Web Servers

1
Web Servers
2
Generic Overview

• http//en.wikipedia.org/wiki/Web_servers

3
Web Servers

• A web server can be
• A computer program
• Responsible for accepting HTTP requests from
  clients (web browsers)
• Returns HTTP responses with optional data
  contents
• Usually web pages
• HTML documents
• Linked objects (images, etc.).
• A computer that runs a computer program which
  provides the above functionality

4
Common Features
5
Common Features

• HTTP
• Accepts HTTP requests from a client
• Provides HTTP responses to the client
• Typically an HTML document
• Can also be
• Raw text file
• Image
• Some other type of document
• defined by MIME-types
• If an error is found in the client request or
  while trying to serve the request
• Web server has to send an error response
• May include custom HTML
• May have text messages to better explain the
  problem to end users.

6
Common Features

• Logging
• Web servers keep detailed information to log
  files
• Client requests
• Server responses
• Allows the webmaster to collect data
• Running log analyzers

7
Additional Features

• Authentication
• Optional authorization before allowing access to
  some or all resources
• Requires a user name and password
• Handle
• Static content
• Dynamic content
• Support one or more related interfaces
• SSI, CGI, SCGI, FastCGI, JSP, PHP, ASP, ASP .NET,
  Server API such as NSAPI, ISAPI, etc.

8
Additional Features

• HTTPS support
• VIA SSL or TLS
• Allows secure (encrypted) connections
• Using port 443 instead of port 80
• Content compression
• I.e. by gzip encoding
• Reduces the size of the responses
• Lower bandwidth usage, etc.

9
Additional Features

• Virtual hosting
• Serve many web sites using one IP address
• Large file support
• Serve files greater than 2 GB
• Typical 32 bit OS restriction
• Bandwidth throttling
• Limit the speed of responses
• Do not saturate the network
• Able to serve more clients

10
Origin of returned content

• Where does it all come from?

11
Content Origin

• The origin of the content may be
• Static
• Comes from an existing file pre-existing in a
  file system
• Dynamic
• Dynamically generated by some other program
• Script
• Application Programming Interface (API) called by
  the web server
• Static content is usually delivered much faster
  than dynamic content
• 2 to 100 times
• Especially if the latter involves data pulled
  from a database

12
Path translation

• How does it find it?

13
Path translation

• Web servers map the path component of a Uniform
  Resource Locator (URL) into
• Local file system resource
• Static requests
• Internal or external program name
• Dynamic requests
• For a static request the URL path specified by
  the client is relative to the Web server's root
  directory

14
Path translation

• Consider the following URL requested by a client
• http//www.example.com/path/file.html
• Client's web browser translates it into a
  connection to www.example.com with the following
  HTTP 1.1 request
• GET /path/file.html HTTP/1.1 Host
  www.example.com
• The web server on www.example.com then appends
  the given path to the path of its root directory
• On Unix machines, this is commonly
  /var/www/htdocs.
• The result would then be the local file system
  resource
• /var/www/htdocs/path/file.html
• Web server then reads the file, if it exists, and
  sends a response to the client's web browser
• Response will describe the content of the file
  and contain the file itself

15
Performance
16
Performance

• Web servers
• Serve requests quickly
• From more than one TCP/IP connection at a time
• Main key performance parameters are
• number of requests per second
• depends on the type of request, etc.
• latency response time in milliseconds for each
  new connection or request
• throughput in bytes per second
• depending on file size, cached or not cached
  content, available network bandwidth, etc.
• Measured under
• Varying load of clients
• Varying requests per client

17
Performance

• Performance parameters may vary noticeably
  depending on the number of active connections
• A fourth parameter is the concurrency level
  supported by a web server under a specific
  configuration
• Specific server model used to implement a web
  server program can bias the performance and
  scalability level that can be reached under heavy
  load or when using high end hardware
• many CPUs, disks, etc.

18
Load limits
19
Load limits

• Web server (program) has defined load limits
• It can handle only a limited number of concurrent
  client connections per IP address (and IP port)
• Usually between 2 and 60,000
• Default between 500 and 1,000
• Can serve only a certain maximum number of
  requests per second depending on
• its own settings
• the HTTP request type
• content origin (static or dynamic)
• whether the served content is or is not cached
• the hardware and software limits of the native OS
• When a web server is near to or over its limits
• It becomes overloaded and thus unresponsive

20
Overload causes
21
Overload causes

• A sample daily graph of a web server's load,
  indicating a spike in the load early in the day.

