Title: monthly reporting


1
SKYBON Polyester Resins For Prapachai
2009. 12. 8. SKYBON
2
A TABLE OF CONTENTS
1. INRODUCTION 2. Solvent soluble polyester 3.
Hot-melt polyester 4. Water soluble
polyester 5. New Item 6. Sales Status in
Japan 7. Q A 8. Brain Storming
3
Introduction
High Mw Polyester Resins
4
About SK Chemicals
  • Established in 1966 as the chemical fibers
    company in Korea.
  • Dedicated in 3 main business domain
  • Specialty chemicals
  • Life science
  • Petrochemicals
  • Sales 1.1 billion dollars in 2007 (except
    subsidiary companies)
  • Number of employees About 1,200 in 2007 (except
    subsidiary companies)
  • World Wide location

SK Chemicals Qingdao Co., Ltd Address12 Jiang
Shan, Middle Road, Economic Technical
Development Zone, Qingdao, China Tel0532-676-3281
3 Fax0532-676-8084 SK Chemicals Shanghai
Office AddressRm. 2308 Shanghai International
Trade Center No. 2201, West Yan An Road(W)
Shanghai, China Tel86-21-6295-7070
Fax86-21-6270-1606 SK Chemicals ShenYang Office
AddressRoom No. 703 Fangyuan Bldg. 1 Yuebin-jie
Shenhe-qu Shenyang Liaoning China
110013 Tel86-24-2250-5161 Fax86-24-2250-5163 SK
Chemicals Suzhou Office Address12F, Nonghang
Bldg. Yoangkang Road, Songling Town, Wujiang
City, Jiangsu Province, China Tel86-512-8516-2008
Fax86-512-8526-2007 SK Pharma Beijing , SK (??)
???????? AddressRoom No.801,Full Tower,9 East
3rd ring Central Road Chaoyang District,
Beijing,China(100020) Tel86-10-8591-0891
Fax86-10-8518-0893
5
Product of SK Chemicals


- Anti-cancer Agent - Sunpla - Gastroprokinetics - Levopride - Antiulcerants - Omed - Antibiotics

- Circulatory Improvement    Agent - Ginexin - Anti-arthritis Drug - Joins

- Blood Preparations - Albumin - Vaccines

- Anti-inflammatory    Analgesic patch - Trast

- Biotech


- Polyester Acoustic Thermal Insulation - Wood Flooring for Housing Area - Biocide - Flame-retardant Polyester Core Material - Coolant / Antifreeze - Chemicals for Housing Environment - Chemicals for Water Treatment Chemicals
- Copolyester Resins (SKYBON) - Polyurethane Resins - Carbon Fiber Composite Materials - Liquid Photopolymer for Printing Plate




- Acetate Fibers - Acetate Tow
  • - RCCF - ACF - LEC - PTC - Electric Compass -
    DFR-Dry Film Photo Resist - Optical
    Telecommunication Devices
  • - Cosmetics
  • PET Resins - High Performance PETG
  • Resins
  •

6
What is Polyester?
Polyester ? Any of numerous synthetic polymers
produced mainly by reaction of dibasic acids
with dihydric alcohols
  • Polyester classification
  • Saturated Polyester
  • PET(polyethylene terephthalate) fiber, film,
    bottle
  • PTT(polytrimethylene terephthalate) fiber
  • PBT(polybutylene terephthalate) engineering
    plastic
  • Polyester Elastomer, BDP(Biodegradable
    Polyester)
  • LCP(Liquid Crystal Polyester)
  • Alkyd Resin
  • High MW Polyester Resin
  • Unsaturated Polyester

7
Comparison vs. Alkyd
ALKYD
High MW POLYESTER
  • Polybasic Acids/Anhydrides
  • Polyhydric Alcohols
  • Polybasic Acids/Anhydrides
  • Polyhydric Alcohols
  • Monobasic Fatty Acids or
  • Triglycerides

Raw Materials
MW
  • Relatively low MW, Tg
  • Unsaturation, branch
  • Relatively high MW, Tg
  • saturated, linear

Cure site (OH)
  • Relatively high
  • poor overbake resistance
  • Relatively low
  • High temperature curable
  • Thermoset character
  • High Solids, Economical
  • Versatile - modifiers
  • Thermoplastic character
  • Flexibility with hardness
  • Durability ...

