BlueOX Energy Management

1
Blue-OX Energy Management

• TJ Chancellor
• Paul Cole
• Sara Habib
• Mira Kim
• Claudio Ramos
• Vicente Rosas

2
Benzene Hydrogenation Process
3
Project 3 Benzene Hydrogenation Process

• Purpose - provide an economic analysis for the
  benzene hydrogenation process.
• Objectives -
• Estimate the total fixed capital investment
• Estimate the annual product cost.
• Estimate the annual cash flow for the life of the
  project.
• Report profitability based on ROI, discounted
  cash flow, (NPW), and POT.
• NPW if products were sold at half or three times
  the price of cyclohexane.

4
Process Flow Diagram
5
Results
6
Annual Cash Flow
7
Annual Total Product Cost
8
Profitability
9
Recommendations

• If market value of cyclohexane falls below
  2.32/gallon the process should be discontinued.

10
Hydrogenation Process Fluid Flow Economics
11
Purpose

• Perform sensitivity analysis for the
  quantification of risk
• Determine the minimum price difference between
  the product and raw material
• Select material types for different piping
  section
• Determine pressure drops through the pipe network
  in order to determine if more pumps are needed
• Perform safety analysis for the suggested pipes
• Suggest insulation material and thickness
• Estimate the Fixed Capital Investment

12
Results
13
FindingsOptimized Pipe Network Insulation Total
Cost
14
FindingsOptimized Pipe Network Insulation Total
Cost Percentage less than the Non-optimized
15
Results

• For Non-optimized pipes the minimum price is
  1.44
• For the Optimized pipes network the minimum price
  drop 4 cents to 1.40
• Pressure Drop around the entire network was found
  negligible

16
Pressure Drops for Each Stream
17
Recommendations

• By using the nominal diameter suggested the
  company will save about 200,000 in the capital
  investment for the pipes
• Blue Ox determine that 2 inches thick rock wool
  insulation is the economical optimum
• Based on the simulation and calculation the
  pressure drop is negligible throughout the pipe
  network thus no new pump or compressor is
  necessary at this time

18
Heat and Material Balances and Pump Analysis
19
Heat and Material Balances and Pump Analysis

• Objectives
• solve heat and material balances for the process
  from Project 3
• select an appropriate material for the reactor
• determine the work needed at the pump for the
  pumping section of the process
• suggest a pump type
• create NPSHA vs. flow rate diagram
• system head vs. flow rate diagram
• estimate the Fixed Capital Investment for the
  pumping section.

20
Results

• Material Balance

Heat Balance
21

• Material
• Stainless Steel
• Reactor contains Hydrogen at high T and P
• Resistant to corrosion
• Ensures reactor safety longevity
• Pump
• Work Needed 5.06 kW
• Pressure Drop 38 psia
• Discharge Pressure 593 psia
• Type regenerative pump (turbine pump )

22
NPSHA and System Head vs. Flow Rate
23
Fixed Capital Investment for the pumping section

24
Heat Transport Equipment
25
Objectives

• Design heat exchanger E1 by hand (using Excel)
  and by simulation (using Pro/II).
• Choose materials for construction of the heat
  exchangers.
• Generate T-Q diagrams for each of the heat
  exchangers.
• Design a distillation column for the process.

26
Hand Design

• Double pass heat exchanger.
• Nominal Tube Size ½ inch
• Tube Length 16 feet
• Total Area 2117 ft2
• Fluid Flow Rate 4.73 m3/s
• Tube Side Pressure Drop 1.71 psi

27
Simulator Design

• Front End Stationary Head Channel and Removable
  Cover
• Shell Type Double Pass with Longitudinal Baffle
• Rear End Head U-Tube Bundle
• Shell Inside Diameter 8 inches
• Tubes per Shell 24
• Area 588ft2

28
(No Transcript)
29
(No Transcript)
30
(No Transcript)
31
Heat Exchanger Materials

• 304 Stainless Steel was chosen as the material
  for construction.
• Stainless steel was chosen because of the
  corrosive properties of methane and benzene.

32
Economics

• Price of a single heat exchanger 12,155
• Purchased Equipment (3 heat exchangers) 36,465
• Fixed Capital Investment 190,530

33
Distillation Column

• 28 Trays. 2 feet between trays. 5 feet for the
  top and bottom trays.
• Column Height 66 feet
• Tray Diameter 93 inches
• Condenser
• Reboiler
• Reflux Ratio 24
