Database Management Systems

1
Database Management Systems Programming
LIS 558 - Week 2 Entity Relationship Modeling I

• Faculty of Information Media Studies
• Summer 2000

2
Class Outline

• Database Models
• Database Design Problems
• Conceptual Design Methodology
• Break
• Purpose of Data Modeling
• Entity-Relationship Design
• E-R Terminology
• Entity-Relationship Method Examples

3
Database Models

• A data model is the relatively simple
  representation, usually graphic, of complex
  real-world data structures. It represents data
  structures and their characteristics, relations,
  constraints, and transformations.
• The database designer usually employs data models
  as communications tools to facilitate the
  interaction among the designer, the applications
  programmer, and the end user.
• A good database is the foundation for good
  applications.

4
Database Models

• Two Categories of Database Models
• Conceptual models focus on the logical nature of
  the data representation. They are concerned with
  what is represented rather than how it is
  represented.
• Implementation models place the emphasis on how
  the data are represented in the database or on
  how the data structures are implemented.

5
Database Models

• Three Types of Implementation Database Models
• Hierarchical database model
• Network database model
• Relational database model

6
A Hierarchical Structure
7
Database Models

• Hierarchical Database Model
• Basic Structure
• Collection of records logically organized to
  conform to the upside-down tree (hierarchical)
  structure.
• The top layer is perceived as the parent of the
  segment directly beneath it.
• The segments below other segments are the
  children of the segment above them.
• A tree structure is represented as a hierarchical
  path on the computers storage media.

8
Database Models

• Hierarchical Database Model
• Advantages
• Conceptual simplicity
• Database security
• Data independence
• Database integrity
• Efficiency dealing with a large database
• Disadvantages
• Complex implementation
• Difficult to manage
• Lacks structural independence
• Applications programming and use complexity
• Implementation limitations
• Lack of standards

9
Database Models

• Network Database Model
• Basic Structure
• Set -- A relationship is called a set. Each set
  is composed of at least two record types an
  owner (parent) record and a member (child)
  record.
• A set is represents a 1M relationship between
  the owner and the member.

10
A Network Database Model
11
Database Models

• Network Database Model
• Advantages
• Conceptual simplicity
• Handles more relationship types
• Data access flexibility
• Promotes database integrity
• Data independence
• Conformance to standards
• Disadvantages
• System complexity
• Lack of structural independencem

12
Evolution of Conceptual Data Models
13
The Evolution of Conceptual Data Models

• Common characteristics required for data models
• A data model must show some degree of conceptual
  simplicity without compromising the semantic
  completeness.
• A data model must represent the real world as
  closely as possible.
• The representation of the real-world
  transformations (behavior) must be in compliance
  with the consistency and integrity
  characteristics of any data model.

14
Database Models

• Relational database
• Codd, E.F. (1970). A relational model for large
  shared data banks. CACM, 13(6), 377-87.
• First relational prototype - IBMs system/R
• Other variants, e.g., INGRES - UC, Berkeley
• 1983 IBM released DB2
• Relational databases required considerable
  computing resources (not feasible until mid-
  1980s)
• low end (Access, Paradox, dBase, FoxPro, Clipper)
• high end (DB2, Oracle, Sybase, Informix, INGRES
  commercial)

15
Database Models

• Relational Database defined
• Logical database model that treats data as if
  they are stored in separate two-dimensional but
  related tables
• Each table consists of data elements describing a
  common theme among which is one (or more)
  elements that uniquely describes each record in
  the table
• Tables are related as long as two tables share a
  common data element
• Information in these tables cam be combined on an
  as-needed basis to get answers to queries and
  generate complex reports

16
Database Models

• Advantages
• Mechanisms for minimizing data redundancy and
  inconsistency
• Logical database design is separated from
  physical aspects
• Relatively program-data independent
• Management of data for access, manipulation, and
  security
• Flexible mechanisms for generating reports and
  queries
• Program development and maintenance costs are
  reduced
• Data can be accessed in a multiplicity of ways
  within and amongst organizations
• Disadvantages
• Ease of use - many untrained people create and
  use databases without considering its design -
  usually incorporate many errors
• Processing resources required

17
The Relational Database Model
Agents
Instruments
Clients
Entertainers
Engagements
Entertainer styles

• represented by tables (like spreadsheets)
• tables are linked with software pointers
• unlike earlier systems, all three types of
  relationships can be represented
• accommodates the design of larger databases that
  involve complex relationships and intricate
  manipulations

18
Linking Relational Tables
19
Database Models

• Entity-Relationship Data Model
• It is one of the most widely accepted graphical
  data modeling tools.
• It graphically represents data as entities and
  their relationships in a database structure.
• It complements the relational data model concepts.

