Double Dirichlet Process Mixtures

1
Double Dirichlet Process Mixtures
Sanjib Basu
Northern Illinois University and Rush University
Medical Center
Siddhartha Chib
Washington University, St. Louis
2

• Dirichlet process mixtures are active research
  areas
• Dirichlet mixtures are it!
• The flexibility of DPM models supported its huge
  popularity in wide variety of areas of
  application.
• DPM models are general and can be argued to have
  less structure.
• Double Dirichlet Process Mixtures add a degree of
  structure, possibly at the expense of some degree
  of flexibility, but possibly with better
  interpretability in some cases
• We discuss applications (and limitations) of
  these semiparametric double mixtures
• We compare fit-prediction duality with competing
  models

3
Other DP extensions

• Double Dirichlet process mixtures are a subclass
  of dependent Dirichlet Process mixtures
  (MacEachern 1999,)
• Double DP mixture are different from Hierarchical
  Dirichlet Processes (The et al. 2006 )
• Double DPM is simply independent DPMS

4
Motivating Example 1

• Luminex measurements on two biomarker proteins
  from n156 Patients
• IL-1ß protein
• C-reactive protein
• The biological effects of these two proteins are
  thought to be not (totally) overlapping.

5
Two Biomarkers (y1 and y2)

• Usual DP mixture of normals (Ferguson 1983,..)

• Questions
• Should we model the two biomarkers jointly?
• Should we cluster the patients based on both
  biomarkers jointly?
• The biomarkers may operate somewhat independently.

6
Double DP mixtures

• Equicorrelation corr(y1i, y2i) are assumed to
  be the same for all i1,,n
• Clustering based on biomarker 1 and based on
  biomarker 2 can be different

7
Motivating Example 2 Interrater Agreement

• Agreement between 2 Raters (Melia and Diener-West
  1994)
• Each rater provides an ordinal rating on a scale
  of 1-5 (lowest to highest invasion)of the extent
  to which tumor has invaded the eye,n885

8
Interrater agreement

• Kottas, Muller, Quintana (2005) analyzed these
  data using a flexible DP mixture of Bivariate
  probit ordinal model which modeled the
  unstructured joint probabilities prob(Rater 1i
  and Rater2 j), i1,,5, j1,,5
• One way to quantify interrrater agrrement is to
  measure departure from the structured model of
  independence
• We consider a (mixture of) Double DP mixtures
  model here which provides separate DP structures
  for the two raters. We then measure agreement
  from this model.

9
Motivating Example 3

• Mixed model for longitudinal data

• It is common to assume (Bush and MacEachern 1996)

• Modeling the error covariance ?i or the error
  variance (if ?i diag(?2i)) extends the normal
  distribution assumption to normal scale mixtures
  (t, Logistic,)

10
Putting the two together

• One way to combine these two structures is

• Do we expect the random effects bi appearing in
  the modeling the mean and the error variances to
  cluster similarly?
• The error variance model often is used to extend
  the distributional assumption.

11
Double DPM

• I will discuss
• Fitting
• Applicability
• Flexibility
• Limitations
• of such double semiparametric mixtures
• I will also compare these models with usual DP
  models via predictive model comparison criteria

12
Dirichlet process

• Dirichlet Process is a probability measure on the
  space of distributions (probability measures) G.
• G Dirichlet Process (?G0), where G0 is a
  probability
• Dirichlet Process assigns positive mass to every
  open set of probabilities on support(G0)
• Conjugacy Y1,., Yn i.i.d. G, ?(G) DP(? G0)
  Then Posterior ?(GY) DP(? G0 nFn) where
  Fn is the empirical distn.
• Polya Urn Scheme

13
Stick breaking and discreteness

• G DP(? G0) implies G is almost surely discrete

14
Bayes estimate from DP

• The discrete nature of a random G from a DP leads
  to some disturbing features, such as this result
  from Diaconis and Freedman (1986)
• Location model
• yi ? ?i, i1,n
• ? has prior ?(?), such as a normal prior
• ?1,, ?n i.i.d. G G DP(G0) -
  symmetrized G0 Cauchy or t-distn
• Then the posterior mean is an inconsistent
  estimate of ?

