ForNet: A Distributed Forensic Network

1
ForNet A Distributed Forensic Network

• Kulesh Shanmugasundaram
• http//isis.poly.edu/projects/fornet/

2
Security Fails.
3
What Mechanisms Do We Have?

• Logging mechanisms and audit trails
• Alerts/Logs from security components
• Logs only perceived security threats
• Host Logs
• First thing to get disabled upon intrusion
• An insider would rather use a host without any
  logs
• Mobility, wireless networks create new problems
• Packet Logs
• Usually at the edges hence blinded easily
• Cant keep data for long
• E.g Infinistream, NFR, NetWitness, SilentRunner

4
What do we need?

• A reliable mechanism for analysis and
  attribution
• An effective response model
• Current response model is mostly manual
• Response time is in days or weeks
• Digital evidence disappears quickly
• Tools that complement security components
• Need some safety net to fall back
• Forensics is that net

5
Challenges Facing Network Forensics

• Lack of Infrastructure
• For data collection, archival, and dissemination
• Volume of Data
• Prolonged storage, processing, and sharing of raw
  data infeasible
• Even a network of 3000 hosts have a 1TB/day
  requirement!
• Process is Manual
• Spans multiple administrative domains
• Response times very long (digital evidence
  disappears)
• Unreliable Logging Mechanisms
• Host logs are usually compromised
• Growing support for mobility makes it difficult
  to maintain prudent logging policies on hosts

6
Our Solution

• Securely collect, store, disseminate, and process
  synopsis of network traffic.
• In other words a device analogous to a
  surveillance camera for the network. Even better
  a co-operating network of such surveillance
  cameras.
• Goal of Project ForNet development of tools,
  techniques, and infrastructure to aid rapid
  investigation and identification of cyber crimes

7
ForNet A Unified, End-to-End Approach to Network
Forensics
8
Design Goals and Trade-Offs

• Complete Correct Evidence
• Longevity
• Succinctness
• Accessibility of Evidence
• Security Privacy of Evidence
• Ubiquity
• Incremental Deployment
• Modular
• Scaleable Design

9
Research Challenges

• Legally admissible evidence
• Chain of custody
• Privacy

• High-speed packet capture
• Storage systems
• Databases
• GUI

• Secure architecture
• Attacks on ForNet
• Use of ForNet

• Identification of events
• Architecture of ForNet
• Query Routing
• Fault Tolerance

• Design of Synopses
• Quantitative Analysis

10
Components of ForNet

• Architectural components can be grouped under
  following functions
• Data Collection
• Data Retention
• Data Dissemination

11
Architecture of a SynApp
12
Synopses in ForNet
Currently being implemented
13
Architecture of Forensic Server
14
Forensic Server

• Forensic Server has the following functions
• Data archiving
• Query processing
• Policy management and enforcement
• Data Archiving
• Periodically receives data from SynApps
  archives them on disk.

15
Forensic Server (cont)

• Query Processor
• XML-based query language
• No relational databases (uses Berkeley DB)
• Does coalescence of synopses
• Given a query can locate appropriate synopses
• Generate and execute a query plan to answer the
  query
• Distributed query processing
• Currently being implemented to talk to nearby
  forensic servers to answer/corroborate
  queries/evidence
• Policy Enforcer
• Two types of policies in ForNet
• Monitoring Policy informs user of what is being
  monitored
• Privacy Policy informs user of how/with whom
  data is shared etc.

16
Architecture of Panorama

• A user interface for
• Building queries
• Data mining
• Visualization

17
Capturing Evidence on The Internet

• Internet is a gigantic state machine
• To support forensics we need to know its precise
  state at any given time!
• Therefore, we need to keep track of state
  transitions
• State transitions can be characterized by
• Links/connections between nodes
• Link content
• Protocol mappings and aliases
• Aggregates generated by state transitions

Archiving raw traffic for this information is an
overkill!
18
What is a Synopsis?

• Data structures and algorithms for representing a
  set of elements succinctly with predefined loss
  in information and has the ability to recall the
  original set of elements with a preset accuracy.

19
Properties of a Good Synopsis

• Contains enough data to answer certain classes of
  queries
• Who sent payload xyz?
• What did host bug.poly.edu send?
• Contains enough data to quantify confidence of
  its answers
• Im 99.37 sure bug.poly.edu sent XYZ
• Have small memory footprint and easy to update
• Need 20GB/day to keep 1TB/day of raw network data
• Need to compute two hashes per packet
• Resource requirements are tunable
• Can only afford 3GB/day, adjust the accuracy to
  accommodate this.

20
Advantages of Using Synopses
Can retain potential evidence for months!

• Succinct representation of raw data makes it
  possible to transfer network data to disks
• Sharing/transferring raw data over network is
  impossible but synopsis can be moved to remote
  sites
• Query processing would be expensive with raw data
• Whats the frequency of traffic to port 80 in the
  past week? (raw data vs. a histogram)
• Easily adaptable to various resource requirements
• Can adopt the size, processing requirements of a
  Bloom Filter based on various hardware resources
  and network load

Allows for cascading different techniques!
21
Cascading of Synopses
22
Packet Digests Bloom Filters

• Snoeren et. al. used it successfully in SPIE for
  single packet traceback (Hash-Based IP
  Traceback)
• Space Efficient
• 16-bits per packet (m/n16) and 8 hashes (k8)
  false positive (FP) 5.74 x 10-4
• No false negatives!
• However, suppose we dont have packets.
• We only have some excerpts of payload
• Dont know where the excerpt was aligned in the
  packet

Extend Bloom Filters to support excerpt/substring
matching
23
Block-based Bloom Filter
Insert each block into a Bloom Filter
24
H1(q00)1 H2(q00)1 H3(q00)0
X
q0q1q2 was seen in a payload at offset s
25
Offset Collisions
For query strings AD, CB, DR, AA etc.
BBF falsely identifies them as seen in the
payload!
Because BBF cannot distinguish between P1 and P2
26
Hierarchical Bloom Filter

• An HBF is basically a set of BBF for
  geometrically increasing sizes of blocks.