20
Database Models

• E-R model is commonly used to
• Translate different views of data among managers,
  users, and programmers to fit into a common
  framework.
• Define data processing and constraint
  requirements to help us meet the different views.
• Help implement the database.

21
Database Models

• Entity Relationship Data Model
• Basic Structure
• E-R models are normally represented in an entity
  relationship diagram (ERD).
• An entity is represented by a rectangle.
• Each entity is described by a set of attributes.
  An attribute describes a particular
  characteristics of the entity.
• A relationship is represented by a diamond
  connected to the related entities.

22
Database Models

• Three Types of Relationships
• One-to-many relationships (1M)
• A painter paints many different paintings, but
  each one of them is painted by only that painter.
• PAINTER (1) paints PAINTING (M)
• Many-to-many relationships (MN)
• An employee might learn many job skills, and each
  job skill might be learned by many employees.
• EMPLOYEE (M) learns SKILL (N)
• One-to-one relationships (11)
• Each store is managed by a single employee and
  each store manager (employee) only manages a
  single store.
• EMPLOYEE (1) manages STORE (1)

23
Relationship Depiction The ERD
24
Database Models

• Entity-Relationship Data Model
• Advantages
• Exceptional conceptual simplicity
• Visual representation
• Effective communication tool
• Integrated with the relational database model
• Disadvantages
• Limited constraint representation
• Limited relationship representation
• No data manipulation language
• Loss of information content

25
Introduction to Database Design

• Database schema defines databases structure,
  tables, relationships, domains, and constraint
  rules
• Tables
• BOOK (ISBN, Title, AuthID, PubID, Price)
• PUBLISHER (PubID, PubName, PubPhone)
• AUTHOR (AuthID, AuthName, AuthPhone)
• Relationships
• Each book is published by one and only one
  publisher
• Each publisher publishes one or more books
• Domains (set of values in a column)
• Physical description (e.g., set of integers 0 lt x
  lt 99999)
• Constraints (business rules)
• Price cannot be less than zero Author phone
  field cannot be left blank

26
Database Terminology

• Tables hold the data
• Database design is the process of separating
  information into multiple tables that are related
  to each other
• Single table designs work only for the simplest
  of situations
• Anomalies often arise in single table designs as
  a result of inserting, deleting, or updating
  records

27
Table
Users view their data in two-dimensional tables.

• table file relation

28
Field
The fields within records contain data. Data
within a field must be of the same data type.
Each field within a table must have a unique
name. Order of fields is unimportant.

• column field attribute

29
Record
A record is a group of related fields of
information about a single instance of one object
or event in a database. Tables consist of zero,
one, or more records. Order of rows is
unimportant.

• row record tuple

30
Data Dictionary and the System Catalog

• Data dictionary contains metadata to provide
  detailed accounting of all tables within the
  database.
• System catalog is a very detailed system data
  dictionary that describes all objects within the
  database.
• System catalog is a system-created database whose
  tables store the database characteristics and
  contents.
• System catalog tables can be queried just like
  any other tables.
• System catalog automatically produces database
  documentation.

31
Sample Data Dictionary
32
Keys

• A key helps define entity relationships.
• The keys role is based on a concept known as
  determination, which is used in the definition of
  functional dependence.
• The attribute B is functionally dependent on A if
  A determines B.
• An attribute that is part of a key is known as a
  key attribute.
• A multi-attribute key is known as a composite
  key.
• If the attribute (B) is functionally dependent on
  a composite key (A) but not on any subset of that
  composite key, the attribute (B) is fully
  functionally dependent on (A).

33
Keys

• Controlled redundancy (shared common attributes)
  makes the relational database work.
• The primary key of one table appears again as the
  link (foreign key) in another table.
• If the foreign key contains either matching
  values or nulls, the table(s) that make use of
  such a foreign key are said to exhibit
  referential integrity.

34
Indexes

• An index is composed of an index key and a set of
  pointers.

