Microsoft Security Fundamentals

1
Microsoft Security Fundamentals

• Andrew Cushman
• EUSecWest - London
• February 20, 2006

2
Intro Who am I?

• Director of Security Community
• Outreach to Community
• Community Advocate w/in Microsoft
• 16 year MS veteran
• Enabled for Code Red and Nimda
• Rejected MSADC vdir defaults change for IIS5
• Responsible for IIS 6 security
• Engineering Group manager for IIS6
• Hired _at_stake for Pen Test engagement

3
Agenda Why am I here?

• To show our work the MS security fundamentals
• Brief review how we got here
• Describe the holistic approach the security
  lifecycle
• Specifics customer requirements our solutions

• 3 things I want you to take away
• MS understands the industry wide security problem
• And that Security requires industry wide
  solutions
• MS delivering excellent results
• Maybe not perfect, but reasonable and industry
  leading
• MS committed to the long term security
  investments
• Security is a journey - its not a destination

4
Brief History

• MSRC creation and early years
• SWI (Secure Windows Initiative)
• 2 guys in their spare time
• TwC memo from Chairman Bill
• Code Red, Nimda, Blaster, Slammer
• Security Community Outreach (03 party at Black
  Hat)
• XPsp2

5
Todays Changed Ecosystem

• Security Industry Matures
• Expanding number of tools experts researchers
• low barrier to entry attracts new entrants
• More researchers more areas lots more bugs
• Criminal element fueling new actions patterns
• AdWare and SpyWare
• The rise of botnets and botherders
• Attacks are constant and targeted
• Move toward targeted attacks
• News reports of corporate and government
  espionage
• Still on the upswing
• unlimited researcher creativity new attack
  surface
• new class of attacks and new vectors

6
The Changing Ecosystem
Indictments were filed by an Israeli prosecutor
against nine men in the industrial espionage case
that involved planting Trojan horses on rival
companies' computers to spy out their secrets.
Security experts have revealed details about a
group of Chinese hackers who are suspected of
launching intelligence-gathering attacks against
the U.S. government.
Alan Paller, SANS Institute in ZDNet November
23, 2005
InformationWeek July 8, 2005
Foreign governments are the primary threat to
the U.K.'s critical national infrastructure
because of their hunger for information, a
British government agency said.
Roger Cummins NISCC Director in ZDNet November
22, 2005
7
Top Security Challenges

• Security Researchers ISVs at odds
• Customers safety is a common goal, but
• Disagreement on tactics
• Security Researchers distrust Software ISVs
• No consensus on Responsible Disclosure
• Differing views of benefit of Exploit code and
  PoC
• Changed economic landscape
• Attribution in Bulletins losing value in new
  economy
• Vulns have value in an above ground economy
• Changed Threat Landscape
• Shrinking delta btw publish and exploitation
• Vuln Full Disclosure increases customer risk

8
Security Focus Microsoft Corporation
Vision

• A secure platform strengthened by security
  products, services and guidance to help keep
  customers safe

• Excellence in fundamentals
• Security innovations

• Scenario-based content and tools
• Authoritative incident response

• Awareness and education
• Collaboration and partnership

9
Technology Investments
10
Security Engineering Communications

• The Security Fundamentals Group at Microsoft
• One team responsible for Microsofts
• Security Development Lifecycle
• Security Engineering (Eng. Standards)
• Penetration Testing (Stds. Enforcement)
• Security Response Updates
• Emergency Incident Response
• Community Outreach

11
Security Focus Sec Fundamentals Group
Vision

• Embed Industry leading Security in the Microsoft
  development culture and in every MS product and
  service

• Cutting edge Research - /GS
• Heap mitigations
• Fuzzing
• Analysis Tools
• Patchguard

• Internal Training
• SWI KB
• SDL article on MSDN
• MSRC Bulletins
• Security Advisories
• Conf. Presentations

• Conf. sponsorship
• CERT collaboration
• GIAIS (ISPs)
• VIA (Virus ISVs)
• BlueHat

12
Security Development Lifecycle
Design
Response
Requirements
Implementation
Verification
Release
Guidelines

Best Practices
Coding Standards
Final Security Review
(
FSR
)
Security
Testing based on threat
Review threat models
Response
models
Feedback loop
Penetration Testing
Tool usage
-
Tools
/
Archiving of Compliance Info
Product Inception
Processes
Threat Modeling
Assign resource
-
Postmortems
Models created
Security Docs

Security plan
-
SRLs
Mitigations in design
Security Push
Tools
and functional specs
Security push training
Customer deliverables
Design
Review threat models
for secure deployment
Design guidelines applied
RTM

Review code
Security architecture
Deployment
Attack testing
Security design review
Signoff
Review against new threats
Ship criteria agreed upon
Meet signoff criteria
13
Security Development Lifecycle

