Chocolate Manufacture

1
Chocolate Manufacture
2
Key elements of chocolate for the confectioner

• Flavor
• Color
• Particle size (fineness)
• Viscosity
• Fat content
• Melt properties (cocoa butter hardness)

3
Chocolate StandardsEssentials

• Only cocoa butter and butter oil permitted fats
• Chocolate flavor from chocolate liquor only
• Only nutritive carbohydrate sweeteners
  permitted
• No flavors simulating chocolate or dairy permitted

4
Milk Chocolate Standard 21 CFR
163.130

• Chocolate liquor 10 minimum
• (no maximum)
• Milk - 12 minimum
• Milk Fat - 3.39 minimum

5
Dark Chocolate Standard 21
CFR 163.123

• Sweet Dark Chocolate
• Chocolate liquor 15 min 35 max
• Milk - 12 maximum
• Semi-sweet / Bittersweet Chocolate
• Chocolate liquor 35 minimum
• Milk - 12 maximum
• No maximum liquor level!

6
White Chocolate Standard21 CFR 163.124

• Only fats permitted are cocoa butter and milk fat
• Cocao Fat 20 Minimum
• Milk 14 Minimum (Whey 5 Max)
• Milk fat 3.5 Minimum
• No flavorings that mimic flavor of chocolate,
  milk, or butter

7
Mixing Ingredients
CHOCOLATE MANUFACTURE
Prerefining
5-Roll Refining
Conching
Standardizing
Chocolate
Liquid Holding
Depositing or Molding
Discs or Drops
10 lb. bars
Tankers
8
Confectionery Coatings

• Current CFR Typically NOT Used
• Referred to as Confectionery Coating
• Cannot be labeled as Chocolate
• Fat other than Cocoa butter used
• Lauric, Nonlauric vegetable fats
• Flavorings not limited
• Sugarfree chocolate flavored ctgs.

9
CONFECTIONERY COATING MANUFACTURING
10
Sensory of Chocolate Confectionery Coating

11
Mixing, Refining, and Conching
12
Batch Mixing

Mix raw materials and a portion of the fat
13
RD Batch Mixing
14
Refining Line
15
Chocolate Paste (Before Refining)
16
Chocolate Refiner Line
17
5 Roll Refiner
18
Relationship of Pre-Refining and Final Refining
19
Mechanical Size Reduction in Chocolate

• Prerefiner conditions mass
• Finished refining completes particle reduction
• Rolls slightly crowned
• Pressure exerted
• Thin film forms on rolls

• Speed of rolls
• Increase bottom to top
• Creates shearing action
• Gap adjustment based on final fineness
• Envelope particles with fat

20
Refiner Flake
21
Refiner flake traveling to Conche
22
Micrometer
23
AACT Micrometer Fineness Method

• Rotating micrometer must be used
• 50 / 50 Oil and chocolate well mixed
• Micrometer cleaned and zeroed
• Temperature sensitive
• Consistent slip or ratchet clutch between
  technicians and micrometers
• Micrometer in good repairfree movement, not
  catching
• Put away clean with the anvils slightly open

24
Particle Analyzer

• Scattered Light
• Measure scatter
• Amount
• Direction
• Calculates
• Size Distribution
• Fast QC Check

25
Sensory of Particle Size

• Taste and evaluate each piece
• For
• Sweetness
• Mouthfeel
• Melt
• Flavor Release

26
Why Different Particle Size?

Boxed Chocolates 10 20 microns
Inclusions - 15- 45 microns
Chocolate Chips 15-35 microns
Novelty items 15-45 microns
Solid Pieces 10-25 microns
Truffles 10-15 microns
27
Conching

• Flavor Development
• Energy into Mass (Shearing Heat)
• Conching Time
• Conching Temperature
• Rounding Particles (Texture)
• Volatile Removal

28
Frise DUC-6 Conche
29
Refiner Flake Feeding Conche
30
High Shear Conches East Greenville
31
Conching
Pilot Frisse Conche
32
Sensory of Conching

• Focus on
• Degree of Chocolate
• Sweetness
• Caramel
• Dairy

33
ViscosityWhat is it and how is it measured

• Viscosity
• Resistance to flow
• (thickness / thinness)
• Rheology
• The science of the deformation
• and flow of fluids

34
Viscosity Check
35
(No Transcript)
36
Viscosity Ranges for Chocolate Use
37
Receiving Chocolate

• Verify that
• Trailer is clean and free of odors
• Product is what it is supposed to be
• Product temper is good
• Product specifications are met
• Satisfactory temperature control during shipment
• Cases are not damaged or torn
• Above all just taste it make sure it is OK

38
Chocolate Storage ProblemsBefore Use

• Pick up of off odors from the storage area
• Other food products (mints, flavor ingredients,
  spices, onions, etc..)
• Other products (maintenance oils, cleaning
  supplies, etc..)
• Air conditioning systems (dirty filters or
  cooling coils, plugged drain pansalso
  microbiological issue)
• Moisture pickup
• From high RH storage, thickens chocolate

39
Viscosity impacts

• Confectioners handling of chocolate
• Coverage percent
• Dipping Thickness uniformity
• Enrobing Side coating
• Molding Feet / tails
• Air bubbles
• Decoration
• Pumping
• Tank agitation

40
Air Bubble Release in Agitated Kettle
41
Feet or Slump on Sides of Finished Goods
42
Drop Depositing
Requires High Yield Value
43
Chocolate pumping after Conching
44
Liquid Chocolate Loading
45
Liquid Chocolate Ready to Deliver
46
10 lb Chocolate Bar Depositing
47
10 lb Bar Packaging
48
Warehousing Chocolate Products
49
Thank You - Questions???
Why am I in Here?
