Reach Your Technical Peak 2004
2
OpenEdge 10 ProDataSets
3
Agenda

• Introduction
• What came before
• The ProDataSet advantage
• Demo
• Whats behind the curtain

4
Guiding Principles of OpenEdge 10
Applications are a collection of software
components that reflect the actual business
processes
They do not exist as an island.
Interoperability and integration are second nature
They are not bound by any one user interface
technology, methodology, or platform
5
OpenEdge Reference Architecture
A Roadmap for Applying Technology
to Business Challenges

• Designed by Product Management and Engineering
• Implemented through Services
• Empowerment
• Education Consulting
• Referenced by Engineering for Product Strategy
  Roadmap decisions

6
Introducing the ProDataSet
The Business of Application Data

• We rarely work these elements as independent sets
  of data
• Relationships are often defined in business
  logic in order to enforce business integrity
• Service Orientation may require these elements
  to be treated as one unit

Data Formats that Match Business Requirements
7
Introducing the ProDataSet
The ProDataSet is a new 4GL object

• Extends core data objects
• (temp-tables, queries, buffers, etc.)
• Provides facilities to create and manage
  multi-set data objects
• Properties include specification of
  Data-Relationships among the set members
• Supports automatic filling of the set from the
  source(s)

8
The Bigger Picture

• ProDataSets become the driving force in OpenEdge
  Applications

OpenEdgeBusiness Logic
OpenEdge.NET Interface
Purchase Order Business Logic
PurchaseOrderProxy
PO ProDataSet
HeaderData
DetailData
OtherData
WebClient / HTML User Interface
OpenEdge4GL Interface
Schema- holder
ADM or other 4GL/Web Interface
Jonas Grumby
OK
110 Desert Isle Path
Cancel
Minnow, HI
RDBMS
OpenEdgeWeb Services Interface
9
Agenda

• Introduction
• What came before
• The ProDataSet advantage
• Demo
• Whats behind the curtain

10
What came before
Before the age of ProDataSets

• TempTables
• Introduced in V7
• TempTables as parameters, dynamic TempTables came
  later
• Dynamic Queries and Buffers
• Introduced in V9
• SDOs and SBOs
• External data sources
• Separate and non-equal
• XML, flat files, ODBC/other DataServer sources

11
What came before
How to make it better?

• Provide language support for logical
  relationships between temp-tables
• Optimize performance when passing temp-tables
• Isolate data-related business logic
• Extend reusability
• Leverage Progress superior data access and
  business logic in a changing business environment

12
Agenda

• Introduction
• What came before
• The ProDataSet advantage
• Demo
• Whats behind the curtain

13
The ProDataSet advantage
More intuitive by design

• Business objects more closely aligned to
  application objects application design is less
  constrained by data source design
• A logical group of heterogenous sources can be
  treated as a single data object
• Introduces levels of indirection for future
  flexibility as business requires
• Provides robust default behaviors

14
The ProDataSet advantage
Performance

• ProDataSet is a Progress in-memory data store
• Within a session, structure and contents can be
  passed by reference for both static and dynamic
  ProDataSets
• Single handle passes ProDataSet definition,
  buffers, and relationships all marshaled along
  with the data.

15
The ProDataSet advantage
Business logic integration

• Closer integration of data objects and related
  business logic within an application
• Supports event-related extensions at appropriate
  points
• Designed to operate effectively in a context-free
  environment
• Before-tables are built-in to capture changes
  made on the client side

16
ProDataSet to ADO.NET DataSet

• ProDataSet maps directly to an ADO.NET DataSet,
  allowing you to
• Design a .NET interface in terms of .NET DataSets

• while still harnessing the Power of Progress to
• Pass data back and forth to Progress AppServer
• Design ProDataSets in terms of Progress
• Build business logic in Progress to be invoked
  from the ProDataSet

17
The ProDataSet advantage
How to get it

• Built on existing language objects
• Default queries speed development
• Structures encourage separation of data
  manipulation from the data sources
• Simplifies data encapsulation in a distributed
  environment