Features
8
Manufacturing Process
Carboxylic acid
Glycol
  • Aromatic Hard, High Tg
  • Terephthalic Acid(TPA) /DMT
  • Isophthalic Acid(IPA) /DMI
  • Phthalic Acid(anhydride)
  • Aliphatic Flexible, Low Tg
  • Adipic Acid /Sebacic Acid /Azealic Acid
  • Ethylene Glycol(EG)
  • Neopentyl Glycol(NPG)
  • Propylene Glycol(PG)
  • 1,4-Butane Diol(BD)
  • 1,6-Hexane Diol(HD)
  • Cyclohexane Dimethanol(CHDM)

Direct Esterification (TPA Process)
Esterification
Catalyst
n HOOC-R1-COOH (n1) HO-R2-OH ?
HO-R2-O-(OC-R1-COO-R2-O)n-H 2n H2O
Oligomer
Trans-esterification (DMTProcess)
n H3COOC-R1-COOCH3 (n1) HO-R2-OH ?
HO-R2-O-(OC-R1-COO-R2-O)n-H 2n CH3OH
Polycondensation
Polycondensation by trans-esterification
HO-R2-O-(OC-R1-COO-R2-O)n-H HO-R2-O-(OC-R1-COO
-R2-O)m-H ? HO-R2-O-(OC-R1-COO-R2-O)nm-H
HO-R2-OH
Polyester Resin gt Mw 6,000
9
Control factors of Reaction
O R-C-OH R'-OH
O R-C-O-R' H2O
- rate of ester formation 1. reactivity of the
functional groups ( for -OH primary, secondary,
tertiary) 2. solubility of reactants 3. reaction
temperature 4. relative proportions of
reactants 5. inclusion of catalyst 6. reverse
reaction water of reaction should be removed
10
Row Material Selection(1)
"Hard" raw materials - short chains -
aromatic rings - cycloaliphatic structure
nature of cross-linking agent plays a key role
in the final hardness of the coating
"Soft" raw materials - long aliphatic chains
HOOCCH2CH2CH2CH2COOH AdA HOCH2CH2CH2CH2CH2CH
2OH 1,6-HD
11
Row Material Selection(2)
Hydroxyl Functional raw materials -
triols.. (TMP etc.) - lower reactivity
. higher stoving temperature ??high
energy consumption . higher addition
levels of catalyst
Carboxylic acid Functional raw materials
- for water soluble polymer . to
provide acidic site for neutralization by amines
12
SKYBON Product Line-Up
ES Solvent-borne type
ET Toner Resin
EW Water-borne type
EH Hotmelt type
Thermoplastic resin used by dispersing with
organic solvent. Widely used as a main binder for
coatings, inks and adhesives.
Water-soluble thermoplastic resin used for
textile sizing or as water soluble coating,
water-based paint, inks and adhesives.
100 non-volatile thermoplastic resin and
maintains solidity in high temperatures without
containing any water or organic solvent.
Thermoplastic resin for toner of laser printer
and copier because of Its excellent
fusing property at low temp- rature. It can be
applied to high speed machine.
13
Application of SKYBON
Industrial Adhesion
Paints Steel Plate
Information Recording
Sizing agents
1. Food Packaging coatings adhesion 2.
Textile(Fabric Label) 3. Doubling Film (PET
PVC Laminated steel) 4. FFC (Flexible Flat
Cable) 5. Automotive Filters 6. Lidding Film 7.
Solar Window 8. Others
1. PCM (Pre Coated Metal) 2. Can coating 3.
Superdurable coating (Superior weatherability) 4.
Others
1. Toner Resin for Laser Printer 2. Toner
Resin for Copier 3. Thermal Transfer
Ribbon (TTR) 4. Dye Diffusion Thermal
Transfer (D2T2) 5. Over Printing Varnish 6. Print
Lamination 7. Others
1. Filament Yarn 2. Spun Yarn 3. Others
14
Solvent soluble Polyester Resins
15
Characteristics of SKYBON ES
  • Fully amorphous structure Industrial Solvent
    soluble, Transparent
  • High molecular weight Linear structure
    Adhesion, Flexibility
  • Wide Tg modification (-1280?) Various coating
    properties
  • Medium polarity Could be applied various
    substrates

