World Class Manufacturer and Supplier of SLR,

1
World Class Manufacturer and Supplier of SLR,
DLTtape and Super DLTtape Drive Automated
Storage Solutions
2
Linear Recording - Technology for the future
3
TOTAL Units by CapacityEMEA 2000-2003
in 1000 units
Source IDC EMEATape Drive Forecast 2000-2003
4
Tape Automation Market worldwide
Source IDC
5
Tape drive price performance is critical for
Entry Level Servers
0-5k
5k-10k
6
Definition of the Tape Storage Server Market Space
Markets Tape based Products Market
Dynamics Enterprise 3480, - High end
Storage Solutions Data Center 3590, - Highly
available on/nearline 9840 DLT 8000, - Strong
tape based Automation growth High-End
Mammoth-2/3, - Strong growth in defacto open
media Network AIT-2/3, SDLT, LTO,
SLR100 5.0-15MB/Second DDS 34, SLR
24-60, - DDS Roadmap Ends at DDS4 SMB / Low-End
Ecrix, Onstream, Mammoth-1, - Price performance
critical for sucess Network AIT-1, DLT
4000/7000, Benchmark DLT-1 - Hard disk drive
and optical disk tech- 1.2-5.0MB/Second nologies
offer attractive alternative to
tape Personal DDS 12, Travan, SLR2-5
Onstream, - Optical and memory cards lead
storage Storage Optical, Solid State,
Diskettes growth. Tape has continuos decline
7
SLR7-100

• Scalable solutions for the Entry Level
• Market

8
SLR Roadmap
9
SLR7 Technical Specification
Available From March 5th

• Capacity (native) 20 GBytes (40GB with 21
  compression)
• Transfer rate (native) 3 MBytes/sec (6,0MB/s
  with 21 compression)
• SCSI interface Ultra2 LVD, 40 MBytes/sec, 16 bit
  bus
• Write compatibility SLR7
• Read compatibility SLR7, SLR5
• Scalability SLR40, SLR60, SLR100,
  Autoloader/Library
• Buffer 8MB
• Read While Write YES
• Hard bit error rate 10-16
• Cartridge SLR7 (SLR100 type, no servo)
• Head Dual channels MR
• Coding VR²

Preliminary data Some parameters may be slightly
changed
10
Entry level Market- What technology will meet
price performance and scalability for the future?
?
HP, Seagate, Sony
DDS-5
18 GB disk
27/36 GB disk
54 GB disk
75 GB disk
9 GB disk
11
Entry Level Tape Drive Pricing
Capacity GB
Data transfer MB/s
US End User Price Febuary 2001
12
Midrange Tape Drive Pricing
Capacity GB
Data transfer MB/s
US End User Price Febuary 2001
13
Highly Reliable Platform

• Benefits
• Only two (2) moving parts
• Excellent access time
• 80 of the wearable parts are in the data
  cartridge

14
Other Technologies 4mm 8mm

• Issues
• 16 parts
• Frail media
• Acceptable access time

15
SLR100/60/40/7 In-Line Compression for Maximum
Continuous Data Transfer Speed
SLR100/60/40/7 In-Line Compression utilizes Data
Buffer 100
Compressed dataonly!
SCSI
Compr ession
Buffer
Tape
Host
Other technologies Look-aside Compression
divides buffer into two sections Compressed and
non-compressed that reduces the effective buffer
size significantly
Buffer
Uncompressed compressed data
16
SLR100/60 Auto Sense - Dynamic Adjustment to
Host Performance

• Data Transferto Tape

Data Inputfrom SCSI
5 MB / s (87.5 ips on SLR100)
Faster
8 MB Buffer
4 MB / s (70 ips on SLR100, 60)
3 MB / s (52.5 ips on SLR100, 60, 40)
8 MB Data Bufferwithin SLR100/60/40/7
Optimized to Host Performance
17
SLR7, 60, 100 Benchmark test Configuration

• System partition (volume C)
• Size 10 GB / Used2.7GB
• Operating System (Win 2000)
• MS Office 2000 SR-1 Premium
• MS Photo Draw
• MS SQL Server 7.0
• Veritas Backup Exec
• Various utilities SW
• Lotus Notes
• Data partition (volume D)
• Size 32GB / Used 27.6
• Mix of typical office environment files
  (Approximately compression rate, Data Partition
  1.5 1.7)
• Word (.doc)
• Powerpoint (.ppt)
• Excel (.xls)
• Graphical (.bmp, .jpg)
• Text (.txt, .pdf)