• Defines security requirements and milestones
• MANDATORY if exposed to meaningful security risks
• Requires response and service planning
• Includes Final Security Review (FSR) and Sign-off

• Mandatory annual training internal trainers
• BlueHat external speakers on current trends
• Publish guidance on writing secure code, threat
  modeling and SDL as well as courses

• In-process metrics to provide early warning
• Post-release metrics assess final payoff ( of
  vulns)
• Training compliance for team and individuals

14
SDL and Microsoft Products

• SDL applies across Divisions and Businesses
• Defines Incident Response Patch Requirements
  and Guidelines
• Defines Engineering Requirements and Guidelines
• Validation to ensure standards are met
• Final product security profile combines
• Customer requirements
• Deployment and Usage requirements and
• Security Requirements
• SDL in practice takes on the personality of the
  Product
• IE looks different than Windows Defender
• Products must pass Final Security Review to ship
• Were paying attention to the what the community
  tells us

15
Feedback from the Community

• You might have a wee problem w/ file parsers
• MS04-011 EMF, WMF
• MS04-025 GIF, BMP
• MS04-041 WordPad DOC Converters
• MS05-002 3 ANI
• MS05-005 DOC
• MS05-009 PNG
• MS05-012 OLE/COM
• MS05-014 CDF
• MS05-018 Fonts
• MS05-020 MSRatings .RAT
• MS05-023 DOC
• MS05-025 PNG
• MS05-025 PNG
• MS05-026 .ITS
• MS05-036 9 ICM (JPG,PNG,BMP)

16
Windows Vista Security Approach

• Stop playing catch up - find fix before ship
• Automate proven techniques
• parser fuzzing,
• banned api removal
• tools
• Methodically Apply Security expertise on whole
  product
• Attack Surface Reduction, Service Hardening
• Feature reviews
• Penetration testing
• Defense in Depth Mitigations
• new GS, heap improvements, etc

17
Security Engineering in Windows Vista
Central PREfix (etc) runs
18
Vista Security Review Overall Approach
Feature Reviews
Penetration Testing
Special Projects
19
Microsoft Security Training Courses

• 2003 - Security Basics was the only class
• 2006 Expanded General discipline specific
  offerings
• Introduction to the SDL and FSR Process
• Basics of Secure Software Design, Development,
  and Test
• Threat Modeling
• Security for Management
• Classes of Security Defects
• Defect Estimation and Management
• Developers
• Secure Coding Practices
• Security Code Reviews
• Testers Program Managers
• Introduction to Fuzzing
• Implementing Threat Mitigations
• Time-tested Security Design Principles
• Attack Surface Reduction and Analysis
• 2007 and beyond Continual and Ongoing effort

20
Education resources
21
BlueHat Conference Training
Training for Execs and Engineers

• March 05
• Dino Dai Zovi Shane McAuley
• Matt Conover
• HD Spoonm
• Dug Song
• Dan Kaminsky

• October 05
• Skape
• Vinnie Liu
• Dave Maynor
• Brett Moore
• Toolcrypt

22
Windows Vista Quality Gates

• Many SDL recommended best practices become
  required engineering tasks in Vista
• Banned API removal
• Over 250,000 removed
• No incoming code uses these APIs
• SAL for ALL headers
• ISVs will get benefit in Platform SDK
• Over 119,000 functions annotated by the time we
  ship
• No incoming code missing SAL
• Banned crypto removal
• ALL new features required threat model along with
  Design, Spec, and Test Plan up front
• Thousands of threat models
• Central Privacy team and Privacy Quality Gate

23
Windows Vista Quality Gates cont

• 120 functions banned
• Use StrSafe or SafeCRT
• Mandatory use of IntOverflow PREfast extension
• Prohibit executable pages
• Writable/Shared PE segments banned
• Newer versions of FxCop and AppVerif required
• Firewall policy created
• The bar to open a port is very high
• Over John Lamberts dead body ?
• Prohibit use of APTCA without deep security
  review
• Banned DES, RC2, SHA1, MD4 and MD5 for new code
• Crypto Board created

24
A Note on SAL

• The most important quality tool we have
• No-one else uses this kind of technology
• Helps source code anaylsis tools find bugs

char fgets(__out_ecount_z(_MaxCount) char
_Buf, __in int _MaxCount, __inout FILE
_File) __checkReturn errno_t
tmpfile_s(__deref_opt_out FILE _File)
__checkReturn Must check return
value __out_ecount_z(n) Outbound null-term
string of len n __in Readonly inbound
argument __inout RW arg, by reference __deref_opt
_out Must deref OK, optional, not null-term
25
Service Hardening

• Write restrictions
• Restrict which resources are write-able
• Define privs you need
• SCM grants ONLY those privs regardless of account
• Per-service SID
• ACL object so only your service can access them
• Network restrictions
• You describe Vista enforces network access
  policy
• Eg foo.exe can only open port TCP/123 inbound
• ActionAllowDirInLPORT123Protocol17AppSy
  stemRoot\foo.exe
• If foo.exe has a bug, the rogue code cannot make
  outbound connections

