9. Car-Borne Information System

1
9. Car-BorneInformation System

• 2005.6

2
Agenda

• Introduction to Automotive Electronics
• Technology and Fields in Automotive Electronics
• Project Car-borne Information System
• Communication

3
The development of Car Industry

• 1885, Carl Benz invented the first car
• 3 revolutions in car industry
• 1914, Ford invented streamline
• 50s-60s, European car boost
• 60s-70, Japanese car industry
• In 2002, 57,700,000 new cars are sold.

4
The development of Electronic

• In 1946, The first computer ENIAC was born in
  America.
• For the past half century
• Army -gt Scientific Research -gt Civil
• PC Revolution
• Internet Economy

5
Pervasive computing
6
Pervasive computing

• Whole new Devices
• Tablet PC, PDA
• Smart Card
• Use Information Technology to change the old
  devices
• Digital Hospital, Industrial Control
• Digital ApplianceDC,Set Top Box
• Digital Automotive Industry Automobile
  Electronics

7
The birth of Automotive Electronics

• Humans new requirement to Car
• Mobility
• Economy
• Safety
• Stability
• Convenient
• Traditional mechanical devices can NOT solve
  certain problems.

8
The birth of Automotive Electronics

• Automobile Electronics
• Automobile Electronics

9
Features in AE

• Require Broad Knowledge
• Mechanical Engineering, Automobile,
  Microelectronics, Automation, Computer hardware,
  computer software
• Different level
• Low Level single chip, PLC
• High Level Embedded OS
• No International Standard
• Car-borne BusJ1850,ODB-2,CAN,LIN,IDB

10
Agenda

• Introduction to Automotive Electronics
• Technology and Fields in Automotive Electronics
• Project Car-borne Information System
• Communication

11
Technology and Fields in Automotive Electronics

• Hardware
• Sensor
• Bus
• Chip, Storage, Display
• Software Platform
• Embedded Operating System
• Application
• Navigation, Positioning, Digital Meter.

12
Hardware -- Sensor

• SensorA -gt D
• Type of sensor
• Speed sensor, temperature sensor, light sensor,
  sound sensor.
• No. of sensor in normal car 30 100
• No. of sensor in advanced car100 300

13
Hardware -- Bus

• Provide unified data transfer channel for all
  kinds of digital devices in car.
• CAN(Controller Area Network)
• Invented by BOSCH in Germany
• 1M bit/s, high speed network

14
Hardware Chip, Storage and Display

• Chip
• ARM7, Xscale and other embedded chips
• Storage
• CD, DVD, CF Card,SD Card
• Display
• Touch Screen,LCD, LED

15
Software Embedded Operating Systems
OSEK
16
Application Digital Meter
Traditional Meter
Digital Meter

• More Clear, More configurable

17
Application Digital Map

• Easy to search, more information

18
Application GPS

• Receive the satellite signal and display current
  position on the map

19
Application Navigation

• GPS GSM GIS
• Can dynamically get the road information
• Can update the map via Internet

20
Application Wireless Phone

• Now, GPRS
• Future, 3G

21
Application Thief Proof

• Set password for the car
• Smartcard login
• Use GPS to report the current position via web
  server

22
Application Entertainment

• DVD Player, CD Player
• Radio Receiver
• Gaming

23
Application Diagnosis

• Diagnose via various of sensors
• Simple oil, water warning
• Complex engine diagnose

24
Application Rearview mirror

• Traditional mirror can not see every place
• Collect pictures through digital cameras.

25
Agenda

• Introduction to Automotive Electronics
• Technology and Fields in Automotive Electronics
• Project Car-borne Information System
• Communication

26
GPS system invented by China
27
(No Transcript)
28
Introduction

• Car-borne information system is an electronic
  system that provides all kinds of information for
  car drivers and passengers.
• It consists of car-borne information terminal and
  information service out of the car
• They are integrated by mobile communication
  technique and wireless network.
• It not only includes information display and
  entertainment device in the car, but also serves
  as a bridge among car, mobile commerce and
  traffic information service

29
Telephone
GPS
Internet
Car Status
Entertainment
Digital Meter
Diagnosis
Digital Rearview mirror
30
Error Diagnosis Database
User Information DB
Car information DB
Information Service System
Integrated Information Service Web Server
Car Status Information Proxy Server
Drivers Passengers
Users out of the car
Users
Terminal Applications
Car-borne Information Terminal
Embedded OS(Windows CE)
Car-borne Computer
Sensors controller chips
Car controllers
Mechanical devices of the car
31
Architecture of Car-borne terminal
Intelligent Navigation
Error Diagnosis
Digital Meters
Digital Rearview mirror
Internet Access
Other software
Windows CE
Micro Processor Intel PXA270
Touch Screen
Digital Camera
CAN Bus Interface
CDMA Wireless Module
Other Hardware
32
(No Transcript)
33
Need Hardware Design?
Design develop your hardware
Get hardware BSP from OEMs
Develop BSP for your hardware
Need platform customization?
Customize your Win CE platform
Get platform SDK from OEMs
Export your SDK
Coding Testing
Release to Manufacture
