CSCI 435 Compiler Design

1
CSCI 435 Compiler Design

• Week 6 Class 3
• Section 4 to Section 4.1.2
• (279-290)
• Ray Schneider

2
Topics of the Day

• Processing the intermediate code
• Interpretation
• Recursive Interpretation
• Iterative Interpretation

3
Where we are ...

• Now we have an annotated syntax tree, either
  actually in memory as a data structure (Broad
  Compilers) or implicitly available during parsing
  (Narrow Compiler).
• The Annotated Syntax tree bears traces of its
  origin, the language constructs and the like,
  represented by nodes and subtrees, despite the
  relative paradigm independence of the methods
  being used
• NOW THE NEXT STEP Transforming the AST into
  Intermediate Code

4
Status of various modules in compiler construction
The AST is full of nodes reflecting the specific
semantic concepts of the source language.
Intermediate Code Generation reduces the set of
specific node types to a small set of general
concepts easily implemented on actual machines.
FIND and REWRITE Intermediate Code Generation
finds the language characteristic nodes and
subtrees in the AST and rewrites them into
subtrees that use only a small number of
features, each corresponding closely to a set of
machine instructions.
5
After FIND and REPLACE

• The resulting tree should be called THE
  INTERMEDIATE CODE TREE but is usually still
  called the AST
• Features of the Intermediate Code Tree are
• expressions, including assignments
• routine calls, procedure headings, and return
  statements,
• conditional and unconditional jumps
• IN ADDITION
• administrative features, ex. memory allocation
  for global variables, activation record
  allocation, and module linkage information
• the entire range of high-level concepts of the
  language is replaced by a few rather low-level
  concepts

6
Processing the Intermediate Code

• Involves either ...
• A Little Pre-processing followed by execution on
  an Interpreter, or
• A lot of Pre-processing in the form of machine
  code generation followed by execution on hardware
• Whatever the processing system ...
• Writing the Run-Time and Library system is the
  majority of the work and is primarily just brute
  force coding.
• We will begin by looking at Interpretation

7
Simplest way ...process AST using an ...

• INTERPRETER
• An Interpreter considers the nodes of the AST in
  the correct order and performs the prescribed
  actions required by the semantics of the language
• NOTE unlike compilation, the input data is
  required
• Interpreter performs actions similar to the CPU
  except that it works on AST nodes rather than
  Machine Instructions
• A CPU by contrast works on Machine Instructions
  given in the correct order and performs the
  actions demanded by the language as translated
  into the instructions required by the semantics
  of the machine
• TWO KINDS OF INTERPRETERS
• RECURSIVE (works directly on the AST), and
• ITERATIVE (works on a linearized version of the
  AST)

8
Simple Recursive Compiler from 1.2.8 fig 1.19
(21)
9
Recursive Interpretation

• An interpreting routine is provided for each node
  type in the AST
• Each such routine calls other similar routines
• The meaning of the language constructs are
  defined as a function of the meanings of their
  components
• The Interpretation Starts by calling the
  interpretation routine for Program with the top
  node of the AST as a parameter
• An important ingredient of a Recursive
  Interpreter is the UNIFORM SELF-IDENTIFYING DATA
  REPRESENTATION

10
Uniform Self-Identifying Data Representation

• The Interpreter has to manipulate data values of
  unknown types and sizes that are not known when
  the Interpreter is written
• Implementation requires a generic model
• implementing values as variable-size records that
• specify the type of the run-time value
• its size and the run time value itself
• a POINTER to such a record serves as the VALUE
  during Interpretation

11
Example Complex Numbers

• Two Parts of Data Representation
• Actual Values, vary from entity to entity
• Type of Value, things in common

"re"
"im"
"real"
Specific to the given value of type
complex_number
Common to all values of type complex_number
12
Status Indicator another important feature

• Used to direct the flow of control
• Primary Component
• Mode of Operation of the Interpreter an
  enumeration value with normal value something
  like "Normal Mode" indicating sequential flow of
  control, other values like Jumps, Exceptions,
  Function Returns
• Second Component
• value in the wider sense Supply more information
  about the Non-Sequential Flow of Control, ex.
  Return Mode, Names and Values of Exceptions,
  Label for Jump Mode, etc.
• Status Indicator should contain file name and
  line number of text where status indicator was
  created and possibly other debugging information
• Each interpreting routine checks the status
  indicator after each call to another routine to
  see how to carry on

13
Outline of a routine for recursive interpretation
of an if-statement
PROCEDURE Elaborate if statement (If node)
SET Result TO Evaluate condition (If node
.condition) IF Status .mode / Normal mode
RETURN IF Result .type / Boolean
ERROR "Condition in if-statement is not of type
Boolean" RETURN IF Result .boolean
.value True Elaborate statement (If node
.then part) ELSE Result .boolean .value
False // Check if there is an else-part at
all IF If node .else part / No node
Elaborate statement (If node .else part)
ELSE If node .else part No node SET
Status .node TO Normal mode
14
Typical Handling of the Symbol Table

