Title: GridFTP: File Transfer Protocol in Grid Computing Networks


1
GridFTP File Transfer Protocol in Grid
Computing Networks
  • Caitlin Minteer

2
Agenda
  • Grid Computing
  • Globus Toolkit
  • Grid FTP
  • Advantages of GridFTP
  • Disadvantages of GridFTP
  • Using GridFTP
  • GridFTP Clients

3
Grid Computing and the Globus Toolkit
  • Grid computing is the rising networking
    infrastructure that is designed to offer access
    to computational data and human resources spread
    over wide area environments
  • The Globus Toolkit is a technology for the grid
  • open source toolkit
  • building computing grids

4
GridFTP
  • GridFTP - File Transfer Protocol in Grid
    Computing Networks.
  • high-performance
  • secure
  • reliable data transfer protocol
  • optimized for high-bandwidth wide-area networks.
  • based upon the Internet FTP protocol
  • it implements extensions for high-performance
    operation

5
GridFTP
  • Provides
  • A highly extensible server
  • a scriptable command-line client
  • a set of development libraries for custom
    solutions.

6
Advantages of GridFTP
  • Security
  • Parallel Streams
  • Striping
  • Partial File Transfer
  • Reliable and Restartable data transfer
  • Data Extensibility
  • Protocol Extensibility

7
GridFTP Security
  • Authentication of users or services
  • Protecting communications
  • Determining authorization
  • Managing user credentials and maintaining group
    membership information.
  • The Globus GridFTP server and client use the Grid
    Security Infrastructure (GSI) protocol that
    allows a secure Public Key Infrastructure (PKI)
    interface, and adds the capability of delegated
    authority through certificates.

8
Parallel Streams
  • GridFTP supports multiple TCP streams in parallel
    between a single source and destination.
  • This feature can improve aggregate bandwidth in
    relation to that done by a single stream.

9
Stripping
  • Stripping - having several network endpoints at
    the source, destination, or both participating in
    the transfer of the same file.
  • Done by having a cluster with a parallel shared
    file system.
  • Each node in the cluster reads a section of the
    file and sends it over the network.
  • Striping and parallelism may be used together
    where one may have more than one TCP streams open
    between each of the servers participating in the
    transfer.

10
Partial File Transfer
  • Partial file access Regions of a file may be
    accessed by specifying an offset into the file
    and the length of the block desired
  • GridFTP supports this capability by specifying
    the byte position in the file to begin the
    transfer.

11
Third Party Control and Reliable/Restartable Data
Transfer
  • To enable reliability, the GridFTP server
    automatically sends restart markers (checkpoints)
    to the client.
  • If the transfer has a fault, the client may
    restart the transfer and provide the markers
    received.
  • The server will restart the transfer, picking up
    where it left off based on the markers.
  • The Reliable File Transfer (RFT) service goes one
    step further by providing a service interface
    (job submission like interface) and writing the
    restart markers to a database so that it can
    survive a local fault.
  • clients are also able to act as a third-party to
    initiate transfers between remote sites.

12
Data Extensibility
  • The Data Storage Interface (DSI) module knows how
    to read and write to the local storage system and
    can optionally transform the data.
  • It completely abstracts away the underlying
    storage.

13
Protocol Extensibility
  • GlobusXIO is the eXtensible Input/Output (XIO)
    framework in the Globus Toolkit.
  • provides a simple abstraction layer to runtime
    loadable IO implementations.
  • system uses a read, write, open, close
    abstraction that Globus GridFTP is able to
    leverge in order to be transport protocol
    agnostic.
  • Therefore, protocols much more aggressive than
    TCP can be used. To meet more specific
    extensibility needs, we also provide easy-to-use
    development libraries.

14
Disadvantages of GridFTP
  • The client needs to remain active at all the
    times until the transfer finishes, which means
    that when the client state has been lost the rich
    set of recovery features of GridFTP can not be
    used.
  • In the event of client state loss, transfer has
    to restart from scratch.
  • GridFTPs many features are tied to its protocol
    and implementation. Reimplementation and
    re-engineering would be required to provide these
    features to other file transfer services.
  • several memory leaks, unclear error responses and
    bugs that have caused many issues in the use of
    GridFTP

15
Using GridFTP Put, Get, Third Party
  • Putting move a file from one system to a
    server
  • globus-url-copy -vb -tcp-bs 2097152 -p 4
    file///filename gsiftp//hostnameofserver/filenam
    e.
  • Getting move a file from the server to the
    local machine
  • globus-url-copy -vb -tcp-bs 2097152 -p 4
    gsiftp//hostnameofserver/filename
    file///filename.
  • Third party transfers move a file between two
    GridFTP servers
  • globus-url-copy -vb -tcp-bs 2097152 -p 4
    gsiftp//othermachinehostname/filename
    gsiftp//localhostname/filename.

16
GridFTP Clients
  • globus-url-copy the provided scriptable,
    command line client
  • Easy to use
  • access multiple protocols that you can specify in
    a URL
  • To use the globus-url-copy, a proxy certificate
    must be obtained.
  • Then a temporary proxy must be generated
  • Globus does not provide an interactive client for
    GridFTP neither GUI nor text based.
  • regular FTP clients will work with GridFTP but
    will not take advantage of all the features of
    GridFTP
  • UberFTP is the first interactive, GridFTP-enabled
    ftp client.
  • supports GSI authentication
  • parallel data channels
  • third party transfers.

17
Summary
  • Grid Computing
  • Globus Toolkit
  • Grid FTP
  • Advantages of GridFTP
  • Security
  • Parallel Streams
  • Striping
  • Partial File Transfer
  • Reliable and Restartable data transfer
  • Data Extensibility
  • Protocol Extensibility
  • Disadvantages of GridFTP
  • Using GridFTP
  • GridFTP Clients