16
Grade Selection Guide High Tg Type
Excellent Weatherability
ES-110
ES-910
ES-710
ES-750
Mn decreased Solvent solubility improved
ES-600
FDA approved
Mn decreased High gloss
Mn decreased Tg increased
ES-100
ES-901
ES-955
Metal adhesion improved
Tg, Mn decreased
FDA approved
FDA approved
ES-420
ES-403
Tg decreased
Low Price
Pigment disperseability improved
ES-120
ES-160
ES-410
ES-460M
ES-900M
Mn increased Solvent solubility improved
FDA approved
Branched Type
FDA approved
Can inner coating
Mn increased
ES-450
ES-240
FDA approved
Polar solvent solubility improved
17
Grade Selection Guide Low Tg Type
High Mn
ES-360
ES-350
ES-320
ES-300
Mn increased
Solubility improved
Metal adhesion improved
FDA approved
Pigment dispeseability improved
Tg decreased
Branched Type
ES-215
ES-360M
ES-500
FDA approved
Branched Type
ES-510
Mid Mn
ES-850
ES-812
Tg increased Mn decreased
Low price
ES-900
FDA approved
ES-960
ES-980
ES-980M
Branched Type
Mn decreased More branched
Tg, Mn increased
18
Properties of ES grades for adhesive
Grade
Tg(oC)
SP(oC)
Class
OH (KOH mg/g)
Mn
Remark
L
ES-100
65
26
21,000
140
Group A
ES-110
65
26
18,000
135
L
ES-120
70
26
28,000
145
L
L
ES-240
50
15
32,000
130
L
ES-210
-12
26
42,000
100
Group B
L
ES-215
-11
26
35,000
100
ES-220
-6
14
35,000
145
L
ES-300
17
15
28,000
105
Group C
L
ES-320
15
15
33,000
110
B
ES-350
15
15
32,000
110
L
L
ES-360
17
15
28,000
110
ES-500
10
26
26,000
90
L
19
Solvent Selection
Resins Solubility Parameter
9.2 - 11.1
8.7 - 9.9
0
Solvents Solubility Parameter
20
Solvent Selection
Example
Solubility parameter of resin 8.7 11.1
Ex 1) Solvesso / CYC 4 / 1 (80/20) Solvesso
8.5 0.8 6.80
CYC (cyclohexanone) 9.9 0.2 1.98
8.78 (less soluble)
Ex 2) Solvesso / DBE 4 / 1 (80/20) Solvesso
8.5 0.8 6.80 DBE 10.7
0.2 2.14 8.94 (more soluble)
21
Relationship between resin Coating Properties(1)
Molecular Weight
Tg,SP, Elongation
Solution Viscosity
22
Relationship between resin Coating Properties(2)
Hardness
- Tg 50?? ? Pencil Hardness H ?
23
Relationship between Polymer Coating
Properties(3)
Processibility
Resin A (Soft) Resin B (Medium) Resin C (Hard)
Processibility
Molecular Weight
24
Relationship between Polymer Coating
Properties(4)
Solution Viscosity
Solution Viscosity (cps)
Non-Volatile (wt)
25
What is Adhesion?
  • Adhesion
  • The state in which two surfaces are held together
    by interfacial forces

Intermolecular force
Chemical bond Physical bond
Adhesion Mechanism
  • Science of Adhesion
  • - Chemistry and physics of surfaces and
    interfaces
  • - Mechanics of fracture of adhesive joints
  • Mechanical analysis of strength of adhesive
    joints
  • Test Method

Ga G0 ?
Adhesion Energy Intrinsic work Energy
dissipation of
adhesion of the crack tip
26
Mechanisms of Adhesion
Adhesion
Wetting (?) Bonding (?)
Cohesive strength of adhesive
Adhesive strength of interface
Mechanical interlocking
Chemical bonding
Electrostatic attraction
Inter diffusion
Adsorption (thermodynamic)
- Macroscopic scale - Pores and projections
(rough surface) - Applied to wood, textiles,
metal, papers (structural adhesives)
- Primary bond - Ionic - Covalent -
Secondary bond - H-Bond - van der Waals
bond - polar inter- action -
acid base interaction
- Interaction between charges created on both
sides of the contact area - Electrostatic
double layer
- Bonding temp. - Bonding time - Molecular level
- molecular weight - flexibility -
polarity
27
Adhesive Strength
Adhesive Failure
Cohesive Strength of Adhesive
Cohesive Failure
Adhesive Strength of interface
interface Failure
? BD Interface Failure ? C Cohesion
Failure
Cohesive Strength Wetting
Mixed Failure
28
Adhesive Strength
The Methods of Improving Adhesive Strength
1) Blending High Tg Low Tg Polyester Resins
2) Using Cross linking Agent
3) Modification Using Other type Resins
29
Adhesive Strength
4-1. Blending High Tg Low Tg Polyester Resins
High Tg Pes Resin
  • Abrasion Resistance
  • Block Resistance(Tack ?)
  • Cohesive Strength

Group A Resin

Low Tg Pes Resin
  • Wetting on Surface
  • Adhesion Strength
  • Lower Activation Temp.

Group B C Resin
Compatibility
Blending Group A and B
A and C Resins are all Compatible.
30
Adhesive Strength
2) Using Cross linking Agent
Isocyanate
Chemical bonding with Treated surface
Good Adhesive Strength
Mechanism
Effect
Treated Polypropylene / Flexible Film
Example
31
5. Cross-linking
Adhesive Strength
Application Area
Adhesive for Lamination
Polyester Film, Aluminum Foil FFC, etc.
Adhesive for PVC
PVC leather, etc.
Isocyanate Cross linking
Binder for Magnetic Tape
PET Film
For Metal
Copper plate, Aluminum plate, etc.
Melamine Cross linking
Coating
PCM, Can, etc.
32
Adhesive Strength
Types of Cross-linking Agent
? Isocyanate (L75, N75, BL3175 etc.) ?
INK, Adhesive L75 ( U-9081 ) N75
(Bayer) BL3175(Bayer)
Curing time Fast
Slow Curing temp. 100 ?
120130 ? 150 ? Pot life
1 days 23days
(Blocked Isocyanate) ? Melamine (Cymel
303...) ? PCM,Can

