SCRAP TIRE MARKET DEVELOPMENT

1
SCRAP TIRE MARKET DEVELOPMENT

• BY
• TERRY GRAY
• TAG RESOURCE RECOVERY
• TIRE WORKSHOP 2013
• SAN ANTONIO, TEXAS
• APRIL 3, 2013

2
PERSPECTIVE

• FIRST PROGRAM IN MINNESOTA IN 1984
• MANY U.S. STATES STILL DONT HAVE SUCCESSFUL
  PROGRAMS
• lt1 UTILIZED IN 1984, BUT ABOUT 80 IN 2011
• MEXICO CAN ACCELERATE ITS GROWTH BASED ON GOOD
  AND BAD HISTORICAL EXPERIENCES

3
US SCRAP TIRE MARKET TRENDS 2005-2011
4
MAJOR APPLICATIONS
5
ENERGY

• CEMENT KILNS
• POWER GENERATION
• PAPER MILLS
• DEDICATED FACILITIES
• PYROLYSIS/GASIFICATION

6
U.S. TIRE-DERIVED FUEL MARKET TRENDS 2005-2011
7
U.S. TIRE-DERIVED FUEL MARKETS 2011
8
CEMENT KILNS

• ENVIRONMENTALLY EXCELLENT
• ECONOMICALLY ATTRACTIVE
• QUICKLY DEVELOPED
• GENERALLY WHOLE TIRES, SOME TDF
• NEEDS CONSISTENT SOURCE
• PROGRAM CORNERSTONE

9
MODERN CEMENT FACILITY
10
CEMENT KILN
11
MANUAL FEED SYSTEM
12
AIR LOCK
13
INTO KILN
14
RAPID COMBUSTION
15
(No Transcript)
16
(No Transcript)
17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
(No Transcript)
23
(No Transcript)
24
POWER AND PAPER INDUSTRIES

• SPECIFIC BOILER TYPES INCLUDE CYCLONE,
  STOKER-FIRED, CFB
• DISPLACES COAL OR OTHER SOLID FUEL
• USES NOMINAL 1 OR 2 TDF, BEAD WIRE REMOVED

25
(No Transcript)
26
(No Transcript)
27
(No Transcript)
28
(No Transcript)
29
(No Transcript)
30
COMPARATIVE TDF PRODUCTION ECONOMICS
(CHIP SIZE VS TIRES/YR)
CHIP SIZE 500,000 1,000,000 1,500,000
2.0 69 -11 -42
1.5 82 BASIS -14
1.0 94 35 0
31
PYROLYSIS

• HISTORICALLY UNSUCCESSFUL
• NO COMMERCIALLY SUCCESSFUL SYSTEMS IN NORTH
  AMERICA
• OVER 500 MILLION EXPENDED
• MAJOR COMPANIES AND SMALL PROMOTERS

32
CRITICAL ISSUES

• TECHNICAL PERFORMANCE
• UNRELIABLE OPERATION
• EXPLOSIONS/FIRES
• ENVIRONMENTAL ISSUES
• AIR
• CHAR DISPOSAL
• ECONOMIC PERFORMANCE
• GAS UTILIZATION
• OIL ONLY BLENDSTOCK
• CHAR MARKET

33
CIVIL ENGINEERING

• LIGHTWEIGHT FILL
• DRAINAGE AGGREGATE
• WHOLE TIRES IN RETAINING WALL CONSTRUCTION

34
Dixon Landing Interchange

• PROBLEM Embankment Constructed on Bay Mud
• SOLUTION Use TDA for the core of the embankment
• CHEAPEST SOLUTION Caltrans saved 470,000
• USED 600,000 tires

35
Typical Cross Section
36
Spread with bulldozer
37
Rt. 91 Wall in Riverside, CA

• Freeway widening
• Objective show that reduced earth pressures can
  reduce overall wall construction costs
• Length 260 ft
• Tires used 75,000 PTE

38
Rt. 91 wall cross section
39
Half of TDA in Place
40
Potential Future Savings for Walls

• Lower pressure on wall ? less rebar
• Potential reduction 28 tons/100 ft
• Potential cost savings 13,000/100 ft

41
RETAINING WALLS

• WHOLE TIRES MECHANICALLY JOINED TO STABILIZE OR
  RETAIN SLOPE
• NOT BROADLY APPLIED IN US DUE TO LABOR COSTS
• MINIMAL CAPITAL EXPENSE FOR SMALL VOLUMES

42
CRUMB RUBBERAPPLICATIONS

• SPORTS SURFACES
• MOLDED PRODUCTS
• RUBBER-MODIFIED ASPHALT
• DECORATIVE MULCH

43
CRUMB RUBBER CHARACTERISTICS

• SLOW OVERALL MARKET GROWTH
• HIGH CAPITAL
• HIGH MAINTENANCE
• MARKET CHALLENGES

44
RURAL CONSIDERATIONS

• VOLUME SENSITIVITY
• REGIONAL PLANS, COLLECTION CENTERS OR PROCESSING
  FACILITIES
• MOBILE PROCESSING
• CAREFULLY EVALUATE BALE APPLICATIONS BEFORE
  STARTING

45
SUGGESTIONS

• FOCUS ON ENERGY (ESPECIALLY CEMENT KILNS)
  INITIALLY
• DEVELOP CE DESIGN EXPERIENCES AND PRACTICES
• BEGIN TO ENCOURAGE CRUMB MARKETS, BUT AVOID
  PREMATURE OVER-COMMITMENT

46
PROCESSING EQUIPMENT

• APPLICATIONS RANGE FROM WHOLE TIRES TO FINE
  POWDER
• SPECIFIC EQUIPMENT REQUIRED TO PRODUCE EACH SIZE
  PRODUCT
• KNOW MARKET BEFORE PURCHASING EQUIPMENT

47
KEYS TO SUCCESS

• LEARN FROM OTHERS SUCCESS AND FAILURE
• EVALUATE BEFORE CHARGING
• CHALLENGE MAGIC PROPOSALS
• RECOGNIZE LOCAL MARKET VARIATIONS
• RECOGNIZE REALITY

48
CONTACT INFORMATION

• TERRY GRAY
• TAG RESOURCE RECOVERY
• EMAIL tagray_at_flash.net
• PHONE [phone]
