Residential Irrigation Water Conservation

1
Residential Irrigation Water Conservation

• A Homeowner Cooperation Project

2
Residential Irrigation Water Conservation Study

• Funded by
• Southwest Florida Water Management District
• Pinellas County Utilities
• UF-IFAS
• Agricultural and Biological Engineering
• Environmental Horticulture

3
The Importance of this Study

• Studies have shown that residential lawn and
  landscape irrigation can account for more than
  50 of a home's total water use.
• Recent research in Florida has indicated that
  homeowners over irrigate.

4
The Importance of this Study

• Adding a rain sensor or soil moisture sensor to
  your existing time-based automatic in-ground
  irrigation system can dramatically decrease
  irrigation water consumption!

5
Experimental Design

• 64 Homes
• divided into 4 locations within Palm Harbor
• Four Treatments (at each location)
• Current irrigation system with rain sensor
• Current irrigation system without rain sensor
• Current irrigation system without rain sensor and
  with a soil moisture controller
• Current irrigation system with rain sensor and
  with educational materials

6
Experimental Procedure

• Conduct irrigation audit
• Equipment check
• Controller operation
• Catch-can test to determine system uniformity
• Measure irrigated area
• Track turf quality
• Monitor water usage
• Install irrigation water meter
• Install rain sensor (if applicable)
• Install soil moisture sensor (if applicable)

7
Irrigation Water Meter

• Installed in ground after utility meter
• Measures volume of water used by irrigation system

All 64 homes will receive this.
8
Uniformity Measurement
All 64 homes will receive this.
9
Rain Sensor

• The rain sensor will bypass (turn off) the
  irrigation system after a rain event to prevent
  over-irrigation.
• The precipitation amount must be above a set
  threshold to bypass the irrigation.
• The sensor attaches at the roof line and is less
  than 2 in height.

32 of the homes will receive this type of
sensor.
10
Soil Moisture Sensor

• A soil moisture sensor is buried in the turf root
  zone. This sensor can bypass the time-based
  irrigation system based on soil moisture content.

• The soil moisture must be above a set threshold
  to bypass the irrigation.
• Controller box mounted near irrigation system
  controller

16 of the homes will receive this type of
sensor.
11
Soil Moisture Sensor Installation
12
Soil Moisture Sensor Installation
13
Irrigation Term Field Capacity

• Only the water applied to the lawn until the
  irrigated area reaches saturation (field
  capacity) is beneficial.
• Therefore, any additional water applied cannot
  be used by the lawn.
• If the lawn is at field capacity additional
  irrigation is unnecessary, it will not effect how
  long the ground is saturated.
• The sensors detect when the has been sufficient
  rain or that the soil moisture content is at
  field capacity.
• Imagine the root zone of your lawn as a
• glass filled with waterpouring more in will
• not keep it full any longer. The sensors
• detect when the glass is full.

14
What if my lawn is not at Field Capacity on the
day I irrigated?

• If the soil moisture sensor or the rain sensor do
  not detect the moisture level to be at the
  threshold with is set to represent field
  capacity, then
• the irrigation system will run as usual.
• The irrigation system will only be bypassed if
  the moisture level is above the set field
  capacity threshold.

15
Benefits to Homeowner

• More than 50 of water consumed by the typical
  homeowner is used for irrigation
• Decrease water used for irrigation
• Save money
• Protect our water supply
• Contribute to valuable irrigation water
  conservation research

16
Thank You

• We look forward to your cooperation and will
  gladly answer any Questions?
• For more information visit our website
• http//irrigation.ifas.ufl.edu