22
Overload causes

• At any time web servers can be overloaded because
  of
• Too much legitimate web traffic
• Thousands or even millions of clients hitting the
  web site in a short interval of time
• DDoS (Distributed Denial of Service) attacks
• Computer worms
• Abnormal traffic because of millions of infected
  computers (not coordinated)
• XSS viruses
• Millions of infected browsers and/or web servers
• Internet web robots
• Traffic not filtered / limited on large web sites
  with very few resources (bandwidth, etc.)
• Internet (network) slowdowns
• Client requests are served more slowly and the
  number of connections increases so much that
  server limits are reached
• Web servers (computers) partial unavailability
• Required / urgent maintenance or upgrade
• HW or SW failures
• Back-end (i.e. DB) failures, etc.
• Remaining web servers get too much traffic and
  they become overloaded

23
Overload symptoms
24
Overload symptoms

• The symptoms of an overloaded web server are
• Requests are served with (possibly long) delays
• from 1 second to a few hundred seconds
• 500, 502, 503, 504 HTTP errors are returned to
  clients
• Sometimes also unrelated 404 error or even 408
  error may be returned
• TCP connections are refused or reset
  (interrupted) before any content is sent to
  clients
• In very rare cases, only partial contents are
  sent
• This behavior may well be considered a bug
• Even if it stems from unavailable system
  resources

25
Anti-overload techniques
26
Anti-overload techniques

• To partially overcome load limits and to prevent
  overload use techniques like
• Managing network traffic by using
• Firewalls
• Block unwanted traffic from bad IP sources or
  having bad patterns
• HTTP traffic managers
• Drop, redirect or rewrite requests having bad
  HTTP patterns
• Bandwidth management and traffic shaping
• Smooth down peaks in network usage
• Deploying web cache techniques
• Using different domain names to serve different
  content (static and dynamic) by separate Web
  servers, i.e.
• http//images.example.com
• http//www.example.com

27
Anti-overload techniques

• Techniques continued
• Use different domain names and/or computers to
  separate big files from small/medium files
• Be able to fully cache small and medium sized
  files
• Efficiently serve big or huge (over 10 - 1000 MB)
  files by using different settings
• Using many Web servers (programs) per computer
• Each bound to its own network card and IP address

• Use many Web servers that are grouped together
• Act or are seen as one big Web server
• See Load balancer

28
Anti-overload techniques

• Techniques continued
• Add more hardware resources
• RAM, disks, NICs, etc.
• Tune OS parameters
• Hardware capabilities
• Usage
• Use more efficient computer programs for web
  servers, etc.
• Use workarounds
• Specially if dynamic content is involved

29
Historical notes
30
Historical notes

• The world's first web server.
• In 1989 Tim Berners-Lee proposed to his employer
  CERN (European Organization for Nuclear Research)
  a new project
• Goal of easing the exchange of information
  between scientists by using a hypertext system
• As a result of the implementation of this
  project, in 1990 Berners-Lee wrote two programs
• A browser called WorldWideWeb
• The world's first web server, which ran on
  NeXTSTEP

31
Historical notes

• The first web server in U.S.A. was installed on
  December 12, 1991
• Bebo White at SLAC
• After returning from a sabbatical at CERN
• Between 1991 and 1994 the simplicity and
  effectiveness of early technologies used to surf
  and exchange data through the World Wide Web
  helped to
• Port them to many different operating systems
• Spread their use among lots of different social
  groups of people
• First in scientific organizations
• Then in universities
• Finally in industry

32
Historical notes

• In 1994 Tim Berners-Lee decided to constitute the
  World Wide Web Consortium (W3C)
• Regulate the further development of the many
  technologies in a standardization process
• HTTP
• HTML
• etc.
• The following years saw an exponential growth of
  the number of web sites and servers

33
Software
34
Software

• July 2007, the most common HTTP serving programs
• Apache HTTP Server
• Microsoft
• Microsoft is the sum of sites running
• Microsoft-Internet-Information-Server
• Microsoft-IIS, Microsoft-IIS-W
• Microsoft-PWS-95
• Microsoft-PWS
• Sun
• The sum of sites running
• SunONE,
• iPlanet-Enterprise
• Netscape-Enterprise
• Netscape-FastTrack
• Netscape-Commerce
• Netscape-Communications
• Netsite-Commerce
• Netsite-Communications
• lighttpd

35
Software

• There are thousands of different web server
  programs available
• Many specialized for very specific purposes
• The fact that a web server is not very popular
  does not necessarily mean
• Lot of bugs
• Poor performance
• See CategoryWeb server software for a longer
  list of HTTP server programs.