• Variables, named constants, other named entities
  are handled by the Symbol Table which is handled
  like the example below for something like
  variable V of type T say a record called
  "Declarable"
• a pointer to the name V,
• the file name and line number of its declaration
• an indication of its kind (variable, constant,
  field selector, etc.)
• a pointer to the type T
• a pointer to newly allocated room for the value
  of V
• a bit telling whether or not V has been
  initialized, if known
• one or more scope- and stack- related pointers,
  depending on the language
• other data as required (language dependent)

15
Summary

• Recursive Interpreter can generally be written
  quickly, so useful for rapid prototyping
• Not the best architecture for heavy duty
  interpreting but good for debugging language
  concepts and features
• Big Disadvantage Very Slow, as much as 1000
  times slower than a compiler for the same
  language
• This can be improved somewhat by doing as much
  static context checking as possible in the
  pre-interpretive phase (see Memoization pg.286)

16
Iterative Interpretation

• Structure of an Iterative Interpreter is much
  closer to that of a CPU than a Recursive
  Interpreter is.
• Consists of a flat loop over a case statement
  which contains a code segment for each node type
• the code segment for a node type implements the
  semantics of that node type
• It requires a fully annotated and threaded AST
  and maintains an ACTIVE NODE POINTER which points
  to the node being interpreted, i.e. the ACTIVE
  NODE
• The interpreter runs the code for the Active Node
  which then points to another node, the successor
  node.

17
include "parser.h" / for types AST_node and
Expression / include "thread.h" / for
Thread_AST() and Thread_start / include
"stack.h" / for Push() and Pop() / include
"backend.h" / for self check / static
AST_node Active_node_pointer static void
Interpret_iteratively(void) while
(Active_node_pointer ! 0) / there is
only one node type, Expression /
Expression expr Active_node-pointer
switch (expr-gttype) case 'D'
Push(expr-gtvalue) break case
'P' int e_left Pop() int e_right
Pop() switch (expr-gtoper)
case '' Push(e_left e_right) break
case '' Push(e_left e_right) break
break
Active_node_pointer Active_node_pointer-gtsuccess
or printf("d\n",Pop()) / print the
result / void Process(AST_node icode)
Thread_AST(icode) Active_node_pointer
Thread_start Interpret_iteratively()
An iterative interpreter for the demo compiler of
1.2 JUST A BIG SWITCH STATEMENT
18
the Iterative Interpreter 1

• Data Structures resemble those inside a compiled
  program more than those in a Recursive
  Interpreter
• ex. Array holding the global data, if source
  language is stack oriented, then the iterative
  compiler maintains a stack.
• Variables and Entities have an address which is
  generally an offset into a memory array
• Symbol table is no longer relevant, but useful to
  generate better error messages

19
the Iterative Interpreter 2

• Iterative interpreter has more information about
  run time events that a compiled program but less
  than a recursive interpreter
• one can make up for the lack of a symbol table in
  an iterative interpreter by using SHADOW MEMORY
  parallel to the memory arrays maintained by the
  interpreter. The Shadow Memory holds properties
  of the corresponding byte in memory, ex. "is
  uninitialized", "is a non-first byte of a
  pointer", "belongs to a read only array" the
  different modes can be encoded with byte-codes
• Some Iterative Interpreters store the AST in a
  single array for several reasons
• easier to write it to file
• more compact representation
• reusable without regenerating the AST

20
Three Forms of Storing an AST a Graph
21
Storing an AST in an array or as
pseudo-instructions
Array
condition
IF
condition
IF_FALSE
statement 1
statement 1
JUMP
statement 2
statement 2
statement 3
statement 3
statement 4
statement 4
Pseudo- Instructions
22
AST Constructions and interpretation

• Usually puts the successor of a node right after
  the node
• may even omit the successor pointer altogether
  and just make it the default and only include
  pointers when the next node is NOT the successor
  node
• Historically an Iterative Interpreter mimics a
  CPU working on a compiled program and the AST
  array mimics the compiled program
• Iterative Interpreters are easier to write even
  than recursive interpreters and much easier than
  compilers
• Only serious deficiency is speed, even the best
  interpreter is typically 30 times slower that an
  optimized compiler

23
Next time ...

• Next time we'll start looking at Code Generation
• We'll spend about two or three classes on it.

24
Homework for Week 8

• Bison Familiarization
• Read the entire 39 pages of "A Compact Guide To
  Lex and Yacc" // you can skim through it the
  first time
• THEN concentrate first on getting the lex example
  on page 10 running
• THEN after you have that running go on to
  Practice, Part 1 and strive to get the primitive
  calculator running (pages 14 through 17)
• HINTS the lex input on page 10 can be made to
  run by extending it with the line (cribbed from
  our text)
• int yywrap(void) return 1 //at the end, and
  you have to put
• include ltstdlib.hgt //at the top of your yy.lex.c
  output then the code will add line number to a
  text file reading the file name in from the
  command line and sending the output to stdout.

25
References

• Text Modern Compiler Design Figures
• Lex A Lexical Analyzer Generator by M.E. Lesk
  and E. Schmidt
• Yacc Yet Another Compiler-Compiler by Stephen C.
  Johnson
• see http//dinosaur.compilertools.net/yacc/index.h
  tml and http//dinosaur.compilertools.net/lex/in
  dex.html