33
Adhesive Strength
Effects
  • Hardness
  • Chemical Resistance
  • Heat Resistance
  • Flexibility

Increasing
Decreasing
Effect of Isocyanate Cross linking with SKYBON ES
Elongation () ?
Tensile Strength ( psi) ?
Wt Cross Linking Agent ?
Wt Cross Linking Agent ?
34
Adhesive Strength
Types of Isocyante Cross Linking Agent
DESMODUR
BASIC
Form Supplied
NCO
mPas(23?)
N 100 N 75 N 3200
HDI
100 75 in MPA/Xylene 11 100
22.0 16.5 23.0
10000 225 2500
N 3300 N 3390
HDI Trimer
100 90 in BA/SN100 11
21.5 19.4
3000 700
HL
HDI/TDI
60 in BA 60 in EA
10.5 10.5
2200 1100
IL IL 1351
TDI Poly-isocyanate
51 in BA 51 in EA
8.0 8.0
1600 700
L
TMP/TDI-Adduct Urethane
75 in EA 67 in MPA/Xylene 11
13.0 11.6
1500 1500
35
Adhesive Strength
Properties of Isocyanate Cross Linking Agent

N L
HL IL
(HDI base)
(TDI/TMP base) (TPI/HDI base)
(TDI/Isocyanate)
Viscosity
Increasing
Reactivity
Increasing
Pot-life
longer
Flexibility
Higher
Weathering (Yellowing)
L lt IL lt
HL lt N
36
Adhesive Strength
3) Modification Using Other type Resins
  • Epoxy Resin (EPON 828)
  • Epoxy Functional Phenol Novolac Resin (EPIKOTE
    154)
  • Epoxy Functional Cresol Novolac Resin (EPIKOTE
    164)

PEs Resin

Good Adhesive Strength in Metal/Film application
Compatibility
Modifier
Supplier
High
Group B (10 75wt)
Group C
EPON 828
Resolution Performance Product
Compatible
Compatible (50wt)
Compatible
EPIKOTE 154 164 are compatible under 20wt
input.
37
Adhesive Strength
Epoxy Resin
Adhesion/reactive site
Chemical resistance
Toughness
High temperature Performance And rigidity
Reactive site
Epoxy Functional Cresol Novolac Resin
38
Tack Control
The Methods of Reducing Coating Tack
1) Using Cross linking Agent
2) Blending High Tg Polyester Resin
3) Modification Using Other type Resins
39
Tack Control
1) Using Cross linking Agent
Experimental Equation (using Aromatic
Polyisocyanate)
Tg(A) Tg of PEs before cross linking Tg(B) Tg
of Pes after cross linking
Tg(B) ? Tg(A) 40
  • Example

ES-210 Softening Point vs.Isocyanate Modification
Aromatic Polyisocyanate
Softening Point(?)
0 5 10
96 gt150
Aromatic Polyisocyanate Mondur CB-75(Bayer),
U9081E(SK Chemicals)
40
Tack Control
2) Blending High Tg Polyester Resin
- Fox Equation
Tg(B) Tg of Blending PEs Tg(L) Tg of Low Tg
PEs Tg(H) Tg of High Tg Pes W(L) Weight
fraction of Low Tg PEs W(H) Weight fraction of
High Tg PEs

Tg(L) Tg(H)
Tg(B)
W(H) Tg(L) W(L)Tg(H)
Ex)
In case, blend 50 ES-100 with 50 ES-300
(17273) (65273)
Tg of Blending PEs
312 K
39?
0.5(17273) 0.5(65273)
41
Coil Coating
42
Introduction of Paint
  • Composition of paints
  • Resin ( Binder)
  • Solvent
  • Pigments
  • Cross-linking agents
  • Additives
  • Technology properties of paint
  • Mechanical coating property
  • Pencil Hardness, T-bending, DuPont impact
  • Adhesive strength
  • Cross-cut explosion
  • Resistance to chemicals
  • MEK Rubbing
  • Anti-corrosion properties
  • Salt spray resistance
  • Weatherbility
  • Q-UV, Out-door exposure
  • Gloss
  • 20,60Gloss
  • Coating Method of Paints
  • Spray
  • Dipping
  • Roller coating