26
Vista and LH Server Defenses

• UAC User Account Control
• Standard User Lower Privileged Account
• Elevate via UI prompt or control via policy
• Mitigates threats but not absolute security
• Process Isolation Challenges
• UI Tampering Secure desktop design change just
  approved
• Registered Window Message
• MIC
• Patch Guard and Malware defenses
• Numerous heap defenses
• Metadata encoding integrity checks,
• randomized, encoded internal ptrs,
• LowFrag heap used more,
• algorithm changes based on usage,

27
A Note on Vista Fuzzing

• Using numerous internally-built fuzzers
• Filefuzzer, FCL, MiddleMan, Rogue, RPCFuzz
  instrumented apps
• To date
• Central team focus only on Fuzzing
• Fuzzed 90 parsers with over 61 million malformed
  files
• By the time we ship
• Fuzz over 200 parsers with over 1 billion
  malformed files

28
Feature Reviews Pen Testing

• Validation in 3 different ways
• Features prioritized using multiple risk factors
• Internet facing, capable of generating Critical
  vuln, etc
• Feature Reviewer meets w/ product team analyzes
  threat models, design, attack surface
• output is bugs, design changes mitigations
• Weak areas referred for deeper inspection
• A Deeper Look
• Targeted review of implementation
• Full Blown Pen Test
• Feature requires in depth multi-week engagement

29
Security Response Process
30
Security Response
SSIRP Incident Response
Monthly Response Process

• Observe the environment
• Watch for triggers
• Know when something needs response

• Evaluate severity, mobilize
• Engineering and analysis
• Industry Relationship partners
• Communications
• Legal and Law Enforcement

• Deep analysis including malware teardown
• Workarounds, solns and tools
• Law Enforcement
• Communications

• Communications
• Lessons learned

31
Case Study WMF Background

• First noticed on newsgroup December 27.
  Immediate escalation to SSIRP Operations Leads
  and first responders.
• Immediate escalation to Orange SSIRP

Watch (Dec 27)

• Teams assembled
• Immediately began monitoring for customer impact
• Immediate outreach to security partners to assess
  initial impact

Alert Mobilize (Dec 27)

• Attack analysis and projection
• Coded fix and started testing
• Intervention partner outreach esp. AV, CERT
  PSS customers
• Multiple Advisories published including effective
  workaround
• Site research and aggressive takedown activity
• Extensive field outreach Extensive press and PR
  response
• Test Pass completed early Released ahead of
  published schedule

Assess Stabilize (Dec 27-Jan 5)

• Post Mortem Completed
• Improvements to internal communication process
  flow
• Early and Aggressive engagement of all product
  teams

Resolve (Jan 5 - present)
32
WMF case study from fix to release

• Coding the Fix
• The team isolated the bug quickly
• Built update, Smoke tested and then deliver to
  test team
• Functional / Regression testing
• More than 450,000 individual GDI/User test cases
• Approximately 22,000 hours of stress
• Over 125 malicious WMFs verified to be fixed by
  the update
• Over 2,000 WMFs from our image library analyzed
• Approximately 15,000 Printing specific variations
  run 2,800 pages verified
• Application Compatibility Testing
• Over 400 Applications tested
• Across all 6 supported Windows platforms
• Security Update Validation Program
• For broad coverage of LOB application
  compatibility and deployment
• International coverage
• Deployment tools
• MBSA 1.2, MBSA 2.0, Microsoft Update/Windows
  Update, AutoUpdate, Software Update Service
  (SUS/WSUS), SMS

33
Security Community Outreach

• Listen, Learn Contribute to Security Community
• Engage the community
• Personalize the engagement w/ a faceless company

• Technical Innovation
• Conference Attendance for cutting edge research
• Industry Partnership
• Conference co-sponsorship
• Participate in the Community
• Guidance
• Connect experts in Product teams Security
  Community
• Promote Responsible Disclosure e.g.,
• Encourage dialog btw researchers Vendors
• Our Goal Coordinated release of vuln details
  the update

34
Security Community Outreach

• Internal Education Act as Community Advocate
• Educate the Microsoft community
• Put a face on hacker threat for execs
  engineers
• Technical Innovation
• Facilitate knowledge transfer to product groups
• Ensure execs engineers understand the state of
  the art
• Exploit Frameworks
• Binary Analysis
• Industry Partnership
• Security Audits and Feature reviews
• Guidance
• Voice of the customer listen to a difficult
  audience
• Promote Dialog and Highlight the Shared Goals

35
Conclusion

• Weve come a long way
• We are in it for the long haul
• Its a lifestyle commitment not a partial new
  years resolution
• Wed like your help
• See me if you want to sign up for Vista beta
• Give us feedback were listening!

36
secure_at_microsoft.com
