Data Replication in OceanStore Dennis Geels UC Berkeley

1
Data Replication in OceanStore - Dennis
Geels UC Berkeley

• Vijay Shiv Kumar

2
Talk Outline

• Introduction to OceanStore
• Replication Approach
• System overview
• Replication subsystem design
• Evaluation and results
• Conclusions and future work

3
Introduction to OceanStore

• A utility infrastructure to span the globe
  and provide continuous access to persistent
  information
• Global-scale storage system
• Designed to support billions of users and
  exabytes of data.
• Utility model No single entity must own or
  control all the machines in the network.
• Does not entrust privacy or integrity of user
  data to any server.

4
Introduction to OceanStore

• Machines communicate using an overlay network
  named Tapestry.
• Each machine has its own GUID.
• Client applications access OceanStore through a
  local daemon process.
• Client machines interact with the inner ring
• Serializes and processes client requests
• Uses a Byzantine-fault-tolerant protocol
• High-bandwidth connections

5
(No Transcript)
6
Why Replication ?

• Only clients and inner ring servers
• Servers have limited CPU, storage and network
  resources.
• Inner ring becomes a bottleneck.
• Some clients may have high access latency
• High availability (even in presence of network
  outages etc.)

7
Replication Approach

• Automatically creates and maintains soft-state
  replicas of data near or on client machines.
• Replicas cooperate to share data and disseminate
  updates efficiently. No compromise on security
  and consistency guarantees.
• Flexible read interface
• Applications can relax data consistency in
  exchange for improved performance
• Supports retrieval of arbitrarily old versions of
  client data (time travel)

8
System overview Data Object Format

• OceanStore is a versioning storage system
• Data Object ordered sequences of read-only
  versions
• Entire stream of versions of a given object is
  named by its AGUID (secure hash of owners key
  application id)
• Each version is named by its VGUID (hash of
  contents)

9
Data Object Format

• For larger versions, data is stored in a B-tree
  structure.
• Individual read-only blocks are stored
  independently and are named by their BGUIDs.
• Allows for sharing of blocks.

10
Data Object

• Heartbeat Mapping between AGUID and latest VGUID

11
System Overview Client Requests

• Heartbeat Requests
• To learn the VGUID of the latest version
• Update Requests
• Must go to the inner ring
• Predicate-based update interface (Bayou)
• Greater flexibility, wide range of consistency
  semantics
• e.g. Current version of data object matches a
  specified VGUID.
• List of ltpredicate, actiongt pairs.
• Signed update response includes a heartbeat
  naming the new version.

12
Client Requests

• Read Requests
• Need not go to the inner ring
• Read responses need not be signed (Client can
  verify the versions contents against the
  requested VGUID).
• Rich predicate-based read interface
• Client needs
• AGUID of data object
• User-level description of the desired portion of
  the data.

13
Replication system design

• Replicas are created on available servers near
  the clients or on the clients themselves
  (Promiscuous caching).
• Design involves a second-tier with two main
  additional components
• Secondary Replica Store copies of data objects
  and process heartbeat/data requests
• Dissemination tree Multicast tree to propagate
  updates/requests among replicas

14
(No Transcript)
15
Secondary Replica

• Data stored is purely soft-state. Easily
  verifiable.

16
Dissemination Tree

• Multicast trees
• Rooted at the primary replica
• Heartbeats, Update / Read
• Certificates, requests
• Updates
• New replicas join the tree by sending a request
  addressed to replica label.
• Periodic rejoining may shrink trees height but
  will never increase it.

17
Dissemination Tree
18
Creating Replicas

• New replicas created on client machine when a
  client application first reads a data object.
• Machine joins the dissemination tree, using a
  join-tree request.
• Can also be created on nearby machines.
• Client sends requests with a TTL parameter.
• If TTL expires before replica found, then last
  machine creates replica (as a proxy).

19
Updating Replicas

• Primary replicas forward down the tree
• heartbeat verifying new versions VGUID,
• Successful action from the update
• VGUID for the previous version
• Each secondary replica
• Checks for the correct initial version
• Applies the update locally
• Verifies that new VGUID matches heartbeat

20
Updating Replicas
21
Reading a Replica

• Clients specify
• AGUID of data object to be read
• Version predicate (Restrictions on versions)
• Most recent version as of certain time
• Sequence number in a specified range
• Selection
• Range of bytes to read, once a version is chosen
• Failure Mode
• Specify behavior of replica if request cannot be
  fully satisfied locally.

22
Reading a Replica
23
Reclaiming resources

• Machines may remove replicas when
• they fall out of use
• resources are needed for more important tasks
• Remaining children in the dissemination tree are
  notified
• they reconnect elsewhere
• Local replica being soft-state, is simply thrown
  away.

24
Evaluation - Benchmarks

• To simulate data sharing among collaborating
  users
• Several clients open the same data object
• Concurrently submit R/W requests for 5 min.
• Wait 5 seconds between requests
• Use this benchmark to measure the effect of local
  replication on client read latency.
• To simulate single-source streaming data
• Single writer repeatedly overwrites portions of a
  data object, with zero think time between updates
• Many readers continually query their local
  secondary replica for the latest version of the
  data object. When they detect a new version, they
  reread the object.
• Use this benchmark to measure the latency of
  update propagation in a dissemination tree.

25
Evaluation - Infrastructure

• Testbed Local cluster of 42 machines at UCB
• Multiple OceanStore machines on each real machine
• Simulated operation in a wide-area network using
  an artificial transit-stub network (?) of 495
  nodes
• Inter-domain latencies of 150 ms
• Local-area latencies of 10-50 ms
• Inner ring servers placed on well-connected nodes
  in different domains
• One hundred other nodes distributed randomly
  throughout the network.

26
Results
27
Results
28
Results
29
Conclusion

• The replication system effectively reduces client
  read latency.
• The self-organizing dissemination trees propagate
  new data quickly and efficiently except in cases
  where write traffic is high.
• The need for versioning and cryptography support
  limits the scope of work
• Should be easily portable to other P2P storage
  systems which support signed, mutable data objects

30
Future Work

• Include selection clause in update format and in
  the dissemination tree lease
• Better replica management based on user activity
• Better cache management by the replica stage
• Extend second tier to perform in the absence of
  primary tier
• Better heuristics for dissemination tree joining
• Piggy-back a read request onto the join-tree
  request

31
QUESTIONS
