Radiation Protection Fundamentals
Craig Maxwell - RCT Radiation Protection
Group Lawrence Berkeley National Laboratory
2
Objectives

• Familiarize you with some of the basics of
  Radiation and Radioactive Decay
• Discuss some of the common instruments found in
  research labs
• Review control methods used to reduce exposure

3
Structure of the Atom
4

• Ionizing radiation
• High energy radiation
• Gamma-rays, x-rays - photons
• Particles alpha, beta, neutron
• Ejects electrons from atoms
• Produces an altered atom - an ion
• Non-ionizing radiation
• Low energy
• Lasers, RF, microwaves, IR, visible
• Excites electrons
• Produces heat

5
Alpha Decay
4He Nucleus Ejected from Nucleus
internal hazard
stopped by paper
found in soil, radon and other radioactive
materials
6
Beta Decay
Either too many neutrons or too many protons
skin, eye and internal hazard
stopped by plastic
Naturally occurring in food, air and water
7
Gamma / X-ray Decay

• Emission of a photon
• Often occurs after ? or ? when nucleus is in an
  excited state

stopped by lead
naturally present in soil and cosmic radiation
medical uses
8
Types of Ionizing Radiation
Paper
Plastic
Lead
Concrete
Alpha
Helium nucleus (2 protons, 2 neutrons) 2 charge
Beta
Electron 1 or -1 charge
Gamma and X-rays
Photon 0 charge
Neutron
Neutron 0 charge
9
Radiation Quantities and Units
10
Radiation Weighting Factors (WR)
Absorbed dose (Rad/Gy) x WR Equivalent dose
(rem)
Photons, electrons muons (all energies) 1
Beta positron 1
Neutrons 5-20
Alpha, fission fragments, heavy nuclei 20
10CFR835
11
Sources of Ionizing Radiation

• Radioactive materials
• Naturally occurring (uranium, carbon-14, )
• Artificial (activated by neutrons from a reactor
  or accelerator beam)
• Radiation Producing Machines
• X-ray machines (characteristic, bremstrahlung)
• Accelerators (ion beams, neutrons, x-rays)

12
Background and Manufactured Radiation In the
U.S. Contributes 360 mrem per year
13
Manufactured Sources of Radiation
Cigarette Smoking - 1300 mrem
Medical 53 mrem

Medical Doses A Dental exam (16 mrem) B
Mammogram (25 mrem) C Tc-99m cardiac function
(75 mrem) D Cranial CT multiple scans (up to 5
rem) E Full body CT screening one scan ( 1
to 2 rem) F Spiral whole body CT scan ( 3 to 10
rem)

Building Materials - 3.6 mrem
Smoke Detectors - 0.0001
mrem
mrem
Fallout lt 1
14
Whole Body Annual Dose Limits
RADIATION WORKER - Federal NRC Limits Whole
Body - 5000 mrem/year Extremities - 50,000
mrem/year Skin - 50,000 mrem/year Eyes - 15000
mrem/year Pregnant - 500 mrem/term / 50
mrem/month General Pubic - 100 mrem/year
15
Effect of Dose and Dose Rate
5 min
100 rems
Localized effects gt500 REM Skin radiation
burn
20 years
Whole body effects LD50/30 500 RAD
Chronic exposures may increase cancer risk.
100,000 people exposed to 100 mREM 4 or 5
additional cancers
16
Risk Perspective

• Average Estimated Days Lost Due to Daily
  Activities
• Health Risk Ave. Est. Days Lost
• Unmarried Male 3,500
• Cigarette Smoking 2,250
• Unmarried Female 1,600
• Coal Miner 1,100
• 25 Overweight 777
• Alcohol (U.S. average) 365
• Construction Worker 227
• Driving a Motor Vehicle 207
• 100 mrem/year for 70 years 10

17

• Radiation
• vs
• Contamination

18
Radiation Vs. Radioactive Contamination
Radiation is particles or waves of energy emitted
from unstable atoms. Radioactive
Contamination is radioactive material usually in
any location you do not want it. Exposing a
material to radiation does not necessarily make
it radioactive, but radioactive material on a
non-radioactive item, makes the item contaminated.
19
Radiation Survey Meters

• Two common Ion Chamber radiation survey
  instruments are

Victoreen
Bicron
20
Beta Contamination Instrument

• Ludlum 3

Type Normally equipped with a Geiger-Mueller
44-9 (pancake) probe Detects Beta, gamma
21
Alpha/Beta Contamination Instrument

• Ludlum 2224

Type Plastic scintillation for beta detection
that has a ZnS (Ag) coating for alpha
detection Detects Alpha and Beta
22
Other Instrumentation

Ludlum 16 with a 44-3 thin window NaI probe
Liquid Scintillation (LSC)
23
Instrument performance

• Dead or low batteries - erratic or no detection
• Calibration has changed - may read high or low
• Defective cable or other problems
• Poor survey technique
• angle of probe to source - only detects part
• to far from source - radiation absorbed by air
• survey too fast only detects part
• You must use them correctly if you expect them to
  work for you

24
Radiation Contamination

• Control Methods
• Used to reduce exposure to
• radiation and
• radioactive material contamination

25
Engineering Controls

• Containment
• Glove box
• Glove bag

• Ventilation
• Fume Hood
• Bio Safety Cabinet

26
Engineering Controls cont.

• Interlocks
• Tamper-Proof Screws/Bolts
• Flange Padlocks
• Security Seals
• Shielding
• Access controls (e.g. card key)

27
Administrative Controls

• Regulations
• Formal Authorizations
• Facility policies and procedures
• Labels, signs, and postings
• Routine radiation surveys
• Machine operational restrictions

28
ALARA As Low As Reasonably Achievable

• ALARA Techniques
• Time - (Reduce)
• Distance (Increase)
• Shielding (Proper Shielding)

Reduce Radiation Doses
29
Control Methods

• Engineering
• Administrative
• ALARA Techniques
• Time
• Distance
• Shielding
• Missing Control

30
Exposure Prevention Methods

• Protective clothing such as lab coats, gloves
  safety glasses
• Self-monitoring to reduce the spread of
  radioactive contamination

31
Good Work Practices
Use deliberate movements and apply lessons
learned from cold runs (mock-ups).
32
Respect and Understand the Postings
Treat all radiological areas as if everything was
contaminated.
33
Common sources of radioactive contamination

• Sloppy work practices
• Poor housekeeping
• Opening radioactive materials/systems without
  proper controls
• Leak or tears in containers
• Damaged Sealed Sources
• Spills

34
Upon Completion of Work
Be sure to survey yourself
35
Upon Completion of Work
Hand washing is a good work practice and an
important final step after working with any
radioactive material.
36
Final Thoughts

• It is our mission to ensure that research and
  learning continue in the safest manner possible.
• Be a mentor
• Be a resource
• Lead by example
• Always use best practices
