Boyer-Moore String Searching Algorithm

1
Boyer-Moore String Searching Algorithm

• By Matthew Brown

2
String-Searching Algorithms

• The goal of any string-searching algorithm is to
  determine whether or not a match of a particular
  string exists within another (typically much
  longer) string.
• Many such algorithms exist, with varying
  efficiencies.
• String-searching algorithms are important to a
  number of fields, including computational
  biology, computer science, and mathematics.

3
The Boyer-Moore String Search Algorithm

• Developed in 1977, the B-M string search
  algorithm is a particularly efficient algorithm,
  and has served as a standard benchmark for string
  search algorithm ever since.
• This algorithms execution time can be
  sub-linear, as not every character of the string
  to be searched needs to be checked.
• Generally speaking, the algorithm gets faster as
  the target string becomes larger.

4
How does it work?

• The B-M algorithm takes a backward approach
  the target string is aligned with the start of
  the check string, and the last character of the
  target string is checked against the
  corresponding character in the check string.
• In the case of a match, then the second-to-last
  character of the target string is compared to the
  corresponding check string character. (No gain
  in efficiency over brute-force method)
• In the case of a mismatch, the algorithm computes
  a new alignment for the target string based on
  the mismatch. This is where the algorithm gains
  considerable efficiency.

5
An example

• Target string rockstar
• Check string -------x-----
• Aligning the start of each string pairs r with
  x.
• Since x is not a character in rockstar, it
  makes no sense to check alignments beginning with
  any character in the check string which comes
  before x, and the B-M algorithm skips all such
  alignments.
• This eliminates several (7, in this case)
  alignments to be checked by the algorithm, and we
  needed to compare only two characters.

6
Efficiency of the B-M Algorithm

• The average-case performance of the B-M
  algorithm, for a target string of length M and
  check string of length N, is N/M.
• In the best case, only one in M characters needs
  to be checked.
• In the worst case, 3N comparisons need to be
  made, leading to a complexity of O(n), regardless
  of whether or not a match exists.

7
Pre-processing Tables

• The B-M algorithm computes 2 preprocessing tables
  to determine the next suitable alignment after
  each failed verification.
• The first table calculates how many positions
  ahead of the current position to start the next
  search (based on character which caused failed
  verification).
• The second table makes a similar calculation
  based on how many characters were matched
  successfully before a failed verification
• These tables are often referred to as jump
  tables, though this leads to some ambiguity with
  the more common meaning of the term in computer
  science, which refers to an efficient way of
  transferring control from one part of a program
  to another.

8
Calculation of Preprocessing Tables

• Table 1
• Starting at the last character of the target
  string, move left toward the first character. At
  each character, if the character is not already
  in the table, add it to the table.
• This characters shift value is equal to its
  distance from the right-most character in the
  string.
• All other characters receive a shift value equal
  to the total length of the string.
• Example peterpan would produce the following
  table (character, shift) (A, 1), (P, 2), (R,
  3), (E, 4),
• (T, 5), (all other characters, 8)

9
Calculation of Preprocessing Tables

• Table 2
• First, for each value of i less than the length
  of the target string, calculate the pattern of
  the last i characters of the target string
  preceded by a mis-match for the character before
  it.
• Then, determine the least number of characters of
  the partial pattern that must be shifted left
  before two patterns match.
• Example for ANPANMAN, the table would be (I,
  pattern, shift) (0, -N, 1), (1, (-A)N, 8), (2,
  (-M)AN, 3), (3, (-N)MAN, 6), (4, (-A)NMAN, 6),
  (5, (-P)ANMAN, 6), (6, (-N)PANMAN, 6), (7,
  (-A)NPANMAN, 6). (here, -X means not X)

10
Comparison of String Searching Algorithm
Complexities

• Boyer-Moore O(n)
• Naïve string search algorithm O((n-m1)m)
• Bitap Algorithm O(mn)
• Rabin-Karp string search algorithm average
  O(nm)
• (n length of search string, m length of
  target string)

11
About the Creators

• Robert Boyer is a retired Professor Emeritus of
  the University of Texas at Austin Computer
  Science Department. He received his BA and PhD
  in mathematics at UT Austin, and has authored and
  co-authored several books concerning automatic
  theorem-proving.

J. Strother Moore is Admiral B.R. Inman
Centennial Chair in Computer Theory of the
Department of Computer Sciences at UT Austin. He
received his BS in mathematics from MIT in 1970,
and his PhD in computational logic from the
University of Edinburgh in 1973. He has authored
and co-authored several books concerning
automatic theorem-proving, some of them in
cooperation with Robert Boyer.
12
References

• Wikipedia.org
• http//www-igm.univ-mlv.fr/lecroq/string/
• Epp, Susanna S. Discrete Mathematics with
  Applications. 3rd Ed., Brooks/Cole 2004.
