Title: Guide to Buying Aluminum sheet


1
(No Transcript)
2
Product Name Picture Alloy Temper Thickness Width
5 bars Aluminum Tread Plate /Aluminu m Checker Plate 1060, 1100, 3003, 3105, 5052, 5083, 5754, 6061 etc. H12, H14, H16, H18, H22, H24, H26, H32, H34, H36, H38, O etc. 1-6mm 2200mm max.
3
Aluminum Mirror Sheet --Mirror Finish Aluminum Sheet, Reflector Aluminum 1100, 1050, 1060, 1070, 1200 2014,2024,3003, 3004, 3005,3105, 5005,5052,5754, 5083, 6061,7075,8011e tc O, H12, H14, H16, H18, H22, H24, H26, H32, H321, T5,T6,T351,T 651, 0.15---400 mm 900mm-4000 mm
Aluminum Diamond Plate 1060, 1100, 3003, 3105, 5052, 5083, 5754, 6063 etc. H12, H14, H16, H18, H22, H24, H26, H32, H34, H36, H40, O etc. 1-8mm 2202mm max.
Aluminum Roofing/Corru gated Aluminum Sheet AA1060 , 1070, 1100 , 1200 , 3A21 , 3003 H1X H2X 0.3-1.5mm 820-1000mm
Aluminum Sheet is a new kind of building
decorative materials for more and more population
among the customer, Aluminum wall panel is
lighter than the iron and steel, also, It's
waterproof, fireproof and much popular
decorative building materials. We would like to
highlight our aluminum sheet with good physical
performance, flat surface and smooth edge ,
Suitable for both deep drawing and Spinning.
The four most common aluminum grades available as
sheet metal are 1XXX, 3XXX, 5XXX series. 1XXX
series is commercially pure aluminum, so it is
highly chemical and weather resistant. It is
ductile enough for deep drawing and weldable, but
low strength. It is commonly used in chemical
4
processing equipment, light reflectors, and
jewelry. 3XXX series is stronger than 1100,
while maintaining the same formability and low
cost. It is corrosion resistant and weldable, It
is often used in stampings, spun and drawn parts,
mail boxes, cabinets, tanks, reflectors and fan
blades. 5XXX series is much stronger than 3003
while still maintaining good formability. It
maintains high corrosion resistance and
weldability, common applications include
electronic classis, tanks, and pressure
vessels. The Mechanical Properties for Aluminum
alloy, Sheets/Strips.
Available at industry leading prices, this range
includes following types
Type Features Applications
6061T6 Excellent joining characteristics, good acceptance of applied coatings, relatively high strength, good wor kability, and high resistance to corrosion Aircraft fittings, camera lens mounts, couplings, marines fittings and hardware, electrical fittings and connectors, decorative or misc. hardware, hinge pins, mag neto parts, brake pistons, hydraulic pistons, appliance fitti ngs, valves and valve parts.
3003H14 Good weldability/formability and very good corrosion resistanc e Food and chemical handling, tanks, trim, litho sheet, pressure vessels, and piping.
5052H32 Good workability, very good corrosion resistance, high fatigue strength, weldability, and moderate strength Aircraft fuel/oil lines, fuel tanks, other transportation areas, sheet metal work, appliances and lighting, wire, and rivets.
2024T3 Good weldability/formability and very good corrosion resistanc e Structural areas such as aircraft structures, fasteners, hardware, wheels, screw machine products.
5
Type Features Applications
7075T6 High tensile strength Used for highly stressed structural parts
1100 O and 1100 H14 Intrinsic formability and corrosion resistance Chemical and food handling, sheet metal, hollowware, heat exchangers, and lighting.
2024T3 Intrinsic formability and corrosion resistance Aircraft structures, fasteners, hardware, wheels, screw machine products
3003H1 Weldability/formability and very good corrosion resistanc e Food and chemical handling, tanks, trim litho sheet, pressure vessels, and piping.
5052H32 Good workability, very good corrosion resistance, high fatigue strength, weldability, and moderate strength Aircraft fuel/oil lines, fuel tanks, other transportation areas, sheet metal work, appliances and lighting, wire, and rivets
6061T651 Excellent joining characteristics, good acceptance of applied coatings, relatively high strength, good workability, and high resistance to corrosion Excellent joining characteristics, good acceptance of applied coatings, relatively high strength, good workability, and high resistance to corrosion
Shipbuilding
Auto oil tank
6
Sino Aluminum Sheet Mirror Advantages
Smooth surface, easy cleaning Aluminum mirror
easy to clean with smooth surface, and silver
color highlights clean, tidy characters.
Shiny bright increase the aesthetics Aluminum
mirror has various colors, good lighting
effects, and strong reflection capacity, widely
used in building materials, car decoration to
highlight the shape and overall structure,
increasing the aesthetics individuality.
Light weight, energy saving environmental
protection Light weight, decreasing the power
lost. Such as auto wheel uses aluminum mirror,
not only has beautiful luster, but also
oxidation resistance with longer life.
Aluminum Sheet Suppliers
7
Ingot?Melting?Online air-removing?Casting?Sawing?S
calper?Heating?Hot rolling?Hot rolling coil
(Casting) ?Cold rolling (Rewind reel/
Annealing)?Horizontal shear?Annealing?Aluminum
sheet?Inspection?Packaging?Delivery
8
Export standard covering with brown paper and
plastic film then packed with wooden case or
wooden pallet, as customer requested. It is
strong enough and good protection for sea
transportation. Usually it is around 2 tons in
one package, and loading 18-22 tons in 1x20'
container.
  • Long history 16years experience in aluminum
    industry
  • Strong strength 3,600 people,300,000 square
    meters, 28 aluminum deep processing lines
  • High quality 0.001 defect rate ,105 countries
    accept
  • High turnover 85,000,000 USD be exported every
    year
  • Wonderful team 30 Professional sales team to
    offer fast response and good service
  • Abundant products 7 series aluminum alloy
    products ,all of aluminum coil/sheet/circle/foil/p
    late
  • Competitive price 12 lower than other supplier
    in the same quality
  • News offered Timely industry news and new price
    for reference.

9
Tianjin Industrial Park, Daqiuzhuang Cangzhou
Hebei China Phone Number 86-323-9807 Email id
Sinoeast3_at_163.com
To learn more about SinoAluminum products ,visit
http//www.sinoaluminum.com