43
Classification of Coil Coating
A. Applications Sandwitch panel, Roofing
B. Resins Si-polyester, Polyester,
Acryl, PVC, Fluoro resin C. Substrates
Galvanized steel, Zinc coated steel,
Chromate steel, Al D. Required
properties Hardness, Anti-corrosion,
Weatherblity, Gloss
A. Applications Refrigerator panel ( front,
back, frame ), VCR Housing, Audio housing,
Washing machine etc. B. Resins Polyester
resin, Polyurethane resin C. Substrates
Galvanizes steel, Zinc coated steel,
Aluminum D. Required properties High Gloss,
High flexibility, Stain resistance, Detergent
resistance, Chemical resistance
ES-SDP
44
Processing Flow
Primer Coater
Drying Chamber
Pre-treatment
Top Coater
Drying Chamber
45
Resin type for Coil coating
Application
Products
Amino-alkyd Type
Low Cost, Coating for Back-plate
Acrylic Type
General (Outdoor)
PVC Organosol
Interior (Outdoor)
PVC Plastisol
Exterior(Outdoor)
Fluorine Modified Resin
Super-Durable Exterior (Outdoor)
Silicon Modified Polyester Type
Durable Exterior (Outdoor)
46
Applications for SKYBON ES(2)
47
Paint Formulation Example White Top Coat
Milling Stage
Charge Ratio
Procedure
Pigment
TiO2
100 Part
37.6
Instrument Mill Dispersibility Below 10um
Resin Sol'n
50
110 Part
41.8
Solvent
CAN/Ko100 /Ko150 1/1/1
55 Part
20.6
Total None Volatile
155 Part
58.5
Let Down (Formulation)
Charge Ratio
M/B
Dispersant
100 Part
37.6
X-Linker
CYMEL-303
5.4 Part
41.8
Resin Sol'n
50
12.7 Part
20.6
Catalyst
CYCAT-500
1.5 Part
Total None Volatile
Paint
58.0
48
CAN Coating
49
Can Coating
? Top Coat Alkyd Resin, Epoxy esters
Thermosetting Acrylics
Over Vanish
Printing Layer
White Base Coat
? Base Color Coat High M/W Polyester Resin
Steel or Aluminum

? Internal Coating Epoxy/Phenol Resin High
M/W Polyester Resin
Inner Coating
? Powder Coating Polyester Hot-melt
Seam Sealing
50
Types of Can
Types
Materials
Applications
Shape
Resin properties
3-Piece can
Soldered seam can
Tin Plate
Food can, Beverage, Aerosol can, 18l can
1. Heat resistance 2. Sterilization
Side seam
Cemented seam can
Tin Free Steel
Welded seam can
Tin plate coated Ni
2-Piece can
DI can (Drawing Ironing)
Al
Beverage can with gas, Beer can
Food can
1. Processbility ( White- based coat)
DRD can (Drawing Redrawing)
Tin Free Steel
51
White Base Coating
Required Properties of White Base
  • Adhesion Strength Formability ( Deep
    Drawing)
  • Leveling Property External appearance and
    compatibility with printing ink
  • Hiding Property Hide the substrates completely
  • Coating Property Good Coating Property in high
    speed process.
  • No Environmental Hormone (ES-410 comply with FDA
    175.300)

Item
OH Value
Softening Point (?)
Molecular Weight
Tg (?)
Characteristics
ES-410
48
120
16,000
47
Adhesion / Flexibility Compatibility
ES-420
48
120
16,000
47
Economic Grade of ES-410
ES-450
48
125
18,000
52
Adhesion to Steel and Al
52
Start Formulation of White Base Coat
1. ES-4 Solution ES-4 Solid 40
Cyclohexanone/S150 5050 60 2. Mill
Base ES-4 Solution(40) 315.3kg
Cyclohexanone/S150 5050 99.5kg
TiO2 227.0kg TOTAL
641.8kg 3.
Letdown Mill Base 641.8kg ES-4
Solution 290.1kg Cymel 303 30.3kg
DNNSA 10.0kg TOTAL
1000 kg DNNSA 50 in
Cellusolve Acetate Leveling Agent
0.51 by Mill Base Solid content of Paint
50 P/B Ratio(Pigment Binder) 1.2 /
1 Cymel / ES-4 Solid 1 / 8 Catalyst
by ES-4 Solid 2
Application
General Can - Top part of Aerosol Can -
Pencil Case - Rice Cooker Closures -
Twist-off cap - Crown Cap - Lids
cap Substrates Al, Tin Plate
53
Blend with Low M/W Pes
  • Low M/W Pes (5560 Solution) 30
  • ES-410 (Solid) 5
  • Tio2 40
  • Benzoguanamine 7
  • ( Blocked Iso-cyanate )
  • others 15
  • Cross-Linker Cymel 300 series (303, 325)
  • Catalyst DNNSA (Cycat 500)
  • Solvent Avoid using Butyl Cellusolve
    or Butyl Cabitol

