Lecture 23 Chapter 12 HumanComputer Interaction Cont.

1
Lecture 23Chapter 12 - Human-Computer
Interaction - Cont.
2
Document Metaphor

• A metaphor of HCI in which interaction with the
  computer involves browsing and entering data on
  electronic documents
• These documents are much like printed documents,
  but because they are in electronic form,
  additional functionality is available to make
  them more interactive
• Hypertext
• Documents that allow the user to click on a link
  and jump to a different part of the document or
  to another document
• Hypermedia
• Technology that extends the hypertext concepts to
  include multimedia content such as graphics,
  video and audio
• World Wide Web is organized around document
  metaphor
• Using HTML (hypertext markup language)
• Based on document metaphor and browser interface

3
(No Transcript)
4
The Dialog Metaphor

• A metaphor of HCI in which interacting with the
  computer is much like carrying on a conversation
  or dialog
• User interface design is often referred to as
  dialog design
• Carrying on a dialog means that each person is
  listening to and responding to questions and
  comments from the other, exchanging information
  in a sequence
• The dialog metaphor is a way of thinking about
  HCI since the computer listens to and responds
  to questions or comments from the user, who
  listens to and responds to questions and
  comments from the computer
• Like the direct manipulation metaphor, the dialog
  metaphor since communication involves messages
  from one object to another

5
(No Transcript)
6
Dialog metaphor (continued)

• Example of a dialog between a manager and an
  assistant
• Manager Did I get any messages while I was out?
• Assistant Yes, you have three messages from
  Bob, Mary and Lim
• Manager What did Lim have to say?
• Assistant Lim left a message at 815 pm last
  night regarding the meeting next Monday about the
  inventory management system.
• Manager I better respond. Say that the change
  is not a problem
• Assistant Okay, Ill leave him that message. Do
  you want the next message?

7

• The dialog on the previous slide involves
• A question
• A response
• Another questions
• A response that might include a request for
  clarification
• Etc.
• Not unlike a dialog you carry out with a computer
• The assistant in the example could have been
  computer application running an intelligent
  assistant
• Like an email application
• The user selects a menu item (e.g. read new mail)
• The computer lists the new mail messages
• If the user selects one, the computer displays it
• Etc.

8

• The user and the computer both send messages
• But each is forced to use a different language
• The computer has to adapt to the user and provide
  its messages in a form that is natural to the
  user (text and graphics)
• Similarly the computer cannot understand complex
  voice messages (although research in speech
  recognition is progressing)
• Computer advances are improving things but the
  typical user interfaces today still rely on mouse
  and keyboard
• Next slide shows the dialog between manager and
  assistant transformed into the languages used by
  the user and the computer
• Interface designers use a variety of informal
  diagrams and written narratives to model
  human-computer interaction next slide is one
  example

9
(No Transcript)
10
Interface Design Guidelines

• Many interface design guidelines have been
  published to help system developers
• Range from general to very specific rules
• System design standards
• General principles and rules that must be
  followed for the interface of any system
  developed by the organization
• Helps to ensure that all user interfaces are
  usable and all systems developed by the
  organization have a similar look and feel

11
Visibility and Affordance

• Two key principles to ensure good human-computer
  interaction (Donald Norman)
• Visibility
• A key principle of HCI that states all controls
  should be visible (so users know its
  availability) and provide feedback to indicate
  the control is responding to the users actions
• E.g. a button that can be clicked should be
  visible, and when it is clicked should look like
  it has been pressed to indicate it is responding
• Affordance
• A key principle of HCI that states that the
  appearance of any control should suggest its
  functionality
• e.g. a button affords clicking, a scroll bar
  affords scrolling, an item in a list affords
  selecting etc.
• Applies to objects on the desktop

12
Implications for designers

• If designers make all controls visible and clear
  more likely the interface will be usable
• Most users are now familiar with Windows user
  interface and common Windows controls
• These principles should also be applied carefully
  to design of web pages, where there are new types
  of controls and possible designs of interfaces
  (not standardized)

