Title: Grouper: A Toolkit for Managing Groups


1
Grouper A Toolkit for Managing Groups
  • Tom Barton
  • blair christensen
  • University of Chicago

2
Outline
  • The problem with groups
  • Case study U Chicagos USITE computer labs
  • Tour of Grouper
  • USITE case study revisited
  • Grouper project status
  • Bonus round personal groups

3
Groups facilitate …
  • Customization application UI tailored to users
    affiliations with the organization
  • Authorization
  • Lightweight - relationship info feeding access
    decisions
  • Heavyweight - assignment of structured
    privileges to groups
  • Messaging, scheduling, collaboration
  • Departments, courses, programs, cmtes, teams, …
  • Posix naming services

4
Group management issues
  • Coordinating many sources of information
  • Provisioning groups in many locations
  • Supporting several styles of access to group
    membership information
  • Aging of groups and of memberships
  • Use of subgroups vs. effective membership
  • Referring to set theoretic combinations of groups
    (compound groups)
  • Privacy visibility requirements

5
The USITE access problem
  • Must control access to computers in labs
    independent of ability to authenticate
  • U Chicagos Networking Services Information
    Technologies (NSIT) established the Identity
    Management Working Group to solve this type of
    problem
  • Youll see nsit and usite in names of things
    to follow

6
USITE access policy
  • Students
  • 23 categories of current students
  • Some entitle USITE access, some disenfranchise,
    others fail to entitle
  • Time of year dependency for some categories
  • Current faculty staff are entitled
  • Other more loosely affiliated people are not
    entitled
  • Exceptional administrative admits and denies
    across all categories above

7
Use of group management
  • Various elemental USITE-related categories of
    people are modeled as groups
  • Subgroups are used to roll-up effective admit or
    deny status
  • Some groups are automatically managed, others
    manually
  • Some roll-up groups are manually managed to deal
    with time dependency or change in access policy

8
Groups model for USITE access (ACL is shaded
green but not red)
usite_eligible (manual)
usite_barred (manual)
admin_admit (manual)
admin_deny (manual)
ucfaculty (auto)
ucstaff (auto)
categories of barred students
categories of entitled students
time dependent student categories
9
Management related groups
  • Management privileges for manually managed groups
    also need to be managed!
  • So, more groups list who has what authority in
    managing groups that mediate USITE access
  • Director of Learning Environments
  • Lab Managers
  • Student staff

10
Data flow Groupers role in USITE access
lab
SIS
HR
Person registry
LDAP
Group registry
Dir. Learning Environments
uid jdoe ucAffiliation … isMemberOf …
Grouper API
Lab Managers
Student staff
11
Grouper groups
  • Stored in an RDBMS, the Group Registry
  • Attributes of groups
  • Name
  • Description
  • Members
  • Possible to extend the set of attributes to
    support groups with more specific purposes

12
Directory of groups
  • Groups are created within a hierarchy of
    directories, like files within a computers
    directory system
  • Directories are also named
  • Sometimes need to use the full name of a group,
    like the full pathname of a file
  • Example /nsit/usite/admin_admit
  • The directory delimiter can be configured for
    different effect
  • Example nsitusiteadmin_admit

13
Grouper privileges
  • Access privileges - who has what access (read,
    write) to a groups attributes
  • Naming privileges - who can create a group or
    subdirectory in what part of the directory of
    groups

14
Access privileges
  • VIEW groups name in lists can refer to it,
    e.g., make it a subgroup of another group
  • READ basic information about a group
  • UPDATE membership and administer VIEW, READ,
    UPDATE privileges
  • ADMIN can modify everything, including group
    name, description, privileges, and can delete
    the group
  • OPTIN can add self to the members list
  • OPTOUT can remove self from the members list

15
Naming privileges
  • STEM privilege in a given directory enables
    creation of subdirectories and administration of
    CREATE and STEM privileges for the directory and
    its immediate subdirectories
  • Motivating idea a directory is a naming stem
    over which authority is exercised and delegated
    by those with stem privilege
  • CREATE a group in a given directory

16
Built-in privilege implementation
  • All access naming privileges can be assigned to
    individual members or to groups
  • Subgroups, compound groups, and aging can be used
    to manage privileges
  • Abstracted interfaces are presented for privilege
    management
  • Sites can hook in their own privilege management
    and bypass Groupers built-in system

17
USITE revisited Groupers role
  • Make an nsitusite directory in the group
    registry
  • Groups created within it
  • dir_learning_env, lab_managers, student_staff
  • usite_eligible, usite_barred
  • admin_admit, admin_deny
  • Give stem privilege for nsitusite to the
    Director of Learning Environments
  • She can run her groups empire within

18
USITE group access privileges (unqualified names
in nsitusite directory)
usite_eligible Adir_learning_env V,Rall
usite_barred Adir_learning_env V,Rall
admin_admit Uusite_manage V,Rusite_view
admin_deny Uusite_manage V,Rusite_view
ucfaculty V,Rall
ucstaff V,Rall
categories of barred students
Vall
Vall
Vall
categories of entitled students
Vall
Vall
time dependent student categories
Vall
Vall
Vall
Vall
19
USITE group management privileges (unqualified
names in nsitusite directory)
20
Grouper v1 features
  • API UI for basic group management
  • Create, read, update, delete, import, export
  • Distributed management
  • Subgroups compound groups
  • Aging of groups and memberships
  • Abstracted interfaces for
  • Group and directory privileges
  • Subject lookup
  • Last activity

21
Phases of Grouper v1 development
  • Phase 1 Basic management and export functions
  • Phase 2 Compound groups Signet integration
  • Phase 3 Aging of groups and memberships
  • Phase 1 API available before end of November 2004

22
Grouper deliverables
  • U Chicago - Java API
  • U Bristol - Java UI
  • You contributed loaders connectors
  • Subject Lookup implementation
  • jointly with Signet project
  • Group Registry creation scripts sample batch
    import/export scripts
  • Documentation

23
Grouper UI status
  • Conceptual mock-up completed
  • Modular design for look and feel
  • Grouper Signet UIs will leave the factory
    floor bearing an I2 family resemblence

24
Personal groups
  • Any user can create groups named
    personalusernamegroupname
  • Good or evil?
  • Yeah! Low overhead to let everyone do groups
  • Booo! Valuable institutional data squirreled away
    in unknowable spaces that go away
  • Configuration
  • on/off
  • Root directory for personal namespace (personal
    above)

25
Further info participation
  • MACE-Dir list
  • MACE-Dir-groups conference calls
  • http//middleware.internet2.edu/dir/groups

26