35
Relational Database Keys
36
Integrity Rules
37
Database Components

• Tables
• Queries
• Forms
• Reports
• Modules

38
Major Components of a Database Application
5. Program - used to automate a database
39
Levels of Database Representation

• Three levels of representation
• external - user views of data
• conceptual - abstract description of data
• internal - physical implementation access
  methods, index construction, data
  structures
• Starting point for design?
• Conceptual general description which is then
  represented in terms of the data contained in the
  database
• Conceptual level is primary focus of this course

40
A Logical View of Data

• Relational database models structural and data
  independence enables us to view data logically
  rather than physically.
• The logical view allows a simpler file concept of
  data storage.
• The use of logically independent tables is easier
  to understand.
• Logical simplicity yields simpler and more
  effective database design methodologies.

41
What is Relational Database Design?

• Relational Database Summary
• logical database model that treats data as if
  they are stored in separate but related tables
• Tables are related as long as two tables share
  common data element
• Information in these tables can be combined on an
  as-needed basis to retrieve answers to queries
  and to generate complex reports

42
What is Relational Database Design?
43
Why use a Relational Data Model Design?

• Small databases can easily be maintained as a
  single flat file (like a spreadsheet)
• For design of larger databases that involve
  complex relationships and intricate
  manipulations, a relational model is essential
• Originally the major limitation of relational
  model was memory and processing speed but this is
  no longer the case
• Relational design model resolves a number of
  potential problems

44
Database Design Problems

• Numerous anomalies can arise during the design of
  databases
• Redundancy
• Multi-valued problems
• Update anomalies
• Insertion anomalies
• Deletion anomalies

45
Database Design Problems

• Redundancy
• unnecessary repetition of data

46
Database Design Problems

• Multi-valued problems
• e.g., 1 - Add multiple rows, one for each value
• Data about a book must be repeated for as many
  times as there are authors of a book (also
  creates redundancy)

47
Database Design Problems

• Multi-valued problems
• e.g., 2 - Add multiple columns, one for each
  value
• How many columns for authors must be included in
  the design (empty fields waste space too)?

48
Database Design Problems

• Multi-valued problems
• e.g., 3 - Include all authors names in a single
  field
• How do you search for a single authors name or
  create an alphabetical list of authors

49
Database Design Problems

• Update Anomalies
• To update an authors telephone, each instance
  must be changed
• if we miss an item or enter it incorrectly we
  create an unreliable table
• sometimes previous errors propagate errors further

50
Database Design Problems

• Update Anomalies
• e.g., Consider the author Austen in the following
  table. What happens if we change her telephone
  number?

51
Database Design Problems

• Insertion anomalies
• What happens if we want to enter information
  regarding a publisher for whom we do not have
  book information?
• Do we add null values for the other fields?

52
Database Design Problems

• Deletion anomalies
• What happens if we delete all the book entries
  for a given publisher?

53
Database Design Problems

• Use of the relational database model removes some
  database anomalies
• Further removal of database anomalies relies on a
  structured technique called normalization
• Proper use of foreign keys is crucial to
  exercising data redundancy control
• Presence of some of these anomalies is sometimes
  justified in order to enhance performance

54
Class Outline

• Database Models
• Database Design Problems
• Design Exercise
• Break
• Database Design Methodology
• Purpose of Data Modeling
• Entity-Relationship Design
• E-R Terminology
• Entity-Relationship Method Examples

55
Characteristics of a Database designer

• Knowledge of the problem you are trying to solve
• Communication skills - extensive discussions with
  users
• Analytical aptitude - keep in mind the broad
  goals even while poring over the smallest details
• Impertinence - question everything!
• Impartiality - find best solution
• Relax constraints - assume anything is possible
• Pay attention to details and definitions
• Reframing - iteratively analyze in new way - be
  creative!

A good designer combines the art of design with
the science of design.
56
Conceptual Design Methodology
1. Define the problem and define database
objectives 2. Analyze current database, assess
user requirements, and create data
model 3. Design data structures (tables, fields,
field specifications, establish
keys) 4. Establish table relationships 5. Clarify
business rules critical to database design (e.g.,
required fields, validation rules) 6. Determine
and establish user views of data 7. Review data
integrity and reiterate design methodology
57
Statement of Purpose

• 1. Declare a specific purpose for the database to
  focus and guide its development
• e.g., The purpose of the All-Star Talent
  database is to maintain the data we use in
  support of the entertainment services we provide
  to our clientele.
• 2. Articulate goals objectives that define
  specific tasks
• We need to maintain complete entertainer
  information.
• We need to maintain complete customer
  information.
• We need to track all customer-entertainer
  bookings.
• We need to maintain financial records of both
  payments from customers and payments to
  entertainers.

