Overview of PCFGs and the insideoutside algorithms

1
Overview of PCFGs and the inside/outside
algorithms
based on the book by E. Charniak, 1993

• Presented by Jeff Bilmes

2
Outline

• Shift/Reduce Chart Parsing
• PCFGs
• Inside/Outside
• inside
• outside
• use for EM training.

3
Shift-Reduce Parsing

• Top down parsing
• start at non-terminal symbols and recurse down
  trying to find a parse of a given sentence.
• Can get stuck in loops (left-recursion)
• Bottom-up parsing
• start at the terminal level and build up
  non-terminal constituents as we go along.
• shift-reduce parsing
• (used often in machine languages which are
  designed to be as unambiguous as possible) are
  quite useful
• Find sequences of terminals that match right-hand
  side of CFG productions, and reduce them to
  non-terminals. Do same for sequences of
  terminal/non-terminals to reduce to
  non-terminals.

4
Example Arithmetic
5
(No Transcript)
6
Shift-Reduce Parsing

• This is great for compiler writers (grammars are
  often unambiguous, and sometimes can be designed
  to not be).
• Problems ambiguity. One rule might suggest a
  shift while another might suggest a reduce.
• S ? if E then S if E then S else S
• On stack if E then S
• Input else
• Should we shift getting 2nd rule or reduce
  getting 1st rule??
• Can get reduce-reduce conflicts as well, given
  two production rules of form A ? ? B ? ?
• Solution backtracking (a general search method)
• In ambiguous situations, choose one (using a
  heuristic)
• whenever we get to situation where we cant
  parse, we backtrack to location of ambiguity

7
Chart Parsing vs. Shift-Reduce

• Shift-reduce parsing computation wasted if
  back-tracking occurs
• the long np in Big brown funny dogs are hungry
  remains parsed while we search for next
  constituent, but it becomes undone if a category
  below it on the stack would need to be reparsed
• Chart parsing avoids reparsing constituents that
  have already been found grammatical by storing
  all grammatical substrings for duration of parse.

8
Chart Parsing

• Uses three main data structures
• 1) a key list, list of next constituents to
  insert in chart (e.g., terminals or
  non-terminals)
• 2) a chart (a triangular table that keeps track
  of starting position (x-axis) and length (y-axis)
  of a constituent
• 3) set of edges (things that mark positions on
  the chart rules/productions, and how far along in
  each rule the parse currently is (it is this last
  category that helps avoid reparsing).
• We can use chart-parsing for producing (and
  summing) parses for PCFGs and for producing
  inside/outside probabilities. But what are these?

9
PCFGs

• A CFG with a P in front.
• A (typically inherently ambiguous) grammar with
  probabilities associated with each production
  rule for a non-terminal symbol.

10
PCFGs

• Example parse
• Prob of this parse is
• 0.80.20.40.050.450.30.40.40.53.5e-10

0.8
0.3
0.2
0.4
0.4
0.05
0.45
0.4
0.5
11
PCFGs

• Gives probabilities for string of words, where
  t1n varies over all possible parse trees for
  word string w1n

12
Domination Notation

• Non-terminal dominating terminal symbols
• So in general, Njk,l means that the jth
  non-terminal (Nj) dominates terminals starting at
  k and ending at l (inclusive).

13
Probability Rules

• starting at k and ending at l, we get
• for any k,l and any m,n,q k m lt n q lt
  l
• X,Y, , Z can correspond to any valid set of
  terminals or non-terminals that partition the
  terminals from k to l.

14
Chomsky Hierarchy (reminder)
15
Regular grammar (reminder)

• Generates regular languages (e.g., regular
  expressions without bells/whistles, FSAs, etc.)
• A?a, where A is a non-terminal and a is a
  terminal.
• A?aB, where A and B are non-terminals and a is a
  terminal.
• A? ?, where A is a non-terminal.
• Ex anbm m,n gt 0 can be generated by
• S?aA
• A?aA
• A?bB
• B?bB
• B? ?

16
Context-Free (reminder)

• Generates context-free languages
• Left-hand side of production rule can be only one
  non-terminal symbol
• Every rule of the form
• A ? ?
• where ? is a string of terminals or
  non-terminals.
• context free since non-terminal A can always be
  replaced by ? regardless of the context in which
  A occurs.

17
Context-Free (reminder)

• Example generate anbn n 0
• A ? aAb
• A??
• Above language cant be generated by regular
  grammar (language is not regular)
• Often used for compilers
• No probabilities (yet).

18
Context-Sensitive (reminder)

• Generates context-sensitive languages
• Generated by rules of the form
• ? A ? ? ? ? ?
• A? e
• where A is a non-terminal, ? is any string of
  terminals/non-terminals, ? is any string of
  terminals/non-terminals, and ? is also any
  non-empty string of terminals-non-terminals.

19
Context-Sensitive (reminder)

• Example anbncn n 1
• A ? abc
• A? aABc
• cB ? Bc
• bB ? bb
• Example 2
• an n prime

20
Type-0 (unrestricted) grammar

• all languages that can be recognized by a Turing
  machine (i.e., ones that the TM can say yes, and
  then halt).
• Known as recursively enumerable languages.
• More general than context-sensitive.
• Example (I think)
• anbm n prime, m is prime following n
• aabbb, aaabbbbb,aaaaabbbbbbb, etc.

21
Independence Assumptions

• PCFGs are CFGs with probabilities, but there are
  other statistical independence assumptions made
  about random events.
• Probabilities are unaffected by certain parts of
  the tree given certain other non-terminals.

