Title: Tamino Technical Overview


1
Tamino Technical Overview
  • John Fitzgerald
  • Business Integration Technologist

2
Agenda
  • Introductions
  • Tamino Introduction and Overview
  • What is Tamino?
  • Tamino Server Architecture
  • Search and Retrieval
  • Document Management
  • Enterprise Class Features
  • APIs and Tools
  • Demo
  • What you can do Today!

3
What is Tamino?
  • Storage system (DBMS) for ...
  • Semi-structured data
  • XML documents, messages, metadata
  • Stores in native XML format
  • Multiple indexing methods
  • Unstructured data
  • Storage and indexing of non-XML objects
  • Images, video, audio, MS Office files, PDF..
  • Major Differentiators
  • Robust complete for mission-critical enterprise
    use
  • Built-in Internet File System
  • Superior XML-aware searching
  • Comprehensive developer support
  • Available for offline use

4
Why Use Tamino?
  • Businesses use Tamino
  • For lowest TCO on managing XML and unstructured
    data
  • Store, find, re-compose, present multi-channel
  • Repurpose to save cost, time resources
  • To increase development productivity
  • Faster through standards, many APIs tools
  • Less efforts to adapt to changes
  • To avoid vendor lock-in through open standards
  • Access 'all areas' via XQuery
  • Fit for SOA - eg. UDDI, SOAP
  • For investment protection and mission-critical
    use
  • Provide secure trusted access to existing
    back-end data
  • Deliver robust operation and protect against
    business outages

5
Tamino in Action Today Approx. 700 customers
worldwide
Retail
6
Tamino XML Server Architecture
Core Services
Obj. Processor Obj. Composer
X-TensionService
Query / Text-RetrievalService XML Parser
Query Interpreter
Security Service
Data Map XML SchemaService
Tokenizer (opt.) Chin.,Jap.,Kor.
Internet File System
Native XMLData Store
Administration Services
Tamino Manager
7
Tamino XML Data Store
8
Tamino Data Map
9
XML Schema Support
  • Complete Support for XML Schema 1.0 Specification
  • Industry Schema Support
  • Docbook 4.4FpML 4.1METS 1.0NewsML 1.2SVG
    1.0UBLVoiceMLWord 2003XBRL 2.1
  • Full DTD Support

10
Tamino Search and Retrieval
for b in input()/bib/book let a b/author
where b/price lt 200 return (b/title, a)
  • W3C XQuery Support
  • User-defined functions
  • If-Then-Else
  • Node-level update
  • XPath Support
  • Extended with text search

11
Tamino Indexing and Retrieval
  • Standard
  • Classical database indexes
  • Index any combination of elements and attributes
  • Supports relational operators, exact comparisons,
    sorting
  • Text
  • Use in conjunction with text retrieval functions
  • Supports wildcard searches
  • Structure
  • Index declared on the document
  • Registers instances of undeclared nodes
  • Reference
  • Indexes specific sub-trees of a document (e.g.
    /doc/a/b)
  • Useful for documents of high complexity
    (multiplicity of sub-trees)
  • Multipath
  • Index any element or attribute that meets an
    XPath expression
  • Compound
  • Index a combination of two elements (e.g.
    lastname and firstname)

12
Tamino and Document Management
  • Integrated Internet File System (WebDAV) for
    document management
  • Drag drop storage/retrieval
  • Instant document validation
  • Higher performance scalability
  • Check-In, Check-Out, Workspaces, ...
  • Embedded security via ACLs
  • XQuery for property searches
  • Versioning - on document level
  • via WebDAV
  • "natively" (auto-versioning)
  • Non-XML Indexer
  • Microsoft Office, PDF, ZIP...
  • Indexing is extensible

Benefit Find your XML un-structured data
quickly(e.g. Office, PDF, ...)
More detailson non-XML indexer
13
Non-XML Indexer
DOC
  • Indexes proprietary Office Documents on storage
  • Depending on MIME type
  • e.g. Word 2003, RTF, StarOffice, OpenOffice,
    PDF, MP3, ZIP, ...
  • Further arbitrary formatsindexable via new,
    extensibleInfrastructure (Server Extension w/
    open Java interface)
  • Stores XML-converted "shadow"documents in
    parallel to originals
  • Content searchable via XQuery
  • Original documents additionallystored 11
  • Modification with Tamino not supported

