MOSS Ltd

1
MOSS Ltd
Manufacturing
Operation Services Supply We
provide services, technologies, equipment in
Upstream and Downstream projects

2
Russia is the biggest market for oil gas
equipment. Russia produces about 10 million
barrels of oil per day with equipment
manufactured mainly in Russia.
3

• Main customers
• - ONGC (India)
• - Oil India Ltd (India)
• - PDO (Oman)
• PDVSa (Venezuela)
• - Pertamina (Indonesia)

MOSS represents equipment of the
following Russian manufacturers
ALNAS (Electric Submersible Pumps)
SIAM (Well Testing Gages, Level Gauges,
Manometers) SUKHOI NAFTA ( Plunger
Membrane Pumps) ELECTON company
(Switchboards, VSD, DHG, PCP) KORVET
company (Wellheads and X-mas trees)
4
A L N A S
Electric Submersible Centrifugal Pumps
ALNAS is the biggest Electric Submersible Pumps
manufacturer in the world. ALNAS produces and
supplies submersible centrifugal pumps of S, M, L
and XL series with rated capacity ranging from 10
up to 2500 m3/day (60 to 15000 BFPD) and total
dynamic head up to 3500 m. There are more than
5000 people working for ALNAS and the company
manufacture up to 1000 complete ESP units per
month. ALNAS is ISO9001 certified
5
Complete Electric Submersible Centrifugal
Pumping systems
6
S I A M
7
Well test equipment manufacturing, supply and
maintenance
SIAM Ltd.
Branches of SIAM Ltd.
Gauges for Well testing
Mobile complexes
Portable complexes
Complex supplies Warranty service and
maintenance
8
SUDOS-mini 2 level gauge
SUDOS mini 2 level gauge is designed for realtime
monitoring of the fluid level in oil producing
wells. The level gauge monitors the static and
dynamic level, records level curves,
automatically records gas pressure in the annulus
at thewellhead.
SUDOS-automat 2 level gauge
SUDOS automat 2 level gauge is designed for
automatic control of the fluid level in oil
producing wells. The level gauge monitors the
static and dynamic level, records level curves,
automatically records gas pressure in the annulus
at the wellhead. The tool is extremely useful for
performing automated pressure transient tests or
timeconsuming level monitoring when the well is
out to the operating regime.
SIDDOS-automat dynamometer
SIDDOS automat dynamometer is designed for
complex monitoring of sucker rod pump units with
two clamp bridle. The tool performs automatic
single and repeated recording of load and
position dynamograms while the pump is operating
or being put to the working regime, as well as
monitors leaks during the static state of the
pump using the 'loss line' technique.
9
E L E K T O N

• ELEKTON is the biggest Russian producer of
  electrical systems and electronic devices for
  optimization of processes in oil production
  including and
• Switchboards for ESP, SRP and PCP
• Variable Speed Drive
• Down Hole Surface Gauges