15
Dirichlet process mixtures (DPM)

• If we marginalize over ?i, we obtain a
  semiparametric mixturewhere the mixing
  distribution G is random and follows DP(?G0)

16
DPM - clusters

• Since G is almost surely discrete, ?1,,?n form
  clusters
• ?1 ?5 ?8 ? ?1unique
• ?2 ?3 ?4 ?6 ?7 ? ?2unique etc.
• The number of clusters, and the clusters
  themselves, are random.

17
DPM MCMC

• The Polya urn/marginalized sampler (Escobar 1994,
  Escobar West 1995) samples ?i one-at-a-time
  from ?(?i ?-i, data)
• Improvements, known as collapsed samplers, are
  proposed in MacEachern (1994, 1998) where,
  instead of sampling ?i , only the cluster
  membership of ?i are sampled.
• For non-conjugate DPM (sampling density f(yi ?i
  ) and base measure G0 are not conjugate), various
  algorithms have been proposed.

18
Finite truncation and Blocked Gibbs

• With this finite truncation, it is now a finite
  mixture model with stick-breaking structure on qj

• (?1,....,?n) and (q1,....,qM) can be updated in
  blocks (instead of one-at-time as in Polya Urn
  sampler) which may provide better mixing

19
Comments

• In each iteration, the Polya urn/marginal sampler
  cycles thru each observation, and for each,
  assigns its membership among a new and existing
  clusters.
• The Poly urn sampler is also not straightforward
  to implement in non-linear (non-conjugate)
  problems or when the sample size n may not be
  fixed.
• For the blocked sampler, on the other hand, the
  choice of the truncation M is not well understood.

20
Model comparison in DPM models

• Basu and Chib (2003) developed Bayes factor/
  marginal likelihood computation method for DPM.
• This provided a framework for quantitative
  comparison of DPM with competing parametric and
  semi/nonparametric models.

21
Marginal likelihood of DPM

• Based on the Basic marginal identity (Chib 1995)
  log-posterior(?)log-likelihood(?)
  log-prior(?) - log-marginallog-marginal
  log-likelihood(?) log-prior(?)
  log-posterior(?)
• The posterior ordinate of DPM is evaluated via
  prequential conditioning as in Chib (1995)
• The likelihood ordinate of DPM is evaluated from
  a (collapsed) sequential importance sampler.

22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
Double Dirichlet process mixtures (DDPM)

• Marginalization obtains a double semiparametric
  mixturewhere the mixing distributions G? and
  G? are random

26
Two Biomarkers case y1 and y2
27
A simpler model normal means only

• We generate n50 (?i,?i) means and then (yi1,yi2)
  observations from this Double-DPM model

28
Double DPM
29
Single DPM in the bivariate mean vector
Double DPM in mean components
30
Model fitting

• We fitted the Double DPM and the Bivariate DPM
  models to these data.
• The Double DPM model can be fit by a two-stage
  Polya urn sampler or a two-stage blocked Gibbs
  sampler.
• Collapsing can become more difficult.

31
(No Transcript)
32
Wallace (asymmetric) criterion for comparing two
clusters/partitions

• Let S be the number of mean pairs which are in
  the same cluster in a MCMC posterior draw and
  also in the true clustering.
• Let nk, k1,..K be the number of means in cluster
  Ck in the MCMC draw.
• Then the Wallace asymmetric criterion for
  comparing these two clusters is

33
Measurements on two biomarker proteins by Luminex
panels

• Frozen parafin embedded tissues, pre and post
  surgery
• Luminex panel
• Nodal involvement

34
Two biomarker proteins

• The bivariate DPM

• vs the Double DPM

35
µpred
36
ypred
37
ypred
38
log CPO log f(yi y-i)
LPML log ?f(yi y-i) Double DP
-1498.67 Bivariate DP -1533.01
39
Model comparison

• I prefer to use marginal likelihood/ Bayes factor
  for model comparison.
• The DIC (Deviance Information Criterion) , as
  proposed in Spiegelhalter et al. (2002) can be
  problematic for missing data/random-effects/mixtur
  e models.
• Celeux et al. (2006) proposed many different DICs
  for missing data models

40
DIC3

• I have earlier considered DIC3 (Celeux et al.
  2006, Richardson 2002) in missing data and random
  effects models which is based on the observed
  likelihood

• The integration over the latent parameters often
  has to be obtained numerically.
• This is difficult in the present problem