Non-XML Indexer
14
Tamino Enterprise Features
  • Replication
  • Replicate Databases available for parallel read
    access
  • High Availability (Hot Standby and Failover)
  • Cluster support
  • Used by Schiphol Airport, Euredit, RTL /
    MaxiMedia, Ideal, Sun,....
  • Security
  • Support for LDAP and OS Security via Tamino
    Manager
  • 2 Phase Commit
  • Available both for Java and .NET
  • Network drive support (NAS/SAN)

15
Tamino Tools and APIs
  • Tamino APIs
  • Java
  • .NET
  • C
  • SOAP
  • UDDI
  • Tamino Tools
  • Schema Editor
  • X-Plorer
  • XQuery Editor
  • Interactive Interface

XQuery Editor
Schema Editor
X-Plorer
16
Performance Highlights Market Acceptance
  • 1TB of Data in 3 Tamino DBs (Vodafone - Spain)
  • 1.125 billion logical reads / month ( 430
    reads/s at Migros Online - CH)
  • 180 million documents in 8 Tamino DBs (tested
    by IDEAL Greece) 15,000 transactions daily via
    400 concurrent users 400 transactions daily via
    2000 subscribed users Tamino internal
    compression of 120 (non-XML), 14 (XML)
  • 1-3 sec application response time w/ 420 users
    querying every 10s (RTL - D)
  • Load 7.2 million docs/hr, 75 MB/s, 16 clients,
    1 index/doctype (Commerzbank- D)
  • Commerzbank Use of Tamino shortens time
    required to integrate new banking products from
    3-9 months to 2 weeks. Cost savings 7 Million /
    year cost amortization after 12-18 months
  • RTLWith MPower and Tamino XML Server RTL has
    created the world's most technically advanced
    editorial system (H. Lutterbach, RTL, Head of IT)

17
Tamino Differentiators
  • Integrated high-performance Internet file system
    (via built-in WebDAV)
  • Built-in versioning (via integrated WebDAV
    natively)
  • Standards support XML, XML Schema, Web
    services, XQuery, UDDI3
  • Enterprise features (HA support, Replication,
    2-Phase-Commit)
  • Multiple indexes for efficient native XML
    storage, search, access and retrieval
  • Multiple XML documents schemas allowed per DB
  • Support for efficient structure changes (schema
    evolution)
  • Structure-independent retrieval times
  • Rich tool utilities set (Schema editor,
    XML-Indexer, text-retrieval, ...)
  • Smart disk space management (compression)
  • Available across multiple OS platforms

18
VODAFONEMulti-Channel Electronic Bills
Presentation
  • Mission
  • Allow customer information from disparate
    systems to be combined together to form a
    service that is unique -gt competitive advantage
  • Solution
  • A system that allows customers and internal users
    to see their invoices and the billing
    information via Internet
  • Using XML, Tamino XML Server, Web-Logic and IXOS
    products
  • Result
  • Access invoices from the web in diverse formats
    (HTML, XML, PDF and Excel)
  • Minimize paper and mail delivery
  • Send billing information to clients through SMS
  • Feed Vodafones System Data Warehouse

19
VODAFONEMulti-Channel Electronic Bills
Presentation
  • Performance Data
  • Cluster solution
  • HP11i-64
  • 4 CPU, 2GB RAM
  • Total of gtgt 1 TB on 3 DBs gt250 .. 350 GB each
  • 140h backup or restore time for 250 GB DB
  • 30 million docs, avg. 35kB min. 9kB .. max.
    180MB
  • gt 2.5 million bills / month (split into to 1MB
    chunks), 1 Doctype w/ 200 elements 200 attribs.
  • gt 9h loading for 250GB DBs Server response
    times 0.1 - 1 sec

20
For More Information
  • Feel Free to Contact me
  • John.Fitzgerald_at_SoftwareAGUSA.com
  • (703) 391-8177
  • Visit Our Website
  • http//www.softwareagusa.com
  • Download a FREE trial Copy
  • http//www.xmlstarterkit.com/