27
Hierarchical Bloom Filter

• Querying is similar to BBF.
• Matches at each level can be confirmed a level
  above.

28
Adapting an HBF for ForNet

• So far an HBF can attest for the presence of a
  bit-string in payloads
• We need to tie this bit-string to a source and/or
  destination hosts
• Our Approach
• Similar to tying an offset to a block/bit-string
• In addition to inserting (blockoffset) also
  insert (blockoffsethostid)
• Hostid could be (srcIPdstIP)

29
Coalescence of Synopses

• HBF requires
• Source IP, destination IP, excerpt
• But where do we get Source IP, Destination IP
• Connection Record/Neoflow
• Given two time intervals can give us list of
  source, destination IPs
• Coalesce these synopses

30
ForNet in Intranet Usage

• Investigation based on payload characteristics
• Determine victims of worm, trojans and other
  malware.
• Detection of potential victims of phising and
  spyware
• Source of IP theft
• Investigation based on connection characteristics
• Detection of zombies
• Detection of malware based on connection pattern
• Investigation based on aggregate characteristics
• Insider abuse
• Network resource abuse
• Etc Etc

31
ForNet Deployed on Internet

• Investigation based on payload characteristics
• Traceback based on partial content of single
  packets
• Source of malware, worms, etc.
• Investigation based on connection characteristics
• Stepping stone detection
• Investigation based on aggregate characteristics
• Attack attribution

32
Current Status

• Implemented a PC based SynApp device for
  placement within an intranet.
• Connection records, HBF, DNS, NewFlow, Mappings
• Implemented Forensics Server with simple querying
  capabilities.
• Current Forensic Server has 1.3TB of storage with
  over 3 months worth of data from the edge-router
  and two subnets
• Normal bandwidth consumption of network is about
  a 1 2 TB/day
• Synopses reduces this traffic to about 20GB/day
• A 4TB Forensic Server will take over operations
  in July
• Implemented Panorama (GUI Client)

33
Tracking MyDoom

• Recorded all email traffic for a week
• Using HBF and raw traffic
• Was not aware of MyDoom during this collection
• When signatures became available we used them to
  query the system
• To find hosts that are infected in our network
• How the hosts were infected
• Some statistics
• 679 hosts originated at least one copy of the
  virus
• 52 of which were in our network
• These hosts sent out copies of the virus to 2011
  hosts outside our network boundary

34
Analyzing MyDoom Infections
35
MyDooms Weekly Progress
36
Neoflow-NG

• Keeps track of everything Neoflow has plus
• Individual packet sizes
• Be able to recall the packet sizes in the same
  sequence
• Inter-arrival times of packets
• Be able to recall the arrival times of individual
  packets
• Content type of flow
• Be able to recall types of content carried by
  flows
• Audio, Video, Plain-Text, Encrypted, Compressed
  etc.

37
Investigating Network Resource Abuse
38
Total Network Bandwidth Composition
39
Detection of Network Proxies
40
Zombie Detection

• Are they any zombies in Poly network? And if so,
  how do we identify them?
• Criterion Hosts that portscan and use IRC at
  likely zombies.
• Tabulate the amount of IRC activity for each
  host.
• Tabulate the amount of portscan activity for each
  host.
• For each host ZOMBIE_LIKELIHOOD PORTSCANS
  IRC_FLOWS
• Sort all hosts by their ZOMBIE_LIKELIHOOD.
• List the top 200 hosts.

41
Work currently in progress

• Identification of useful network events
• Network is the virtual crime scene that holds
  evidence in the form of network events
• Developing efficient synopses
• Handling connection oriented connectionless
  traffic
• Techniques for payload attribution (esp. IRC/IM)
• Automatic cascading of various synopsis
  techniques
• Analysis and mining techniques
• Zombie detection
• Stepping stone detection

42
Work currently in progress

• Integration of information from synopses across
  networks
• Development of a protocol for secure
  communication of various ForNet components
• Query processing and storage of synopses
• A query language transparent of various
  underlying synopsis techniques
• A query manage system to interpret the language
  for the underlying database
• Various storage and garbage collection strategies
  for collected-SynApps
• Storage and query processing infrastructure for
  Forensics Servers

43
Research Challenges

• Integration of information from synopses across
  networks
• Real power of ForNet is realized when information
  from SynApps is fused to answer queries
• Development of a protocol for secure
  communication of various ForNet components
• Query processing and storage of synopses
• A query language transparent of various
  underlying synopsis techniques
• A query management system to interpret the
  language for the underlying database
• Analysis
• A frame-work to compare effectiveness/trade-offs
  of synopses

44
Attacks on ForNet

• Resource Exhaustion
• Flood the network with random bits of data
• Malicious Transformation
• Create packets of length (blocksize 1)
• Stuffing
• Stuff every other block with application
  dependent escape characters
• For smaller blocks we can try to guess for larger
  blocks it is not possible!
• Exploiting Collisions
• Hash collisions
• Very unlikely for strong hash functions
• We use a random seed for every HBF so it makes it
  more difficult
• Packet collisions
• A possibility in Block-based Bloom Filters but
  not in HBFs
• Streaming transformations
• Encryption, compression

45
For more information visit http//isis.poly.edu/p
rojects/fornet/
