CEE 434

1
RETAINING WALLS PART I
CEE 434 GEOTECHNICAL DESIGN FALL 2008
2
Why?
3
Applications
Do not go where the path may lead, go instead
where there is no path and leave a trail.
-Ralph Waldo Emerso
4
Permanent / Temporary Retaining Structures
Cantilever retaining wall
Braced excavation
Anchored sheet pile
From N. Sivakugan
5
Additional Applications
Gravity Retaining wall
Soil nailing
Reinforced earth wall
From N. Sivakugan
6
Sheet Pile Walls
From N. Sivakugan
7
Mechanically Stabilized Earth (MSE) Walls
Reinforced earth walls are increasingly becoming
popular.
From N. Sivakugan
8
Crib Walls
filled with soil
Good drainage allow plant growth.
Looks good.
Interlocking stretchers and headers
From N. Sivakugan
9
Active/Passive Earth Pressures
Wall moves away from soil
Wall moves towards soil
A
B
smooth wall
Granular Soils
From N. Sivakugan
10
From N. Sivakugan
11
Active Earth Pressure
- in granular soils
As the wall moves away from the soil,
?v
active earth pressure
pa
From N. Sivakugan
12
Passive Earth Pressure
- in granular soils
As the wall moves towards the soil,
passive earth pressure
?v
pa
From N. Sivakugan
13
(No Transcript)
14
Rankine vs. Coulomb Theory
Source B.M. Das
15
Coulomb Active Case
Source B.M. Das
16
Coulomb Passive Case
Source B.M. das
