ALU
• Throughput 1 instruction/cycle

21
RISC

• Simplicity of RISC instructions
• permits high clock rates
• long-latency ALU instructions are divided further
  as necessary
• super-pipelined processors
• MIPS R4000 8-stage pipeline
• All instructions are 32-bits
• Simplifies
• pre-fetch,
• superscalar issue,
• branch management

22
RISC - Simple Hardware, Complex Compiler

• Basic hardware is simple
• and hard-wired
• ie no microcode
• but
• Pipeline stalls can reduce throughput
• Optimizing Compiler needed
• Fully exploit capabilities
• Dependence Analysis
• Instruction re-ordering
• Avoid pipeline stalls
• Instruction grouping in super-scalar, VLIW

23
Post-RISC Era

• RISC was not a specific technology as much as it
  was a design strategy that developed in reaction
  to a particular school of thought in computer
  design.  It was a rebellion against prevailing
  norms--norms that no longer prevail in today's
  world.
• David Ditzel, the chief architect of Sun SPARC
  family and CEO of Transmeta
• "Today in RISC we have large design teams
  and long design cycles," he said. "The
  performance story is also much less clear now.
  The die sizes are no longer small. It just
  doesn't seem to make as much sense." The result
  is the current crop of complex RISC chips.
  "Superscalar and out-of-order execution are the
  biggest problem areas that have impeded
  performance leaps," Ditzel said. "The MIPS
  R10,000 and HP PA-8000 seem much more complex to
  me than today's standard CISC architecture, which
  is the Pentium II. So where is the advantage of
  RISC, if the chips aren't as simple anymore?"
• "CISC" was invented retroactively as a catch-all
  term for the type of thinking against which RISC
  was a reaction.
• We now live in a "post-RISC" world, where the
  terms RISC and CISC have lost their relevance
  (except to marketing departments and platform
  advocates). In a post-RISC world, each
  architecture and implementation must be judged on
  its own merits, and not in terms of a narrow,
  bipolar, compartmentalized worldview that tries
  to cram all designs into one of two "camps.
• http//www.arstechnica.com/cpu/4q99/risc-cisc/rvc-
  1.html (Hannibal)

24
Memory Addressing

• Addressing Memory how to specify and interpret
  memory address is important since all data are
  initially in the memory.
• Interpreting Memory Addresses
• All computers, except DSPs, are byte-addressed,
  providing access for bytes, half-words (2 bytes),
  words (4 bytes), and double words (8 bytes)
• Ordering bytes within a larger object 4 bytes in
  a word
• Little Endian
• Big Endian

• Alignment of bytes
• an access to an object of size s bytes at byte
  address A is aligned if A mod s 0.
• Memory is aligned on a multiple of a word or
  double-word boundary
• In general
• object larger than 1 byte must be aligned to
  reduce HW complexity

25
(No Transcript)
26
Addressing Mode

• How architectures specify an address of an object
  to be accessed
• Addressing mode can specify
• Constant
• Register
• Location in memory (effective address)
• See figure B.6
• PC-relative addressing a displacement mode using
  PC as register and used primarily for specifying
  code addresses in branches
• Complex addressing mode
• Reduce instruction counts a lot
• Add complexity (may increase the cycle time)
• Increase average CPI
• Know what modes to include is important

27
Figure B.6 addressing modes
28
What Addressing Modes are Common?

• Measure VAX using three SPEC89, which supports
  all Addressing modes in figure B.6
• Immediate and displacement dominate (not
  including PC-relative and register)
• See figure B.7

29
Figure B.7 summary of memory addressing mode
30
Immediate or Literal AM

• Use of immediate
• Arithmetic operations
• Comparisons (primarily for branches)
• Moves where a constant is wanted in a register
• Constants written in code (small)
• Add reg , 2
• Address constants (large)
• Need to know whether they need to be supported by
  all Ops or for only a subset

31
Frequency of Immediate for Different Instructions

• Very high in ALU and comparisons gt many are 0
• See figure B.9
• Data taken on Alpha architecture with full
  optimization for SPEC CPU 2000, integet CINT2000
  and FP CFP2000

32
Figure B.9 CINT2000 in SPEC CPU 2000
33
Range of Immediate Values

• Range affects instruction length
• Small values are most common
• Large values sometimes address calculations
• See figure B.10
• Data taken on Alpha architecture with full
  optimization for SPEC CPU 2000, integet CINT2000
  and FP CFP2000

34
Figure B.10 distributions of immediate values
35
Displacement Addressing Mode

• What ranges Displacement used?
• Various displacement sizes determine the length
  of the displacement field -gt length of
  instructions
• Displacement for data accesses (not branches)
• See figure B.8

36
Figure B.8 displacement values
37
Memory Addressing Summary

• Use a GPR machine a reg-reg one
• A new ISA at least support the following
  addressing modes
• Displacement
• Immediate 75-99 of AM
• Reg indirect
• Size of the address for displacement modes to be
  at least 12-16 bits gt 75-99 of displacements
• Immediate field is at least 8-16 bits gt
  capture 50-80 of immediates
