Grounding and Cabling for the Small Studio

• David Etlinger
• 1/17/2006

2
Disclaimers

• NEVER defeat the AC ground!! (round prong)
• AC current can KILL if in doubt, stop and get
  more info
• I am not an electrician so dont count on me to
  keep you safe

3
Objectives

• How can we get rid of that annoying hum?!?
• How can we reduce the noise floor through proper
  cabling?
• How can we keep our equipment and ourselves safe
  while doing it?
• Can we do this systematically, not haphazardly?

4
Basic Definitions

• Voltage (Potential) difference in charge
  between two points (V Volts)
• Current the flow of electricity (positive to
  negative) (I Amperes)
• Resistance a components opposition to current
  flow (R Ohms)

V I R
5
Part I

• Grounding

6
Grounding (Earthing)

• Ground (1) Literally the Earth, effectively a
  point with 0 potential and infinite
  charge-holding capacity
• Ground (2) The lowest potential point in a
  circuit, serving as a current return path

Signal Ground
Chassis Ground
Earth Ground
7
Two-Prong Outlets
Hot Black, Red or Blue Neutral - White
8
Three-Prong Outlets
Hot Black, Red or Blue Neutral White Ground
Green
9
Already a Problem

• Many, many home AC circuits are wired improperly
• This can cause noise and shock hazards
• Use a multimeter or 5 Radioshack tester to
  verify every AC outlet

10
Short Circuit with Proper Grounding
11
Short with Broken Ground
Mics and Electric Guitars with broken grounds are
especially dangerous
12
(No Transcript)
13
Ground Noise

• All signals are referenced to ground
• Noise (voltage changes) on the ground line create
  noise in the signal
• Since AC oscillates at 60Hz, this often results
  in a 60Hz hum

14
Ground Loops

• One point, two paths to ground
• Current requires a closed loop to flow
• Two paths to ground makes a closed loop
• Ground noise is then possible

15
(No Transcript)
16
Chassis-to-Chassis

• Touching chassis can form an electrical
  connection
• Rackmount rails can also connect chassis
• This can be good or bad, depending on the
  situation

17
Noise Source Two Circuits
Easiest solution Put both devices on one AC
circuit
18
Noise Source Dirty Ground

• Remember V I R Low resistance means big
  current
• Solve with a power conditioner (Furman, etc.) or
• isolation transformer
• Or put everything on one AC outlet, but watch
  the
• power draw

19
Induced Current
20
Induced Ground Current
21
Solution
22
Induced Current, Contd

• Usually, 6 separation is enough to eliminate
  induced current
• Wall-wart transformers have unpredictable fields
  keep them as isolated as possible
• Induced currents cannot be totally eliminated

23
Other Sources of Ground Noise

• Internal Power Supply (Induction and Capacitance)
• Upgrade or mod the equipment
• use balanced cables

24
Fixing Ground Loops

• Put everything on one AC circuit
• Use a current meter like Kill-a-Watt or Power
  Angel to measure current draw
• Separate Signal cables from AC cables (and esp.
  Wall-wart transformers)
• Try to keep at least 6 between
• Cross at 90 if necessary
• Use Balanced Cables wherever possible

25
Part II

• Cabling

26
Balanced Cabling CMR
27
Balanced Advantages

• High rejection of ground noise
• Also rejects external EMF
• CMR not perfect still wise to minimize ground
  noise
• Proper operation depends on proper ground wiring

28
AC vs. Signal Ground

• AC Ground is designed for safety
• Signal Ground is an internal reference for
  circuit paths
• Signal Ground is usually tied to Chassis Ground
  at one point
• Balanced cables should ALWAYS use chassis ground

29
(No Transcript)
30
WRONG Signal Ground
31
RIGHT Chassis Ground
32
Problems

• Much old or cheap equipment uses signal ground
• Unfortunately, this can cause noise even with
  balanced connections
• The only choices are upgrading or modding

33
Finding Improper Grounding

• Visual Inspection
• Use a multimeter to test for voltage between
  shield and chassis
• Should be very low (ideally 0V)
• But, could tie to both chassis and signal ground

34
Fixing Improper Balanced I/O

• Best Cut the trace to signal ground and bond to
  chassis ground
• Easier Disconnect the cable shield at the end
  tied to signal ground
• Breaks any ground loops
• But shield is now an RF antenna
• Can alleviate by bonding shield to chassis
  through a 0.01µF capacitor
• But then why not just mod the equipment?!?

