Title: Reconfigurable Systems Development Research at BWRC


1
Reconfigurable Systems Development Research at
BWRC
  • John Wawrzynek
  • University of California, Berkeley
  • Berkeley Wireless Research Center

2
System Development and Prototyping
A long tradition
  • These systems prototypes validate novel
    algorithms and circuits.
  • Enable synergy and join optimization not possible
    otherwise.
  • Provide students with broad education.

Infopad (Brodersen, Rabaey et al - First ever
wireless multimedia terminal (1995)
Critical to the continued success of the
center Is our agility in building working system
prototypes.
3
Central Themes in Systems Design Research
  • Complexity Management controlling design and
    verification costs.
  • Ease of specification/programming, modularity
    and reuse.
  • Robustness designs that work in the presence of
    uncertainly.
  • Scalability, design longevity, tolerance to
    poorly controlled technologies, defects, faults,
    etc.
  • Power, Price, Performance

4
Keys to Advancement
  • Proper design abstractions
  • Models of computation / programming, etc.
  • Reconfigurable computing platforms
  • Ideal sandboxes (emulations platforms)
  • Properly engineered reconfigurable systems
    provide huge price/performance/power and
    robustness advantages

5
Promising Design Abstractions
Simulink (discrete time block-based diagrams) has
been used successfully at BWRC.
  • Related, more general, models of computation have
    emerged in recent years
  • e.g. KPN, SCORE, CLICK,
  • Systems as networks of decoupled
    software/hardware processes with stream-based
    asynchronous communication links.
  • Models make communication explicit.
  • Latency tolerance of streams enable efficient,
    flexible execution schedules, and eases
    placement/routing, deals with uncertainty in the
    mapping process.

6
BEE2 Platform Development
Chen Chang, Pierre Droz, Henry Chen, Andrew
Schultz, Dan Burke, Bob Broderson
  • 5 Virtex-IIPro70 FPGAs ? 2.5M logic gates
    equivalents
  • 20GB DRAM
  • 20 10Gbps connections
  • 10GigE/Infiniband
  • Inter-module connections
  • I/O, analog interfaces

7
BEE2 Module Design
FPGAs
DRAM
10GigE ports
Compact Flash Card
DVI/HDMI
USB
10/100 Enet
14X17 inch 22 layer PC board 4K/module w/o
FPGAs or DRAM
8
BEE2 Analog Interface
  • Use IBOB to fanout the serial Infiniband/Enet
    connections to parallel LVDS/LVPEL signals
  • IBOB can be connected to BEE2 modules or directly
    to Infiniband/Enet switches
  • Several ADC and DAC modules have been developed.

With Dan Werthimer, UC Berkeley Space Sciences Lab
9
If You Build it, They Will Come
Current and Soon to Be Users
  • BWRC ASIC/SOC emulation, Cognitive Radio
    Algorithm Exploration, PicoRadio simulation, LDPC
    simulation, EM Antenna Simulation
  • SSL, UC Radio Astronomy Lab SETI, Allen
    Telescope Array
  • GSRC Home Media Gateway
  • RAMP UCB, Stanford, UW, UT Austin, CMU, MIT,
    Intel Multiprocessor Emulation
  • Bob Conn/ Research Triangle Inst. Spice Circuit
    Simulation
  • Rob Reutenbar/CMU Speech Recognition
  • Stanford BioInformatics Group Biological
    signaling research
  • Chris Dick, Kees Vissers / Xilinx Signal/Media
    Processing
  • Microsoft Research / Chuck Thacker Computer
    System Research
  • ST Microelectronics
  • Widespread interest and dozens of other requests.

10
Lots of BEE2s
  • Hardware
  • Module in production use, JPL Deep
    Space-Network (Barstow, CA)
  • 10 modules in test/bring-up
  • Currently allocated to BWRC, SSL, RAL, Xilinx
  • Working with SAE Materials to move from prototype
    to turn-key production and move production
    management away from BWRC
  • Production of another 25 modules underway
  • Gateware/Software
  • Linux port
  • Simulink/Xilinx-EDA integration for automatic
    compilation to bit-files
  • Several Radio Astronomy applications (with ADC
    interface) complete (spectrometers, correlators)
  • Board-support package close to release (test
    suites, docs, app notes)
  • First BEE2 users hands-on workshop January 17-19.

