I

1
II Formulations

• Dr. Ken Roach
• JohnsonDiversey

CSPA Cleaning Products Fundamentals Seminar
2
What are II Products?

• Institutional
• products used to clean, sanitize and improve
  appearance of surfaces in a restaurant, hotel,
  hospital, school, office building, retail store,
  etc.
• Industrial
• products used clean, sanitize and improve
  appearance of surfaces in an Industrial setting
• products used to enhance an Industrial process

CSPA Cleaning Products Fundamentals Seminar
3
Institutional Applications

• Machine Dishwashing
• Hard Surface Cleaning
• Sanitizing / Disinfecting of Hard Surfaces
• Laundry
• Floor Care
• Air Care

CSPA Cleaning Products Fundamentals Seminar
4
Industrial Applications

• Hard Surface Cleaning
• CIP (Clean-In-Place)
• COP (Clean-Out-of-Place)
• OPC (Open Plant Cleaning)
• Sanitizing / Disinfecting of Hard Surfaces
• Process Aids
• lubricants
• metal treatment
• others

CSPA Cleaning Products Fundamentals Seminar
5
Sinners Circle

• If you have a bad cleaning result, you probably
  did not use enough of one or more of the 4
  necessary components of cleaning
• time
• temperature
• mechanical energy / agitation
• chemical
• Decrease any one and one or more of the others
  must be increased to maintain performance

CSPA Cleaning Products Fundamentals Seminar
6
Formulators Sinners Circle

• If your formulation does not give you a good
  cleaning result, you probably did not use enough
  of one or more of the 4 necessary components of
  cleaning
• alkalinity / acidity
• chelation
• emulsibility / surfactant conc
• solvency / solvent conc
• Decrease any one and one or more of the others
  must be increased to maintain performance

CSPA Cleaning Products Fundamentals Seminar
7
Institutional Machine Dishwashing

• Hot Water Sanitizing
• 2 product system
• detergent
• powder, solid, slurry or liquid
• rinse aid
• Chemical Sanitizing (LED/LTD)
• 3 product system
• detergent
• usually liquid
• rinse aid
• sanitizer
• usually hypochlorite

(Low Energy Dishwashing / Low Temperature
Dishwashing)
CSPA Cleaning Products Fundamentals Seminar
8
Institutional MachineDishwashing Detergents

• Caustic
• 10-50 as active
• replace with metasilicate for soft metal safe
  product
• Chelant
• 10-35 as active
• usually STPP
• NTA used in liquids in Canada
• Polymer
• 0-2.5 as active
• usually acrylic acid homopolymer

CSPA Cleaning Products Fundamentals Seminar
9
Institutional MachineDishwashing Detergents

• Chlorine source
• 0-10 of 12 NaOCl in liquids
• 0-2.5 of dichloroisocyanurate in powders
• Other actives
• corrosion inhibitor
• enzymes
• Filler
• water for liquids
• soda ash / sodium sulfate for powders

CSPA Cleaning Products Fundamentals Seminar
10
Institutional MWW Rinse Aids

• Nonionic surfactant
• 10-30 as active
• reverse temperature-solubility profile
• Hydrotrope
• typically SXS / SCS
• for product stability dispersion
• Preservative
• Dye
• Water

CSPA Cleaning Products Fundamentals Seminar
11
InstitutionalHard Surface Cleaners

• Wide variety of formulation types
• aqueous
• alkaline / neutral / acidic
• surfactant based / solvent based / chelant based
• non-aqueous
• Best option depends on soil/substrate combination
• In most instances, more than one type of
  chemistry can be used successfully

CSPA Cleaning Products Fundamentals Seminar
12
InstitutionalHard Surface Cleaners
CSPA Cleaning Products Fundamentals Seminar
13
Highly Alkaline HardSurface Cleaners
Example Oven Cleaner

• Solvent
• 0-10 as active
• usually glycol ether
• Chelant
• 0-5 as active
• gluconate / phosphonate
• Filler

• Caustic
• 5-25 as active
• Surfactant
• 2-10 as active
• usually high foam nonionic