35
Worst Case

• Both input and output tied to signal ground
• No standard solution, but most people connect one
  end of the shield
• Which end is unimportant, but you must make the
  same choice each time
• Might be a very slight benefit to lifting at the
  input side

36
One More Problem

• Units with a wall-wart transformer are not
  connected to AC ground
• These units can have balanced I/O
• Solve this by bonding the ungrounded chassis to a
  known grounded chassis

37
Sidebar Cable Quality

• Cable quality varies substantially
• Foil shields best protection but easily damaged
• Use in fixed installations
• Braided shields look for maximum coverage

38
Some Brands

• Pro Quality Canare, Mogami
• Also good Belden, Gepco, Rapco, Whirlwind
• AVOID HOSA
• Monster Good but way overpriced
• Or make your own pro quality at a budget price
• Connectors Neutrik, Switchcraft

39
Unbalanced Cabling

• Two conductors Hot and Neutral
• No CMR no magnetic field rejection
• Often found on semi-pro or consumer gear
• ¼ TS (mono) RCA
• Always keep unbalanced runs as short as possible

40
Shield goes to Signal Ground!

• Shield acts as current return path
• Necessary to form a complete circuit
• Not a true shield but does offer some protection

41
Best Solution Convert to Balanced
42
Next Best Solution Transformers
www.whirlwindusa.com
Audio Isolation Transformers DI Boxes Many
Preamps etc.
43
(No Transcript)
44
Last Resort Cut the Shield

• N.B. Cutting the shield on a single-wire cable
  will ruin the cable!!
• We are going to cut the shield on a two-wire
  (balanced) cable
• This modified cable can then be used to connect
  unbalanced lt-gt balanced

45
Most Common Unbalanced ? Balanced

• Simply disconnect the shield at one end
• TRS sleeve XLR pin 1

46
Balanced ? Unbalanced
47
Balanced ? Unbalanced
48
Balanced ? Unbalanced
49
Hierarchy of Preference

• Balanced --gt Balanced
• Unbalanced --gt Balanced
• Balanced --gt Unbalanced
• Unbalanced --gt Unbalanced
• Chassis-shielded at both ends
• Chassis-shielded at one end, other end lifted
• Signal-shielded at one end, other end lifted

50
More Info

• If the choice of which end to cut is arbitrary,
  make the same choice each time
• Many possible scenarios
• See the two Rane references for excellent charts
• Also see Jensen whitepapers for a more technical
  discussion

51
Summary of Best Practices

• Connect all devices to one AC circuit
• Use balanced I/O whenever possible
• Transformer-Isolate unbalanced lines when
  possible
• Cut shielding at one end if necessary
• Keep signal lines away from AC (esp. wall-warts)
• Cross signal and AC lines at 90 if necessary

52
Noise Isolation Procedure

• Disconnect everything
• Connect monitors to main I/O verify good
  grounding and no noise
• Connect balanced gear one by one verify no noise
• Connect unbalanced gear one by one modify until
  noise is acceptable

53
Sidebar Advanced Studio Grounding

• Pros
• Can reduce noise floor to commercial-studio
  levels
• Cons
• Complex
• Expensive
• Often a workaround for improper cabling or
  equipment design

54
Primary Techniques

• Isolated Ground drive a dedicated ground bar,
  completely separate from the main AC grid
• Star Grounding Use heavy copper wiring to ground
  every device to one central point

55
Balanced Power
Common-Mode Rejection Cancels Ground Noise (just
like balanced audio!)
56
Balanced Power Pros and Cons

• Pros
• Eliminates noise from reactive current (i.e., bad
  internal design)
• Isolates from building power
• Cons
• Wont solve all ground loop problems
• Pricey!! (1000 and up)

57
Digital Audio Cables

• Digital signals themselves should be immune to
  ground noise
• But, the cabling can create ground loops that
  affect other signals
• AES/EBU Isolation transformers prevent loops
• Optical S/PDIF (TOSLink) No electrical
  connection so no loops
• Coaxial S/PDIF Supposedly isolated but some
  cheap equipment isnt
• Can build an isolator usually easier solutions

58
Interfacing with the Computer

• Tricky!!!
• High power load might require a separate AC
  circuit
• Many different I/O paths

59
Common I/O schemes

• Soundblaster-type cards
• Almost always unbalanced
• Treat like any other unbalanced I/O
• Firewire Interfaces (MOTU 828, etc.)
• Firewire grounds to the computer
• Must then consider the computer part of the
  grounding topology

60
Computer I/O Contd

• Cable Modem
• Ethernet interfaces usually wont link grounds
• USB interfaces can link computer to cable ground
• Use a Cable Isolator to break the coax ground
• Many other I/Os possible
• Youll need to experiment

61
Final Sidebar Impedance

• Too complex to cover here
• Basically, impedance is like a frequency-dependent
  resistance
• Really good CMR requires I/O circuits with good
  impedance design
• If you want really really low noise, read up on
  impedance

62
Grounding References

• http//www.epanorama.net/documents/groundloop/
• http//www.equitech.com/articles/articles.html
• http//www.rane.com/note151.html
• http//www.dself.dsl.pipex.com/ampins/groundloops/
  grndloop.htm

63
Cabling References

• http//www.jensen-transformers.com/apps_wp.html
• http//www.rane.com/note110.html

64
http//www.davidetlinger.com

• Good luck!!