18
Components of a ProDataSet
19
Steps to Create a DataSet
Static DataSet

• Define Temp Tables
• Define DataSet
• Define top-level Query
• Define DataSources
• Prepare the top-level Query
• Attach DataSources to the DataSet
• FILL the DataSet

20
A ProDataSet is made of Temp-Tables

• Define temp-tables in the usual way

DEFINE TEMP-TABLE ttOrder LIKE Order FIELD
OrderTotal AS DECIMAL FIELD CustName LIKE
Customer.Name FIELD RepName LIKE
SalesRep.RepName. DEFINE TEMP-TABLE ttOline LIKE
OrderLine. DEFINE TEMP-TABLE ttItem FIELD
ItemNum LIKE ITEM.ItemNum FIELD ItemName LIKE
ITEM.ItemName FIELD Price LIKE ITEM.Price
FIELD Weight LIKE ITEM.Weight FIELD OnHand
LIKE ITEM.OnHand FIELD OnOrder LIKE
ITEM.OnOrder.
21
Define the DataSet

• Define the DataSet in terms of the temp-tables it
  combines and their relationship to each other

DEFINE DATASET dsOrder FOR ttOrder, ttOline,
ttItem DATA-RELATION OrderLine FOR ttOrder,
ttOline RELATION-FIELDS (OrderNum, OrderNum)
DATA-RELATION LineItem FOR ttOline, ttItem
RELATION-FIELDS (ItemNum, ItemNum) REPOSITION.
22
Defining a Data-Source with a Query

• Define a query for a top-level table
• For example, which Order(s) to start with
• Or to define a join between buffers

DEFINE QUERY qOrder FOR Order, Customer, SalesRep.
DEFINE DATA-SOURCE srcOrder FOR QUERY qOrder ...
QUERY qOrderQUERY-PREPARE
23
FILL the ProDataSet
DATASET dsOrderFILL().
24
Round-Trip Scenario
Server-Side
Client-Side
UI
25
Agenda

• Introduction
• What came before
• The ProDataSet advantage
• Demo
• Whats behind the curtain

26
Data-Relations

• Data-Relations define the relationship between
  parent-child tables
• The Relation-Fields define fields in parent and
  child to use for selection

DATA-RELATION OrderLine FOR ttOrder,
ttOline RELATION-FIELDS (OrderNum,
OrderNum)

• Relation-Fields are used to determine how to
  populate the DataSet by default
• Data-Relations also define default navigation of
  the DataSet

27
Data Relations
Demo sample code
DEFINE DATASET dsOrder FOR ttOrder, ttOline,
ttItem DATA-RELATION OrderLine FOR ttOrder,
ttOline RELATION-FIELDS (OrderNum,
OrderNum) DATA-RELATION LineItem FOR ttOline,
ttItem RELATION-FIELDS (ItemNum, ItemNum)
REPOSITION.
28
Populating with Data-Relations
DATA-RELATION OrderLine FOR ttOrder,
ttOline RELATION-FIELDS (OrderNum,
OrderNum)

• When a DataSet is populated, Progress retrieves
  children of the current parent

ProDataSet
OrderTT
79 1 02/10/93
Data-Relation
OrderLineTT
29
Navigating with Data-Relations
DATA-RELATION OrderLine FOR ttOrder,
ttOline RELATION-FIELDS (OrderNum,
OrderNum)

• When a DataSet is navigated, Progress filters on
  children of the current parent

ProDataSet
OrderTT
6 1 01/05/9336 1 01/19/9379 1 02/10/93
Data-Relation
OrderLineTT

• 6 1 00009
• 2 00009
• 6 3 00011
• 1 00009
• 36 2 00009
• 36 3 00011

30
Defining Data-Sources

• You can define a Data-Source for each temp-table
  buffer in the DataSet
• Each Data-Source can define database buffers or a
  query or both
• Data-Source is separate from any DataSet