22
Example

• Following parse tree has equation

B1,3 is outside C4,5
A1,5 is above C4,5
23
Chomsky vs. Conditional Independence

• The fact that it is context-free means that only
  certain production rules can occur in the grammar
  specification. The context-free determines the
  set of possible trees, not their probabilities.
• This alone does not mean that the probabilities
  may not be influenced by parses outside a given
  non-terminal. This is where we need the
  conditional independence assumptions over
  probabilistic events.
• The events are parse events or just dominance
  events. E.g., without independence assumptions,
  p(w4,w5C4,5,B2,3) might not be the same as
  p(w4,w5C4,5,B1,3), or could even change
  depending on how we parse some other set of
  constituents.

24
Issues

• We want to be able to compute
• But number of parses of a given sentence can grow
  exponentially in the length of the sentence, for
  a given grammar ? naïve summing wont work.

25
Problems to Solve

• 1) compute probability of a sentence for a given
  grammar, p(w1nG)
• 2) find most likely parse for a given sentence.
• 3) Train grammar probabilities in some good way
  (e.g., maximum likelihood).
• These can all be solved by inside-outside
  algorithm.

26
A Note on comparisons to HMMs

• Text says that HMMs and probabilistic regular
  grammars (PRG) assign different probabilities to
  strings.
• PRG is such that summing probabilities of all
  sentences of all lengths should be one.
• HMM says that summing probabilities of all
  sentences of a given length T should be one.
• But HMMs have an implicit conditional on T. HMM
  probability is

27
A Note on comparisons to HMMs

• But HMMs can be defined to have an explicit
  length distribution
• This can be done implicitly in HMM by having a
  start and a stop state, thus defining P(T).
• We can alternatively explicitly make P(T) equal
  to the PRG probability of summing over all
  sentences of length T.

28
Example PRG its parses
29
forward/backward in HMMs

• Forward (alpha) recursion
• Backward (Beta) recursion
• Probability of a sentence

30
association of ?/? with outside/inside

• For PRG, backwards ? probability is like the
  stuff below a given non-terminal, or perhaps
  inside the non-terminal.
• For PRG, forwards ? probability is like the stuff
  above a given non-terminal, or perhaps outside
  the non-terminal.

31
Inside/Outside (?/?) probability defs.

• Inside probability the stuff that is inside (or
  that is dominated by) a given non-terminal,
  corresponding to the terminals in the range k
  through l.
• Outside probability the stuff that is outside
  the terminal range k through l.

32
Inside/Outside probability defs.
Outside Nj
Inside Nj
33
Inside/Outside probability

• Like in HMMs, we can get sentence probabilities
  given inside outside probabilities for any
  non-terminal.

34
Inside probability computation

• For Chomsky-Normal form
• for more general case, see todays handout from
  Charniak text, need to use details about edges in
  chart.
• Base case (to then go from terminal on up the
  parse tree)
• Next case consider range k through l, and all
  non-terminals that could generate wkl. Since
  Chomsky normal form, we have two non-terminals Np
  and Nq, but we must consider all possible
  terminal ranges within k through l so that these
  two non-terminals jointly dominate k through l.

35
Inside probability computation
sum over all pairs of non-terminals p,q and
location of split m.
by def. of chain rule of probability.
PCFG conditional independence
Rename
36
Inside probability computation

• m unique production rules
• n length of string
• computational complexity is
• O(n3m3)

37
Outside probability

• Outside probability
• it can also be used to compute the word
  probability, as follows
• how do we get this?

38
Outside probability computation

• Note again this is true for any k at all.
• So how do we compute outside probabilities?
• Inside probabilities are calculated bottom up,
  and (not surprisingly), outside probabilities are
  calculated top down, so we start at the top

un-marginalizing all non-terminals j.
chain rule
conditional independence and rename
39
Outside probability computation

• Starting at the top
• Next, to calculate outside probability for Njk,j,
  (and considering weve got Chomsky normal form),
  there are two possibilities that this could have
  come from higher constituents, namely Nj is
  either on the left or the right of its sibling

These two events are exclusive and exhaustive,
so this means well be needing to sum
probabilities of the two cases.
40
Outside probability computation
41
Outside probability computation
42
Outside probability computation

• m unique production rules
• n length of string
• computational complexity is
• O(n3m3)

43
Other notes

• We can form products of inside/outside values
  (but they have slightly different meaning than
  with HMMs).
• So final sum is the probability of the word
  sequence, and some non-terminal constituent
  spanning k through l (diff than HMM, which is
  just the observations). We get

follows again from conditional indep.
44
Training PCFG probabilities

• inside/outside procedure can be used to compute
  expected sufficient statistics (e.g., posteriors
  over production rules) so that we can use these
  in an EM iterative update procedure.
• this is very useful when we have a database of
  text, but we dont have a database of observed
  parses for this (i.e., when we dont have a
  treebank). We can use EM inside/outside to find
  a maximal likelihood solution to the probability
  values.
• All we need are equations that give us expected
  counts.
• note book uses notation and mentions ratios of
  actual counts C, but they really are expected
  counts Ecount which are sums of probabilities,
  as in normal EM. Recall expected value of an
  indicator is its probability.
• E1event Pr(event)

45
Training PCFG probabilities

• First, we need definition of posterior as ratio
  of expected counts for production
• Next we need expected counts

46
Training PCFG probabilities

• Lastly, we need terminal node expected counts
  that non-terminal Ni produced vocab word wj

47
Summary

• PCFGs are powerful
• Good training algorithms for them.
• But are they enough? Context-sensitive grammars
  were really developed for natural (written and
  spoken) language, but algorithms for them not
  efficient.