41
DIC9

• I am proposing to use DIC9 which is similar to
  DIC3 but is based on the conditional likelihood

42
Convergence rate results Ghosal and Van Der
Vaart (2001)

• Normal location mixturesModel Yi i.i.d. p(y)
  ???(y-?)dG(?), i1,,n
  G DP(G0), G0 is Normal Truth
  p0(y) ???(y-?)dF(?)
• Ghosal and Van Der Vaart (2001) Under some
  regularity conditions, Hellinger distance (p,
  p0) ? 0 almost surely at the rate of
  (log n)3/2/?n

43
Ghosal and Van Der Vaart (2001) results contd.

• Bivariate DP location-scale mixture of normals
  Yi i.i.d. p(y) ????(y-?)dH(?,?),
  i1,,n H DP(H0)
• Ghosal and Van Der Vaart (2001) If H0 is Normal
  ?a compactly supported distn, then the
  convergence rate is (log n)7/2/?n
• Double DP location-scale mixture of normalsYi
  i.i.d. p(y) ????(y-?)dG?(?) dG?(?),
  i1,,n G? DP(G?0), G? DP(G?0)
• Ghosal and Van Der Vaart (2001) If G?0 is
  Normal, G?0 is compactly supported and the true
  density p0(y) ????(y-?)dF1(?) dF2(?) is also
  a double mixture, then Hellinger distance (p,
  p0) ? 0 at the rate of (log n)3/2/?n

44
Interrater data

• Agreement between 2 Raters (Melia and Diener-West
  1994)
• Each rater provides an ordinal rating on a scale
  of 1-5 (lowest to highest invasion)of the extent
  to which tumor has invaded the eye,n885

45
DPM multivariate ordinal model

• Kottas, Muller and Quintana (2005)

46
Interrater agreement

• The objective is to measure agreement between
  raters beyond what is possible by chance.
• This is often measured by departure from
  independence, often specifically in the
  diagonals
• Polychoric correlation of the latent bivariate
  normal Z has been used as a measure of
  association.
• of the latent bivariate normal
  mixtures???

47
Latent class model (Agresti Lang 1993)

• C latent classes

• Ratings of the two raters within a class are
  independent

48
Mixtures of Double DPMs

• For each latent class, we model pc1j and pc2k by
  two separate univariate ordinal probit DPM models

49
Computational issue

• The sample size nc in latent group c is not
  fixed. This causes problem for the
  polya-urn/marginal sampler which works with fixed
  sample size
• Do, Muller, Tang (2005) suggested a solution to
  this problem by jointly sampling the latent ?il
  (?il,?il2) and the latent rating class
  membership ?i.

50
Estimated cell probabilities
51
Marginal probability estimates

• Latent Group 1

52
Marginal probability estimates

• Latent Group 2

53
Joint mean covariance modeling

• Trial with n200 patients who had acute MI within
  28 days of baseline and are depressed/low social
  support
• Underwent 6 months of usual care (control) or
  individual and/or group-based cognitive
  behavioral counseling (treatment).
• Response y depression (Beck Depression
  Inventory) measured at 0,182,365,548, 913, 1278
  days (but actually at irregular intervals)
• Covariate Treatment, Family history, Age, Sex,
  BMI,
• Intermittent missing response, missing covariate.

54
(No Transcript)
55
Model

• Model for the mean

• Model for the covariance

• Pourahmadi (1999), Pourahmadi and Daniels (2002)
  use a Cholesky decomposition of the covariance
  which allows one to use log-linear model for the
  variances and linear regression for the
  off-diagonal terms

56
Modeling the covariance

• We assume

57
Mean and variance level random effects

• ? A joint DPM for the two random effects together
  which allows clustering at the patient level

• ? Or Double DPM, that is, independent DPM
  separately for the each of the two random effects
  which allows separate clustering at the mean and
  variance level

• Most frequentist and parametric Bayesian analyses
  use the latter independence among the mean and
  variance level random effects.

58
(No Transcript)
59
Fixed effects estimates
60
Pseudo marginal likelihood
61
Summary

• Double DP mixtures may add a level of structure
  to mixture modeling with DP.
• They produce interesting product-clustering
• They are applicable to specific problems that may
  benefit from this structure

62

• Thank you

basu_at_niu.edu