58
Assessment of User RequirementsWhat is analyzed?

• interview transcripts
• meeting minutes
• observational notes
• business mission and strategy statements
• questionnaire results

• document analyses
• business forms
• reports
• flow charts
• presentations
• computer-generated output
• training manuals
• consultant reports
• job descriptions

59
Assessment of User RequirementsSpecific
requirements
Goals of analysis of user requirements collect a
list of business goals, entities to track, a
database schema, and sample report outputs.

• What are subjects/objects for the business?
• What characteristics describe each object?
• What unique characteristic distinguishes each
  object from other objects of the same type?
• How do you use this data (e.g, summary reports)?
• Over what period of time are you interested in
  this data?
• Are all instances of each object the same?
• What events occur that imply associations between
  various objects?
• Is each activity or event always handled the same
  way or are there special circumstances?

60
Rules for Conducting User Interviews

• Create a quiet, stress-free environment set a
  limit of six people
• Have an agenda - provide it to participants ahead
  of time
• Focus on the problem at hand maintain control of
  the interview
• Conduct separate interviews for users and
  management
• Identify the decision maker
• Avoid technical jargon
• Show concern for user needs
• Give everyone equal and undivided attention
• Write down everything where it can be seen by
  participants
• Encourage blue sky thinking
• Arbitrate disputes
• Keep the pace of the interview moving
• Dont foreclose your options too soon

61
Data Modeling

• A model is a simplified representation (usually a
  graphic) of a complex object in reality to make
  it understandable
• If the elements in the model are correctly
  associated with elements in reality, the model
  can be used to solve problems in reality (e.g.,
  engineers model to determine a bridges weight
  tolerance if the model is incorrect...)
• an ER model is integrated set of concepts that
  describes data, relationships between data, and
  the constraints on the data as they are used
  within a specific organization a data model
  renders organizations (users) view of objects
  and/or events and their associations
• ER model is a blueprint from which a
  well-structured database is created
• ER models are independent of details of
  implementation

62
Purpose of Data Modeling

• High level description
• integrated set of concepts that describes data,
  relationships between data, and the constraints
  on the data as they are used within a specific
  organization
• View of objects or events
• data model renders organizations (users) view
  of objects and/or events and their associations
• Representation of data in a simplified fashion
  that makes it understandable
• Once established, database design is relatively
  straightforward

63
E-R Modeling Concepts
Connectivity
Participation
Objects
Cardinality
64
Entities

• Entity
• Something that can be identified in the users
  environment about which we want to store data
  typically is a noun
• Entities or objects must have occurrences that
  can be uniquely identified
• Identified by an organization or its users
• Consists of tangible or intangible objects or
  events
• Entity Instance
• A single entity occurrence or instance within a
  collection of entities

e.g., STUDENT is an entity Annie Abel is an
entity instance as are Bob Brown and Cathy Chen.
STUDENT
65
Attributes

• properties that describe characteristics of an
  entity - assumed all instances of a given entity
  have the same attributes
• use atomic attributes, those that cannot be
  divided further (e.g., not composite attributes
  (e.g., use last name first name, not name)
• do not use derived attributes (attributes that
  can be calculated using other attributes e.g.,
  age)
• use single value attributes not multi-valued
  (e.g., medication1, medication2, etc.)
• multi-valued attributes, if they have their own
  important attributes should be elevated to
  entities

e.g., attributes of the entity STUDENT might
include name, address, etc.
last name
phone
STUDENT
birth date
first name
66
Identifiers

• Each entity occurrence has a unique identifier
• The identifier is an attribute (or group of
  attributes) that describes or identifies each
  entity occurrence
• An identifier should be unique to each occurrence
• Referred to as a primary key in relational
  models

e.g., in the list of potential attributes of the
entity STUDENT, the identifier could be Student
Number.
STUDENT
StudentID, ...
67
Relationships

• Association or connection between two or more
  entities
• Usually a verb
• HAS-A is also a common relationship(EMPLOYEE-has
  a-DEPENDENT)
• E-R model also contains relationship classes

StudentID, ...
CourseID, ...
68
Degree of Relationship Binary

• In a binary relationship, two entities are
  associated.
• This is the most common degree of relationship.

VACATIONER
EMPLOYEE
takes
works for
TRIP
DEPARTMENT
69
Degree of Relationship Ternary

• In a ternary relationship, three entities are
  associated.

70
Degree of Relationship Unary (Recursive)

• In a recursive relationship, one entity is
  associated with itself.