13
Eight Golden Rules

• Ben Shneiderman proposes eight underlying
  principles applicable to most interactive systems
  (and key to usability)
• Strive for consistency
• Enable frequent users to use short cuts
• Offer informative feedback
• Design dialogs to yield closure
• Offer simple error handling
• Permit easy reversal of actions
• Support internal locus of control
• Reduce short-term memory load

14
1. Strive for Consistency

• Information arranged on forms, the names and
  arrangement of menus, the size and shape of icons
  etc. should be consistent throughout the system
• This allows for many actions to become automatic
• If a new application comes along with a different
  way of functioning have to relearn all the basic
  operations
• Apple Macintosh was first to emphasize the
  benefits of consistency
• Mac applications were consistent and a standards
  document was created for people writing Mac
  applications (so if you knew one you could figure
  out other applications easily since they were
  consistent)
• E.g. consistency in the menu bar for File, Edit
  and Format
• However some applications may not fit such
  guidelines and inconsistency may be useful for
  differentiating applications (for running and
  learning)

15
2. Enable Frequent Users to Use Short Cuts

• Users who work with one application all the time
  are willing to invest time to learn short cuts
• They begin to lose patience with long menu
  sequences when they know exactly what they want
  to do
• Short-cut keys can reduce the number of
  interactions for a given task
• Designers can provide macro facilities for users
  to create their own short cuts
• E.g. mail order entry clerks at RMO wouldnt want
  long multiple menus to slow them down, but
  instead short-cuts would make them more productive

16
3. Offer Informative Feedback

• Every action a user takes should result in some
  type of feedback from the computer
• Eg. If the user clicks a button it should
  visually change and perhaps make a sound to
  indicate it has responded
• Feedback of information to the user is also
  important
• E.g. if a mail-order clerk enters a customer ID
  number in the screen, the computer should display
  the name and address for confirmation by the
  clerk
• E.g. if the clerk enters a product ID for the
  order, the system should display a description of
  the product

17
4. Design Dialogs to Yield Closure

• Each dialog with the system should be organized
  with a clear sequence (with a beginning and an
  end)
• Reading ones email
• If the system requirements are defined as events
  to which the system responds, each event leads to
  processing of one specific, well-defined activity
• Traditional approach
• Each activity is defined by data flow diagrams
  and structured English
• Object-oriented approach
• Each activity (a use case) might be further
  defined as multiple scenarios, each with a flow
  of events

18
5. Offer Simple Error Handling

• Errors can be costly so designers must try to
  prevent users from making errors
• Chief way is by limiting available options and
  allowing user to choose from valid options at any
  point in the dialog
• Adequate feedback also reduces errors
• When errors occur need ways to handle it
• Error messages should state specifically what is
  wrong and explain how to create it
• Avoid message that scare or blame the user
• e.g. FATAL ERROR 2001
• Also provide information that makes it easy to
  correct the error
• e.g. The date of birth entered is not valid.
  Check to be sure only numeric characters in
  appropriate ranges are entered in the date of
  birth fields

19
6. Permit Easy Reversal of Actions

• Users need to feel that they can explore options
  and take actions that can be canceled or reversed
  easily
• Allows users to learn about the system by
  exploring
• If they make a mistake, they can cancel the
  action
• Should include cancel buttons on all dialog boxes
• Also if user is going to delete something
  substantial (e.g. a file) the system should ask
  the user to confirm the action

20
7. Support Internal Locus of Control

• Experienced users want to feel they are in charge
  of the system and the system responds to them
• They should not be forced to do anything or made
  to feel the system is controlling them
• Much of this comfort and control is provided by
  the wording of prompts and messages
• Writing out a dialog (like example we saw) can
  help to lead to such a design

21
8. Reduce Short-Term Memory Load

• People have short-term memory limitations
• People remember only about seven chunks of
  information at a time
• Interface designer cannot assume the user will
  remember anything from form to form, or dialog
  box to dialog box
• If user has to stop and ask Now what was the
  filename? The customer ID? then the design is
  placing a burden on the users memory