ProDataSet
Data-Source SrcOrder
OrderTT
Query Q1 for Order
Database
OrderLineTT
Data-Source SrcOline
OrderLine
1 53 01/01/93 2 81 01/04/93 3 66 01/04/93
1 53 01/01/93 2 81 01/04/93 3 66 01/04/93
Query Q2 for OrderLine
31
Defining Data-Sources
Demo sample code
DEFINE DATA-SOURCE srcOrder FOR QUERY qOrder
Order KEYS (OrderNum), Customer KEYS (CustNum),
SalesRep KEYS (SalesRep). DEFINE DATA-SOURCE
srcOline FOR OrderLine. DEFINE DATA-SOURCE
srcItem FOR ITEM KEYS (ItemNum).
32
Defining a Data-Source without a Query

• If theres a Data-Relation, its fields can tell
  Progress how to construct a query

DATA-RELATION OrderLine FOR ttOrder,
ttOline RELATION-FIELDS (OrderNum,
OrderNum)
DEFINE DATA-SOURCE srcOline FOR OrderLine
KEYS (OrderNum).
ProDataSet
OrderTT
6 1 01/05/9336 1 01/19/9379 1 02/10/93
Data-Relation
OrderLineTT
6 1 000096 2 000096 3 00011
33
Attaching Data-Sources

• Data-Sources are defined separately from the
  ProDataSet
• You can attach/detach any available Data-Source
  independent of the ProDataSet definition
• Data-Sources do not travel with the ProDataSet

Database
ProDataSet
Data-Source SrcOrder
OrderTT
1 53 01/01/93 2 81 01/04/93 3 66 01/04/93
6 1 01/05/9336 1 01/19/9379 1 02/10/93
Query Q1 for Order
34
Attaching Data-Sources
Demo sample code
/ Attach datasources before fill / BUFFER
ttOrderATTACH-DATA-SOURCE(DATA-SOURCE
srcOrderHANDLE,
"Customer.Name,CustName"). BUFFER
ttOlineATTACH-DATA-SOURCE(DATA-SOURCE
srcOlineHANDLE). BUFFER ttItemATTACH-DATA-SOURC
E(DATA-SOURCE srcItemHANDLE).
/Detach datasources after fill / DO iBuff 1
TO DATASET dsOrderNUM-BUFFERS DATASET
dsOrderGET-BUFFER-HANDLE(iBuff)DETACH-DATA-SOURC
E(). END.
35
Dynamic ProDataSets

• Every element of a ProDataSet can be dynamic
• CREATE DATASET
• ADD-BUFFER()
• ADD-RELATION()
• A Data-Source can also be dynamic
• CREATE DATA-SOURCE
• And a DataSet can use dynamic temp-tables
• CREATE TEMP-TABLE
• Attributes and methods lets you manipulate the
  DataSet through its handle

36
Dynamic ProDataSet
Static
DEFINE NEW SHARED DATASET
dataset-name FOR buffer-name , buffer-name
... DATA-RELATION data-rel-name FOR
data-rel-spec , DATA-RELATION data-rel-name
data-rel-spec ...
Dynamic
CREATE DATASET dataset-handle IN WIDGET-POOL
widget-pool-name LIKE other-dataset-name
other-dataset-handle DELETE OBJECT
dataset-handle.
37
Dynamic ProDataSet
Demo sample code
CREATE DATASET phDataSet. DO iEntry 1 TO
NUM-ENTRIES(pcSources) CREATE TEMP-TABLE
hTable. hTableCREATE-LIKE(ENTRY(iEntry,
pcSources)). hTableTEMP-TABLE-PREPARE("tt
" ENTRY(iEntry, pcSources)).
phDataSetADD-BUFFER(hTableDEFAULT-BUFFER-HANDLE)
. END. . . .
38
Populating a ProDataSet

• Use the FILL method to populate the DataSet
• FILL on the DataSet fills every table starting
  with top-level buffers
• FILL on a buffer fills that table and its
  descendents
• FILL-MODE
• NO-FILL skip this table
• EMPTY empty the table first
• APPEND add more records to the table
• MERGE add records and eliminate dups

39
Audience Quiz What is the sample code statement
that populates the DataSet dsOrder?
hDSOrderFILL().
40
Passing a ProDataSet as a Parameter

