Database design with a relational model

1
Database design with a relational model

• Internal Level Physical Storage and Access

2
Ordered Files

• One field (attribute) selected for ordering
• If a key field, data is key-sequenced
• Allows binary searches for faster retrieval
  (always retrieves mid-page between upper and
  lower limits until correct page is found), since
  log2(B) blocks accessed
• Inserts and deletes require ordering to be
  maintained (may require writing all pages above
  affected record)
• Overflow (transaction) file will help to reduce
  this problem
• Typically only used if a primary index is applied
• No gain for non-ordered fields
• Typically requires indexed file access path

3
File storage Ordered with linked lists

• Assume one record/page (i.e., 5B/Fixed Block)
• Then
• Insert Dad
• Delete Geode
• Insert Pod

4
File storage Ordered with linked lists

• Assume one record/page (i.e., 5B/Fixed Block)
• Then
• Insert Dad
• Delete Geode
• Insert Pod

5
Hash Files

• Records written in non-sequential order
• Hash function calculates address of the page
  where record is stored
• based on a one or more base fields (hash field)
• If a key field, called hash key
• Hash function creates even spread of records
  across file
• Folding applies math to different parts of the
  has field (empID 0110 could become (01)10. 11
  is address of disk page
• Division-remainder uses mod 0110 mod 100. 10 is
  address of the disk page
• Can use
• Open addressing, Unchained overflow, Chained
  overflow, Multiple hashing, Dynamic hashing
• Limitations
• Useful for exact match
• Poor for ranges, patterns, additional fields

6
Hash Files

• Extendable hashing example
• A sequence of has function based on a single hash
  function
• Hashes a unique search-key value into a b-bit
  integer identifying page location
• For each k, 0 lt k lt b, hk(v) is the integer
  formed by the last k bits of h(v)
• This makes the range of each function twice its
  predecessor
• Buckets are created as needed
• A directory (Bucket Address Table) contains the
  depth (the number of bit positions used)
• Record can be found in two reads, with the first
  typically in memory
• No relational logic utilized

Depth 3
Depth 2
Depth 1
7
Indexes

• Ordered indices values in sorted fashion
• Hash indices values distributed across
  buckets by using a function
• An index record consists of a value and pointers
  to one or more records with that value. Can be
• Dense every value group indexed
• Sparse only some values are indexed
• Include
• Compound indexes (values from more than one data
  column)
• Covering index (uses values in the index for the
  SELECT clause)
• Unique index
• Clustering indexes (stores similar data rows near
  each other)
• Bitmap indexes (assigns 1 if a value is true, 0
  if false)

8
B-Trees

• Well established as the most common structures
  for indexes
• Multi-level
• d is the order of the tree it is a measure of
  the tree node capacity
• Every node except the root contains m entries,
  where d/2 lt m lt d
• The root node contains 1 lt m lt d entries
• Non-leaf nodes with m index entries contain m1
  pointers to children
• Pointer Pi points to a subtree with K values such
  that Ki-1 lt K lt Ki

9
B-Trees (order 2) one algorithm

• Query find all values with a pointer value of P
• If search value is lt SearchKey value, go left
  otherwise, go right

10
B Tree index/sequence sets
Index Set
Sequence Set
11
B Trees datapage leaf
Sort order Anizy,Apach,Apensen,Ardwick,Arnham,Ath
ens
12
B Tree Example

• Rules for this example
• d is the order of the tree it is a measure of
  the capacity of child nodes
• Every node except the root contains m entries,
  where d/2 lt m lt d
• The root node contains 1 lt m lt d entries
• Non-leaf nodes with m index entries contain
  between (m1)/2 and m1 pointers to children
• Pointer Pi points to a subtree with K values such
  that Ki-1 lt K lt Ki
• Search uses pointer to the right for greater than
  or equal to in non-leaf nodes, greater than in
  leaf nodes until equal to is found or not found

13
Records in a block

• How to store records in blocks?
• number of records r
• block size B
• record size R
• blocking factor bf number of records in a
  block
• Bf ?B/R? (spanned, unspanned)
• number of blocks needed b
• b ?r/bf?

14
B-trees performance impact

• A 4k page can many records per page
• ((4 b/pointer 4b/field)n, 4b/pointer) order
  of 512
• Root 511 records
• Level 1 261,632 records
• Level 2 133,955,584 records
• Total 134,217,727 records
• Shallow is better

15
B-trees performance impact

• 1,000,000 records of 300B (including header)
• Search key is a 4 byte int a pointer requires 4
  bytes
• 4KB blocks, no block header, random placement,
  avg. retrieval time 5.6 ms
• No time for memory reads
• 13.6 records/block 76924 blocks to store data
• 512 indexes/block 1954 blocks to store index
• No index
• (76924/2) 38462 block accesses (avg.)
• Time to find a record 38462 5.6 ms 215.4 s
• Indexed, binary search
• log(1954) 1 11 1 12 block accesses
  (maximum)time to find a record 12 5.6 ms
  67.2 ms
• Indexing increased speed by 3205 times.
