CS457 Functional Dependencies

1

• CS457 Functional Dependencies
• and Normalization
• Chapter 10

2
 Relation Schema Goodness

• Logical level - relations and views
• Storage level - relations as files
•
•  Placing one set of attributes in a table is
  better than placing them in other tables. Why?

3
Schema design

• Design the schema so it is easy to explain the
  semantics
• semantics the meaning associated with the
  attributes
• want to minimize
• storage space
• redundant information

4
Informal Guidelines

• Semantics should be clear
• Reduce the redundant values
• Reduce null values
• Disallow spurious tuples

5
    Semantics

• Do not combine attributes from gt 1
  entity/relationship type Fig 10.3
• Reduce the redundant values
• Design schema so no anomalies occur
• Update anomalies insert, delete, modify
•

6
Updates

• Insertion
• if insert new employee into EMP_DEPT and no
  department yet? Fig 10.3
• If create a new department if no employee?
• If add employee in department?

7
Updates

• Deletion
• if delete last employee of a department?
• Modification
• if change the values of a particular
  department?
• Design schemas so no anomalies occur but what
  about performance?
• Must always do join between employee and
  department
• In general it is best if specify joins as views
  so anomaly free

8
Reduce null values

• Avoid placing attributes in a base relation
  whose values may be null for a majority of tuples
• If use null values can mean different things
• "fat" tuples - if many attributes and lots of
  nulls wastes space
• aggregate functions are a problem with nulls

9
Disallow spurious tuples

• Spurious tuples represent wrong information that
  is not valid
• Result of joins with equality conditions on
  attributes that are not PKs or FKs
• Design relations so there can be an equijoin with
  a PK and a FK or no spurious tuples
• Lossless join guarantees no spurious tuples
• Fig 10.5, 10.6 join on plocation

10
Functional Dependencies

• What is the most importance concept in relational
  schema design?
•     Functional Dependencies
• Formal concepts and theory to define goodness of
  relational schemas
• Functional dependency FD between 2 sets of
  attributes as
• X -gt Y
• Constraint on the possible tuples that can form a
  relation instance

11
 Functional Dependencies

• X -gt Y means
• X functionally determines Y
• Y depends on X
• Values of Y component depend on, determined
  by values of X component

12
Functional Dependencies

• Given t1 and t2
• if t1X t2 X then t1Y t2 Y (1)
• In other words if the values of X are equal, then
  Y value are equal
• Values of X component uniquely (functionally)
  determine values of Y component iff (1)

13
Example

• for example city, address -gt zipcode
• ssn -gt name
• if X is a candidate key implies X -gt Y
• if X -gt Y, does this imply Y -gt X?
• dont know - FD is a property of semantics
• dependency is a constraint
• if satisfy FD, instances are legal relation
  instances (extension)

14
FDs - set F

• describes a relation instance
• constraints must hold at all times
• property of relation schema not a particular
  extension
• therefore, it cannot be automatically deduced, it
  must be defined explicitly by designer

15
Normalization

• Normalization of data - method for analyzing
  schemas
• Unsatisfactory schemas decomposed into smaller
  ones with desirable properties
• Objectives of normalization
• good relation schemas disallowing update
  anomalies

16
Formal framework

• database normalized to any degree (1, 2, 3, 4, 5,
  etc.)
• normalization is not done in isolation
• need
• lossless join
• dependency preservation
• additional normal forms meet other desirable
  criteria

17
Normal Forms

• 1st, 2nd, 3rd, BCNF consider only FD and key
  constraints
• constraints must not be hard to understand or
  detect
• need not normalize to highest form (e.g. for
  performance reasons)

18
1NF - 1st normal form

• part of the formal definition of a relation
• disallow multivalued attributes, composite
  attributes and their combination
• In 1NF single (atomic, indivisible) values

19
Example

• There are 2 ways to look at
• DEPARTMENT (dnumber, dlocations) Fig.
  10.8
• dlocations is a set of values
• dnumber -gt dlocations, but dlocations is not in
  1NF
• dlocations atomic values
• dnumber does not functionally determine
  dlocations

20
How to resolve this?

• Nested relation - multivalued composite
  attributes Fig. 10.9
• research attempts to allow and formalize nested
  relations
• Oracle 9i allows it
• Normalize it to 1NF