• You can pass a DataSet parameter as
• DATASET static reference like TABLE for
  temp-tables
• DATASET-HANDLE dynamic reference to the DataSet
  and its definition, like TABLE-HANDLE for a
  temp-table
• HANDLE passes a simple DataSet handle to a
  local procedure
• Within a session you can pass a DataSet
  BY-REFERENCE to avoid the overhead of copying the
  DataSet

41
Passing DataSets as Parameters
Demo sample code
/ RUN OrderMain.p (INPUT iOrderNum, OUTPUT
DATASET dsOrder). / IF tAppServer THEN RUN
AppServerCode/ProDataSet/OrderMain.p ON SERVER
hAppServer (INPUT iOrderNum, OUTPUT
DATASET dsOrder). ELSE RUN
ProDataSet/OrderMain.p (INPUT
iOrderNum, OUTPUT DATASET dsOrder BY-REFERENCE).
42
Event Callback Procedures

• You can define event procedures for
• Before and After FILL of the ProDataSet
• Before and After FILL of any temp-table buffer
• Before and After FILL of any record
• Use ProDataSet events to prepare queries, attach
  Data-Sources, etc.
• Use Buffer events to manipulate the table
• Use Record events to populate calculated fields

43
ProDataSet event procedure
Demo sample code
phDSOrderSET-CALLBACK-PROCEDURE
("BEFORE-FILL", "preDataSetFill", THIS-PROCEDURE).
PROCEDURE preDataSetFill DEFINE INPUT
PARAMETER DATASET hDset. hqOrderQUERY-PREPARE
(FOR EACH Order WHERE Order.OrderNum
STRING(piOrderNum) , FIRST
Customer OF Order, FIRST SalesRep OF Order). END
PROCEDURE. / preDataSetFill /
44
Record-level event procedure
Demo sample code
hBuffSET-CALLBACK-PROCEDURE
("AFTER-ROW-FILL", "postRecordFill",
THIS-PROCEDURE).

• Fills a calculated OrderTotal field

PROCEDURE postRecordFill DEFINE INPUT PARAMETER
DATASET hDset. hBuff hDsetGET-BUFFER-HANDLE(
ttOrder). FOR EACH OrderLine WHERE
OrderLine.OrderNum
INTEGER(hBuffBUFFER-FIELD("OrderNum")BUFFER-VALU
E) dTotal dTotal
OrderLine.ExtendedPrice. END.
hBuffBUFFER-FIELD("OrderTotal")BUFFER-VALUE
dTotal. END PROCEDURE.
45
Updating Through the ProDataSet

• ProDataSet and companion before-tables retain the
  information needed to apply updates
  (add/change/delete)
• Used to pass changes to the server to be made in
  the Data-Source via SAVE-ROW-CHANGES
• Maps to .NET support for update versions
• There are update callback events as well when
  temp-table rows are changed
• Full support for optimistic locking

46
Before-Image Table for a DataSet

• Original values for every modified record

• Initial values for every added record

• Original values for every deleted record

ProDataSet
OrderTT
6 1 01/05/9336 1 01/19/9379 1 02/10/93
Data-Relation
OrderLineTT
6 1 000096 2 000106 3 00011 6 4 00077
0 0 00000 A 6 2 00009 M 6 5 00022 D
47
ProDataSet Futures

• Planned for release 10.0B
• Additional events to support data retrieval
  transparency (OFF-END, FIND-FAILED)
• BATCH-SIZE and LAST-BATCH attributes
• MERGE-DATASET method
• Planned for subsequent OE10 releases
• Standard Data Access and Business Entity
  templates with DataSets for the OERA
• Direct to-or-from XML conversion

48
Additional Resources

• John Sadds whitepapers
• http//www.progress.com/progress/products/document
  ation/docs/dataset/papern.pdf
• for n 1 to 6
• Instructor-led course Using ProDataSets
• OpenEdge online documentation set
• http//www.progress.com/products/documentation/sta
  rt_openedge10/index.ssp

49
(No Transcript)