11
SOCRE (System-on-Chip Realtime Emulation)
Brian Richards, Pierre Droz, Chen Chang, Bob
Broderson
  • Builds on success with BEE Chip in a Day
  • Extends to systems-on-chip
  • heterogeneous mixed-signal systems
  • Processors cores, analog blocks
  • Uses BEE2 platform for system emulation
  • (Challenging issues in analog block emulation)

Could we place cell phone calls on the BEE2?
12
SOCRE Demonstration for DARPA
Correlator for Image Formation
Custom XMAC chips
  • Computing requirements grow with square of size
    of array.
  • Representative of many signal processing tasks.
  • Simple control processor for diagnostics and
    control.
  • Demonstrates design flow on BEE2 and 90nm node.

In collaboration with Dan Werthimer, UCB SSL
13
Research Accelerator for Multiple Processors
  • Problem
  • Compilers, operating systems, architectures not
    ready for 1000s of CPU per chip, but thats where
    were headed
  • How do research on 1000 CPU systems in compilers,
    OS, architecture?
  • Solution
  • Create 1000 CPU system from 40 FPGAs
  • Distribute out-of-the-box Massively Parallel
    Processor that runs standard binaries of OS and
    applications to all major research institutes in
    the US
  • 500K committed by Xilinx
  • NSF Infrastructure grant under review

Core Team D. Patterson, J. Wawrzynek, J. Rabaey
(UCB), J. Hoe (CMU), D. Chiou (UT Austin), C.
Kozyrakis (Stanford), K. Asanovic (MIT), M.
Oskin (U Wash.), S. Lu (Intel)
14
RAMP as a Multiprocessing Watering Hole
Parallel file system
Dataflow language/computer
Data center in a box
Thread scheduling
Internet in a box
Security enhancements
Multiprocessor switch design
Router design
Compile to FPGA
Fault insertion to check dependability
Parallel languages
  • RAMP as next Standard Research Platform? (e.g.,
    VAX/BSD Unix in 1980s)
  • RAMP attracts many communities to shared artifact
    ? Cross-disciplinary interactions ? Accelerate
    innovation in multiprocessing

15
RAMP Design Framework
  • Question How do we get contributing developers
    from across the country to work independently on
    CPUs, network interfaces, memory systems, etc.?
  • Answer RAMP Desription Language (RDL)
  • Defines and supports standard module interfaces
    and execution model.
  • Supports both cycle-accurate emulation of
    detailed parameterized machine models and rapid
    functional-only emulations
  • Carefully counts for Target Clock Cycles
  • Units in any hardware design languages (will
    work with Verilog, VHDL, BlueSpec, C, ...)
  • RDL used to describe plumbing to connect units

16
RAMP Description Language
Greg Gibeling, Andrew Schultz, Krste Asanovic
  • Design composed of units that send messages over
    channels via ports
  • Units (gt 10,000 gates)
  • CPU L1 cache, DRAM controller.
  • Channels ( FIFO)
  • Lossless, point-to-point, unidirectional,
    in-order message delivery

Similar to process network models (KPN, SCORE,
click/cliff) with explicit management of target
clock cycles.
17
Smart Home Gateway The Challenge
  • New devices are entering the home environment at
    an increasing rate, often effectively replacing
    older ones. VCR ? DVD
  • Standards are proliferating communication,
    recording and playback, display
  • Devices do not interconnect
  • Control is a nightmare

18
Dealing with the Myriad of Protocols and Formats
Put the Intelligence in the Network Smart Home
Routers
Home routers Provide on-the-fly protocol
conversion and trans-codingbased on properties
of source and destination devices
Courtesy SIA-MARCO GSRC
19
The Reconfigurable Home Gateway
  • Research Opportunities
  • Unique high-efficiency Codec development
  • Reconfigurable and power-aware processor
    architectures (targeted high-performance,
    high-computational density)
  • Techniques for plug-and-play (discovery,
    transcoding, etc.)
  • High-level control architecture (new level
    abstraction to allow feedback to user in a device
    independent way)
  • Adaptive wireless, soft radios
  • User-aware adaptation (ex baby-cam feed follows
    you around the house, audio sweet-spot
    automatically adjusts)
  • Protocols, including encryption, compression

20
Reconfigurability is Key
  • Adaptation to changing requirements
  • New devices with new Codecs constantly being
    added - need true plug-and-play.
  • Residents make minute to minute system
    configuration changes - system resources must be
    reallocated as needed.
  • Reconfigurable devices offer high-computational
    density (ASIC-level performance) needed to
    efficiently process HD video, etc.

Current work uses off the shelf FPGA development
boards. New work involves design of novel
reconfigurable architectures.
Xilinx XUP Board
21
Current Status
Dan Burke, Chris Baker, Stanley Chen, Yury
Markovskiy, Kaushik Ravindran, Ken Lutz, Jan
Rabaey