22
Visibility and Affordance

• Two key principles to ensure good human-computer
  interaction (Donald Norman)
• Visibility
• A key principle of HCI that states all controls
  should be visible (so users know its
  availability) and provide feedback to indicate
  the control is responding to the users actions
• E.g. a button that can be clicked should be
  visible, and when it is clicked should look like
  it has been pressed to indicate it is responding
• Affordance
• A key principle of HCI that states that the
  appearance of any control should suggest its
  functionality
• e.g. a button affords clicking, a scroll bar
  affords scrolling, an item in a list affords
  selecting etc.
• Applies to objects on the desktop

23
Eight Golden Rules

• Ben Shneiderman proposes eight underlying
  principles applicable to most interactive systems
  (and key to usability)
• Strive for consistency
• Enable frequent users to use short cuts
• Offer informative feedback
• Design dialogs to yield closure
• Offer simple error handling
• Permit easy reversal of actions
• Support internal locus of control
• Reduce short-term memory load

24
Application of Rules in Usability Engineering

• Can use guidelines, like the rules above to
  create coding schemes for analyzing video tapes
  of users interacting with systems
• Can also use them for usability inspection
• Usability inspection involves walking through
  an interface to see if there are problems or
  things that could be improved
• Usability inspector (analyst) conducts the
  walkthrough
• For example, try stepping through a web site and
  evaluating (which allows direct customer
  ordering) in terms of the following (see the
  assignment)
• Visibility
• Affordance
• The eight rules above
• Can evaluate sites in terms of these criteria and
  note problems with the interface (and areas for
  improvement)

25
Documenting Dialog Designs

• There are many techniques to help design dialogs
• These are used to create a menu hierarchy
• Allows the user to navigate each diaglog
• Storyboards, protoypes and UML diagrams can be
  used to complete the design

26
Events, Subsystems and Menu Hierarchy

• In chapter 11 we saw how inputs and outputs are
  obtained from data-flow diagrams (traditional
  approach)
• Also saw how how inputs and outputs were obtained
  from sequence diagrams (OO approach)
• Each input obtained interactively from a user
  requires a dialog design
• Each output produced at the request of a user
  also requires a dialog design
• Events documented early in analysis are key to
  listing needed dialogs (external events are
  triggered by inputs and temporal events produce
  outputs)

27

• Dialog design must be done simultaneously with
  other design activities
• Traditional approach
• Structure charts for each subsystem (transaction
  analysis) includes details about menu structure
  of the interactive parts
• Structure chart for each event (transform
  analysis of each DFD fragment) also includes
  details about the dialog
• OO approach
• Sequence diagrams and collaboration diagrams
  contain details about the dialog

28
Menu Hierarchy

• From the standpoint of the user, the overall
  system structure is reflected in the menus
  available
• Each menu contains a hierarchy of options, and
  they are arranged by sub-system or by actions on
  objects
• RMO example includes
• Order entry subsystem
• Order fulfillment subsystem
• Customer maintenance subsystem
• Catalog maintenance subsystem
• Reporting subsystem
• Alternatively, menus could be arranged based not
  on subsystems but on objects
• Customers
• Orders
• inventory, and shipments

29
Menus continued

• Sometimes several versions of the menus are
  needed based on type of user
• E.g. mail-order clerks at RMO do not need to know
  many of the options available since they only
  process new orders
• Menus should also include options not in the
  event list
• E.g. options related to controls (see Chapter 11)
• Backup and recovery of databases
• User account maintenance
• User preferences are usually provided to allow
  the user to tailor the interface
• Menus should always include help facilities
• See next slide for the menu hierarchy for RMO
  customer support system

30
(No Transcript)
31

• A dialog design is created for each menu option
  (e.g. for each menu option on previous slide)
• After completing the dialog design for all
  options, the designer can define the structure of
  the menus for different types of users
• Menu hierarchies can be rearranged easily as the
  design evolves