CSPA Cleaning Products Fundamentals Seminar
14
Highly Alkaline HardSurface Cleaners
Example Degreaser

• Caustic
• 3-10 as active
• Surfactant
• 5-15 as active
• usually anionic / nonionic blend
• Solvent
• 2-10 as active
• usually glycol ether
• some terpene

• Chelant
• 0-5 as active
• EDTA/phosphate
• Rheology modifier
• 0-2 as active
• natural or synthetic polymers
• clays
• Dye / Fragrance / Preservative / Filler

CSPA Cleaning Products Fundamentals Seminar
15
Mildly Alkaline HardSurface Cleaners
Example All Purpose Cleaner

• Caustic
• 0-5 as active
• Surfactant
• 5-20 as active
• usually anionic / nonionic blend
• Solvent
• 5-20 as active
• usually glycol ether
• some terpenes and/or alcohols

• Chelant
• 0-5 as active
• EDTA/phosphate
• Rheology modifier
• 0-2 as active
• natural or synthetic polymers
• clays
• Dye / Fragrance / Preservative / Filler

CSPA Cleaning Products Fundamentals Seminar
16
pH Neutral HardSurface Cleaners

• Example Hand Dishwashing Products
• Anionic surfactant
• 10-80 as active
• predominantly LAS
• SAS / LES also used
• Nonionic surfactant
• 0-10 as active
• coco DEA / APG / amine oxide
• Rheology modifier
• Usually to thin rather than thicken
• Dye / Perfume / Preservative / Filler

CSPA Cleaning Products Fundamentals Seminar
17
pH Neutral HardSurface Cleaners

• Example Glass Cleaner
• Surfactant
• 0-2 as active
• anionic and/or nonionic
• Solvent
• 10-30 as active
• lower boiling glycol ether and/or alcohol
• Alkalinity
• 0-5 ammonia and/or alkanolamine
• Dye / Perfume / Preservative / Filler

CSPA Cleaning Products Fundamentals Seminar
18
Mildly Acidic HardSurface Cleaners
Example Tub Tile Cleaner

• Acid
• 5-15 as active
• typically organic and/or phosphoric
• Surfactant
• 5-20 as active
• usually nonionic / amphoteric blend

• Solvent
• 5-20 as active
• usually glycol ether
• Chelant
• 3-10 as active
• EDTA
• Dye / Fragrance / Preservative / Filler

CSPA Cleaning Products Fundamentals Seminar
19
Highly Acidic HardSurface Cleaners

• Example Lime Scale Remover
• Acid
• 10-60 as active
• predominantly phosphoric or phosphoric blends
  with HCl / nitric / sulfuric
• Nonionic surfactant
• 0-2 as active
• Glycol ether solvent
• 0-5 as active
• Dye / Perfume / Water

CSPA Cleaning Products Fundamentals Seminar
20
Non-AqueousHard Surface Cleaners

• Example Stainless Steel Polish
• Low viscosity mineral oil
• 50-100
• Glycol ether solvent
• 0-50

CSPA Cleaning Products Fundamentals Seminar
21
InstitutionalSanitizers Disinfectants

• 2 chemistries dominate market
• hypochlorite
• quat
• Other available chemistries include
• iodophors
• peroxide / peracid
• acid anionics
• phenolics
• gluteraldehyde
• EPA registration is required
• often subregistration of suppliers primary

CSPA Cleaning Products Fundamentals Seminar
22
Product Classification

• No Rinse sanitizers
• typically just biocidal agent water
• quat use conc 150-200 ppm
• chlorine use conc 50 ppm
• Detergent sanitizers
• biocidal agent incorporated into detergent
  formulation
• Detergent disinfectants
• biocidal agent incorporated into detergent
  formulation
• quat use conc up to 800 ppm
• chlorine use conc 200 ppm

CSPA Cleaning Products Fundamentals Seminar
23
Institutional Laundry

• OPL (on-premise laundry)
• small scale
• hotel / restaurant / small health care
• Commercial
• large scale
• linen supply / uniform supply

CSPA Cleaning Products Fundamentals Seminar
24
OPL

• Typically 4 - 5 products
• builder
• detergent (suds)
• sour
• bleach
• softener