54
Ink Binder
55
Ink Binder
Viscosity bp of Solvent N.V
Solvent
CA, Anon, Xylene,Kocosol
Screen High High
60 Gravure Low
Low 4050
Toluene MEK, EA, MC, Acetone
Start Formulation for Gravure Ink
Start Formulation for Screen Ink
Group A (1) (50) 30part Group B (2) (50)
10part Titanium dioxide 23part Pigment
1part Toluene 36part
-----------------------------------
100 part
Group A
16.5part Group B
16.5part Titanium dioxide
15.0part Cyclohexanone or Xylene
50.0part Additives
2.0part ---------------------------------------
------------
100 part
Group A (50) 7part Group B (50)
3part Vinyl Resin (3) 8part Filler (TiO2)
30part Solvent 47part Additives
5part -----------------------------
------ 100 part
  • (1) Group A ES-100, ES-110, ES-120, ES-160,
    ES-240
  • (2) Group B ES-300, ES-320, ES-350, ES-360,
    ES-360M, ES-500, ES510
  • (3) Partially-hydrolyzed Vinyl Chloride / Vinyl
    Acetate Resin, Maker DOW Chemical, Grade UCAR
    Solution Vinyl VAGH

56
Ink Binder - Tack Control
Cross Linker
L75
N75
L75
N75
BL3175
Cross liking speed
fast
slow
Cross liking Temp(?)
100?
120-130?
Over 150?
Pot life
1day
2-3day
Made by
Bayer
Bayer
Bayer
57
Adhesive
58
Adhesive for Lamination
Films
PET PVC OPP PE / PP
or
  • On Line / Off Line
  • Pre-treatment of Substrates or Films
  • Heat Resistance
  • Chemical Resistance

CHECK POINT
ES-100 ES-420 PVC Steel (On Line) ES-360
ES-420 PVC Steel (Off Line) ES-300
ES-100 General Adhesives (PET Fabric
etc.) ES-300 ES-210 Stamping Foil, Non-Slip,
Sand paper, Signage ...
59
Processing Flow for PET/PET Lamination
PET Roll
Drying OVEN120?
120?
ES-100S
Drying OVEN120?
PET Roll
ES-300SX-Linker
Wind up
60
Processing Flow for Stamping Foil
1
3
Drying Chamber
2
Squeeze Roller
Heating Roller
Immersion Roller
Adhesive
PET Film
Al
Fabrics
Fabric
Adhesive
Press Roller
Al Vaporized PET film
Winding Roller
4
61
Adhesive for Lamination ( Main Resin)
Grades
Softening Point
Glass Transition Temp(1)
Shore Hardness
Tensile Strength
Elongation at Break
Hydroxyl Number
Molecular Weight(2)

7002
ASTM D2240
ASTM D638
ASTM D638
SRTM No.
1021
7001
?
?
D
Kg/?

KOH mg/g
ES-300
10510
173
30
55
620
32
26000
ES-360
11010
173
30
60
630
32
28000
ES-360M
11010
183
30
60
630
72
32000
ES-500
9010
103
20
24
1400
42
26000
SRTM No. SK Chemicals Methods ? All data herein
are believed to be correct. However, this should
not be accepted as a guarantee of their accuracy,
and conforming tests should be run in your
own plant or laboratory.
62
Adhesive for Lamination ( Resin for Tack Control)
(1) DSC (2)GPC
SRTM No. SK Chemicals Methods ? All data herein
are believed to be correct. However, this should
not be accepted as a guarantee of their accuracy,
and conforming tests should be run in your
own plant or laboratory.
63
FFC
64
What is FFC?
- FFC Multi- connected Cable which made from
two flexible PET Films included Cu wire - History
PVC cable? Round Cable ? FFC ? High
performance FFC(non-halogen,)
  • FFC composition and properties
  • 1) Insulating film 2025um PET Film
    coated adhesive layer
  • - Adhesion power peeling test,
    (conductor and film test)
  • - Shrinkage test 105? 168hr
  • - Dielectric withstanding
  • - Insulation Resistance ( gt 100MO)
  • - Chemical resistance
  • - Blocking test
  • - Worst condition test ( Temp. ,
    Humidity etc)
  • 2) Supporting film Connecting film (film
    188um ? 30-40um coating layer)
  • - Coating type (solution type)
  • - Extrusion type (Hot-melt type)
  • 3) Metal wire
  • - 2mm wire
  • - Pitch 1mm under

65
What is FFC?
FFC Flat Flexible Cable consist of flat tin
plated copper conductors insulated
between Polyester based tapes. -
Supporting Film (Reinforcement tapes)
Added to the cables ends to allow for connector
compatibility
Insulating Film
connector
Conductor
Supporting Film
66
Required Properties
A. Insulation Film
  • metal adhesion
  • Flammability UL-VTM-0, UL-758
  • environmental friendly
  • - Low Dioxin emission
  • - Halogen Free
  • shrinkage below 0.5

B. Protecting Tape (or Supporting Film )
  • metal adhesion and film adhesion
  • Anti blocking ( Due to non-Pigmentation)

