Local-Area Networks

1
Local-Area Networks
2
Topology

• Defines the Structure of the Network
• Physical topology actual layout of the wire
  (media)
• Logical topology defines how the media is
  accessed by the hosts

3
Physical Topology
4
LAN Devices in a Topology
5
Network Interface Cards (NICs)

• When Selecting a NIC, Consider the Following
• Network architecture
• Operating system
• Media type
• Data transfer speed
• Available bus types

6
NICs

• Bus Architectures
• ISA (Industry Standard Architecture)
• EISA (Extended ISA)
• PCI (Peripheral Component Interconnect)
• MCA (Micro Channel Architecture)
• PCMCIA (Personal Computer Memory Card
  International Association)

7
NICs in the OSI Model
8
Media

• The basic function of media is to carry a flow of
  information, in the form of bits.
• Layer 1 components.

9
Repeaters Layer 1
10
Repeaters
A repeater solves the problem of too many nodes
and not enough cable cleans, amplifies, and
resends a signal that is weakened by long cable
length.
11
Hubs Layer 1
12
Hubs

• Regenerate and repeat signals
• Used as network concentration points
• Multiport repeater

13
Bridges Layer 2
14
Bridges
Bridges filter traffic by looking at MAC
addresses.
Designed to create two or more LAN segments, each
of which is a separate collision domain
15
Switches Layer 2
16
LAN Switches
Combine the connectivity of a hub with the
traffic regulation of a bridge on each port
17
Switches
18
Routers Layer 3
19
Routers

• Two primary purposes path selection, and
  switching of packets to the best route
• Use logical addresses (network layer addresses)

20
Network Cloud
Layer 1 through 7 device
21
Network Segments
Connected by networking devices
22
Devices / Function / Layers
23
Data Flow Through LANs