TEAM
COURSE
71
Recursive Relationships

• A relationship can exist between occurrences of
  the same entity set

72
(No Transcript)
73
Implementation of the MN Recursive PART
Contains PART Relationship
74
Implementation of the MN COURSE
Requires COURSE Recursive Relationship
75
Implementation of the 1M EMPLOYEE Manages
EMPLOYEE Recursive Relationship
76
Connectivity

• Connectivity describes constraints on
  relationship (also referred to as maximum
  cardinality)
• Number of instances of entity B that can (or
  must) be associated with each instance of entity
  A

1
M
rents
Child
Toy
One-to-Many
1
1
has
Employee
Office
One-to-One
M
N
sings
Musician
Song
Many-to-Many
77
Representing MN binary relationships

• MN relationships are represented by two 1M
  relationships.
• the relationship is itself an entity, called a
  composite entity (rectangle around the diamond)
• The composite entity often has its own attributes

M
N
enrolls in
CLASS
STUDENT
M
1
1
M
enrolls in
CLASS
STUDENT
Date
Mark
78
Cardinality

• Cardinality is the specific number of entity
  occurrences associated with one occurrence of the
  related entity
• often referred to as business rules because
  cardinality is usually determined by
  organizational policy

e.g., at a toy lending library, a given child may
not borrow any toys at all or they may borrow
more than one (up to 3) toys. A toy may not be
borrowed by anyone, or it may be borrowed by one
child.
1
M
Toy
borrows
Child
(0,3)
(0,1)
79
Occurrences Diagram

• Pictorial mapping of the occurrences between two
  entities assists in understanding connectivity
  and cardinality

C1 T1 C2 T2 C3 T3 C4 T4 C5 T5
C6 T6
A child may rent between 0 and 3 toys a toy may
only be rented by 0 or 1 child. One child may
rent many toys (1M)
80
Relationship Participation

• Also referred to as minimum cardinality
• Mandatory Participation
• An instance of a given entity must definitely
  match an instance of a second entity
• e.g., each student must enroll in exactly one
  course
• Optional Participation
• An instance of a given entity does not
  necessarily participate in the relationship
• lower bound of cardinality is zero
• e.g., a faculty member teaches zero, one, or two
  courses

1
N
makes
DONATION
MEMBER
(0,N)
(1,1)
OPTIONAL
MANDATORY
a member may or may not make a donation but a
donation must be associated with a member
81
Example Customers Orders

• From the CUSTOMER perspective
• a customer may make many orders (M orders of 1M
  connectivity)
• a customer does not necessarily make orders
  (optional participation of orders, cardinality is
  (0,N))
• From the ORDER perspective
• an order is made by (associated with) one and
  only one customer (1 customer of 1M
  connectivity)
• an order must be made by (associated with) a
  customer (mandatory participation, cardinality is
  (1,1))

82
Example Customers Orders
common field
parent table
related table
83
Entity-Relationship Design

• First step - develop a list of entities and
  attributes that are of interest to the enterprise
• Entities or objects must have occurrences that
  can be uniquely identified
• E-R Design consists of determining entities,
  attributes, relationships, relationship types,
  level of participation in relationships,
  identifiers, and then drawing an E-R Diagram
• E-R Diagram (model) is a blueprint from which a
  well-structured database is created

84
Steps in Entity-Relationship Modeling

• 1. Identify entities
• 2. Identify relationships
• 3. Determine relationship type
• 4. Determine level of participation
• 5. Assign an identifier for each entity
• 6. Draw completed E-R diagram
• 7. Deduce a set of preliminary skeleton tables
  along with a proposed primary key for each table
  (using rules provided)
• 8. Develop a list of all attributes of interest
  (not already listed and systematically assign
  each to a table in such a way to achieve a 3NF
  design (i.e., no repeating groups, no partial
  dependencies, and no transitive dependencies)

85
E-R Method Example Library Database

• Step 1. Identify entity types

• Step 2. Identify relationships

86
Library Database (contd)

• Step 3. Determine relationship type. Ask
• Each book is written by how many authors? Each
  author writes how many books?
• Each book may be authored by zero (anonymous),
  one, or more than one author and each author may
  write zero, one, or more than one book. The
  relationship type is many-to-many or

• For PUBLISHER-publishes-BOOK, each publisher
  publishes zero, one, or more books and each book
  is published by exactly one publisher. The
  relationship type is one-to-many where BOOKS is
  on the many side and PUBLISHER is one the one
  side.