21
Normalize into 1NF?

• How to normalize nested relations into 1NF?
• Remove nested relation (or set-valued) attributes
  into new relation
• propagate PK
• combine PK and partial PK
• recursively unnest - multilevel nesting
• useful in converting hierarchical schemes into
  1NF

22
 Difficulties with 1NF

• insert, delete, update
•  Determine if describe entity identified by PK?
• If not, called non-full FDs
• we need full FDs for good inserts, deletes,
  updates

23
 Second Normal Form - 2NF

• Uses the concepts of FDs, PKs and this
  definition
• An FD is a Full functional dependency if
• given Y -gt Z
• Removal of any attribute from Y means the FD does
  not hold any more

24
2NF

• Examples Fig. 10.10
• ssn, pnumber -gt hours
• is a full FD since neither
• ssn -gt hours nor pnumber -gt hours holds
• ssn, pnumber -gt ename is not a full FD
• (it is called a partial dependency)
• since ssn -gt ename also holds

25
2NF

• A relation schema R is in 2NF if
• Relation is in 1NF
• Every non-prime attribute A in R is fully
  functionally dependent on the primary key
• Definition Prime attribute - attribute that is
  a member of the primary key K
• R can be decomposed into 2NF relations via the
  process of 2NF normalization
• Remove partial dependencies
• create new relations where partials are full

26
2NF problems

• even if no partial dependencies problems with
  insert, delete, modify
• why?
• Transitive dependencies
• Given a set of attributes Z, where Z is not a
  subset of any key and
• X is a key
• Both X -gt Z and Z -gt Y
• then we have a transitive dependency Fig. 10.10b
•

27
 3rd Normal Form (3NF)

• No non-prime attribute is transitively dependent
  on a primary key and the table is in 2NF
• intuitively, this means we need independent
  entity facts steps for normalization
• disallow partial and transitive dependency on
  primary keys

28
Examples

• Examples Fig 10.10
• ssn -gt dmgrssn is a transitive FD since
• ssn -gt dnumber and dnumber -gt dmgrssn
• ssn -gt ename is non-transitive
• since
• there is no set of attributes X
• where ssn -gt x and x -gt ename
•

29
3NF

• A relation schema R is in 3NF if
• it is in 2NF
• no non-prime attribute A in R is transitively
  dependent on the primary key
• R can be decomposed into 3NF relations via the
  process of 3NF normalization

30
General Normal Form Definitions

• The above definitions consider the primary key
  only (can be gt 1 column)
• The following more general definitions take into
  account relations with multiple candidate keys

31
2NF

• A relation schema R is in 2NF if every non-prime
  attribute A in R is fully functionally dependent
  one every key (including candidate keys of R)
  Fig. 10.11
• County_name and lot are candidate keys

32
3NF

• Definition
• a superkey of relation schema R - a set of
  attributes S of R that contains a key of R
• A relation schema R is in 3NF if whenever
• X -gt A  holds in R
• then either
• a) X is a superkey of R or
• b) A is a prime attribute of R
• a) means every non-prime attribute is fully
  functionally dependent on every key
• b) means no transitive dependencies on any
  key Fig. 10.11

33
 Example of 3NF

• Example

34
Normal forms

• Each normal form is strictly stronger than the
  previous one
• every 2NF relation is in 1NF
• every 3NF relation is in 2NF

35
Goal

• The goal is to have each relation in 3NF
• Additional criteria may be needed to ensure the
  set of relations in a relational database are
  satisfactory
• lossless joins
• dependency preservation property

36
Additional normal forms

• 4NF - based on multi-valued dependencies
• No table may contain 2 or more 1N or NM
  relationships that are not directly related
• ename - gt pname, ename -gt dep_name
• 5NF - based on join dependencies as a way to
  decompose relations
• If cant decompose with lossless join into 2
  tables, decompose into 3 tables
• Join dependency Supplier, part, project
• Must join all of these to get a valid tuple

37
Decomposition

• Relational database schema design is synthesis
  and decomposition
• synthesis - grouping attributes together
• decomposition - avoiding transitive and partial
  dependencies
• strict decomposition - start with a universal
  relation
• OR
• ER model mapped to a set of relations
• Maps to 3NF

38
Good design

• A "good" design is not simple individual
  relations in a higher normal form
• also a set of relations with characteristics such
  as
• attribute preservation - each attribute appears
  once (at least)
• dependency preservation - each dependency is a
  constraint to enforce a join
• union of dependencies holds - does not guarantee
  a lossless join