ELEKTON Switchboards of various modifications are
operating successfully in such oil companies, as
Yukos, Sibneft, LUKoil, TNK, Slavneft, Bashneft
and Rosneft in Russia, Ukraine, Kazakhstan,
Uzbekistan, as well as companies in Indonesia,
India, Libya, Oman.
10
ELEKTON-04 Switchboards is the most simple and
cheap way to ensure protection for your
Electrical Submersible Pump or Sucker-Rod Pump
Switchboard ELEKTON-04
ELEKTON-05 Switchboard with VSD (Variable Speed
Drive) let you not only protect but also adjust
the performance of ESP to the best efficient way.
Variable speed drive. Switchboard ELEKTON-05
ELEKTON-07 Switchboard with Soft Start is
designed for control and protection of ESP motor.
ELEKTON-07
11
ELEKTON-06 Switchboards are specially designed
for control and protection of sucker-rod pumps
(SRP), conventional pumping unit and its gear
(three-phase asynchronous motor) for oil
production.
Switchboard ELEKTON-06
Down Hole Gauge ELEKTON-TMS-2 is designed for
monitoring of downhole and wellhead parameters.
Control systems consist of a controller installed
in the switchboard, wellhead sensors (to control
wellhead parameters) and downhole sensor.
ELEKTON multi-channel down-hole sensor monitors
the down-hole data including pump intake
pressure, motor oil pressure, motor temperature
and vibration.
ELEKTON-TMSP-2
12
Submersible Progressing Cavity Pump
Through Tubing Conveyed Submersible Progressing
Cavity Pump (SPCP) is intended for viscous high
gas factor oil recovery in marginal wells with
minimum internal casing string size of 122 mm.
Pumping unit consists of going-in with
oil-well tubing submersible four-pole electric
motor with power cable, starting clutch, seal
section, base coupling and intake receptacle.
Assembling and disassembling of SPCP is carried
out through oil-well tubing with borehole cable
of geodesic elevator. The SPCP includes two
working screw gages (left and right), gear box
with axial and radial bearings, tubing
anchor/packoff. Rotation is transmitted from gear
box to screw gages via flexshaft.
1 - oil-well tubing2 - power cable3 - tubing
anchor/packoff4 - screw gages left/right       5
- intake receptacle6 - flex shaft7 - gear
box8 - base coupling9 - seal10 - starting
clutch11 - motor
Through Tubing Conveyed Submersible Progressing
Cavity Pump VVN-54
13
K O R V E T
KORVET is the most dynamic Russian manufacturer
of Wellheads, X-mas trees, valves, manifolds and
pipeline equipment. KORVET equipment meets API
Spec 6A and 6D requirements and since 1997 has
been produced with API monogram. KORVET is
certified for ISO 90012000 standard.
14
X-MASS TREES
KORVET produces any scheme of tree, resulting of
combining blocks valves, chokes, crosses and so
on. WP is up to 10 000 psi. H2S and CO2
concentration is up to 6.
15
WELLHEADS
KORVET produces wide range of wellhead equipment
for surface applications. Safety requirements,
robustness and cost effectiveness are most
considering goals for KORVET. Rig time savings
were also a strong consideration taken into
account. Certified for API6A.
16
CHECK VALVES
Swing-type and spring-type check valves are
designed to cut off back flow of operating medium
in pipelines. Sealing surfaces are made of
stainless steels. Casted or forged body. Flanged
and weld connections available. WP in range
6-250 bar.
17
BALL VALVES
Ball valves are designed to control pipelines
with natural gas, oil, oil products and other
non-agressive fluids. They are reliable, of
simple design, easy to mount and to operate,
compact and light. The valve design (the body
with seats and a ball is disposed between two
flanges and tightened with studs) ensures
disassembly of the valve without cutting
pipelines. It is very convenient for monitoring
and running repair. Ball valves are available
manually operated, including for underground
application and with electric or pneumatic
actuators.
18
MANIFOLDS
Manifolds are designed for controlling and
distributing gas or fluids flow to collector.
Manifolds are delivered as a set of units such a
valves, fittings, check valves, chokes and so on.
Any unit fulfils some technological operations.
Manifolds and technological equipment are
manufactured according to the requirements of
Elaboration Institute and State Technical
Inspection.
Gas mainfold

• ADVANTAGES
• short term of acquisition
• easy assembling
• reduced number of
• welding connections
• high quality ofequipment.

19
S U K H O I
PDN-44-1200 PUMP

• The PDN-44-1200 is a tubing sucker-rod pump with
  plunger-diaphragm chambers designed for pumping
  wellbore fluids containing high amounts of
  mechanical impurities. The PDN-44-1200 is
  patented (PCT numbers WO 99/04166, WO 9915791A1)
  and has been proven successful in Russian oil
  field operations. The pump possesses the
  simplicity of a plunger-type pump with the heavy
  oil pumping capabilities of progressive cavity
  type pumps. Well operators should find that the
  PDN-44-1200 pump will reduce their operating
  costs and downtime significantly.

PDN-44-1200 Installation near Bakersfield
California
20
OPERATION
Scheme of the pump operation

• The pump
• Hydraulic drive
• Rod-plunger
• Valve of suction
• Valve of pressure
• Camera of suction
• Cavity of suction
• Collector cavity
• Cylinder
• Membrane
• Tail unit
• Change level
• Fixative

21
ADVANTAGES
The PDN-44-1200 was designed to provide the
heavy, abrasive oil lifting capabilities of the
progressive cavity pumps with the simplicity and
dependability of conventional plunger type pumps.
This design principal provides the following
advantages         The PDN is powered by a
conventional beam pump jack that is less costly
and more reliable than surface hydraulic power
units.         The PDN has been shown to pump
heavy, viscous oil that conventional plunger
pumps were not able to lift.         The PDN has
been shown to operate for one full year without
any needed repairs. This time frame is two to
four times longer than progressive cavity
pumps.         When repairs are needed, the PDN
only requires a few inexpensive replacement
parts. Progressive cavity pumps require the
replacement of the rotor and stator which is
almost as expensive as a new pump.         The
PDN generates a high amount of suction turbulence
at the pump suction area. This turbulence
prevents sand buildup thereby eliminating the
problem of suction blockage.         The cost of
the PDN is less than a comparably sized
progressive cavity pump.
22
Contact us
5 Bratislavskaya street, Moscow 109451 Russia
Tel [phone] Fax [phone]
4981 e-mail moscow_at_moss-ltd.ru www.moss-ltd.ru