36
Statistics
37
Statistics

• The most popular web servers, used for public web
  sites, are tracked by
• Netcraft Web Server Survey
• Details given by
• Netcraft Web Server Reports
• According to this site
• Apache has been the most popular web server on
  the Internet since April of 1996
• August 2007 Netcraft Web Server Survey
• 50.92 web sites on the Internet use Apache
• 34.28 web sites use IIS
• With the active sites
• 48.42 running Apache
• 36.21 running IIS

38
Popular Web Servers

• Whos running the show?
• What are they?
• The big two

39
Apache

• http//en.wikipedia.org/wiki/Apache_web_server
• Were number one!

40
Apache

• Apache HTTP Server, referred to simply as Apache
• A web server
• Notable for playing a key role in the initial
  growth of the World Wide Web
• Apache
• First viable alternative to Netscape
  Communications Corporation web server
• Currently known as Sun Java System Web Server
• Evolved to rival other Unix-based web servers
• Functionality and performance
• Since April 1996 Apache has been the most popular
  HTTP server on the World Wide Web
• Since March 2006 however it has experienced a
  steady decline of its market share
• Lost mostly against Microsoft IIS and the .NET
  platform
• September 2007 Apache served 50 of all websites

41
Apache

• Project's name was chosen for two reasons
• Respect for the Native American Indian Apache
  tribe
• Well-known for their endurance and their skills
  in warfare
• Project's roots as a set of patches to the
  codebase of NCSA HTTPd 1.3
• Making it "a patchy" server
• Apache is developed and maintained by
• an open community of developers
• under the auspices of the Apache Software
  Foundation
• Available for a wide variety of OSs
• Microsoft Windows
• Novell NetWare
• Unix-like operating systems e.g. Linux and Mac
  OS X
• Released under the Apache License
• Apache is free software / open source software.

42
Apache History
43
History

• The first version of the Apache web server was
  created by Robert McCool
• Heavily involved with the National Center for
  Supercomputing Applications web server
• Known simply as NCSA HTTPd
• When Rob left NCSA in mid-1994
• Development of httpd stalled
• Left a variety of patches for improvements
  circulating through e-mails
• Rob McCool was not alone in his efforts
• Several other developers helped form the original
  "Apache Group"
• Brian Behlendorf, Roy T. Fielding, Rob Hartill,
  David Robinson, Cliff Skol nick, Randy Terbush,
  Robert S. Thau, Andrew Wilson, Eric Hagberg,
  Frank Peters, and Nicolas Pioch

44
History

• Version 2 of the Apache server was a substantial
  re-write of much of the Apache 1.x code
• Strong focus on further modularization and the
  development of a portability layer, the Apache
  Portable Runtime
• Apache 2.x core several major enhancements over
  Apache 1.x
• UNIX threading
• Better support for non-Unix platforms
• New Apache API
• IPv6 support
• First alpha release of Apache March 2, 2000
• First general availability release on April 6,
  2002
• Version 2.2 introduced a new authorization API
  that allows for more flexibility
• Also features improved cache modules and proxy
  modules

45
Features
46
Features

• Apache supports a variety of features
• Many implemented as compiled modules which extend
  the core functionality
• Range from server-side programming language
  support to authentication schemes
• Common language interfaces support
• mod_perl, mod_python, Tcl, and PHP
• Popular authentication modules include
• mod_access, mod_auth, and mod_digest.