67
FFC Manufacturing
  • FFC film process

? Insulation coating process ?
Nozzle coating (comma coating)
Pre-M/X
Chamber drying with non shrinkage
Milling
Chamber
Rolling
120?/1-1.5m
Reservoir
? supporting coating process (extrusion type)
?
Rolling
Primer Coating
Die coating
68
FFC Manufacturing
  • FFC Process

? FFC MAKING PROCESS ?
180? supporting tape
- FFC -
Pressing with high Temp. gt Non-Tack Roller
Metal wire
Slitting for each application
Pressing roller (140-170?,2-3m/min)
Punching For connecting area
69
Reference
70
Reference
71
Reference
72
Reference
73
Business value chain
FFC Insulation FILM
FFC
Application
Low material
FFC Film
  • LG electronic
  • SONY etc
  • Korea KFC, Young-sin
  • Japan SONY, Sumitomo
  • Fujikura
  • Taiwan
  • China
  • Pes resin
  • - SK Chemical
  • - Toyobo
  • - Unitica
  • - Nippon chemical
  • frame retardant
  • Solvent
  • pigment,
  • Korea
  • - Shin-chang
  • - Saehan media
  • - Dongjin chem.
  • Japan
  • - SONY
  • - Sumitomo
  • - Riken
  • - Hitachi
  • - Fuikura
  • China

74
Business value chain
Trend
  • Japan manufacturers M/S gt 70 ?
  • Mainly used type Halogen type gt Trend
    changed to Non Deca or Non -halogen
  • Environmental friendly
  • Non-Halogen type gt next target
  • Factory moving to overseas for unit-price down (
    China, South-eastern country)
  • more stricter for every Properties test

75
New application for Adhesive
1. Lidding Film ( easy peelable Film )
a. Grades ES-220/ ES-250 b. Required
properties FDA approved c. Structures
d. Detail application Sandwich, Soup
liquids, Snacks 2. Solar Window Window
coating a. ES-215 Modifier ( ES-350,
ES-360M ) Ink/Dye (light blue) ? Compounding
b. Properties Preventing UV into indoor
c. Relatively forecasting volume large 3.
Signage a. ES-210, ES-215, ES-360 b.
Structures PET( release film) // Adhesives
// PVC or Lexan( Engineering plastic ) c.
Required properties qualification during 18
24months in Florida test, and so on. 4.
TTR(Thermal Transfer Ribbon) D2T2(Dye Diffusion
Thermal Transfer) a. ES-110, 120, 320, EW-210
76
Heat Sealable Packaging(Lidding Film)
77
Lidding Film
78
TTR
Print Structure
Ribbon Structure
79
TTR-Application and Market
Application FAX Bar Code Serial
Main Producer DNP Sony, Ricoh Fujicopian
Market trend Cost Down Hot stamping ? TTR Should be disappear
Now SKYBON is selling ES-110 to Sony chemicals
for this application
80
D2T2
81
D2T2 Application and Market
82
Thermoplastic Copolyester Hot-Melt adhesive
83
Characteristics of SKYBON EH
  • Saturated Thermoplastic Polyester
  • Not use solvent, water
  • No VOC Environmental Human Health
  • Easy to use
  • Lower Performance than Solvent Soluble Polyester
  • Required Pellet Type and Block Resistance in
    Atmosphere

84
Applications
85
Film Extrusion T-die Process
86
Film Extrusion Inflation Process
87
Automotive Filter Manufacture
Applicator
Nozzle
Folding
Cutting
Air Filter
Cutting Filtering Paper
Applicator
Pellet
About 200?
Filter(200Mesh)
Heat Plate
G/P
Gear Pump
Nozzle
88
Master Batch for PET Fiber
PET Chip
SKYBON EH
C/B
C/B
Cool Air
Tumbler
Kneader
Crushing
Cooling
Heating
Pre-Mixing
Mixing
Extruder
Pellet
Water Bath
89
Properties
Monomer
Structural Modification
Diverse Physical Property
  • Crystallinity
  • Flexibility
  • Polymerization
  • Degree

Melt Viscosity (MV)
Viscosity
Aromatic Diacid
Melt for Index (MI)
Molecular Weight (Mn)
Aliphatic Diacid
Intrinsic Viscosity (IV)
Glass Transition Temperature (Tg)
Melting
Melting Temperature (Tm)
Diol
Softening Point (SP)
90
Grades Properties
91
Apparent Melt Viscosity
Measuring Condition
92
Apparent Melt Viscosity
Measuring Condition
93
Chemical Resistance
94
Water-Dispersible Polyester Resins
95
Advantages
Characteristics
  • Readily dispersible in water
  • Non-dispersible in ionic environments
  • Good adhesive performance characteristics
  • Amine/ammonia-free
  • Stable pH/viscosity

Applications
  • Water-Based Paper Coating, Clear Varnish
  • Vehicle or Binder for Water-based Ink
  • Water-Based Adhesive
  • Modifier for Aqueous Resin Dispersion, etc.

