Critical Care Bioinformatics at Columbia University Medical Center

1
Critical Care Bioinformatics atColumbia
University Medical Center

• J. Michael Schmidt, PhD
• Neurological Institute of New York
• Columbia University College of Physicians and
  Surgeons

2
Disclosures

• CMA Microdialysis Speakers Bureau

3
Clinical Needs for ICU Informatics System

• Understand patient physiology
• Evaluate effectiveness of treatments
• Potential for automatic processing of data for
  diagnosis and prognosis
• Support clinical decision making
• Also noteworthy
• Digital Note
• Quality Assurance
• Clinical Research support

4
Meeting the Need

• 3 problems 1
• Data Collection
• Data Interrogation
• Data Analysis
• Best use of data for clinical decision making

5
Columbia Neuro-ICU System
6
The GOOD
7
(No Transcript)
8
(No Transcript)
9

• 18 bed ICU
• Useful for threshold based alarms and nursing
  workflow.
• Data only saved for 72 hours then gone.
• Not all device data can go into system
• Difficult to visualize data

10
(No Transcript)
11
(No Transcript)
12

• Saves parameter data every 5 seconds SQL database
• Saves visible waveform data
• Requires 300 GB / year data storage

13

• Data from many bedside devices do not interface
  with the bedside monitor
• If they do interface, often ones want greater
  precision or all available parameters

14
(No Transcript)
15
(No Transcript)
16
(No Transcript)
17
(No Transcript)
18
Data Visualization
19
(No Transcript)
20

• Visualize data to track effects of interventions
• Can visualize physiologic relationships
• Multi-parameter event detection

21
(No Transcript)
22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25

• Collect parameter and waveform data
• Collecting data from devices that do not go into
  monitor
• Able to visualize data over extended periods of
  time

• Can elucidate relationships among different
  parameters
• Data stored permanently

26
The BAD
27
(No Transcript)
28

• Labs available via copy and paste
• Infusion pump data must be manually entered
• Cant get it from EMR
• Cant get it from the pump
• Evaluate effectiveness of interventions
• Did the intervention have the desired effect?
• How quickly?
• Does repeated administrations work equally
  effectively?

29
(No Transcript)
30

• Tools to evaluate waveforms are lacking in our
  system.
• Phase analysis between MAP and ICP to determine
  autoregulation status.
• Heart rate variability analysis can be used to
  understand dysautonomia.

31
The UGLY
32

• Network Performance
• Equinox boxes communicate with the server using
  UDP
• Must be in contact with server at least once
  every 60 seconds else goes offline
• Must be rebooted to reestablish the connection
• Some will not go back

33

• Network Reliability
• ICU Pilot computers cant always connect to
  servers.
• Server and computer operate on different
  networks. Connection can fail (cant ping
  server).
• Network Drive mapping fails
• Map network drive
• Setup ICU Pilot to use mapped network drive for
  use as the database
• Start SQL client, which fails to connect
  sometimes, or gets corrupted and needs reinstall

34

• Standard Informatics infrastructure for hospital
  level system
• Maintenance Server failure lead to corrupted
  database
• Backup was not properly done
• Used recovery tool to get data currently
  running scripts to recover the data will take 2
  years to complete (need to write special program
  to make that faster). Who is going to do that?

35

• Standard Informatics infrastructure for hospital
  level system
• Server switch to Virtual server plus problems
  (OLTP versus OLAP)
• I/O disk write time delays as databases got large
• Need separate system for data processing
• Didnt work the same.
• SQL didnt load before bedmaster causing
  problems.
• Processor didnt necessarily always have enough
  resources to meet demand

36
Summary of Columbia experience
37

• Store data from the patient monitor forever in
  open SQL format
• Can get data from devices that do not plug into
  the patient monitor or do so inadequately
• Able to visualize relationships among parameters

• Infusion pump, intervention, and lab data not in
  system
• Tools not readily available to quantify the
  effectiveness of treatments
• No tools to perform waveform analysis

• Informatics infrastructure not robust.
• Lead to
• Connectivity failures
• Backup systems failed
• Virtual server not up to task.

38
?
39

• Other data systems not connected
• Have to copy and paste in lab values
• Infusion pump data must be manually entered
• Cant get it from EMR
• Cant get it from the pump
• No good tools to evaluate effectiveness of
  interventions
• Did the intervention have the desired effect?
• How quickly?
• Does repeated administrations work equally
  effectively?
•  No tools for waveform analysis