18
SLR7 and 60 vs competition Benchmark
Full Backup Data Partition (Comp. ON)
Higher bar indicates greater throughput-better
performance
450
400
350
300
250
200
150
100
50
0
Tandberg
Tandberg
Benchmark
Sony SDX-
HP C5683A
SLR40
SLR60
DLT1
300C (AIT-1)
DDS-4
19
SLR7 and 60 vs competition Benchmark
Full Restore Data Partition (Comp. ON)
Higher bar indicates greater throughput-better
performance
350
300
250
200
150
100
50
0
Tandberg
Tandberg
Benchmark
Sony SDX-
HP C5683A
SLR40
SLR60
DLT1
300C (AIT-1)
DDS-4
20
SLR7,60,100

• Reliable
• Scalable
• Backwards compatible
• Best in Class Price/performance

20-50 GB 5.25-inch Half Height
21
Super DLTtape Technology
22
SDLTtape in CompetitionRevenue in Mill. USD
Source IDC 2000
23
Tandberg DLTtape Roadmap
24
SDLT220 Technical Specification

• Capacity (native) 110 GBytes (220GB with
  21 compression)
• Transfer rate (native) 11 MBytes/sec (22MB/s
  with 21 compression)
• SCSI interface Ultra2 LVD, 80 MBytes/sec, 16 bit
  bus
• Write compatibility SDLT
• Read compatibility SDLT, DLTtape IV
  (DLT1/4000/7000/8000)
• Scalability Future SDLT, Autoloader/Library
• Read While Write YES
• Hard bit error rate 10-17
• Cartridge SDLTtape1 (green)
• Head MR Cluster
• Coding PRML

25
Super DLTtape Pivoting Optical Servo combines
magnetic optical strengths
Super DLTtape combines the best of magnetic
optical media !
26
DLT8000 and Super DLTtape MRC Heads
Super DLTtape Magneto Resistive Cluster Head
DLT8000 Head
27
Competing against LTO

• SuperDLT reassures
• the end-user
• 10-years reliability track record
• Compatible with 80 of the installed base in
  midrange
• Superior technology using only 10 of capacity
  capability
• Complete range of product (incl.Benchmark)
• no compelling reason to change

• LTO confuses the end-user
• unproven reliability
• no compatibility with any existing technology
• Limited product family
• LTO OEMs endorse DLT!
• no compelling reason to switch (other than price)

28
Opto-Magnetic Storage SystemsO-MaSS
A Tandberg Data Company
29
Increase of Storage
Shipments in PBytes (1015)
6400
Total
Others
3200
1600
NT
800
400
Unix
0
1998
1999
2000
2001
2002
2003
30
O-MaSS will

• Develop a unique device bridging the gap between
  hard disk and tape
• Integrate the new device into intelligent systems
• Offer enterprise level functionality at mid-range
  cost
• Target a broad market including near-line
  storage, SSPs, e-businesses, security and backup
  applications

31
Breaking the limits of traditional tape storage

• Tandberg has worked with Optical technology for
  tape readout since 1993 (TD has patents and
  IP)
• Matrix Planar Write Head - a revolution in
  writing with small track pitch (TD has
  exclusive rights)
• New inventions has overcome the shortcomings of
  the technology
• Allows a major leap in track density
• Ultra high optical resolution
• This combination allows very high density and
  parallelism at low cost

32
32 Tracks and More Written Simultaneously
33
Optical Readout Head
Collimated laser
Detector
Beam splitter
array
Objective lens
Solid Immersion Lens Without Air Gap (SILWAG)
34
Introducing a new revolutionary storage device
First generation product

• Technology enablers
• Matrix Planar Write Head
• Optical Read Head
• New mechanical platform
• New Cartridge Concept
• Technology allows fast introduction of new
  product generations (every 18 months)

• Capacity 600GB native
• Transfer rate 64MB/s native
• Average access time
• Media cost lt 0.1/GB
• SCSI and Fiber interface
• Automation friendly design
• Very competitive cost

lt3,5 sec.
35
Very Cost Competitive
NetApp Filer

• 1TB NAS system from NetApp is 235K
• 1TB Celerra system from EMC is 1000K
• 1,2 TB NAS system(2 drives 2 HDD thin
  server) from O-MaSS can be lt20K

EMC Celerra
36
Development Plan

• Important milestone Q2 2001
• Critical technology will be demonstrated
• Q4 2000 Optical read technology
• Q1 2001 32 channel write
• Partner agreements in place
• First generation product specified
• Product Development Start
• Development time 24 months

37
Tandberg Data

• Your storage partner today and in the future