CSPA Cleaning Products Fundamentals Seminar
25
Laundry Builder

• Alkali
• caustic / silicate
• 30-50 as active
• Chelant
• phosphate / NTA / EDTA / polymer
• 20-35 as active
• Surfactant
• predominantly anionic
• lt5 as active
• Optical brightener
• Dye / Filler

CSPA Cleaning Products Fundamentals Seminar
26
Laundry Detergent

• Anionic surfactant
• predominantly LAS
• 5-15 as active
• Nonionic surfactant
• NP6 / NP9 blend is workhorse
• LAE blends gaining
• 10-30 as active

• Alkali
• 0-10 as active
• Chelant
• 0-10 as active
• Optical brightener
• Anti-redeposition Aid
• Dye / Perfume / Preservative / Filler

CSPA Cleaning Products Fundamentals Seminar
27
OPL 1-Shot Detergent

• Combination builder detergent
• Difficult to formulate sufficient actives level
  to allow for reasonable dose size without
  sacrificing performance
• Limited application to household type machines or
  situations where performance standards are not
  difficult to attain

CSPA Cleaning Products Fundamentals Seminar
28
Laundry Sour

• Sodium silicofluoride / sodium bifluoride
• 10-50 as active
• Dye / Filler

CSPA Cleaning Products Fundamentals Seminar
29
OPL Laundry Bleach

• 8-12 sodium hypochlorite
• water

CSPA Cleaning Products Fundamentals Seminar
30
Softeners

• Two categories dominate
• imidazoline quats
• dialkyl (tallow) quats
• 5-25 as actives
• Fragrance very important
• up to 2 of formulation
• Dye / Opacifier / Preservative / Filler

CSPA Cleaning Products Fundamentals Seminar
31
Commercial Laundry

• Similar basic product mix
• Additional products may include
• water conditioner (100 chelant)
• prespoters
• specialty detergents
• high enzyme product for operating room linen
• oxygen bleach for chlorine sensitive fabric or as
  an antichlor
• starch for shirt laundries

CSPA Cleaning Products Fundamentals Seminar
32
Floor Finishes

• Styrene / Acrylic Co-Polymer
• backbone of the formulation
• 12-24 as actives
• Waxes
• primary method of adjusting slip properties
• PE / PP waxes dominate
• typically a blend of two different waxes used
• 2-5 as actives
• ASR
• key to removability
• 1-3 as active

• Plasticizers
• TXIB
• dibutyl phthalate
• Benzoflex 131
• Leveling Aids
• TBEP
• Coalescing Solvents
• glycol ethers
• Wetting aids
• fluorosurfactant
• Defoamer
• Preservative / Water

CSPA Cleaning Products Fundamentals Seminar
33
Floor Strippers

• Chelant
• EDTA
• 3-10 as active
• Solvent
• glycol ethers
• 10-30 as active
• Alkalinity
• MEA dominates
• 30-50 as active
• Filler

CSPA Cleaning Products Fundamentals Seminar
34
Air Fresheners

• Perfume
• Up to 7
• Solvent
• typically highly volatile alcohol (MeOH/EtOH/IPA)
• Dye / Preservative / Water
• dye must be non-staining

CSPA Cleaning Products Fundamentals Seminar
35
Industrial Hard Surface Cleaners(food industry)

• CIP (Clean In Place)
• detergent solution circulated through inside of
  pipes, tanks other difficult to access places
• COP (Clean Out of Place)
• detergent bath prepared in a recirculating tank
  for cleaning small parts easily removed
  replaced
• OPC (Open Plant Cleaning)
• detergent solution sprayed on walls, floors
  easily accessed areas of permanently installed
  and/or large equipment

CSPA Cleaning Products Fundamentals Seminar
36
CIP Detergents

• Alkali
• predominantly caustic
• silicate used for soft metal safe products
• 25-50 as active
• Chelant
• gluconate / EDTA / phosphonate
• 0-10 as active
• Bleach
• 0-5 as active
• Surfactant
• low foam non-ionic
• 0-5 as active
• Water

