Title: GE Substation Automation System Solutions


1
GE Substation Automation System Solutions
Providing innovative product and service
solutions for markets and customers worldwide.
2
Substation Automation System Solutions
POWER SYSTEM CONSULTING
W h y G E
APPLICATION DESIGN
A Complete System Solution Supplier Global Focus
With Engineering And Field Support Experience
Over A Broad Range Of Industries A corporate
commitment to six sigma quality Financial
Strength
PROJECT MANAGEMENT
INTEGRATION SERVICES
STARTUP AND COMISSIONING
PROJECT FINANCING
ASSET MAINTENANCE
REMOTE DIAGNOSTICS
Dedicated to bringing the best Automation
solutions to our customers
3
GESA - A System Solution that Delivers
Productivity
More Effective Long Term Planning Loading
Decisions
Real-time Analysis that Avoids Interruptions
Reduction in the Need for Costly Field Visits
Precise and Confident Operator Decisions in
Restoring Service
Translating data into information at the users
fingertips
4
The Challenge Putting Information to Work
Enterprise
Operations
  • Fine-tune planning
  • Streamline settlements
  • Budget accurately
  • Asses cost of service
  • Allocate capacity
  • Faster service response
  • Remote status control
  • Analyze power quality
  • Identify events, SOE
  • Receive fault records
  • Target maintenance
  • Monitor loading trends

On-Line Information Your key competitive
advantage
5
The Foundation of the Solution Mission critical
monitoring and control
ELECTRICAL PARAMETERS
LOAD INFORMATION, DEMAND PATTERNS
POWER QUALITY INFORMATION PF, HARMONICS
OPERATING INFORMATION TAP CHANGERS, CAPACITOR
BANKS
RELAY OPERATIONS, RECLOSE STATISTICS, CAPACITOR
FUSE STATUS
RELAY BREAKER SELF-TEST/DIAGNOSTICS
GE-SA An Integrated Solution
6
GE Substation Automation - The most competitive
solution
Sub-second response for Ethernet connected devices
Dual master redundancy with automatic system
control transfer
Automatic interleaving of events and metering
values
Ethernet substation UCA 2.0 LAN Peer to peer
communications
Remote view nodes and web browser compatible HMI
Interface
Automatic oscillography upload
Object oriented system tools for reliable, low
cost reconfiguration
Real-time system status and control execution
Maximize your Competitive Edge
7
GE Substation Automation System
Three powerful dimensions to a complete
Substation Automation Solution
  • Proven, off the shelf components that integrate
    todays IEDs
  • Ethernet for data transport in the substation and
    to remote sites
  • Pre-engineered software, application tools and
    device interfaces

8
Built Upon a New Generation Substation
Architecture
Training/ Testing
Level 2 - Integration Host User
Operational Efficiency/ Reliability
Power Analysis Tools
Configuration Tools
Event Logger
OPC/ DDE/ CORBA
HTML Graphics
UCA - MMS Server
Legacy Server
SCADA Protocols
Interface to Corporate WAN/ LAN
Redundant Substation Ethernet LAN
Level 1 - IEDs
Redundant Substation Ethernet LAN
Interoperability
Interoperability
Open System Solution -- Relays, Software,
Communications, Networking
9
How many ways can I receive event information?
  • In Equipment Monitor
  • HMI (1) Annunciator Panel
  • HMI (2) One-Line Diagram
  • HMI (3) Beeper / Email
  • Event log
  • View Node PC - Intranet or Internet
  • Level 3 System
  • UR Itself

GE guarantees that your critical information is
always available when you need it
10
GESA System Architecture
Remote Monitoring Diagnostic Layer
Intranet / Internet
Data Analyzer
Reporting Tool
Application Layer
Standard DDE / Net DDE / OPC
IPC Operating System Layer
Windows NT Server/ Workstation
Ethernet Modbus / UCA-MMS
Legacy/ 3rd Party Media
StandardRS-485Modbus
Modem
Dial UpAccess
Other Protocols
3rd Party SEL 251 SEL 351 SEL 321 SEL 587
METERS E3710 PQM E3720 E7700 E7300
GE Relays Other 239 565 750 DFP100 MDP 269 735
760 DFP200 MMII 489 745 ALPS LPS SM3
GE Universal Relays
UCA/MMS Devices
11
Software
  • Smart Screen Wizards
  • One Line Diagrams
  • Event Logger
  • IED Faceplate
  • IED Tabular Values
  • Annunciator Panel
  • Alarm List with Sorting Feature
  • Trending

Integration Productivity and Reliability
12
Creative tools to help you solve your automation
challenges
  • Wizard Technology
  • Standard Wizard Technology
  • Ease of use- 1000s of HMI points defined
  • with 3 - 4 user inputs
  • Canned Development - Guaranteed high quality
  • UR Wizard Technology
  • Design Flexibility - 1 wizard for entire UR
    Family
  • User Configuration - Screens chosen by user
  • Integration Flexibility - New UR types and
  • screens can be added without rebuilding
    wizard