47
Features

• Other features include
• SSL and TLS support
• mod_ssl
• A proxy module
• A useful URL rewriter
• also known as a rewrite engine, implemented under
  mod_rewrite
• Custom log files
• mod_log_config
• Filtering support
• mod_include
• mod_ext_filter
• Apache logs can be analyzed through a web browser
  using free scripts
• AWStats/W3Perl
• Visitors

48
Features

• Virtual hosting allows one Apache installation to
  serve many different actual websites
• For example, one machine, with one Apache
  installation could simultaneously serve
• www.example.com
• www.test.com
• test47.test-server.test.com
• etc.
• Apache features
• Configurable error messages
• DBMS-based authentication databases
• Content negotiation
• It is also supported by several graphical user
  interfaces (GUIs)
• Permit easier, more intuitive configuration of
  the server

49
Usage
50
Usage

• Apache is used to serve both static content and
  dynamic Web pages
• Many web applications are designed expecting the
  environment and features that Apache provides
• Apache is the web server component of the popular
  XAMPP web server application stack
• Partners with
• MySQL
• PHP/Perl/(Python) programming languages

51
Usage

• Apache is redistributed as part of various
  proprietary software packages including the
• Oracle Database
• IBM WebSphere application server
• Mac OS X integrates Apache
• Its built-in web server
• Support for its WebObjects application server
• It is also supported by Borland
• Kylix and Delphi development tools

52
Usage

• Apache is included with Novell NetWare 6.5
• Default web server
• Apache is used for many other tasks where content
  needs to be made available in a secure and
  reliable way
• Sharing files from a personal computer over the
  Internet
• A user who has Apache installed on their desktop
  can put arbitrary files in the Apache's document
  root which can then be shared
• Programmers developing web applications
• Locally installed version of Apache
• Preview and test code as it is being developed

53
Usage

• Microsoft Internet Information Services (IIS) is
  the main competitor to Apache
• Trailed by
• Sun Java System Web Server
• Host of other applications
• such as Zeus Web Server

54
License
55
License

• The software license under which software from
  the Apache Foundation is distributed is a
  distinctive part of the Apache HTTP Server's
  history and presence in the open source software
  community
• The Apache License allows for the distribution of
  both open and closed source derivations of the
  source code
• The Free Software Foundation does not consider
  the Apache License to be compatible with version
  2 of the GNU General Public License (GPL)
• Software licensed under the Apache License cannot
  be integrated with software that is distributed
  under the GPL

56
License

• It is a free software license
• Incompatible with the GPL
• Has a specific requirement that is not in the GPL
• Has certain patent termination cases that the GPL
  does not require
• However, version 3 of the GPL includes a
  provision (Section 7e) which allows it to be
  compatible with licenses that have patent
  retaliation clauses, including the Apache License
• The name Apache is a registered trademark and may
  only be used with the trademark holder's express
  permission

57
Microsoft IIS

• http//en.wikipedia.org/wiki/IIS
• Were 2

58
IIS

• Microsoft Internet Information Services (IIS)
• Formerly called Internet Information Server
• Set of Internet-based services for servers using
  Microsoft Windows
• World's second most popular web server in terms
  of overall websites
• September 2007 it served 34.94 of all websites
  and 36.63 of all active websites (Netcraft)
• Services currently include
• FTP
• SMTP
• NNTP
• HTTP/HTTPS

59
History of IIS

• IIS initially released as additional set of
  Internet based services for Windows NT 3.51
• IIS 2.0 added support for the Windows NT 4.0
• IIS 3.0 introduced the Active Server Pages
  dynamic scripting environment
• IIS 4.0 dropped support for the Gopher protocol
• Bundled with Windows NT as a separate "Option
  Pack" CD-ROM

60
History of IIS

• Current shipping versions of IIS
• 7.0 for Windows Vista
• 6.0 for Windows Server 2003
• Added support for IPv6
• 5.1 for Windows XP Professional
• IIS 5.1 for Windows XP is a restricted version of
  IIS that supports only 10 simultaneous
  connections and a single web site

61
History of IIS

• FastCGI module available for IIS5.1, IIS6 and
  IIS7
• Windows Vista does not install IIS 7.0 by default
• Can be selected among the list of optionally
  installed components
• IIS 7.0 on Vista does not limit the number of
  connections allowed
• Restricts performance based on active concurrent
  requests

62
Security
63
Security

• Earlier versions of IIS had lot of
  vulnerabilities
• Chief among them CA-2001-19
• Led to the infamous Code Red worm
• Version 7.0 currently has no reported issues
• In perspective, as of 11 September 2007, the free
  software Apache web server has one unpatched
  reported issue
• Affecting only MS Windows systems
• Rated "less critical

64
Security

• IIS 6.0 opted to change the behavior of
  pre-installed ISAPI handlers
• Many of which were culprits in the
  vulnerabilities on 4.0 and 5.0
• Reduced the attack surface of IIS
• IIS 6.0 added a feature called "Web Service
  Extensions
• Prevents IIS from launching any program without
  explicit permission by an administrator