96
Wetting Control
SKYBON EW is water-dispersible polyester
EW dispersant
O C-O---
O ---O-C
OSO O-M
water
Typical liquid surface at 20? (mN/m)
Surface tension
Liquid
72.8
water
22.3
ethanol
27.5
n-octanol
4248
Solvent based adhesive
The reduction of interfacial tension due
to molecular attraction between solid and
liquid is necessary.
4450
water based adhesive
43
Untreated PET
53
Corona-treated PET
485
mercury
97
Wetting Control
Surface tension
- Force per unit length acting in the surface of
a liquid which opposes the increase the area
of the liquid
droplet
?s solid surface tension ?l liquid surface
tension ?sl solid-liquid interfacial tension
- ? contact angle ? 0 ? liquid
spreads freely, completely wetting
? molecular interaction molecular
interaction between solid and
gt between liquid liquid
molecules molecules
98
Wetting Control
Reduction of surface tension
If necessary
- Adding alcohols ? Long chain alcohol is more
effective.
- Adding surfactants
1 methyl alcohol 2 ethyl alcohol 3 n-propyl
alcohol 4 n-butyl alcohol
The effect of short chain alcohol
Schematic illustration of a typical
surface tension vs surfactant concentration
99
Product Range
Grade
EW210
EW300
EW730
EW312
EW370
Molecular Weight
10,000 15,000
10,000 12,000
8,000 10,000
10,000 15,000
10,000 15,000
Tg (oC)
5763
3238
-28-22
5763
4046
Acid Value (KOH mg/g)
5
5
5
5
5
Hydroxyl Value (KOH mg/g)
1015
1015
1015
510
510
Ion
anion
anion
anion
anion
anion
Dispersion Media
DW
DW
DW/IPA
DW/IPA
DW/IPA
Application
Coating
Ink, adhesive For film
Coating
Adhesion Promoter
DW deionized water, IPA isopropyl alcohol
100
Additives
  • gt Thickening Polymer Dispersions
  • The viscosity of formulated products based on
    SKYBON EW dispersion
  • can be increased by the addition of
    conventional thickening agents,
  • such as those listed below.
  • Acrysol RM825 Rohm and Haas
  • Partially Hydrolyzed Polyvinyl alcohol (PVA), DP
    500, 1700
  • gt Surfactants and Defoamer
  • According to the applications, several
    chemical agents may be used in
  • the formulated products such as surfactants,
    deformer, etc.
  • Surfactants Surfynol 104PA, PG(Air Products)
  • Deformer DC 65 (Dow Corning), Surfynol DF-75(Air
    Products)
  • Wax emulsion Jonwax 26(S.C. Johnson), Michem
    46940, 48040(Michelman)
  • Slip agent Glide 100, 410 (Tego)

101
Adhesion Promoter
  • To improve properties of EVA emulsion
  • Heat Resistance
  • Adhesion Strength
  • Water Resistance

102
Adhesion Promoter
Test Result of Adhesive Strength
EVA EW370 Dispersion (25)
Dosage ratio of EW-370 dispersion
0
Viscosity, cps
4000
2.1
0.433
1.5
80
Adhesive strength
103
Adhesion Promoter
Test Method
500 g
104
New Product
105
Flame Retardant Polyester
  • What is SKYBON Flame Retardant Polyester?
  • Its semi-crystallized high Molecular
    polyester that contains phosphorus flame
    retardant agent.
  • The Feature
  • 1. Good Flame Retardant Property (VTM 0
    Level)
  • 2. Environment Friendly
  • - Adoption of Phosphorus Flame Retardant
    Agent (Halogen Free)
  • - Not contain Halogen
  • 3. Can be used as a master batch with PET,
    PETG
  • 4. Can make PET Film or PET Filament (High IV)
  • Application
  • 1. packaging Film for LCD TV Converter,
    Battery of Mobilephone and Laptop
  • 2. Interior Film (ex. Wall Paper)
  • 3. Wig Filament
  • 4. Flame Retardant PET, PETG sheet

106
Flame Retardant Polyester
  • EH-100F, EH-800 are SKYBON Flame Retardant
    Polyester grades
  • - They differ in P content (Phosphorus Flame
    Retardant Polyester Content)

Property Unit EH-100F EH-800
IV dl/g 0.66 0.70
Tg ? 71 62
Tc ? 138 117
Tm ? 235 206
P content ppm 8,200 21,800
Mn daltons 17,000 21,000
( EH-800 has low crystallinity, so
Tc(Cross-linking Temp.) may not be shown
depending on DSC rate.)
107
QA
Thank you for your cooperation!!! If you have
any question, please let me know.
About PowerShow.com