13
PMCS Sequence of Event Log
Monitors and records all system event
characteristics
  • Time stamped to nearest milli-second
  • Synchronizable to GPS via IRIG-B
  • Automatic retrieval from IED to Host
  • Storage on host disk
  • Automatically forward to operations PC
  • Data sort capability included
  • Standard filters
  • Time
  • Device Type
  • Alarm Condition
  • Custom filters per your needs

14
Alarm Annunciator Panel
  • Configurable Alarm Conditions
  • Any present value can drive an alarm
  • Set range of operation
  • Failure Alarms
  • Equipment generated
  • System generated
  • Grouped per IED

Remote Communication of Critical Alarms
15
Oscillography/Fault Reporting
  • Automatic upload from IEDs via
  • your Wide Area Network
  • Comtrade format for file storage
  • Remote file access
  • Full feature viewer with analysis tools

16
Hardware
  • UR Relay Family
  • PQM, EPM7700
  • 239, 269, 469 Relays
  • 489, 565, 735 Relays
  • 745, 750, 760 Relays
  • DFP100, 200, ALPS, LPS
  • SEL251, 321 (2020)
  • SEL351, 587 (2020)
  • Fanuc 90/30
  • GE SM3, BE2001
  • DLP, MCP, DDS
  • DTP,DGP, SEL2BFR
  • ABB DPU200,REL301

Broad library provides added integration
flexibility
17
Integrated Solutions to help you succeed
INTEROPERABILITY
PEER TO PEER COMMUNICATIONS
RELIABILITY OF SOFTWARE OBJECTS AND MODULES
MODULARITY OF HARDWARE MODULES AND COMPONENTS
DYNAMIC RECONFIGURATION
REAL-TIME STATE ANALYSIS AND OPERATION
18
.Towards Web based Arch for service
  • Thrust
  • Web based, standardized architecture for all
    systems
  • Open system, Scalability Performance
  • Ethernet - Wireless/fiber
  • HTML graphics to be embedded into IEDs
  • Easy integration of third party systems -
    acquisitions
  • Strength
  • Design geared towards services, remote
    monitoring
  • Entire system is configurable/ upgradable over
    the web
  • Remote monitoring diagnostics over
    Internet/Intranets
  • HMI neutral - HTML wizards
  • Designed to Support HTML graphics in next
    generation devices
  • Designed for corporate data ware housing
  • N Level redundancy
  • Interoperability among GE systems.

Web based Architecture - Easy Integration of new
systems and improved support
19
Future GESA System Architecture
Remote Monitoring, Config, Diag Layer
ActiveX Controls
JAVA/HTML Support
ActiveX WebBrowser
Application Layer
CIMPLICITY
Intouch
Web Browser
Trender
WEB SERVER
GE Control Tool Box
Waveform Server
EventServer
Cost Allocation Logger
DDE / OPC
OPC / DDE
DDE/OPC Operating System Layer
PMCS DDE Server
Ethernet Server
PML ION Server
PMCS MMS Server
Lon DB
Windows NT Serve r/ Workstation 5.0 - 4.0 /
Windows 98 / 95 ...
Ethernet
Mutliple Serial Port
IP Server MMS - Modbus
Dial UpAccess
UR series
LON Works
EGD
MMS
Monitor Replacement
20
GEs Commitment to Automation Systems
  • 50 person development, project management and
    marketing team
  • 4 year 12MM investment in new software and
    networking hardware
  • 200 industrial utility system installations
  • 250 system orders in backlog
  • Coupled with a Multi-million investment in the
    UR platform
  • 80 MM in acquisitions to build system integrator
    capabilities

21
W o r l d w i d e Experience
SUBSTATION AUTOMATION INSTALATIONS AROUND THE
WORLD
North AmericaConEdPSEG PECO Salt
River Europe AfricaERZ
South AmericaElectroperuIneparElectronorte EDE
NORRio LightFurnas Electrosul CHESF
COPEL
Asia PacificAliu ZhouZhe ZhangGuang Xi
22
Critical to Quality Metrics
What our Customers Require -- That GE is
Committed to Deliver
Access to system application experts -- before,
during and after a sale
Open architecture solutions, built on industry
standards - future upgrade path
Thorough specification of the system to be
delivered - fully understood by the user
Deliver and commission on schedule within budget
- supplier and customer
Effective operator training - establishing basic
user competency
Return on investment - work together to obtain
the expected benefits
C u s t o m e r F o c u s e d
23
GE Substation Automation System Solutions The
products of the future to meet your present
automation needs