87
Library Database (contd)

• Step 4. Determine level of participation
• Since each book does not have to be authored
  (anonymous) and since each author does not have
  to write a book (may make CD) the level of
  participation is optional for both sides of the
  relationship of AUTHOR-writes-BOOK combination

N

• For the PUBLISHER-publishes-BOOK combination, the
  level of participation for PUBLISHER is optional
  (publishers do not necessarily have to publish a
  book, perhaps newsletters) and the level of
  participation for the BOOK side is mandatory
  (each book must have a publisher)

1
N
(0, N)
(1,1)
88
Library Database (contd)

• Step 5. Assign an identifier for each entity
• AuthorID, ISBN, PublisherID
• Step 6. Draw completed E-R diagram

ISBN, ...
AUTHOR
BOOK
N
M
(1,1)
AuthorID, ...
N
(0,N)
(0,N)
1
(0,N)
PublisherID, ...
89
Library Database (contd)

• Step 6. Draw completed E-R diagram - resolve MN
  relationships

M
1
1
M
AUTHOR
BOOK
(0,N)
(0,N)
(1,1)
(1,1)
(1,1)
M
ISBN, ...
AuthorID, ...
AuthorID,ISBN, ...
(0,N)
1
PublisherID, ...
90
E-R Modeling University Example

• A database is to be set up to record information
  about faculty, the courses they teach, and the
  students who take courses. Some courses are
  taught by teams of faculty members.
• Step 1. Identify entity types

• Step 2. Identify relationships

91
University Example (contd)

• Step 3. Determine relationship type. Ask
• Each faculty member teaches how many courses?
• Each course is taught by how many faculty?
• Each student takes how many courses?
• Each course is taken by how many students?
• Use occurrences diagram to visualize relationship
  between entities

F1 C1 F2 C2 F3 C3 F4 C4 F5 C5 F6 C6
S1 C1 S2 C2 S3 C3 S4 C4 S5 C5 S6 C6
92
University Example (contd)

• Step 3. Determine Relationship type (contd)
• For FACULTY-teaches-COURSE we are told each
  faculty member teaches zero, one, or two courses.
  We are told some courses are taught by zero,
  one, two, or three faculty. This is a
  many-to-many relationship.

M
N
teaches
FACULTY
COURSE

• For STUDENT-takes-COURSE each student enrols in
  one to six courses and each course is taken by
  zero or up to 30 students. This too is a
  many-to-many relationship.

M
N
takes
STUDENT
COURSE
93
University Example (contd)

• Step 4. Determine level of participation
• FACULTY-teaches-COURSE - level of participation
  is optional, since sometimes Faculty do not have
  to teach (e.g., sabbatical) similarly, a course
  may not have anyone interested in teaching it

(0,2)
(0,3)

• STUDENT-takes-COURSE - level of participation is
  mandatory since students must take at least one
  course a course, however, may or may not have
  students taking it

94
University Example (contd)

• Step 5. Assign an identifier for each entity
• FacultyID, CourseID, StudentID
• Step 6. Draw completed E-R diagram

CourseID, ...
95
University Example (contd)

• You are now told that in addition to the
  relationships given, each student is assigned a
  faculty advisor who gives direction in choosing
  courses.
• Use occurrences diagram to visualize relationship
  between entities
• We are told each student is advised by exactly
  one faculty advisor. We can assume that each
  faculty member advises zero, one, or more
  students. This means the additional relationship
  is of type one-to-many or 1M.
• The STUDENT is on the many side of the
  relationship and must be advised therefore,
  faculty is mandatory to student FACULTY on the
  one side of the relationship may or may not have
  a student, therefore student is optional to
  faculty.

1
M
advises
STUDENT
FACULTY
(0,N)
(1,1)
96
University Example (contd)

• Step 6. Draw completed E-R diagram

97
Evaluation of the E-R Model

• Using data models to conceptualize the design of
  a database saves time and money because a
  completed E-R diagram is the actual blueprint of
  the database. Its composition must reflect an
  organization's operations accurately if the
  database is to meet that organization's data
  requirements.
• The completed E-R diagram also lets the designer
  communicate more precisely with those who
  commissioned the database design. Its easier to
  correct design flaws at the data modeling stage.
• Do not confuse entities and relationships with
  actual tables. The transformation or
  decomposition of E-R models will be discussed
  within the next few weeks.
• E-R modeling is an iterative process. Even when
  complete, ER models generally do not provide a
  complete picture (e.g., business rules cannot
  always be shown), therefore, much additional
  documentation is necessary.

98
Week 2 - Exercises 1-2
99
Week After Next

• More entity-relationship modeling exercises
• Transformation of E-R Models
• Read Rob Chapter 4
• Complete Adamskis tutorial 3