65
Security

• IIS 7.0 the components were modularized
• Only the required components have to be installed
• Further reducing the attack surface
• Security features such asURLFiltering were added
• Rejects suspicious URLs based on a user defined
  rule set

66
Security

• In IIS 5.1 and lower
• By default all websites were run
• In-process
• Under the System account
• a default Windows account with elevated rights

67
Security

• In IIS 6.0 all request handling processes have
  been brought under a Network Services account
• Has significantly fewer privileges
• If there is an exploit in a feature or custom
  code
• Wouldn't necessarily compromise the entire system
• Given the sandboxed environment the processes run
• Contains a new kernel HTTP stack (http.sys)
• Stricter HTTP request parser and response cache
  for both static and dynamic content

68
Authentication mechanisms
69
Authentication mechanisms

• IIS 5.0 and higher support the following
  authentication mechanisms
• Basic access authentication
• Digest access authentication
• Integrated Windows Authentication
• .NET Passport Authentication

70
Internet Information Services 7.0
71
Internet Information Services 7.0

• Debuting with Windows Vista
• To be included in Windows Server 2008
• IIS 7.0 features a modular architecture
• Instead of a monolithic server which features all
  services
• IIS 7 has a core web server engine
• Modules offering specific functionality can be
  added to the engine to enable its features
• Advantages
• Only the features required need be enabled
• The functionalities can be extended by using
  custom modules

72
Internet Information Services 7.0

• IIS 7 will ship with a handful of modules
• Microsoft will make other modules available
  online
• The following sets of modules are slated to ship
  with the server
• HTTP Modules
• Security Modules
• Content Modules
• Compression Modules
• Caching Modules
• Logging and Diagnostics Modules that integrates
  with the new configuration store, as well as the
  new management environment

73
Internet Information Services 7.0

• Writing extensions to IIS 7 using ISAPI has been
  deprecated in favor of the module API, using
  which modules can plug in anywhere in the request
  processing pipeline.
• Much of IIS's own functionality is built on this
  API
• Developers will have much more control over a
  request process than was possible in prior
  versions
• Modules can be written using C or using the
  ihttpmodule class of the .NET Framework language
• Modules can be loaded globally where the services
  provided by the module can effect all sites, or
  loaded on a per-site basis.
• IIS 7 has an integrated mode application pool
  where .NET modules are loaded into the pipeline
  using the module API, rather than ISAPI.
• As a result ASP.NET code can be used with all
  requests to the server
• For applications requiring strict IIS 6.0
  compatibility, the Classic application pool mode
  loads asp.NET as an ISAPI.

74
Internet Information Services 7.0

• A significant change from previous versions
• All web server configuration information is
  stored solely in XML configuration files
• Instead of in the metabase
• The server has a global configuration file
• Provides defaults
• Each virtual web's document root (and any
  subdirectory thereof) may contain a web.config
• Containing settings that augment or override the
  defaults

75
Internet Information Services 7.0

• Changes to these files take effect immediately
• Marks a significant departure from previous
  versions whereby web interfaces, or machine
  administrator access, were required to change
  simple settings such as default document, active
  modules and security/authentication
• It also eliminates the need to perform metabase
  synchronization between multiple servers in a
  farm of web servers

76
Internet Information Services 7.0

• Features a completely rewritten administration
  interface
• Takes advantage of modern MMC features such as
• Task panes
• Asynchronous operation
• Configuration of ASP.NET is more fully integrated
  into the administrative interface.

77
Internet Information Services 7.0

• Other changes
• PICS content ratings, support for Microsoft
  Passport, and server-side image maps are no
  longer included
• Executing commands via server-side includes is no
  longer permitted.
• IISRESET -reboot has been removed
• The CONVLOG tool, which converts IIS log files
  into NCSA format, has been removed
• Support for enabling a folder for "Web Sharing"
  via the Windows Explorer interface has been
  removed.
• IIS Media Pack, which allows IIS to be used as a
  bare-bones media server, without using Windows
  Media Services
• New FTP module, that integrates with the new
  configuration store, as well as the new
  management environment

78
Summary

• Concentrated on HTTP servers
• Apache and IIS are the main web serving tools
• Apache still king
• IIS Up and coming
• Usage tracked
• Netcraft Web Server Survey