CSPA Cleaning Products Fundamentals Seminar
37
COP Detergents

• Typically same product used for both CIP and COP
• COP tonnage is typically insufficient to justify
  a separate product

CSPA Cleaning Products Fundamentals Seminar
38
OPC Detergents

• Alkali
• predominantly caustic
• silicate used for soft metal safe products
• 5-35 as active
• Chelant
• EDTA
• 0-5 as active

• Surfactant
• high foam anionic / non-ionic blends
• 5-15 as active
• Bleach
• 0-5 as active
• Water

CSPA Cleaning Products Fundamentals Seminar
39
Disinfectants

• 4 main chemistries
• hypochlorite (CIP OPC)
• quat (OPC only)
• peracid / peroxide (mainly CIP)
• acid anionic (CIP OPC)
• Other chemistries include
• iodophors
• mixed halides
• chlorine dioxide / ASC
• EPA registration is required
• seldom rely on subregistration of suppliers
  formulation

CSPA Cleaning Products Fundamentals Seminar
40
Lubricants

• Food applications
• aqueous
• fatty acid / fatty amine based
• silicone based
• Non-food applications
• aqueous
• as above
• non-aqueous
• hydrocarbon / mineral oil based

CSPA Cleaning Products Fundamentals Seminar
41
Fatty Acid Lubricants

• Fatty acid
• C16-C18 provide best lubrication
• 5-20 as active
• Alkali
• caustic
• sufficient to neutralize fatty acid
• Chelant
• 0-1 as active
• mainly EDTA
• Water

CSPA Cleaning Products Fundamentals Seminar
42
Silicone Based Lubricants

• Silicone emulsion
• 5-15 as active
• Preservative
• Water

CSPA Cleaning Products Fundamentals Seminar
43
Metal Phosphatizing

• Phosphoric acid
• 10-15 as active
• Caustic
• enough to make MSP
• Accelerator
• oxidizer (NO3-) / reducer (hydroxyammonium
  sulfate)
• 0.5-1 as active
• Surfactant
• low foam non-ionic
• 0.5-2 as active
• Water

CSPA Cleaning Products Fundamentals Seminar
44
Paint Booth Cleaner

• Non-Aqueous
• toluene/xylene
• MEK
• Aqueous
• glycol ether
• glycol ether acetate
• N-methyl pyrrolidone

CSPA Cleaning Products Fundamentals Seminar
45
Paint Booth Maskant

• Resin
• polymeric film former
• 30-70 as active
• Solvent
• aqueous
• emulsifier system
• preservative
• non-aqueous
• Corrosion Inhibitor

CSPA Cleaning Products Fundamentals Seminar
46
Transportation Cleaners

• Car Wash
• concern about stripping wax
• resembles hand dish liquids
• moderate-high foam surfactant
• no solvent or chelant
• minimal (if any) alkalinity

• Truck Wash
• wax seldom used so no concern
• resembles degreaser type products
• low foam surfactant
• solvent
• chelant
• moderate alkalinity

CSPA Cleaning Products Fundamentals Seminar
47
Felt Cleaner

• Alkaline Cleaner
• Alkali (caustic)
• 10-15 as active
• Chelant (EDTA / gluconate)
• 3-7 as active
• Surfactant (anionics / amphoterics)
• 1-5 as active
• Solvent (glycol ethers)
• 0-10 as active

• Acid Cleaner
• Acid (organic)
• 10-15 as active
• Chelant (EDTA)
• 3-7 as active
• Surfactant (nonionics)
• 5-10 as active
• Solvent (glycol ethers)
• 0-10 as active

CSPA Cleaning Products Fundamentals Seminar
48
Summary

• II applications are highly varied compared to
  consumer applications
• II products are formulated to work under a wide
  variety of conditions

CSPA Cleaning Products Fundamentals Seminar
49
Summary

• Formulator must be aware of the intended
  application and the restrictions inherent in that
  application
• knowledge of the soils to be removed
• knowledge of the surface to be cleaned
• knowledge of the types of chemistry available and
  how each will function in the given application

CSPA Cleaning Products Fundamentals Seminar
